Felizmente estaba usando una imagen superpuesta, con el siguiente MWE (reemplace Annulus-PBma-essai.pdf por cualquier archivo .pdf)
\documentclass [12pt]{amsbook}
\usepackage{graphicx}
\usepackage{xcolor}
\usepackage[percent]{overpic}
\begin{document}
\begin{figure}[ht]
\center\begin{overpic}[width=10cm]{Annulus-PBma-essai.pdf}
\put (32,65) {$z_{0}$}
\put (52,44){$z_1$}
\end{overpic}
\end{figure}
\end{document}
Eso es hasta la nueva versión de overpic, que no parece aceptar el "ancho" como opción. Por lo tanto recibo un mensaje de error. ¿Me perdí algo? Si no, ¿hay alguna manera de obtener el mismo efecto que "ancho" con la nueva versión? [Lo siento, no puedo reproducir el mensaje de error (tenía que ver con setkeyval), ya que actualicé la computadora de mi oficina pero no la de mi casa.]
Aquí está el registro completo
This is pdfTeX, Version 3.141592653-2.6-1.40.25 (TeX Live 2023) (preloaded format=pdflatex)
restricted \write18 enabled.
entering extended mode
(./Untitled.tex
LaTeX2e <2023-11-01>
L3 programming layer <2024-01-04>
(/usr/local/texlive/2023/texmf-dist/tex/latex/amscls/amsbook.cls
Document Class: amsbook 2020/05/29 v2.20.6
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsmath/amsmath.sty
For additional information on amsmath, use the `?' option.
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsmath/amstext.sty
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsmath/amsgen.sty))
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsmath/amsbsy.sty)
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsmath/amsopn.sty))
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsfonts/umsa.fd)
(/usr/local/texlive/2023/texmf-dist/tex/latex/amsfonts/amsfonts.sty))
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics/graphicx.sty
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics/keyval.sty)
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics/graphics.sty
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics/trig.sty)
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics-cfg/graphics.cfg)
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics-def/pdftex.def)))
(/usr/local/texlive/2023/texmf-dist/tex/latex/xkeyval/xkeyval.sty
(/usr/local/texlive/2023/texmf-dist/tex/generic/xkeyval/xkeyval.tex
(/usr/local/texlive/2023/texmf-dist/tex/generic/xkeyval/xkvutils.tex)))
(/usr/local/texlive/2023/texmf-dist/tex/latex/overpic/overpic.sty
(/usr/local/texlive/2023/texmf-dist/tex/latex/eepic/epic.sty
Enhancements to Picture Environment. Version 1.2 - Released June 1, 1986
)) (/usr/local/texlive/2023/texmf-dist/tex/latex/xcolor/xcolor.sty
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics-cfg/color.cfg)
(/usr/local/texlive/2023/texmf-dist/tex/latex/graphics/mathcolor.ltx))
(/usr/local/texlive/2023/texmf-dist/tex/latex/l3backend/l3backend-pdftex.def)
(./Untitled.aux) (/usr/local/texlive/2023/texmf-dist/tex/latex/amsfonts/umsa.fd
) (/usr/local/texlive/2023/texmf-dist/tex/latex/amsfonts/umsb.fd)
(/usr/local/texlive/2023/texmf-dist/tex/context/base/mkii/supp-pdf.mkii
[Loading MPS to PDF converter (version 2006.09.02).]
) (/usr/local/texlive/2023/texmf-dist/tex/latex/epstopdf-pkg/epstopdf-base.sty
(/usr/local/texlive/2023/texmf-dist/tex/generic/infwarerr/infwarerr.sty)
(/usr/local/texlive/2023/texmf-dist/tex/latex/grfext/grfext.sty
(/usr/local/texlive/2023/texmf-dist/tex/generic/kvdefinekeys/kvdefinekeys.sty))
(/usr/local/texlive/2023/texmf-dist/tex/latex/kvoptions/kvoptions.sty
(/usr/local/texlive/2023/texmf-dist/tex/generic/ltxcmds/ltxcmds.sty)
(/usr/local/texlive/2023/texmf-dist/tex/latex/kvsetkeys/kvsetkeys.sty))
(/usr/local/texlive/2023/texmf-dist/tex/generic/pdftexcmds/pdftexcmds.sty
(/usr/local/texlive/2023/texmf-dist/tex/generic/iftex/iftex.sty))
(/usr/local/texlive/2023/texmf-dist/tex/latex/latexconfig/epstopdf-sys.cfg))
pdfTeX warning: /Library/TeX/texbin/pdflatex (file ./DS4-3-image1b.pdf): PDF in
clusion: found PDF version <1.6>, but at most version <1.5> allowed
./Untitled.tex:8: Package xkeyval Error: `width' undefined in families `OVP'.
See the xkeyval package documentation for explanation.
Type H <return> for immediate help.
...
l.8 ...gin{overpic}[width=10cm]{DS4-3-image1b.pdf}
?
[1{/usr/local/texlive/2023/texmf-var/fonts/map/pdftex/updmap/pdftex.map} <./DS4
-3-image1b.pdf, page is rotated 270 degrees>] (./Untitled.aux) )</usr/local/tex
live/2023/texmf-dist/fonts/type1/public/amsfonts/cm/cmmi12.pfb></usr/local/texl
ive/2023/texmf-dist/fonts/type1/public/amsfonts/cm/cmr8.pfb></usr/local/texlive
/2023/texmf-dist/fonts/type1/public/amsfonts/cm/cmr9.pfb>
Output written on Untitled.pdf (1 page, 84995 bytes).
SyncTeX written on Untitled.synctex.gz.
Transcript written on Untitled.log.
