Estoy rastreando un problema de rendimiento con las solicitudes SSL.
Ejecutamos dos servidores web en dos instancias EC2 (us-east-2a/us-east-2b) con un ALB que también realiza la terminación SSL allí, Route53 está a cargo del dominio con un CNAME para el CNAME del ALB. Todo corre en una VPC privada, con dos subredes privadas, ambas subredes tienen una tabla de rutas con acceso a Internet a través de una puerta de enlace NAT. Estoy usando una VPN para llegar a los puntos finales del balanceador/EC2.
Ir directamente al ALB usando HTTP (sin redirección de HTTP a HTTPS),
% ab -n10 -c1 \
-H "Host: service.internal.stg" \
http://service.internal.stg/
This is ApacheBench, Version 2.3 <$Revision: 1843412 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking service.internal.stg (be patient).....done
Server Software: Skipper
Server Hostname: service.internal.stg
Server Port: 80
Document Path: /
Document Length: 199 bytes
Concurrency Level: 1
Time taken for tests: 5.015 seconds
Complete requests: 10
Failed requests: 1
(Connect: 0, Receive: 0, Length: 1, Exceptions: 0)
Non-2xx responses: 10
Total transferred: 4059 bytes
HTML transferred: 1989 bytes
Requests per second: 1.99 [#/sec] (mean)
Time per request: 501.536 [ms] (mean)
Time per request: 501.536 [ms] (mean, across all concurrent requests)
Transfer rate: 0.79 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 203 251 51.0 243 315
Processing: 216 251 43.5 221 309
Waiting: 216 250 43.5 221 309
Total: 420 501 77.9 520 617
Percentage of the requests served within a certain time (ms)
50% 520
66% 536
75% 550
80% 612
90% 617
95% 617
98% 617
99% 617
100% 617 (longest request)
Llegando directamente al ALB usando HTTPS,
% ab -n10 -c1 \
-H "Host: service.internal.stg" \
http://service.internal.stg/
This is ApacheBench, Version 2.3 <$Revision: 1843412 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking service.internal.stg (be patient).....done
Server Software: Skipper
Server Hostname: service.internal.stg
Server Port: 443
SSL/TLS Protocol: TLSv1.2,ECDHE-RSA-AES128-GCM-SHA256,2048,128
Server Temp Key: ECDH P-256 256 bits
TLS Server Name: service.internal.stg
Document Path: /
Document Length: 199 bytes
Concurrency Level: 1
Time taken for tests: 9.822 seconds
Complete requests: 10
Failed requests: 0
Non-2xx responses: 10
Total transferred: 4060 bytes
HTML transferred: 1990 bytes
Requests per second: 1.02 [#/sec] (mean)
Time per request: 982.242 [ms] (mean)
Time per request: 982.242 [ms] (mean, across all concurrent requests)
Transfer rate: 0.40 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 633 737 100.4 792 883
Processing: 220 245 31.5 231 303
Waiting: 220 245 31.5 231 303
Total: 858 982 105.1 1039 1114
Percentage of the requests served within a certain time (ms)
50% 1039
66% 1041
75% 1061
80% 1108
90% 1114
95% 1114
98% 1114
99% 1114
100% 1114 (longest request)
Obtuve tiempos de conexión muchísimo más altos. Pero, al ejecutar ab con HTTP Keepalive (-k), solo tengo una solicitud lenta (~900 ms), pero mientras tanto estamos bastante bien alcanzando ~320 ms.
% ab -n10 -c1 \
-H "Host: service.internal.stg" \
http://service.internal.stg/
This is ApacheBench, Version 2.3 <$Revision: 1843412 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking service.internal.stg (be patient).....done
Server Software: Skipper
Server Hostname: service.internal.stg
Server Port: 443
SSL/TLS Protocol: TLSv1.2,ECDHE-RSA-AES128-GCM-SHA256,2048,128
Server Temp Key: ECDH P-256 256 bits
TLS Server Name: service.internal.stg
Document Path: /
Document Length: 199 bytes
Concurrency Level: 1
Time taken for tests: 3.242 seconds
Complete requests: 10
Failed requests: 1
(Connect: 0, Receive: 0, Length: 1, Exceptions: 0)
Non-2xx responses: 10
Keep-Alive requests: 10
Total transferred: 4109 bytes
HTML transferred: 1989 bytes
Requests per second: 3.08 [#/sec] (mean)
Time per request: 324.238 [ms] (mean)
Time per request: 324.238 [ms] (mean, across all concurrent requests)
Transfer rate: 1.24 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 0 92 292.2 0 924
Processing: 217 232 22.7 223 279
Waiting: 217 232 22.6 223 279
Total: 217 324 289.5 224 1146
Percentage of the requests served within a certain time (ms)
50% 224
66% 227
75% 269
80% 279
90% 1146
95% 1146
98% 1146
99% 1146
100% 1146 (longest request)
Entonces tengo dudas con el rendimiento de la terminación SSL en el ALB, pero no estoy seguro de cómo manejar/trabajar en esto.
