Hemos estado experimentando un problema que nos causa dolor durante los últimos meses.
El problema parece ser que, en ocasiones, cuando solicitamos un pod a través del ejecutor de Kubernetes, este no se crea.
Por ejemplo, una cápsula de chispa puede fallar con el siguiente error:
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Warning FailedCreatePodSandBox 20m (x3 over 32m) kubelet, k8s-agentpool1-123456789-vmss00000q (combined from similar events): Failed create pod sandbox: rpc error: code = Unknown desc = failed to create a sandbox for pod "spark-worker-cc1d28bf3de8428a826c04471e58487c-8577d5d654-2jg89": operation timeout: context deadline exceeded
Normal SandboxChanged 16m (x150 over 159m) kubelet, k8s-agentpool1-123456789-vmss00000q Pod sandbox changed, it will be killed and re-created.
Warning FailedCreatePodSandBox 5m7s (x14 over 161m) kubelet, k8s-agentpool1-123456789-vmss00000q Failed create pod sandbox: rpc error: code = Unknown desc = failed to create a sandbox for pod "spark-worker-cc1d28bf3de8428a826c04471e58487c-8577d5d654-2jg89": operation timeout: context deadline exceeded
Al observar los registros, vemos "SyncLoop" de kubelet solicitando un nuevo pod.
Jul 16 16:33:58 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:33:58.001997 4797 kubelet.go:1908] SyncLoop (ADD, "api"): "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)
También hay algunos registros que indican que los volúmenes están montados...
Jul 16 16:34:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:33:58.175573 4797 reconciler.go:252] operationExecutor.MountVolume started for volume "default-shared" (UniqueName: "kubernetes.io/glusterfs/8272d74f-a7e7-11e9-8f1c-000d3a7b202b-default-shared") pod "d9b3911585c4461c9728aefa39716c44" (UID: "8272d74f-a7e7-11e9-8f1c-000d3a7b202b")
Vemos que se va a crear un pod Sandbox:
Jul 16 16:34:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:34:29.627374 4797 kuberuntime_manager.go:397] No sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
Parece que no vemos nada más hasta que vemos esto registrado:
Jul 16 16:36:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:29.629252 4797 kuberuntime_manager.go:662] createPodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": operation timeout: context deadline exceeded
Jul 16 16:36:29 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:29.629301 4797 pod_workers.go:190] Error syncing pod 8272d74f-a7e7-11e9-8f1c-000d3a7b202b ("d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)"), skipping: failed to "CreatePodSandbox" for "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" with CreatePodSandboxError: "CreatePodSandbox for pod \"d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)\" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod \"d9b3911585c4461c9728aefa39716c44\": operation timeout: context deadline exceeded"
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:43.937085 4797 kuberuntime_manager.go:397] No sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940691 4797 remote_runtime.go:96] RunPodSandbox from runtime service failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940731 4797 kuberuntime_sandbox.go:68] CreatePodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940747 4797 kuberuntime_manager.go:662] createPodSandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod "d9b3911585c4461c9728aefa39716c44": Error response from daemon: Conflict. The container name "/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0" is already in use by container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27". You have to remove (or rename) that container to be able to reuse that name.
Jul 16 16:36:43 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: E0716 16:36:43.940805 4797 pod_workers.go:190] Error syncing pod 8272d74f-a7e7-11e9-8f1c-000d3a7b202b ("d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)"), skipping: failed to "CreatePodSandbox" for "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" with CreatePodSandboxError: "CreatePodSandbox for pod \"d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)\" failed: rpc error: code = Unknown desc = failed to create a sandbox for pod \"d9b3911585c4461c9728aefa39716c44\": Error response from daemon: Conflict. The container name \"/k8s_POD_d9b3911585c4461c9728aefa39716c44_default_8272d74f-a7e7-11e9-8f1c-000d3a7b202b_0\" is already in use by container \"2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27\". You have to remove (or rename) that container to be able to reuse that name."
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: W0716 16:36:44.221607 4797 docker_sandbox.go:384] failed to read pod IP from plugin/docker: NetworkPlugin cni failed on the status hook for pod "d9b3911585c4461c9728aefa39716c44_default": CNI failed to retrieve network namespace path: cannot find network namespace for the terminated container "2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27"
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:44.222749 4797 kubelet.go:1953] SyncLoop (PLEG): "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)", event: &pleg.PodLifecycleEvent{ID:"8272d74f-a7e7-11e9-8f1c-000d3a7b202b", Type:"ContainerDied", Data:"2a7ecfd3725bbe6604b3006abf6c59a36eb8a5d7142e71a3791f5f7378bf5e27"}
Jul 16 16:36:44 k8s-agentpool1-123456789-vmss00000T kubelet[4797]: I0716 16:36:44.739387 4797 kuberuntime_manager.go:415] No ready sandbox for pod "d9b3911585c4461c9728aefa39716c44_default(8272d74f-a7e7-11e9-8f1c-000d3a7b202b)" can be found. Need to start a new one
Pensamos que podría ser un error de CNI, sin embargo, revisamos los registros de Azure CNI y parece que ni siquiera llega a la parte donde comienza a solicitar una IP, solo muestra un error que el comando DEL completó con err.
