502 Bad Gateway al cargar archivos (NGINX y NodeJS)

Question

Estoy desarrollando una aplicación donde el usuario puede subir archivos. Si bien la llamada de backend parece funcionar bien, la llamada al cargar archivos devuelve un mensaje 502 Bad Gateway.

Los archivos realmente se cargan pero aparece el mensaje de error. Creo que tiene algo que ver con mi configuración de nginx, así que espero que puedan señalar dónde me estoy equivocando.

Aquí está el mensaje de registro de errores de nginx

[error] 3807#3807: *138 connect() failed (111: Connection refused) while connecting to upstream, client: 189.62.45.133, server: api-dev.app.com.br, request: "GET /users/pics/5218de9eec94a7bb4467c95219b37b41ec1920420c808d9e11244f8d2a234cd6 HTTP/1.1", upstream: "https://161.35.116.108:2000/users/pics/5218de9eec94a7bb4467c95219b37b41ec1920420c808d9e11244f8d2a234cd6", host: "api-dev.app.com.br", referrer: "https://dev.app.com.br/profile"

Aquí está mi archivo nginx.conf:

user www-data;
worker_processes auto;
pid /run/nginx.pid;
include /etc/nginx/modules-enabled/*.conf;

events {
    worker_connections 768;
    # multi_accept on;
}

http {

    ##
    # Basic Settings
    ##

    sendfile on;
    tcp_nopush on;
    tcp_nodelay on;
    keepalive_timeout 65;
    types_hash_max_size 2048;
    client_max_body_size 100M;
    # server_tokens off;

    # server_names_hash_bucket_size 64;
    # server_name_in_redirect off;

    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    ##
    # SSL Settings
    ##

    ssl_protocols TLSv1 TLSv1.1 TLSv1.2; # Dropping SSLv3, ref: POODLE
    ssl_prefer_server_ciphers on;

    ##
    # Logging Settings
    ##

    access_log /var/log/nginx/access.log;
    error_log /var/log/nginx/error.log;

    ##
    # Gzip Settings
    ##

    gzip on;

    # gzip_vary on;
    # gzip_proxied any;
    # gzip_comp_level 6;
    # gzip_buffers 16 8k;
    # gzip_http_version 1.1;
    # gzip_types text/plain text/css application/json application/javascript text/xml application/xml application/xml+rss text/javascript;

    ##
    # Virtual Host Configs
    ##

    include /etc/nginx/conf.d/*.conf;
    include /etc/nginx/sites-enabled/*;
}

Mi carpeta conf.d está vacía, sin embargo, tengo una configuración específica en sitios habilitados.

Aquí está mi app.com.br.conf:

proxy_cache_path  /etc/nginx/cache levels=1:2 keys_zone=nuxt-cache:25m max_size=1g inactive=60m use_temp_path=off;

server {
    listen 80;
    listen [::]:80;
    server_name dev.app.com.br api-dev.app.com.br;
    return 301 https://$server_name$request_uri;
}

server {
    server_name dev.app.com.br;
    index index.html;

    root /opt/siena/App-Web-Nuxt/dist;

    listen [::]:443 ssl ipv6only=on;
    listen 443 ssl;
    ssl_certificate /etc/letsencrypt/live/dev.app.com.br-0001/fullchain.pem; # managed by Certbot
    ssl_certificate_key /etc/letsencrypt/live/dev.app.com.br-0001/privkey.pem; # managed by Certbot
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        try_files $uri $uri/index.html $uri.html;
    }

}


server {
    server_name api-dev.app.com.br;

    listen [::]:443 ssl;
    listen 443 ssl;
    ssl_certificate /etc/letsencrypt/live/api-dev.app.com.br/fullchain.pem; # managed by Certbot
    ssl_certificate_key /etc/letsencrypt/live/api-dev.app.com.br/privkey.pem; # managed by Certbot
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        # more_set_headers 'Access-Control-Allow-Origin: *';
        # more_set_headers 'Access-Control-Allow-Methods: GET,POST,OPTIONS,DELETE,PUT';
        # more_set_headers 'Access-Control-Allow-Headers:DNT,X-Mx-ReqToken,Keep-Alive,User-Agent,X-Requested-With,If-Modified-Since,Cache-Control,Content-Type,Authorization';

        # Simple requests (simples to fix CORS)
        if ($request_method ~* "(GET|POST)") {
            more_set_headers "Access-Control-Allow-Origin:  *";
        }

        # Preflighted requests
        if ($request_method = OPTIONS ) {
            more_set_headers "Access-Control-Allow-Origin:  *";
            more_set_headers "Access-Control-Allow-Methods: GET, POST, OPTIONS, HEAD";
            more_set_headers "Access-Control-Allow-Headers: Authorization, Origin, X-Requested-With, Content-Type, Accept";
            return 204;
        }

        proxy_read_timeout 300s;
        proxy_connect_timeout 75s;
        proxy_redirect off;
        proxy_pass https://161.35.116.108:2000/;
    }
}

Si tiene más preguntas sobre el sistema y la configuración, hágamelo saber.

Gracias de antemano.
