Wireguard está perdiendo la conexión sin motivo alguno. Sin problemas de conexión

tag-icon • tag-icon wireguard
Wireguard está perdiendo la conexión sin motivo alguno. Sin problemas de conexión

Tengo un "servidor" WG en ubuntu 18.04.6 LTS, alojado en el nivel gratuito de Oracle.

He instalado Wireguard usando conocidoshttps://github.com/angristan/wireguard-installguion. Luego generé varias configuraciones para mis computadoras de escritorio, teléfonos, etc. Se conecta y funciona perfectamente, pero a veces simplemente se congela sin motivo alguno. No hay problemas de conectividad ni nada por el estilo. Los registros en el lado del cliente dicen algo así en el escritorio de Win:

2022-06-21 03:01:01.845: [TUN] [win] Keypair 17 created for peer 1
2022-06-21 03:01:01.846: [TUN] [win] Sending keepalive packet to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:03:01.822: [TUN] [win] Sending handshake initiation to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:03:01.884: [TUN] [win] Receiving handshake response from peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:03:01.884: [TUN] [win] Keypair 16 destroyed for peer 1
2022-06-21 03:03:01.884: [TUN] [win] Keypair 18 created for peer 1
2022-06-21 03:03:01.884: [TUN] [win] Sending keepalive packet to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:05:02.058: [TUN] [win] Sending handshake initiation to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:05:02.106: [TUN] [win] Receiving handshake response from peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:05:02.106: [TUN] [win] Keypair 17 destroyed for peer 1
2022-06-21 03:05:02.106: [TUN] [win] Keypair 19 created for peer 1
2022-06-21 03:05:02.106: [TUN] [win] Sending keepalive packet to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:06:21.302: [TUN] [win] Retrying handshake with peer 1 (SERVER_IP:SERVER_PORT) because we stopped hearing back after 15 seconds
2022-06-21 03:06:21.302: [TUN] [win] Sending handshake initiation to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:06:26.423: [TUN] [win] Handshake for peer 1 (SERVER_IP:SERVER_PORT) did not complete after 5 seconds, retrying (try 2)
2022-06-21 03:06:26.423: [TUN] [win] Sending handshake initiation to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:06:31.471: [TUN] [win] Handshake for peer 1 (SERVER_IP:SERVER_PORT) did not complete after 5 seconds, retrying (try 3)
2022-06-21 03:06:31.473: [TUN] [win] Sending handshake initiation to peer 1 (SERVER_IP:SERVER_PORT)
2022-06-21 03:06:36.517: [TUN] [win] Handshake for peer 1 (SERVER_IP:SERVER_PORT) did not complete after 5 seconds, retrying (try 4)

o en iphone:

