¿Cómo mantener los estilos `X` y `Q` al mismo tiempo en `tabularray`?

¿Cómo mantener los estilos `X` y `Q` al mismo tiempo en `tabularray`?

tabularrayes bastante útil ya que necesito hacer estas cosas:

  1. Mantenga la mesa tan ancha como\textwidth
  2. Necesito insertar note{}en el título de la tabla.
  3. El encabezado de la tabla son dos muchos caracteres, por lo que están divididos en varias líneas en una celda. En este caso, necesito mantener las cabezas cortas para que estén en el centro de la celda de la mesa.
  4. Mantenga el número decimal alineado

Que yo sé:

  • Para lograrlo 1, puedo usar tblro talltblrcon Xformato.
  • Para lograrlo 2, necesito usartalltblr
  • Para lograrlo 4, puedo usar talltblrwith Xysi={}

Pero, ¿cómo puedo 3lograrlo talltblr? Si podemos fusionar Qel formato talltblr, estas cuatro funciones podrían lograrse al mismo tiempo.

Por ejemplo:

\documentclass{article}

\usepackage{tabularray}
\usepackage{siunitx}
\usepackage{romannum}
\UseTblrLibrary{booktabs, siunitx}
\begin{document}
\begin{table}[h]
  \begin{talltblr}
    [caption={Main component geographic information table\TblrNote{1}},
     label={tab:Main component geographic information table},
     note{1}={The data is obtained through satellite maps, and there are certain errors},
     note{2}={The latitude and longitude of the surface is the latitude and longitude of its centroid. There is a certain error in the measurement of latitude and longitude, for reference},
     note{3}={This length is the length in our study area}
    ]
    {colspec={
              X[1.5,r] X[1.3,c] X[1.3,c] X[c,si={table-format=4.2},0.8] X[c,si={table-format=4.2},0.8] X[c,si={table-format=1.2},0.8]
              }
    }
    \toprule
      name  & latitude\TblrNote{2} & longitude &{gggggg\unit{\m}}  & gggggg\unit{\m} \TblrNote{3} &{{{area total\unit{\km\squared}}}}\\

         \midrule
      DongLake      &\ang{30;33;29.52}N &\ang{114;22;47.55}E &             &         & 12.74 \\
      dongtinglake     &\ang{30;33;12.71}N &\ang{114;20;46.87}E &         &         &0.12 \\
      great river      &\ang{30;33;33.66}N &\ang[minimum-integer-digits=2]{114;20;09.29}E & 1682.88&         &        \\
     bigbig lake      &\ang[minimum-integer-digits=2]{30;34;06.02}N &\ang{114;19;45.86}E &         &         & 2.74    \\
     inside the gate   &\ang{30;33;54.85}N &\ang{114;18;35.99}E &         &         & 0.06  \\
      new ditches     &\ang{30;35;33.19}N &\ang[minimum-integer-digits=2]{114;23;02.77}E & 977    &         &         \\
      west part of new gate   &\ang{30;35;26.31}N &\ang{114;21;43.67}E & 5213.77 &         &         \\
     luoai port   &\ang[minimum-integer-digits=2]{30;37;08.49}N &\ang{114;21;27.93}E & 3770.58 &         &         \\
qingling port     &\ang[minimum-integer-digits=2]{30;39;02.32}N &\ang{114;24;30.27}E &         &         & 0.13   \\
      from port to lake &\ang[minimum-integer-digits=2]{30;37;03.06}N &\ang{114;24;22.99}E & 345.15 &         &        \\
    east part of the gate   &\ang[minimum-integer-digits=2]{30;38;05.41}N &\ang{114;24;27.64}E &2926.08 &         &         \\
   Yangzi river     &\ang{30;37;43.29}N &\ang{114;20;58.87}E &         &         &         \\
      east part of the lake   &\ang{30;35;55.14}N &\ang{114;23;14.49}E & 1090.45 &         &         \\
      donghu port     &\ang{30;35;37.38}N &\ang{114;23;45.81}E & 7332.3 & \num{4614.19} &         \\
   west section of qingqing   &\ang[minimum-integer-digits=2]{30;38;01.20}N &\ang{114;24;11.10}E & 3449.86 &         &         \\
    new road   drainage station &\ang{30;33;55.17}N &\ang{114;18;48.14}E &         &         &         \\
nanjing drainage station  &\ang{30;33;52.23}N &\ang{114;18;29.72}E &         &         &         \\
      beijing pumping station   &\ang{30;37;22.34}N &\ang[minimum-integer-digits=2]{114;21;01.01}E &         &         &         \\
      guilin road gata   &\ang{30;37;19.42}N &\ang{114;20;57.23}E &         &         &       \\
      the last gate     &\ang{30;39;16.08}N &\ang{114;24;31.97}E &         &         &     \\
    \bottomrule
\end{talltblr}
\end{table}
\end{document}

