TikZ: decorar el grosor del trazo arroja "Dimenson demasiado grande" pero se ve bien (lo mismo ocurre con las marcas)

Question

Estoy trabajando en algunos adornos en mi macro de marca ídem (verTikz: use la longitud del látex para la longitud del camino (lo mismo ocurre con las marcas)). Es decir, utilizar espesor variable para los trazos. A continuación se implementa como la versión destacada de la macro.

Sin embargo, cuando intento utilizar un trazo de grosor variable, obtengo 35 Dimension too largeerrores por cada uno \ditto*, aunque el trazado generado se ve bien...

¿Cómo puedo solucionar esto?

MWE:

\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{xparse}

\makeatletter

\usepackage{tikz}
\usetikzlibrary{math}
\usetikzlibrary{decorations}

\pgfkeys{/pgf/decoration/.cd,
    start stroke width/.store in = \startstrokewidth,
    end stroke width/.store in   = \endstrokewidth,
}
\pgfkeys{/tikz/.cd,
    pen stroke/.style args={#1,#2}{
        decorate,
        decoration={
            variable stroke width,
            start stroke width=#1,
            end stroke width=#2,
        }
    }
}

\pgfdeclaredecoration{variable stroke width}{initial}{%
    % modified version of:
    % https://tex.stackexchange.com/questions/14283/stroke-with-variable-thickness
    \state{initial}[width=0pt, next state=line, persistent precomputation={%
        \pgfmathsubtract@{\startstrokewidth}{\endstrokewidth}%
        \pgfmathdivide{\pgfmathresult}{\pgfdecoratedpathlength}%
        \let\strokeincrement=\pgfmathresult%
        \def\strokewidth{\startstrokewidth}%
    }]{}
    \state{line}[width=\startstrokewidth, persistent postcomputation={%
        \pgfmathsubtract@{\strokewidth}{\strokeincrement}%
        \let\strokewidth=\pgfmathresult%
    }]{%
        \pgfsetlinewidth{\strokewidth}%
        \pgfsetarrows{-}%
        \pgfpathmoveto{\pgfpointorigin}%
        \pgfpathlineto{\pgfqpoint{.75pt}{0pt}}%
        \pgfusepath{stroke}%
    }
    \state{final}{%
        \pgfsetlinewidth{\pgflinewidth}%
        \pgfpathmoveto{\pgfpointorigin}%
        \pgfusepath{stroke}%
    }
}


\newdimen\dto@x
\newdimen\dto@y
\newdimen\dto@spc
\NewDocumentCommand\ditto{ s O{2ex} m }{%
    % #1 = starred means use pen stroke, unstarred use regular line
    % #2 = minimum width
    % #3 = string to use for calculating width
    \settowidth{\dto@x}{#3}%
    %\showthe\dto@x%
    \dto@x = \ifdim#2<\dto@x\the\dto@x\else\the\dimexpr#2\relax\fi% whichever is widest of #2 and #3
    \divide\dto@x by 4% sine wave has 4 points
    \dto@y = .0675ex% .125ex%
    \dto@spc = .5pt% ditto mark sizing
    \begin{tikzpicture}[baseline=-.5ex,cap=round]
        \IfBooleanTF{#1}{% starred
            \draw[pen stroke={.4pt,.35pt}] (0,0) sin (1\dto@x, \dto@y) cos (2\dto@x, 0) sin (3\dto@x, -\dto@y) cos (4\dto@x, 0);
        }{% unstarred
            \draw (0,0) sin (1\dto@x, \dto@y) cos (2\dto@x, 0) sin (3\dto@x, -\dto@y) cos (4\dto@x, 0);
        }%
        \draw[xshift=-.2ex, pen stroke={.4pt,.35pt}] (2\dto@x + .25pt, 3\dto@y) -- (2\dto@x - .25pt, -3\dto@y);
        \draw[xshift=.2ex, pen stroke={.4pt,.35pt}] (2\dto@x + .25pt, 3\dto@y) -- (2\dto@x - .25pt, -3\dto@y);
    \end{tikzpicture}%
}

\makeatother

\begin{document}

\noindent
blah blah Test blah blah\\
blah blah \ditto{Test} blah blah\\
blah blah \ditto*{Test} blah blah\\     % throws 'Dimension too large' several times, but looks great in doc?!
blah blah Testing testing blah blah\\
blah blah \ditto{Testing testing} blah blah\\
%blah blah \ditto*{Testing testing} blah blah\\
blah blah \ditto{} blah blah\\
%blah blah \ditto*{} blah blah\\
blah blah \ditto[10em]{Test} blah blah\\
%blah blah \ditto*[10em]{Test} blah blah\\
blah blah \ditto[10em]{Testing testing} blah blah\\
%blah blah \ditto*[10em]{Testing testing} blah blah\\
blah blah \ditto[10em]{} blah blah\\
%blah blah \ditto*[10em]{} blah blah\\

