Estoy intentando conectar un iniciador a un respondedor usando ipv6
Ambos están activados Ubuntu 20.04y strongswan 5.9.0
el Iniciador está en una máquina virtual (usando VMware) en una computadora personal detrás de una caja conectada a la red de mi ISP. La VM utiliza una red NAT con la computadora host. El respondedor es un VPS en línea.
El iniciador obtuvo un ipv6 (el de su host) y puede hacer ping al ipv6 del respondedor. Es ipv6. <initiator_ipv6>
El ipv6 del respondedor parece configurado correctamente, puedo hacer ping y ssh usándolo. es ipv6 es<responder_ipv6>
IPv6 se ha activado usando la siguiente configuración (según lo proporcionado por mi proveedor de VPS)
/etc/netplan/51-ipv6.yaml
network:
version: 2
ethernets:
<responder_interface>:
dhcp4: true
dhcp6: false
match:
name: <responder_interface>
addresses:
- <responder_ipv6>/128
gateway6: <responder_ipv6_gateway>
routes:
- to: <responder_ipv6_gateway>
scope: link
Ambos strongswan se han construido en el iniciador usando configure con los siguientes comandos:
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run
make
make install
Tienen el mismo strongswan.conf, que es principalmente el predeterminado con una opción de registro de archivos para facilitar la depuración.
charon {
load_modular = yes
plugins {
include strongswan.d/charon/*.conf
}
filelog {
logger {
path = <custom_dir>/swanctl.log
time_format = %b %e %T
ike_name = yes
default = 1
flush_line = yes
}
}
}
include strongswan.d/*.conf
El respondedor tiene el siguiente swanctl.conf
connections {
# Seems to change nothing
local_addrs = <responder_ipv6>
pubkey-vm {
pools = primary-pool-ipv4, primary-pool-ipv6
local {
auth = pubkey
certs = <responder_cert>
id = <responder_id>
}
remote {
auth = pubkey
id = <initiator_id>
}
children {
client {
}
}
}
}
pools {
primary-pool-ipv4 {
# Totally arbitrary value
addrs = 10.0.0.0/24
}
primary-pool-ipv6 {
# Totally arbitrary value
addrs = 2620:0:2d0:200::7/97
}
}
El iniciador tiene la siguiente configuración
connections {
initiator-to-host {
remote_addrs = <responder_ip>
# Any value works, at long as vips got a value (but assigned ip will be in the respodner pool)
vips = 1.2.3.4
local {
auth = pubkey
certs = <initator_cert>
id = <initiator_id>
}
remote {
auth = pubkey
id = <responder_id>
}
children {
to-host {
start_action = none
}
}
}
}
Cuando intento conectarme usando el respondedor ipv4, funciona y el inicio se completó exitosamente. Cuando cambio la IP a IPv6, no funciona y aparecen los siguientes registros en el respondedor.
<pubkey-vm|4> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (80 bytes)
<pubkey-vm|4> parsed INFORMATIONAL request 2 [ D ]
<pubkey-vm|4> received DELETE for IKE_SA pubkey-vm[4]
<pubkey-vm|4> deleting IKE_SA pubkey-vm[4] between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|4> IKE_SA deleted
<pubkey-vm|4> generating INFORMATIONAL response 2 [ ]
<pubkey-vm|4> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (80 bytes)
<pubkey-vm|4> lease 10.0.0.1 by '<initiator_id>' went offline
<5> received packet: from <initiator_ipv6>[1016] to <responder_ipv6>[500] (392 bytes)
<5> parsed IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<5> <initiator_ipv6> is initiating an IKE_SA
<5> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<5> remote host is behind NAT
<5> sending cert request for "C=FR, O=Test, CN=Test CA"
<5> generating IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<5> sending packet: from <responder_ipv6>[500] to <initiator_ipv6>[1016] (273 bytes)
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (356 bytes)
<5> parsed IKE_AUTH request 1 [ EF(2/2) ]
<5> received fragment #2 of 2, waiting for complete IKE message
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (1220 bytes)
<5> parsed IKE_AUTH request 1 [ EF(1/2) ]
<5> received fragment #1 of 2, reassembled fragmented IKE message (1504 bytes)
<5> parsed IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<5> received cert request for "C=FR, O=Test, CN=Test CA"
<5> received end entity cert "C=FR, O=Test, CN=<initiator_id>"
<5> looking for peer configs matching <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> selected peer config 'pubkey-vm'
<pubkey-vm|5> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<pubkey-vm|5> checking certificate status of "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> certificate status is not available
<pubkey-vm|5> reached self-signed root ca with a path length of 0
<pubkey-vm|5> using trusted certificate "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> authentication of '<initiator_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> peer supports MOBIKE
<pubkey-vm|5> authentication of '<responder_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> IKE_SA pubkey-vm[5] established between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> scheduling rekeying in 14286s
<pubkey-vm|5> maximum IKE_SA lifetime 15726s
<pubkey-vm|5> sending end entity cert "C=FR, O=Test, CN=<responder_id>"
<pubkey-vm|5> peer requested virtual IP 1.2.3.4
<pubkey-vm|5> reassigning offline lease to '<initiator_id>'