¿Cómo hacer esta tabla para lograr las cuatro solicitudes? ingrese la descripción de la imagen aquí

Otra pregunta: ¿por qué no puedo reemplazar ggggggcon Length? Cuando hice esto, hay un error:Package siunitx Error: Invalid number 'e'.

Respuesta1

Editar: Ups, no subí la última versión del código y la imagen. Corregido ahora. Lo siento por el ruido...

Como punto de partida:

\documentclass{article}
\usepackage{tabularray}
\UseTblrLibrary{booktabs, siunitx} % libraries loads packages of the same names

\begin{document}
    \begin{table}[h]
    \sisetup{minimum-integer-digits=2}
\begin{talltblr}[
caption = {Main component geographic information table},
  label = {tab:Main component geographic information table},
remark{Note} = {The data are obtained through satellite maps, and there are certain errors},
     note{1} = {The latitude and longitude of the surface is the latitude and longitude of its centroid. There is a certain error in the measurement of latitude and longitude, for reference},
     note{2} = {This length is the length in our study area},
     note{3} = {Total area}
                ]{colsep = 3pt,
                  colspec = {@{} X[2,l, m, font=\linespread{0.84}\selectfont] r r
                            *{2}{X[c, si={table-format=4.2}]}
                                 X[c, si={table-format=2.2,
                                          minimum-integer-digits=1}]
                            @{}},
                   row{1} = {font=\small\bfseries, c, m}
    }
    \toprule
name        & latitude\TblrNote{1}
                & longitude
                     & {{{gggggg \unit{\metre}}}}
                        & {{{gggggg\TblrNote{2} \unit{\metre}}}}
                            & {{{area\TblrNote{3} \unit{\km\squared}}}}\\

    \midrule
Dong Lake    & \ang{30;33;29.52}N
                & \ang{114;22;47.55}E
                    &   &   & 12.74         \\
Dongting Lake
            & \ang{30;33;12.71}N
                &\ang{114;20;46.87}E
                    &   &   & 0.12          \\
Great river & \ang{30;33;33.66}N
                & \ang{114;20;09.29}E
                    & 1682.88
                        &   &               \\
Big lake    & \ang{30;34;06.02}N
                & \ang{114;19;45.86}E
                    &   &   & 2.74          \\
inside the gate
            & \ang{30;33;54.85}N
                & \ang{114;18;35.99}E
                    &   &   & 2.74          \\
new ditches & \ang{30;35;33.19}N
                &\ang{114;23;02.77}E
                    & 977
                        &   &               \\
west part of new gate
            & \ang{30;35;26.31}N
                & \ang{114;21;43.67}E
                    & 5213.77
                        &   &               \\
Luoai port  & \ang{30;37;08.49}N
                &\ang{114;21;27.93}E
                    & 3770.58
                        &   &               \\
qingling port
            & \ang{30;39;02.32}N
                &\ang{114;24;30.27}E
                    &   &   & 0.13          \\
from port to lake
            & \ang{30;37;03.06}N
                & \ang{114;24;22.99}E
                    & 345.15
                        &   &               \\
east part of the gate
            & \ang{30;38;05.41}N
                & \ang{114;24;27.64}E
                    & 2926.08
                        &   &               \\
Yangzi river
            & \ang{30;37;43.29}N
                & \ang{114;20;58.87}E
                    &   &   &               \\
east part of the lake
            & \ang{30;35;55.14}N
                & \ang{114;23;14.49}E
                    & 1090.45
                        &   &               \\
Donghu port & \ang{30;35;37.38}N
                & \ang{114;23;45.81}E
                    & 7332.3
                        & 4614.19
                            &               \\
west section of qingqing
            & \ang{30;38;01.20}N
                & \ang{114;24;11.10}E
                    & 3449.86
                        &   &               \\
new road  drainage station
            & \ang{30;33;55.17}N
                &\ang{114;18;48.14}E
                    &   &   &               \\
nanjing drainage station
            & \ang{30;33;52.23}N
                & \ang{114;18;29.72}E
                    &   &   &               \\
Beijing pumping station
            & \ang{30;37;22.34}N
                &\ang{114;21;01.01}E
                    &   &   &               \\
Guilin road gata
            & \ang{30;37;19.42}N
                &\ang{114;20;57.23}E
                    &   &   &               \\
the last gate
            & \ang{30;39;16.08}N
                & \ang{114;24;31.97}E
                    &   &   &               \\
    \bottomrule
\end{talltblr}
    \end{table}
\end{document}

