Muchas subfiguras en una figura.

Question

Me gustaría poner 81 subfiguras en una figura con un título y cada subfigura etiquetada con un número. Cada subfigura tiene el mismo tamaño (así que probablemente no la necesite tabularxpara esto). Quisiera 4 subfiguras en una fila, de la siguiente manera,

SUBFIG1 Y SUBFIG2 Y SUBFIG3 Y SUBFIG4

..

SUBFIG77 Y SUBFIG78 Y SUBFIG79 Y SUBFIG80

SUBFIG81

TÍTULO: XXX

Debajo de cada subfigura me gustaría un número entre corchetes, por ejemplo, debajo de SUBFIG1 me gustaría (1), etc.

¿Cuál es la mejor manera de hacer esto dentro del látex? he probado el tabularambiente

\documentclass{report}
\usepackage{subcaption}
\begin{figure}
\begin{tabular}{cccc}
\subfloat[(1)]{\includegraphics[width=2cm]{SUBFIG1.eps}}
    & \subfloat[(2)]{\includegraphics[width=2cm]{SUBFIG2.eps}}
    &  \subfloat[(3)]{\includegraphics[width=2cm]{SUBFIG3.eps}}
    & \subfloat[(4)]{\includegraphics[width=2cm]{SUBFIG4.eps}} \\
\subfloat[(5)]{\includegraphics[width=2cm]{SUBFIG5.eps}}
    & \subfloat[(6)]{\includegraphics[width=2cm]{SUBFIG6.eps}}
 ...
\end{tabular}
\caption{XXX}
\label{xxx}
\end{figure}

pero aquí subfloattiene az como delimitador de conteo y tan pronto como llego a 24 subfiguras, se sale de la página (es decir, no comienza la subfigura 25 en una página nueva). ¡Gracias!

Answer 1

Dado que todas las imágenes tienen el mismo ancho, no es necesario utilizar un enfoque de tipo tabular. Simplemente use \subfloatdirectivas para colocarlos, cuatro por fila.

Dado que carga el subcaptiontítulo (y por lo tanto también el captionpaquete), puede usar \ContinuedFloatdirectivas en la parte superior de cada figureentorno consecutivo.

La siguiente captura de pantalla muestra el último de los figureentornos producidos por el código siguiente.

\documentclass{report}
\usepackage[margin=2.5cm]{geometry} % set page parameters suitably
\usepackage[demo]{graphicx} % remove 'demo' option in real document

\usepackage{subcaption}
\renewcommand\thesubfigure{\arabic{subfigure}} % arabic numerals
\captionsetup[figure]{skip=0.5\baselineskip}
\captionsetup[subfigure]{skip=0.25\baselineskip,position=below}

\begin{document}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\caption{XXX}\label{fig:xxx}

\subfloat[]{\includegraphics{SUBFIG01}}\hfill
\subfloat[]{\includegraphics{SUBFIG02}}\hfill
\subfloat[]{\includegraphics{SUBFIG03}}\hfill
\subfloat[]{\includegraphics{SUBFIG04}}

\medskip
\subfloat[]{\includegraphics{SUBFIG05}}\hfill
\subfloat[]{\includegraphics{SUBFIG06}}\hfill
\subfloat[]{\includegraphics{SUBFIG07}}\hfill
\subfloat[]{\includegraphics{SUBFIG08}}

\medskip
\subfloat[]{\includegraphics{SUBFIG09}}\hfill
\subfloat[]{\includegraphics{SUBFIG10}}\hfill
\subfloat[]{\includegraphics{SUBFIG11}}\hfill
\subfloat[]{\includegraphics{SUBFIG12}}

\medskip
\subfloat[]{\includegraphics{SUBFIG13}}\hfill
\subfloat[]{\includegraphics{SUBFIG14}}\hfill
\subfloat[]{\includegraphics{SUBFIG15}}\hfill
\subfloat[]{\includegraphics{SUBFIG16}}

\medskip
\subfloat[]{\includegraphics{SUBFIG17}}\hfill
\subfloat[]{\includegraphics{SUBFIG18}}\hfill
\subfloat[]{\includegraphics{SUBFIG19}}\hfill
\subfloat[]{\includegraphics{SUBFIG20}}

\medskip
\subfloat[]{\includegraphics{SUBFIG21}}\hfill
\subfloat[]{\includegraphics{SUBFIG22}}\hfill
\subfloat[]{\includegraphics{SUBFIG23}}\hfill
\subfloat[]{\includegraphics{SUBFIG24}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG25}}\hfill
\subfloat[]{\includegraphics{SUBFIG26}}\hfill
\subfloat[]{\includegraphics{SUBFIG27}}\hfill
\subfloat[]{\includegraphics{SUBFIG28}}