<pubkey-vm|5> assigning virtual IP 10.0.0.1 to peer '<initiator_id>'
<pubkey-vm|5> selected proposal: ESP:AES_GCM_16_128
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI cffdef3f (FAILED)
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI c028512b (FAILED)
<pubkey-vm|5> unable to install inbound and outbound IPsec SA (SAD) in kernel
<pubkey-vm|5> failed to establish CHILD_SA, keeping IKE_SA
<pubkey-vm|5> generating IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<pubkey-vm|5> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (1216 bytes)
Los registros del lado del cliente están aquí
Starting IKE charon daemon (strongSwan 5.9.0, Linux 5.4.0-56-generic, x86_64)
loading ca certificates from '<custom_path>/etc/ipsec.d/cacerts'
loading aa certificates from '<custom_path>/etc/ipsec.d/aacerts'
loading ocsp signer certificates from '<custom_path>/etc/ipsec.d/ocspcerts'
loading attribute certificates from '<custom_path>/etc/ipsec.d/acerts'
loading crls from '<custom_path>/etc/ipsec.d/crls'
loading secrets from '<custom_path>/etc/ipsec.secrets'
loaded plugins: charon aes eap-aka eap-dynamic eap-identity eap-sim eap-tls des rc2 sha2 sha1 md5 mgf1 random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem fips-prf gmp curve25519 xcbc cmac hmac drbg attr kernel-netlink resolve socket-default stroke vici updown xauth-generic counters
spawning 16 worker threads
loaded certificate 'C=FR, O=Test, CN=<responder_id>'
loaded certificate 'C=FR, O=Test, CN=<initiator_id>'
loaded certificate 'C=FR, O=Test, CN=Test CA'
loaded RSA private key
loaded RSA private key
added vici connection: host-host
vici initiate CHILD_SA 'to-host'
<host-host|1> initiating IKE_SA host-host[1] to <responder_ipv6>
<host-host|1> generating IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<host-host|1> sending packet: from <initiator_ipv6>[500] to <responder_ipv6>[500] (392 bytes)
<host-host|1> received packet: from <responder_ipv6>[500] to <initiator_ipv6>[500] (273 bytes)
<host-host|1> parsed IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<host-host|1> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<host-host|1> local host is behind NAT, sending keep alives
<host-host|1> received cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> sending cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> authentication of '<initiator_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> sending end entity cert "C=FR, O=Test, CN=<initiator_id>"
<host-host|1> establishing CHILD_SA to-host{1}
<host-host|1> generating IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<host-host|1> splitting IKE message (1504 bytes) into 2 fragments
<host-host|1> generating IKE_AUTH request 1 [ EF(1/2) ]
<host-host|1> generating IKE_AUTH request 1 [ EF(2/2) ]
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (1220 bytes)
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (356 bytes)
<host-host|1> received packet: from <responder_ipv6>[4500] to <initiator_ipv6>[4500] (1216 bytes)
<host-host|1> parsed IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<host-host|1> received end entity cert "C=FR, O=Test, CN=<responder_id>"
<host-host|1> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<host-host|1> checking certificate status of "C=FR, O=Test, CN=<responder_id>"
<host-host|1> certificate status is not available
<host-host|1> reached self-signed root ca with a path length of 0
<host-host|1> using trusted certificate "C=FR, O=Test, CN=<responder_id>"
<host-host|1> authentication of '<responder_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> IKE_SA host-host[1] established between <initiator_ipv6>[<initiator_id>]...<responder_ipv6>[<responder_id>]
<host-host|1> scheduling rekeying in 13877s
<host-host|1> maximum IKE_SA lifetime 15317s
<host-host|1> installing new virtual IP 10.0.0.1
<host-host|1> received NO_PROPOSAL_CHOSEN notify, no CHILD_SA built
<host-host|1> failed to establish CHILD_SA, keeping IKE_SA
<host-host|1> peer supports MOBIKE
¿Alguna idea de cómo solucionar eso?
Probé una solución usando --enable-kernel-libipsecla opción de configuración. Así que ahora tengo
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run --enable-kernel-libipsec
Los registros del lado del iniciador siguieron siendo los mismos, pero obtuve nuevos registros del lado del respondedor a continuación.
[CFG] <pubkey-vm|1> selected proposal: ESP:AES_GCM_16_128
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[IKE] <pubkey-vm|1> unable to install inbound and outbound IPsec SA (SAD) in kernel
[IKE] <pubkey-vm|1> failed to establish CHILD_SA, keeping IKE_SA
Respuesta1
Si hay una NAT entre sus hosts, como lo detectan aquí los pares:
<5> remote host is behind NAT
y
<host-host|1> local host is behind NAT, sending keep alives
La encapsulación UDP para ESP se habilitará para las SA de IPsec (NAT-Traversal). Sin embargo, eso requiere soporte por parte de la pila IPsec, que Linux solo proporciona desde 5.8 para IPv6. Entonces, con kernels más antiguos, esto no funcionará.
Debe usar un kernel más nuevo, eliminar la NAT, volver a usar IPv4 o usar una pila IPsec alternativa (como la propia de strongSwan).libipsec).
