Hemos realizado la implementación de Kubernetes utilizando el proveedor Terraform Kubernetes, mientras creamos el propio clúster eks.
Cuando intentamos destruirlo después de eso, todavía no usamos el producto, solo probamos la destrucción. Obtuve el siguiente error con la destrucción de terraform.
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m30s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m30s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m40s elapsed]
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m40s elapsed]
kubernetes_persistent_volume_claim.prometheus-pvc: Still destroying... [id=default/prometheus-pvc, 19m50s elapsed]
kubernetes_persistent_volume_claim.register-pvc[0]: Still destroying... [id=default/register-pvc, 19m50s elapsed]
╷
│ Error: Persistent volume claim prometheus-pvc still exists with finalizers: [kubernetes.io/pvc-protection]
│
│
╵
╷
│ Error: Persistent volume claim register-pvc still exists with finalizers: [kubernetes.io/pvc-protection]
│
│
╵
time=2022-06-17T19:38:38Z level=error msg=1 error occurred:
* exit status 1
Error destroying Terraform
volúmenes persistentes:
kubectl get pv
NAME CAPACITY ACCESS MODES RECLAIM POLICY STATUS CLAIM STORAGECLASS REASON AGE
pvc-51256bfd-4e32-4a4f-a24b-c0f47f9e1d63 100Gi RWO Delete Bound default/db-persistent-storage-db-0 ssd 171m
pvc-9453236c-ffc3-4161-a205-e057c3e1ba77 20Gi RWO Delete Bound default/prometheus-pvc hdd 171m
pvc-ddfef2b9-9723-4651-916b-2cb75baf0f22 20Gi RWO Delete Bound default/register-pvc ssd 171m
Reclamaciones de volumen de persistencia:
kubectl get pvc
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
db-persistent-storage-db-0 Bound pvc-51256bfd-4e32-4a4f-a24b-c0f47f9e1d63 100Gi RWO ssd 173m
prometheus-pvc Terminating pvc-9453236c-ffc3-4161-a205-e057c3e1ba77 20Gi RWO hdd 173m
register-pvc Terminating pvc-ddfef2b9-9723-4651-916b-2cb75baf0f22 20Gi RWO ssd 173m
Y los eventos:
45m Normal VolumeDelete persistentvolume/pvc-0e5c621a-529c-4458-b224-39ea22a783fc error deleting EBS volume "vol-0e36ca327609ae963" since volume is currently attached to "i-0bff735f4c0871705"
46m Warning NodeNotReady pod/quicksilver-pg2wb Node is not ready
46m Normal Killing pod/reducer-0 Stopping container reducer
46m Normal Killing pod/reducer-0 Stopping container checkup-buddy
45m Warning Unhealthy pod/reducer-0 Readiness probe failed: Get "http://10.0.130.242:9001/": dial tcp 10.0.130.242:9001: connect: connection refused
46m Warning NodeNotReady pod/register-0 Node is not ready
44m Normal TaintManagerEviction pod/register-0 Cancelling deletion of Pod default/register-0
Y esa instancia parece ser parte del grupo de kubernetes de escalado automático.
[ec2-user@ip-172-31-16-242 software]$ kubectl get po
NAME READY STATUS RESTARTS AGE
auto-updater-27601140-4gqtw 0/1 Error 0 50m
auto-updater-27601140-hzrnl 0/1 Error 0 49m
auto-updater-27601140-kmspn 0/1 Error 0 50m
auto-updater-27601140-m4ws6 0/1 Error 0 49m
auto-updater-27601140-wsdpm 0/1 Error 0 45m
auto-updater-27601140-z2m7r 0/1 Error 0 48m
estimator-0 3/3 Terminating 0 51m
reducer-0 1/2 Terminating 0 51m
[ec2-user@ip-172-31-16-242 software]$ kubectl get pvc
NAME STATUS VOLUME CAPACITY ACCESS MODES STORAGECLASS AGE
db-persistent-storage-db-0 Bound pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2 100Gi RWO ssd 52m
estimator Terminating pvc-e028acd5-eeb1-4028-89c2-a42c1d28091e 200Gi RWO hdd 52m
[ec2-user@ip-172-31-16-242 software]$ kubectl get logs estimator-0
error: the server doesn't have a resource type "logs"
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0
error: a container name must be specified for pod estimator-0, choose one of: [postgres estimator resize-buddy]
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c estimator
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c postgres
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs estimator-0 -c resize-buddy
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$
Y detalles de vaina reductora.
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0
Default container name "data-cruncher" not found in pod reducer-0
error: a container name must be specified for pod reducer-0, choose one of: [reducer checkup-buddy] or one of the init containers: [set-resource-owner]
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0 -c reducer
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
[ec2-user@ip-172-31-16-242 software]$ kubectl logs reducer-0 -c checkup-buddy
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
Incluso yo revisé los módulos de actualización automática. También aparece un error de autorización similar.
kubectl logs auto-updater-27601140-4gqtw
Error from server (InternalError): Internal error occurred: Authorization error (user=kube-apiserver-kubelet-client, verb=get, resource=nodes, subresource=proxy)
E intenté verificar el contenido de PVC usando kubectl edit y obtuve la siguiente información.
volumen.beta.kubernetes.io/storage-provisioner: kubernetes.io/aws-ebs
[ec2-user@ip-172-31-16-242 ~]$ kubectl describe pv pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2
Name: pvc-ca829a02-9bf5-4540-9900-b6e5ab4624a2
Labels: topology.kubernetes.io/region=us-west-2
topology.kubernetes.io/zone=us-west-2b
Annotations: kubernetes.io/createdby: aws-ebs-dynamic-provisioner
pv.kubernetes.io/bound-by-controller: yes
pv.kubernetes.io/provisioned-by: kubernetes.io/aws-ebs
Finalizers: [kubernetes.io/pv-protection]
StorageClass: ssd
Status: Terminating (lasts 89m)
Claim: default/db-persistent-storage-db-0
Reclaim Policy: Delete
Access Modes: RWO
VolumeMode: Filesystem
Capacity: 100Gi
Node Affinity:
Required Terms:
Term 0: topology.kubernetes.io/zone in [us-west-2b]
topology.kubernetes.io/region in [us-west-2]
Message:
Source:
Type: AWSElasticBlockStore (a Persistent Disk resource in AWS)
VolumeID: aws://us-west-2b/vol-02bc902640cdb406c
FSType: ext4
Partition: 0
ReadOnly: false
Events: <none>
Sin archivos adjuntos de volumen
[ec2-user@ip-172-31-16-242 ~]$ kubectl get volumeattachment
No resources found
nodos:
kubectl get node
NAME STATUS ROLES AGE VERSION
ip-10-0-134-174.us-west-2.compute.internal NotReady <none> 3h8m v1.21.12-eks-5308cf7
ip-10-0-142-12.us-west-2.compute.internal NotReady <none> 3h5m v1.21.12-eks-5308cf7
Y no hay nodos en la sección de cálculo.
Sugiera cómo solucionar este problema.