Información adicional: - Hacer ping desde mi ubicación a la instancia EC2
% ping 10.1.1.95 -c 10 ~
PING 10.1.1.95 (10.1.1.95): 56 data bytes
64 bytes from 10.1.1.95: icmp_seq=0 ttl=61 time=203.177 ms
64 bytes from 10.1.1.95: icmp_seq=1 ttl=61 time=202.369 ms
64 bytes from 10.1.1.95: icmp_seq=2 ttl=61 time=317.346 ms
64 bytes from 10.1.1.95: icmp_seq=3 ttl=61 time=232.651 ms
64 bytes from 10.1.1.95: icmp_seq=4 ttl=61 time=252.859 ms
64 bytes from 10.1.1.95: icmp_seq=5 ttl=61 time=271.837 ms
64 bytes from 10.1.1.95: icmp_seq=6 ttl=61 time=204.135 ms
64 bytes from 10.1.1.95: icmp_seq=7 ttl=61 time=208.154 ms
64 bytes from 10.1.1.95: icmp_seq=8 ttl=61 time=201.772 ms
64 bytes from 10.1.1.95: icmp_seq=9 ttl=61 time=208.608 ms
--- 10.1.1.95 ping statistics ---
10 packets transmitted, 10 packets received, 0.0% packet loss
round-trip min/avg/max/stddev = 201.772/230.291/317.346/37.138 ms
- AB ejecutándose desde una instancia EC2 en la misma VPC
ubuntu@ip-10-1-11-72:~$ ab -n10 -c1 \
-H "Host: service.internal.stg" \
http://service.internal.stg/
This is ApacheBench, Version 2.3 <$Revision: 1807734 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking service.internal.stg (be patient).....done
Server Software: Skipper
Server Hostname: service.internal.stg
Server Port: 443
SSL/TLS Protocol: TLSv1.2,ECDHE-RSA-AES128-GCM-SHA256,2048,128
TLS Server Name: service.internal.stg
Document Path: /
Document Length: 199 bytes
Concurrency Level: 1
Time taken for tests: 0.164 seconds
Complete requests: 10
Failed requests: 2
(Connect: 0, Receive: 0, Length: 2, Exceptions: 0)
Non-2xx responses: 10
Total transferred: 4058 bytes
HTML transferred: 1988 bytes
Requests per second: 61.11 [#/sec] (mean)
Time per request: 16.363 [ms] (mean)
Time per request: 16.363 [ms] (mean, across all concurrent requests)
Transfer rate: 24.22 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 4 6 2.6 5 11
Processing: 8 11 2.1 11 15
Waiting: 8 11 2.1 11 15
Total: 12 16 4.0 15 24
Percentage of the requests served within a certain time (ms)
50% 15
66% 16
75% 20
80% 21
90% 24
95% 24
98% 24
99% 24
100% 24 (longest request)
- AB ejecutándose desde una instancia EC2 en la misma VPC y accediendo al servidor web.
ubuntu@ip-10-1-11-72:~$ ab -n10 -c1 -k \
> -H "Host: service.internal.stg" \
> http://10.1.1.95:9999/
This is ApacheBench, Version 2.3 <$Revision: 1807734 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking 10.1.1.95 (be patient).....done
Server Software: Skipper
Server Hostname: 10.1.1.95
Server Port: 9999
Document Path: /
Document Length: 199 bytes
Concurrency Level: 1
Time taken for tests: 0.075 seconds
Complete requests: 10
Failed requests: 0
Non-2xx responses: 10
Keep-Alive requests: 10
Total transferred: 4110 bytes
HTML transferred: 1990 bytes
Requests per second: 133.79 [#/sec] (mean)
Time per request: 7.475 [ms] (mean)
Time per request: 7.475 [ms] (mean, across all concurrent requests)
Transfer rate: 53.70 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 0 0 0.1 0 0
Processing: 6 7 1.4 7 11
Waiting: 6 7 1.4 7 11
Total: 6 7 1.4 7 11
Percentage of the requests served within a certain time (ms)
50% 7
66% 8
75% 8
80% 9
90% 11
95% 11
98% 11
99% 11
100% 11 (longest request)
ubuntu@ip-10-1-11-72:~$
Respuesta1
El establecimiento de la conexión requiere pocas solicitudes del cliente al servidor; según la versión de TLS, está entre 1 y 4, desde la memoria.
Su latencia hacia el servidor es de 200 a 320 ms y es muy variable. La alta latencia es la razón por la cual el establecimiento de la sesión SSL es lento desde su ubicación y también explica por qué es mucho más rápido cuando se ejecuta localmente.
Las soluciones podrían incluir:
- Ubicar el servidor más cerca de usted o de sus usuarios, o ejecutar múltiples servidores con geolocalización
- Utilice CloudFront para realizar la terminación/descarga de TLS en el borde. Probablemente no sea una gran solución para realizar la terminación https en el borde, pero tal vez CloudFront o una CDN puedan hacer esto más eficiente utilizando una red más optimizada.
- Fuerce versiones más nuevas de TLS, que son más eficientes.
