Estoy usando Stunnel, Varnish y nginx con una aplicación nodejs y tengo problemas para redirigir páginas que no son https (http://administrador.dominio.com) a su respectiva página https (https://administrador.dominio.com). Me quedo atrapado en un bucle de redireccionamiento porque todo el tráfico pasa primero por el barniz. La razón principal de esta configuración es utilizar sockets con ssl.
Stunnel escucha en el puerto 443. Termina las conexiones SSL y pasa el tráfico a Varnish en el puerto 80. Varnish escucha en el puerto 80 y divide el resto del tráfico según sea necesario entre Nginx en 81 y Node.js en el puerto 3000. Nginx escucha en el puerto 81. Sirve archivos estáticos y otras páginas que no sean de Node.js.
Aquí está el archivo de configuración de nginx
upstream nodejs {
server 127.0.0.1:3000;
server 127.0.0.1:3000;
}
server {
listen 81;
server_name www.domain.net;
rewrite ^(.*) http://domain.com$1 permanent;
}
server {
listen 81;
server_name manager.domain.com;
rewrite ^(.*) https://manager.domain.com$1 permanent;
}
server {
listen 81;
server_name domain.com manager.domain.com help.domain.com;
access_log /srv/www/domain.com/logs/access.log timed;
error_log /srv/www/domain.com/logs/error.log info;
root /srv/www/domain.com/public;
#everything else
location / {
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
proxy_set_header Host $http_host;
proxy_set_header X-NginX-Proxy true;
proxy_pass http://nodejs/;
proxy_redirect off;
}
gzip on;
gzip_comp_level 6;
gzip_proxied any;
gzip_min_length 1000;
gzip_disable "MSIE [1-6]\."
gzip_types text/plain text/css application/json application/x-javascript text/xml application/xml application/xml+rss text/javascript;
}
Aquí está el archivo de configuración de barniz.
backend default {
.host = "127.0.0.1";
.port = "81";
.connect_timeout = 5s;
.first_byte_timeout = 30s;
.between_bytes_timeout = 60s;
.max_connections = 800;
}
backend nodejs {
.host = "127.0.0.1";
.port = "3000";
.connect_timeout = 1s;
.first_byte_timeout = 2s;
.between_bytes_timeout = 60s;
.max_connections = 800;
}
sub vcl_recv {
set req.backend = default;
set req.grace = 120s;
#set the correct IP so my backends don’t log all requests as coming from Varnish
if (req.restarts == 0) {
if (req.http.x-forwarded-for) {
set req.http.X-Forwarded-For =
req.http.X-Forwarded-For + ", " + client.ip;
} else {
set req.http.X-Forwarded-For = client.ip;
}
}
#remove port, so that hostname is normalized
set req.http.Host = regsub(req.http.Host, ":[0-9]+", "");
#Removed: code for purging
#part of Varnish’s default config
if (req.request != "GET" &&
req.request != "HEAD" &&
req.request != "PUT" &&
req.request != "POST" &&
req.request != "TRACE" &&
req.request != "OPTIONS" &&
req.request != "DELETE") {
/* Non-RFC2616 or CONNECT which is weird. */
return (pipe);
}
if (req.request != "GET" && req.request != "HEAD") {
return (pass);
}
#pipe websocket connections directly to Node.js
if (req.http.Upgrade ~ "(?i)websocket") {
set req.backend = nodejs;
return (pipe);
}
#do not cache large static files
if (req.url ~ "\.(avi|flv|mp(e?)g|mp4|mp3|gz|tgz|bz2|tbz|ogg)$") {
return(pass);
}
#general URL manipulation and cookie removal
#lines 60-109 from https://github.com/mattiasgeniar/varnish-3.0-configuration-templates/blob/d86d6c1d7d3d0ddaf92019dd5ef5ce66c9e53700/default.vcl
if(req.http.Host ~"^(www\.)?domain.com"){
#Removed: Redirect for URL normalization using error 701
# Requests made to this path, relate to websockets - pass does not seem to work (even for XHR polling)
if (req.url ~ "^/socket.io/") {
set req.backend = nodejs;
return (pipe);
}
#My other PHP/MySQL sites get included here, each in its own block
}
# part of Varnish’s default config
if (req.http.Authorization || req.http.Cookie) {
/* Not cacheable by default */
return (pass);
}
return (lookup);
}
sub vcl_pipe {
#we need to copy the upgrade header
if (req.http.upgrade) {
set bereq.http.upgrade = req.http.upgrade;
}
#closing the connection is necessary for some applications – I haven’t had any issues with websockets keeping the line below uncommented
#set bereq.http.Connection = "close";
return (pipe);
}
sub vcl_pass {
return (pass);
}
sub vcl_hash {
hash_data(req.url);
if (req.http.host) {
hash_data(req.http.host);
} else {
hash_data(server.ip);
}
return (hash);
}
sub vcl_hit {
return (deliver);
}
sub vcl_miss {
return (fetch);
}
sub vcl_fetch {
if (beresp.ttl <= 0s ||
beresp.http.Set-Cookie ||
beresp.http.Vary == "*") {
/*
* Mark as "Hit-For-Pass" for the next 2 minutes
*/
set beresp.ttl = 120 s;
return (hit_for_pass);
}
return (deliver);
}
sub vcl_deliver {
return (deliver);
}
sub vcl_error {
set obj.http.Content-Type = "text/html; charset=utf-8";
set obj.http.Retry-After = "5";
synthetic {"
<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Strict//EN"
"http://www.w3.org/TR/xhtml1/DTD/xhtml1-strict.dtd">
<html>
<head>
<title>"} + obj.status + " " + obj.response + {"</title>
</head>
<body>
<h1>Error "} + obj.status + " " + obj.response + {"</h1>
<p>"} + obj.response + {"</p>
<h3>Guru Meditation:</h3>
<p>XID: "} + req.xid + {"</p>
<hr>
<p>Varnish cache server</p>
</body>
</html>
"};
return (deliver);
}
sub vcl_init {
return (ok);
}
sub vcl_fini {
return (ok);
}
Respuesta1
Tiene dos serverbloques en el puerto 81 manager.domain.comconfigurados como encabezado de host: nginx no tiene forma de saber si una solicitud pasó por stunnel o no, por lo que el primero gana y la redirección siempre ocurre.
Recomendaría que Varnish haga la redirección en función de si la solicitud proviene de Stunnel o no (verifique la solicitud client.ip: 127.0.0.1 significa que es de Stunnel), o que Varnish marque las solicitudes de Stunnel con un encabezado para que nginx pueda decidir. cómo manejarlos.