ingrese la descripción de la imagen aquí

Notas: Realmente lees (una y otra vez) la documentación del paquete. No solo leer, sino también experimentar con diferentes configuraciones para el formato de columnas. Mis experiencias me muestran que el mejor método de aprendizaje esaprender haciendo. Al principio lleva un poco de tiempo, pero pronto descubrirás la filosofía de tabularrayla sintaxis.

  • El significado de las opciones c(centro), l(izquierda), r(derecha) y m(centro), t(arriba) b(abajo, las tres últimas están definidas en el arraypaquete) es el mismo que en las mesas clásicas. - Además de las opciones mencionadas, tabularrayintroduzca tres opciones más: h(cabeza, en la parte superior de la celda), f(pie, en la parte inferior de la celda) y j(justificado).
  • Estas opciones se pueden utilizar de forma independiente o como atributos de Xtipos Qde columnas. Por ejemplo:
    • X[c] tiene ancho, que es calculado por LaTeX y el contenido de la columna es horizontal
    • `X[2,l] tiene el doble de ancho, lo cual se calcula mediante LaTeX y el contenido de la columna alineado a la izquierda
    • Q[c, 2cm]o Q[c, wd=2cm]definir una columna con 2 cm de ancho y contenido centrado horizontalmente
    • X[j]tiene texto justificado, que se divide con guiones cuando es necesario
    • la columna cse comporta igual que en las tablas "clásicas" el ancho de la columna es igual al ancho del contenido más largo en las celdas y está centrado horizontalmente (lo mismo ocurre con otras opciones)
  • En Slas columnas (definidas como Scolumna o, por ejemplo Q[c, si], donde el formato se puede definir \sisetupfuera de la tabla, consulte siunitxla documentación), el contenido sin número de dicha celda tenía que corresponder al siunitxpaquete en las tablas clásicas encerradas entre llaves:
    • por esto se interrumpe table-formatla configuración,
    • Deshabilite la interpretación incorrecta del significado del contenido (tenga en cuenta que siunitxse usan algunas letras para designar números, por ejemplo, ¡ 10e5significa 10 x 10^5!
  • Debido al tabularrayprocesamiento diferente de la tabla (usando l3exp) es necesario agregar dos pares de llaves más (ese siunitxrequisito funciona en todas las circunstancias).
  • El tabularraypaquete permite formatear filas. Por ejemplo:
    • con row{1} = {font=\bfseries}texto en negrita prescrito en todas las celdas de la primera fila,
    • con row{Z} = {font=\scfaily, c}fuente prescrita en versalitas y centrado del contenido en la última fila de la tabla
  • etc.,

Apéndice: Es posible que le guste el formato de tabla, que agrupa filas, por ejemplo con tres, e inserta un espacio vertical adicional entre ellas. Para esto agregar al preámbulo

  \ExplSyntaxOn
\NewChildSelector{eachthree}
  {
    \int_step_inline:nnnn {5}{3}{\l_tblr_childs_total_tl}
      { \clist_put_right:Nn \l_tblr_childs_clist {##1} }
  }
\ExplSyntaxOff

y al preámbulo de la presentación:

                   row{eachthree} = {abovesep=2ex},

Considerando estas adiciones, la tabla quedará de la siguiente manera:

ingrese la descripción de la imagen aquí
