Voy a unir 3 líneas de Internet en una sola red.
Estoy usando el enrutador Mikrotik RB750, configuré este enrutador así:
/ip firewall mangle
add chain=input in-interface=WAN2 action=mark-connection new-connection-mark=WAN2_conn
add chain=input in-interface=WAN3 action=mark-connection new-connection-mark=WAN3_conn
add chain=input in-interface=WAN4 action=mark-connection new-connection-mark=WAN4_conn
add chain=input in-interface=WAN5 action=mark-connection new-connection-mark=WAN5_conn
add chain=output connection-mark=WAN2_conn action=mark-routing new-routing-mark=to_WAN2
add chain=output connection-mark=WAN3_conn action=mark-routing new-routing-mark=to_WAN3
add chain=output connection-mark=WAN4_conn action=mark-routing new-routing-mark=to_WAN4
add chain=output connection-mark=WAN5_conn action=mark-routing new-routing-mark=to_WAN5
add chain=prerouting dst-address=192.168.2.0/24 action=accept in-interface=bridge1
add chain=prerouting dst-address=192.168.3.0/24 action=accept in-interface=bridge1
add chain=prerouting dst-address=192.168.4.0/24 action=accept in-interface=bridge1
add chain=prerouting dst-address=192.168.5.0/24 action=accept in-interface=bridge1
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/0 action=mark-connection new-connection-mark=WAN2_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/1 action=mark-connection new-connection-mark=WAN3_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/2 action=mark-connection new-connection-mark=WAN4_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/3 action=mark-connection new-connection-mark=WAN5_conn passthrough=yes
add chain=prerouting connection-mark=WAN2_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN2
add chain=prerouting connection-mark=WAN3_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN3
add chain=prerouting connection-mark=WAN4_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN4
add chain=prerouting connection-mark=WAN5_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN5
/ip route
add dst-address=0.0.0.0/0 gateway=192.168.2.1 routing-mark=to_WAN2 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.3.1 routing-mark=to_WAN3 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.4.1 routing-mark=to_WAN4 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.5.1 routing-mark=to_WAN5 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.2.1 distance=1 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.3.1 distance=2 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.4.1 distance=2 check-gateway=ping
add dst-address=0.0.0.0/0 gateway=192.168.5.1 distance=2 check-gateway=ping
/ip firewall nat
add chain=srcnat out-interface=WAN2 action=masquerade
add chain=srcnat out-interface=WAN3 action=masquerade
add chain=srcnat out-interface=WAN4 action=masquerade
add chain=srcnat out-interface=WAN5 action=masquerade
Nota: El enrutador tiene 5 puertos físicos (WAN1, WAN2, WAN3, WAN4, WAN5) y 1 puerto inalámbrico. WAN1 y el puerto inalámbrico conectados entre sí a través de Bridge1todos los nodos de la red conectados al Bridge1 (WAN1 o inalámbrico), ahora no hay problemas en la conexión a Internet y está funcionando bien. pero cuando un nodo en esta red quiere visitar un sitio web (por ejemplo: google.com), la solicitud se enviará a google.com desde todas las líneas de Internet. Entonces, para cada nodo, enviaremos 2 solicitudes más a un solo sitio web.
Quiero dividir estas líneas de Internet entre nodos de red, por ejemplo, cada rango de IP usa una línea de Internet específica, como esta:
192.168.1.1 - 192.168.1.64: Use first Internet line
192.168.1.65 - 192.168.1.128: Use second Internet line
192.168.1.129 - 192.168.1.254: Use third Internet line
¿Es posible? ¿me puedes ayudar?
Respuesta1
Está intentando utilizar PCC (clasificador por conexión) pero lo que solicita es equilibrio de carga según el rango de direcciones IP de origen.
Elimine las siguientes reglas de su configuración:
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/0 action=mark-connection new-connection-mark=WAN2_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/1 action=mark-connection new-connection-mark=WAN3_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/2 action=mark-connection new-connection-mark=WAN4_conn passthrough=yes
add chain=prerouting dst-address-type=!local in-interface=bridge1 per-connection-classifier=both-addresses-and-ports:4/3 action=mark-connection new-connection-mark=WAN5_conn passthrough=yes
add chain=prerouting connection-mark=WAN2_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN2
add chain=prerouting connection-mark=WAN3_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN3
add chain=prerouting connection-mark=WAN4_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN4
add chain=prerouting connection-mark=WAN5_conn in-interface=bridge1 action=mark-routing new-routing-mark=to_WAN5
Y agregue lo siguiente:
add chain=prerouting src-address=192.168.1.0/26 in-interface=bridge1 dst-address=!192.168.1.0/24 action=mark-routing disabled=no new-routing-mark=to_WAN2 passthrough=no
add chain=prerouting src-address=192.168.1.64/26 in-interface=bridge1 dst-address=!192.168.1.0/24 action=mark-routing disabled=no new-routing-mark=to_WAN3 passthrough=no
add chain=prerouting src-address=192.168.1.128/25 in-interface=bridge1 dst-address=!192.168.1.0/24 action=mark-routing disabled=no new-routing-mark=to_WAN4 passthrough=no
No es necesario marcar las conexiones y luego marcar la ruta después. Puede marcar la ruta directamente según el rango de direcciones de origen.