\medskip
\subfloat[]{\includegraphics{SUBFIG29}}\hfill
\subfloat[]{\includegraphics{SUBFIG30}}\hfill
\subfloat[]{\includegraphics{SUBFIG31}}\hfill
\subfloat[]{\includegraphics{SUBFIG32}}

\medskip
\subfloat[]{\includegraphics{SUBFIG33}}\hfill
\subfloat[]{\includegraphics{SUBFIG34}}\hfill
\subfloat[]{\includegraphics{SUBFIG35}}\hfill
\subfloat[]{\includegraphics{SUBFIG36}}

\medskip
\subfloat[]{\includegraphics{SUBFIG37}}\hfill
\subfloat[]{\includegraphics{SUBFIG38}}\hfill
\subfloat[]{\includegraphics{SUBFIG39}}\hfill
\subfloat[]{\includegraphics{SUBFIG40}}

\medskip
\subfloat[]{\includegraphics{SUBFIG41}}\hfill
\subfloat[]{\includegraphics{SUBFIG42}}\hfill
\subfloat[]{\includegraphics{SUBFIG43}}\hfill
\subfloat[]{\includegraphics{SUBFIG44}}

\medskip
\subfloat[]{\includegraphics{SUBFIG45}}\hfill
\subfloat[]{\includegraphics{SUBFIG46}}\hfill
\subfloat[]{\includegraphics{SUBFIG47}}\hfill
\subfloat[]{\includegraphics{SUBFIG48}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG49}}\hfill
\subfloat[]{\includegraphics{SUBFIG50}}\hfill
\subfloat[]{\includegraphics{SUBFIG51}}\hfill
\subfloat[]{\includegraphics{SUBFIG52}}

\medskip
\subfloat[]{\includegraphics{SUBFIG53}}\hfill
\subfloat[]{\includegraphics{SUBFIG54}}\hfill
\subfloat[]{\includegraphics{SUBFIG55}}\hfill
\subfloat[]{\includegraphics{SUBFIG56}}

\medskip
\subfloat[]{\includegraphics{SUBFIG57}}\hfill
\subfloat[]{\includegraphics{SUBFIG58}}\hfill
\subfloat[]{\includegraphics{SUBFIG59}}\hfill
\subfloat[]{\includegraphics{SUBFIG60}}

\medskip
\subfloat[]{\includegraphics{SUBFIG61}}\hfill
\subfloat[]{\includegraphics{SUBFIG62}}\hfill
\subfloat[]{\includegraphics{SUBFIG63}}\hfill
\subfloat[]{\includegraphics{SUBFIG64}}

\medskip
\subfloat[]{\includegraphics{SUBFIG65}}\hfill
\subfloat[]{\includegraphics{SUBFIG66}}\hfill
\subfloat[]{\includegraphics{SUBFIG67}}\hfill
\subfloat[]{\includegraphics{SUBFIG68}}

\medskip
\subfloat[]{\includegraphics{SUBFIG69}}\hfill
\subfloat[]{\includegraphics{SUBFIG70}}\hfill
\subfloat[]{\includegraphics{SUBFIG71}}\hfill
\subfloat[]{\includegraphics{SUBFIG72}}

\end{figure}

\begin{figure}[ht!]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG73}}\hfill
\subfloat[]{\includegraphics{SUBFIG74}}\hfill
\subfloat[]{\includegraphics{SUBFIG75}}\hfill
\subfloat[]{\includegraphics{SUBFIG76}}

\medskip
\subfloat[]{\includegraphics{SUBFIG77}}\hfill
\subfloat[]{\includegraphics{SUBFIG78}}\hfill
\subfloat[]{\includegraphics{SUBFIG79}}\hfill
\subfloat[]{\includegraphics{SUBFIG80}}

\medskip
\subfloat[]{\includegraphics{SUBFIG81}}\hfill

\end{figure}


\end{document}

Answer 2

Tal vez, si coloca las cifras en una tabla y luego las divide en las páginas usando un archivo \ContinuedFloat. Aunque, en este enfoque, tendrías que dividir la figura manualmente, lo que por supuesto no es muy elegante.

\documentclass{scrreprt}
\usepackage{graphicx}
\usepackage{subcaption}

\DeclareCaptionSubType*{figure}\renewcommand\thesubfigure{\arabic{subfigure}}
\newcommand{\sub}[1]{\begin{minipage}{.2\linewidth}\includegraphics[width=\linewidth]{#1}\subcaption{}\end{minipage}}
\newcommand{\tabfig}[4]{\sub{#1} & \sub{#2} & \sub{#3} & \sub{#4}\\}

\begin{document}
\begin{figure}[ht]
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\begin{figure}[ht]\ContinuedFloat
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\end{document}
