Quiero mostrar una tabla en mi documento LaTeX. Quiero que la tabla se pueda dividir en 2 páginas. Mi código proporciona un espacio vacío después de lorem ipsum y la tabla comienza en una página nueva. Este es mi código.
\documentclass[a4paper,oneside,11pt]{article}
\usepackage[left=2.5cm,right=2.5cm,top=4cm,bottom=2.7cm]{geometry}
\usepackage{amsmath}
\usepackage{amsthm}
\usepackage{graphicx}
\usepackage{array}
\usepackage{newtxtext,newtxmath}
\usepackage{lipsum}
%\usepackage{longtable}
\begin{document}
\theoremstyle{definition}%tegak hurufnya
\newtheorem{theorem}{Theorem}[section]
\newtheorem{example}[theorem]{Example}
\lipsum[1-3]
\begin{example}
This is the examples of t-norm and t-conorm.
\begin{table}[h!]
\centering
\caption{Example of t-norm and t-conorm}
\resizebox{\textwidth}{!}{
\renewcommand{\arraystretch}{1.5}
\begin{tabular}{|m{2cm}|c|c|}
\hline
\hfill \textbf{Name}\hfill \strut&\textbf{t-norm}&\textbf{t-conorm}\\
\hline
Standard intersection/ standard union&\newline$T_m(x,y)=\min(x,y)$&$C_m(x,y)=\max(x,y)$\\
\hline
Bounded sum&$T_b(x,y)=\max(0,x+y-1)$&$C_b(x,y)=\min(1,x+y)$\\
\hline
Algebraic product/ Algebraic sum&$T_p(x,y)=xy$&$C_p(x,y)=x+y-xy$\\
\hline
Drastic&$T_D(x,y)=
\begin{cases}
y&\text{if }x=1\\
x&\text{if }y=1\\
0&\text{otherwise}
\end{cases}$
&
$C_D(x,y)=
\begin{cases}
y&\text{if }x=0\\
x&\text{if }y=0\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Nilpotent minimum/ Nilpotent maximum&$T_{nM}(x,y)=
\begin{cases}
\min(x,y)&\text{if }x+y> 1\\
0&\text{otherwise}
\end{cases}$&
$
C_{nM}(x,y)=
\begin{cases}
\max(x,y)&\text{if }x+y<1\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Hamacher product/ Einstein sum&$T_{H_0}(x,y)=
\begin{cases}
0&\text{if }x=y=0\\
\dfrac{xy}{x+y-xy}&\text{otherwise}
\end{cases}$&
$
C_{H_2}(x,y)=\dfrac{x+y}{1+xy}
$
\\
\hline
\end{tabular}
\label{tabelnorma}
}
\end{table}
\end{example}
\end{document}
He leído sobre dividir la tabla en 2 páginas enHacer una tabla que abarque varias páginas. Intento usar longtablecomo se muestra a continuación.
\documentclass[a4paper,oneside,11pt]{article}
\usepackage[left=2.5cm,right=2.5cm,top=4cm,bottom=2.7cm]{geometry}
\usepackage{amsmath}
\usepackage{amsthm}
\usepackage{graphicx}
\usepackage{array}
\usepackage{newtxtext,newtxmath}
\usepackage{lipsum}
\usepackage{longtable}
\begin{document}
\theoremstyle{definition}%tegak hurufnya
\newtheorem{theorem}{Theorem}[section]
\newtheorem{example}[theorem]{Example}
\lipsum[1-3]
\begin{example}
This is the examples of t-norm and t-conorm.
%\begin{table}[h!]
%\centering
%\caption{Example of t-norm and t-conorm} moved into longtable
\resizebox{\textwidth}{!}{
\renewcommand{\arraystretch}{1.5}
\begin{longtable}{|m{2cm}|c|c|}
\caption{Example of t-norm and t-conorm}
\hline
\hfill \textbf{Name}\hfill \strut&\textbf{t-norm}&\textbf{t-conorm}\\
\hline
Standard intersection/ standard union&\newline$T_m(x,y)=\min(x,y)$&$C_m(x,y)=\max(x,y)$\\
\hline
Bounded sum&$T_b(x,y)=\max(0,x+y-1)$&$C_b(x,y)=\min(1,x+y)$\\
\hline
Algebraic product/ Algebraic sum&$T_p(x,y)=xy$&$C_p(x,y)=x+y-xy$\\
\hline
Drastic&$T_D(x,y)=
\begin{cases}
y&\text{if }x=1\\
x&\text{if }y=1\\
0&\text{otherwise}
\end{cases}$
&
$C_D(x,y)=
\begin{cases}
y&\text{if }x=0\\
x&\text{if }y=0\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Nilpotent minimum/ Nilpotent maximum&$T_{nM}(x,y)=
\begin{cases}
\min(x,y)&\text{if }x+y> 1\\
0&\text{otherwise}
\end{cases}$&
$
C_{nM}(x,y)=
\begin{cases}
\max(x,y)&\text{if }x+y<1\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Hamacher product/ Einstein sum&$T_{H_0}(x,y)=
\begin{cases}
0&\text{if }x=y=0\\
\dfrac{xy}{x+y-xy}&\text{otherwise}
\end{cases}$&
$
C_{H_2}(x,y)=\dfrac{x+y}{1+xy}
$
\\
\hline
\label{tabelnorma}
\end{longtable}
}
%\end{table}
\end{example}
\end{document}
Lo he usado longtable, pero en este código me da un error y no puedo dividir la tabla en dos páginas.