\end{document}

Relacionado:

• Trazo con espesor variable

Answer 1

Siempre el mismo problema: veclenno me gustan los valores pequeños. Ver esta publicación:como poner una marca

una solución conxfp

\documentclass{article}
\usepackage[showframe]{geometry}
\usepackage{xparse}

\makeatletter

\usepackage{tikz,xfp}
\usetikzlibrary{math}
\usetikzlibrary{decorations}

\pgfkeys{/pgf/decoration/.cd,
    start stroke width/.store in = \startstrokewidth,
    end stroke width/.store in   = \endstrokewidth,
}
\pgfkeys{/tikz/.cd,
    pen stroke/.style args={#1,#2}{
        decorate,
        decoration={
            variable stroke width,
            start stroke width=#1,
            end stroke width=#2,
        }
    }
}

\pgfdeclaredecoration{variable stroke width}{initial}{%
    % modified version of:
    % https://tex.stackexchange.com/questions/14283/stroke-with-variable-thickness
    \state{initial}[width=0pt, next state=line, persistent precomputation={%
        \pgfmathsubtract@{\startstrokewidth}{\endstrokewidth}%
        \pgfmathdivide{\pgfmathresult}{\pgfdecoratedpathlength}%
        \let\strokeincrement=\pgfmathresult%
        \def\strokewidth{\startstrokewidth}%
    }]{}
    \state{line}[width=\startstrokewidth, persistent postcomputation={%
        \pgfmathsubtract@{\strokewidth}{\strokeincrement}%
        \let\strokewidth=\pgfmathresult%
    }]{%
        \pgfsetlinewidth{\strokewidth}%
        \pgfsetarrows{-}%
        \pgfpathmoveto{\pgfpointorigin}%
        \pgfpathlineto{\pgfqpoint{.75pt}{0pt}}%
        \pgfusepath{stroke}%
    }
    \state{final}{%
        \pgfsetlinewidth{\pgflinewidth}%
        \pgfpathmoveto{\pgfpointorigin}%
        \pgfusepath{stroke}%
    }
}


\newdimen\dto@x
\newdimen\dto@y
\newdimen\dto@spc
\NewDocumentCommand\ditto{ s O{2ex} m }{%
    % #1 = starred means use pen stroke, unstarred use regular line
    % #2 = minimum width
    % #3 = string to use for calculating width
    \settowidth{\dto@x}{#3}%
    %\showthe\dto@x%
    \dto@x = \ifdim#2<\dto@x\the\dto@x\else\the\dimexpr#2\relax\fi% whichever is widest of #2 and #3
    \divide\dto@x by 4% sine wave has 4 points
    \dto@y = .0675ex% .125ex%
    \dto@spc = .5pt% ditto mark sizing
    \begin{tikzpicture}[baseline=-.5ex,cap=round]
        \IfBooleanTF{#1}{% starred
            \draw[pen stroke={.4pt,.35pt}] (0,0) sin (1\dto@x, \dto@y) cos (2\dto@x, 0) sin (3\dto@x, -\dto@y) cos (4\dto@x, 0);
        }{% unstarred
            \draw (0,0) sin (1\dto@x, \dto@y) cos (2\dto@x, 0) sin (3\dto@x, -\dto@y) cos (4\dto@x, 0);
        }%
        \draw[xshift=-.2ex, pen stroke={.4pt,.35pt}] (2\dto@x + .25pt, 3\dto@y) -- (2\dto@x - .25pt, -3\dto@y);
        \draw[xshift=.2ex, pen stroke={.4pt,.35pt}] (2\dto@x + .25pt, 3\dto@y) -- (2\dto@x - .25pt, -3\dto@y);
    \end{tikzpicture}%
}

\pgfmathdeclarefunction*{veclen}{2}{%
\begingroup%
  \pgfmath@x#1pt\relax%
  \pgfmath@y#2pt\relax%
\pgf@xa=\pgf@x%
\pgf@ya=\pgf@y%
\edef\tkz@temp@a{\fpeval{\pgfmath@tonumber{\pgf@xa}}}
\edef\tkz@temp@b{\fpeval{\pgfmath@tonumber{\pgf@ya}}}
\edef\tkz@temp@sum{\fpeval{(\tkz@temp@a*\tkz@temp@a+\tkz@temp@b*\tkz@temp@b)}}
\edef\tkzFPMathLen{\fpeval{sqrt(\tkz@temp@sum)}}
%\edef\pgfmath@tmp{\fpeval{round(\tkzFPMathLen,6)}}
%\pgfmath@tmp %
  \pgfmath@returnone\tkzFPMathLen pt%
  \endgroup%
}
\makeatother