2019/07/16 16:23:06 [net] Deleting veth pair azv4ea5d9d9527 eth0.
2019/07/16 16:23:06 [net] Deleted endpoint &{Id:8e963d34-eth0 HnsId: SandboxKey: IfName:eth0 HostIfName:azv4ea5d9d9527 MacAddress:ce:93:bf:4d:e9:19 InfraVnetIP:{IP:<nil> Mask:<nil>} IPAddresses:[{IP:10.250.18.22
5 Mask:fffff800}] Gateways:[10.250.16.1] DNS:{Suffix: Servers:[168.63.129.16]} Routes:[{Dst:{IP:0.0.0.0 Mask:00000000} Src:<nil> Gw:10.250.16.1 Protocol:0 DevName: Scope:0}] VlanID:0 EnableSnatOnHost:false Enabl
eInfraVnet:false EnableMultitenancy:false NetworkNameSpace:/proc/10781/ns/net ContainerID:8e963d340597f1c9f789b93a7784e8d44ffb00687086de8ee6561338aab7c72d PODName:jupyter-some-person-10 PODNameSpace:defaul
t InfraVnetAddressSpace:}.
2019/07/16 16:23:06 [net] Save succeeded.
2019/07/16 16:23:06 [cni] Calling plugin azure-vnet-ipam DEL nwCfg:&{CNIVersion:0.3.0 Name:azure Type:azure-vnet Mode:bridge Master: Bridge:azure0 LogLevel: LogTarget: InfraVnetAddressSpace: PodNamespaceForDualN
etwork:[] MultiTenancy:false EnableSnatOnHost:false EnableExactMatchForPodName:false CNSUrl: Ipam:{Type:azure-vnet-ipam Environment: AddrSpace: Subnet:10.250.16.0/21 Address:10.250.18.225 QueryInterval:} DNS:{Na
meservers:[] Domain: Search:[] Options:[]} RuntimeConfig:{PortMappings:[] DNS:{Servers:[] Searches:[] Options:[]}} AdditionalArgs:[]}.
2019/07/16 16:23:06 [cni] Plugin azure-vnet-ipam returned err:<nil>.
2019/07/16 16:23:06 Get number of endpoints for ifname eth0 network azure
2019/07/16 16:23:06 [cni-net] DEL command completed with err:<nil>.
2019/07/16 16:23:06 [cni-net] Plugin stopped.
2019/07/16 16:36:38 [cni-net] Plugin azure-vnet version v1.0.18.
2019/07/16 16:36:38 [cni-net] Running on Linux version 4.15.0-1040-azure (buildd@lgw01-amd64-030) (gcc version 5.4.0 20160609 (Ubuntu 5.4.0-6ubuntu1~16.04.10)) #44-Ubuntu SMP Thu Feb 21 14:24:01 UTC 2019
Client:
Version: 3.0.3
API version: 1.40
Go version: go1.11.4
Git commit: 48bd4c6d
Built: Wed Jan 23 16:17:56 2019
OS/Arch: linux/amd64
Experimental: false
Server:
Engine:
Version: 3.0.4
API version: 1.40 (minimum version 1.12)
Go version: go1.11.4
Git commit: 8ecd530
Built: Fri Jan 25 01:45:38 2019
OS/Arch: linux/amd64
Experimental: false
containerd:
Version: v1.2.2
GitCommit: 9754871865f7fe2f4e74d43e2fc7ccd237edcbce
runc:
Version: 1.0.0-rc6+dev
GitCommit: 96ec2177ae841256168fcf76954f7177af9446eb
docker-init:
Version: 0.18.0
GitCommit: fec3683
Aquí está la información de la versión k8s:
Server Version: version.Info{Major:"1", Minor:"13", GitVersion:"v1.13.5", GitCommit:"2166946f41b36dea2c4626f90a77706f426cdea2", GitTreeState:"clean", BuildDate:"2019-03-25T15:19:22Z", GoVersion:"go1.11.5", Compiler:"gc", Platform:"linux/amd64"}
Aquí está la información de nuestro nodo: estamos utilizando el motor AKS para crear un clúster de Kubernetes que utiliza nodos Azure VMSS.
Kernel Version: 4.15.0-1050-azure
OS Image: Ubuntu 16.04.6 LTS
Operating System: linux
Architecture: amd64
Container Runtime Version: docker://3.0.4
Kubelet Version: v1.13.5
Kube-Proxy Version: v1.13.5
No tengo ideas sobre qué podemos hacer para solucionar este problema aún más, ya que ni siquiera podemos recrear este problema.
Entiendo que esta alerta de "fecha límite de contexto excedida" es un tiempo de espera de gRPC genérico, pero no estoy seguro de en qué transacción de gRPC se está bloqueando.
Respuesta1
El problema fue un error en Kubernetes/el kernel de Linux discutido aquí que involucró a los cgroups creciendo exponencialmente y causando problemas que incluían un alto uso de CPU/memoria.
El problema se describeaquí:
Aquí se documenta una solución alternativa: solución para fugas de grupo c
La solución es un conjunto de demonios que ejecuta la limpieza cada hora.