¿Alguien puede ayudarme?
Respuesta1
En el siguiente MWE, utilicé xltabularen lugar de cambiar el tamaño un archivo longtable. Además, también agregué lo que faltaba \\para que el código fuera compilable. Algunos cambios adicionales se comentan en el código de ejemplo siguiente:
\documentclass[a4paper,oneside,11pt]{article}
\usepackage[left=2.5cm,right=2.5cm,top=4cm,bottom=2.7cm]{geometry}
\usepackage{amsmath}
\usepackage{amsthm}
\usepackage{graphicx}
%\usepackage{array} % already loaded by xltabular
\usepackage{newtxtext,newtxmath}
\usepackage{lipsum}
\usepackage{xltabular} % Replaced longtable with xltabular to make table as wide as the textwidth.
\renewcommand{\tabularxcolumn}[1]{m{#1}} % To vertically center the contents of the cells
\usepackage[column=0]{cellspace} % improved vertical spacing around cell's contents
\setlength{\cellspacetoplimit}{\tabcolsep}
\setlength{\cellspacebottomlimit}{\cellspacetoplimit}
\addparagraphcolumntypes{X}
\begin{document}
\theoremstyle{definition}%tegak hurufnya
\newtheorem{theorem}{Theorem}[section]
\newtheorem{example}[theorem]{Example}
\lipsum[1-4]
\begin{example}
This is the examples of t-norm and t-conorm.
% \resizebox{\textwidth}{!}{ % removed resizebox
% \renewcommand{\arraystretch}{1.5}
{\setlength{\tabcolsep}{3pt}
\begin{xltabular}{\textwidth}{|>{\raggedright\arraybackslash}0{X}|0c|0c|} % Replaced longtable with xltabular to make table as wide as the textwidth.
\caption{Example of t-norm and t-conorm}\label{tabelnorma} \\ % added missing \\ here.
\hline
\centering \textbf{Name}&\textbf{t-norm}&\textbf{t-conorm}\\ % replaced \hfill with \centering
\hline
Standard intersection/ standard union&\newline$T_m(x,y)=\min(x,y)$&$C_m(x,y)=\max(x,y)$\\
\hline
Bounded sum&$T_b(x,y)=\max(0,x+y-1)$&$C_b(x,y)=\min(1,x+y)$\\
\hline
Algebraic product/ Algebraic sum&$T_p(x,y)=xy$&$C_p(x,y)=x+y-xy$\\
\hline
Drastic&$T_D(x,y)=
\begin{cases}
y&\text{if }x=1\\
x&\text{if }y=1\\
0&\text{otherwise}
\end{cases}$
&
$C_D(x,y)=
\begin{cases}
y&\text{if }x=0\\
x&\text{if }y=0\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Nilpotent minimum/ Nilpotent maximum&$T_{nM}(x,y)=
\begin{cases}
\min(x,y)&\text{if }x+y> 1\\
0&\text{otherwise}
\end{cases}$&
$
C_{nM}(x,y)=
\begin{cases}
\max(x,y)&\text{if }x+y<1\\
1&\text{otherwise}
\end{cases}
$
\\
\hline
Hamacher product/ Einstein sum&$T_{H_0}(x,y)=
\begin{cases}
0&\text{if }x=y=0\\
\dfrac{xy}{x+y-xy}&\text{otherwise}
\end{cases}$&
$
C_{H_2}(x,y)=\dfrac{x+y}{1+xy}
$
\\
\hline
% \label{tabelnorma} % moved label to the caption to avoid overly long vertical lines
\end{xltabular}
}
\end{example}
\end{document}