\begin{document}

\noindent
blah blah Test blah blah\\
blah blah \ditto{Test} blah blah\\
blah blah \ditto*{Test} blah blah\\     % throws 'Dimension too large' several times, but looks great in doc?!
blah blah Testing testing blah blah\\
blah blah \ditto{Testing testing} blah blah\\
%blah blah \ditto*{Testing testing} blah blah\\
blah blah \ditto{} blah blah\\
%blah blah \ditto*{} blah blah\\
blah blah \ditto[10em]{Test} blah blah\\
%blah blah \ditto*[10em]{Test} blah blah\\
blah blah \ditto[10em]{Testing testing} blah blah\\
%blah blah \ditto*[10em]{Testing testing} blah blah\\
blah blah \ditto[10em]{} blah blah\\
%blah blah \ditto*[10em]{} blah blah\\

\end{document}

Otra modificación de Loop Space

\pgfmathdeclarefunction*{veclen}{2}{%
  \begingroup%
  \pgfmath@x#1pt\relax%
  \pgfmath@y#2pt\relax%
  \ifdim\pgfmath@x<0pt\relax%
  \pgfmath@x-\pgfmath@x%
  \fi%
  \ifdim\pgfmath@y<0pt\relax%
  \pgfmath@y-\pgfmath@y%
  \fi%
  \ifdim\pgfmath@x=0pt\relax%
  \pgfmath@x\pgfmath@y%
  \else%
  \ifdim\pgfmath@y=0pt\relax%
  \else%
  \ifdim\pgfmath@x>\pgfmath@y%
  \pgfmath@xa\pgfmath@x%
  \pgfmath@x\pgfmath@y%
  \pgfmath@y\pgfmath@xa%
  \fi%
  % We use a scaling factor to reduce errors.
  % First, see if we should scale down
  \let\pgfmath@tmp@scale=\divide
  \let\pgfmath@tmp@restore=\multipy
  \ifdim\pgfmath@y>10000pt\relax%
  \c@pgfmath@counta1500\relax%
  \else%
  \ifdim\pgfmath@y>1000pt\relax%
  \c@pgfmath@counta150\relax%
  \else%
  \ifdim\pgfmath@y>100pt\relax%
  \c@pgfmath@counta50\relax%
  \else%
  % Not scaling down, should we scale up?
  \let\pgfmath@tmp@scale=\multiply
  \let\pgfmath@tmp@restore=\divide
  \ifdim\pgfmath@y<0.00001pt\relax%
  \c@pgfmath@counta1500\relax%
  \else%
  \ifdim\pgfmath@y<0.0001pt\relax%
  \c@pgfmath@counta150\relax%
  \else%
  \ifdim\pgfmath@y<0.001pt\relax%
  \c@pgfmath@counta50\relax%
  \else
  \c@pgfmath@counta1\relax%
  \fi%
  \fi%
  \fi%
  \fi%
  \fi%
  \fi%
  \pgfmath@tmp@scale\pgfmath@x\c@pgfmath@counta\relax%
  \pgfmath@tmp@scale\pgfmath@y\c@pgfmath@counta\relax%
  \pgfmathreciprocal@{\pgfmath@tonumber{\pgfmath@y}}%
  \pgfmath@x\pgfmathresult\pgfmath@x%
  \pgfmath@xa\pgfmath@tonumber{\pgfmath@x}\pgfmath@x%
  \edef\pgfmath@temp{\pgfmath@tonumber{\pgfmath@xa}}%
  %
  % Use A+x^2*(B+x^2*(C+x^2*(D+E*x^2)))
  % where
  % A = +1.000012594
  % B = +0.4993615349
  % C = -0.1195159052
  % D = +0.04453994279
  % E = -0.01019210944
  %
  \[email protected]\pgfmath@xa%
  \advance\[email protected]\relax%
  \pgfmath@x\pgfmath@temp\pgfmath@x%
  \advance\[email protected]\relax%
  \pgfmath@x\pgfmath@temp\pgfmath@x%
  \advance\[email protected]\relax%
  \pgfmath@x\pgfmath@temp\pgfmath@x%
  \advance\[email protected]\relax%
  \ifdim\pgfmath@y<0pt\relax%
  \pgfmath@y-\pgfmath@y%
  \fi%
  \pgfmath@x\pgfmath@tonumber{\pgfmath@y}\pgfmath@x%
  % Invert the scaling factor.
  \pgfmath@tmp@restore\pgfmath@x\c@pgfmath@counta\relax%
  \fi%
  \fi%
  \pgfmath@returnone\pgfmath@x%
  \endgroup%
}