2022-06-21 21:23:40.061830: [NET] peer(5RLe…eMBc) - Sending keepalive packet
2022-06-21 21:23:55.063406: [NET] peer(5RLe…eMBc) - Sending keepalive packet
2022-06-21 21:24:10.064855: [NET] peer(5RLe…eMBc) - Sending keepalive packet
2022-06-21 21:24:15.581989: [NET] Network change detected with satisfied route and interface order [en0, utun3, pdp_ip0]
2022-06-21 21:24:15.585825: [NET] DNS64: mapped SERVER_IP to itself.
2022-06-21 21:24:15.586117: [NET] peer(5RLe…eMBc) - UAPI: Updating endpoint
2022-06-21 21:24:15.587259: [NET] Routine: receive incoming v4 - stopped
2022-06-21 21:24:15.587273: [NET] Routine: receive incoming v6 - stopped
2022-06-21 21:24:15.587645: [NET] UDP bind has been updated
2022-06-21 21:24:15.587713: [NET] peer(5RLe…eMBc) - Sending keepalive packet
2022-06-21 21:24:15.588106: [NET] Routine: receive incoming v6 - started
2022-06-21 21:24:15.588220: [NET] Routine: receive incoming v4 - started
2022-06-21 21:24:25.367681: [NET] peer(5RLe…eMBc) - Sending handshake initiation
2022-06-21 21:24:29.810482: [NET] peer(5RLe…eMBc) - Retrying handshake because we stopped hearing back after 15 seconds
2022-06-21 21:24:30.442990: [NET] peer(5RLe…eMBc) - Handshake did not complete after 5 seconds, retrying (try 2)
2022-06-21 21:24:30.443269: [NET] peer(5RLe…eMBc) - Sending handshake initiation
2022-06-21 21:24:35.470291: [NET] peer(5RLe…eMBc) - Handshake did not complete after 5 seconds, retrying (try 2)
2022-06-21 21:24:35.470610: [NET] peer(5RLe…eMBc) - Sending handshake initiation
2022-06-21 21:24:40.744565: [NET] peer(5RLe…eMBc) - Handshake did not complete after 5 seconds, retrying (try 2)
2022-06-21 21:24:40.744847: [NET] peer(5RLe…eMBc) - Sending handshake initiation
2022-06-21 21:24:45.466608: [NET] peer(5RLe…eMBc) - Retrying handshake because we stopped hearing back after 15 seconds

Si vuelvo a conectar el cliente WG, se conecta inmediatamente y todo está bien.

¿Algún consejo? Intenté experimentar con el parámetro PersistentKeepAlive (¡en ambos lados!) que no cambia nada.

Mi servidor cfg:

[Interface]
Address = 10.66.66.1/24,fd42:42:42::1/64
ListenPort = SERVER_PORT
PrivateKey = M?????Uyg4r3mo=

PostUp = iptables -I FORWARD -i ens3 -o wg0 -j ACCEPT; iptables -I FORWARD -i wg0 -j ACCEPT; iptables -t nat -A POSTROUTING -o ens3 -j MASQUERADE; ip6tables -A FORWARD -i wg0 -j ACCEPT; ip6tables -t nat -A POSTROUTING -o ens3 -j MASQUERADE; sudo iptables -I INPUT -i ens3 -p udp --dport SERVER_PORT -m state --state NEW,ESTABLISHED -j ACCEPT
PostDown = iptables -D FORWARD -i ens3 -o wg0 -j ACCEPT; iptables -D FORWARD -i wg0 -j ACCEPT; iptables -t nat -D POSTROUTING -o ens3 -j MASQUERADE; ip6tables -D FORWARD -i wg0 -j ACCEPT; ip6tables -t nat -D POSTROUTING -o ens3 -j MASQUERADE; sudo iptables -D INPUT -i ens3 -p udp --dport SERVER_PORT -m state --state NEW,ESTABLISHED -j ACCEPT

### Client iphone
[Peer]
PublicKey = 0+V???????4HnM=
PresharedKey = s???????amJCxJyqcE=
AllowedIPs = 10.66.66.2/32,fd42:42:42::2/128

### Client mac
[Peer]
PublicKey = Tet4??????mI=
PresharedKey = Ld???r8=
AllowedIPs = 10.66.66.3/32,fd42:42:42::3/128

Mi cliente cfg

[Interface]
PrivateKey = 4Bp????=
Address = 10.66.66.2/32,fd42:42:42::2/128
DNS = 8.8.8.8,1.1.1.1

[Peer]
PublicKey = 5R?????c=
PresharedKey = sY????E=
Endpoint = SERVER_IP:SERVER_PORT
AllowedIPs = 0.0.0.0/0,::/0

algunas estadísticas

root@oraclevpn:~# wg show all
interface: wg0
  public key: 5R?????c=
  private key: (hidden)
  listening port: SERVER_PORT

peer: 0+?????nM=
  preshared key: (hidden)
  endpoint: 666.666.666.666:11111
  allowed ips: 10.66.66.2/32, fd42:42:42::2/128
  latest handshake: 2 minutes, 2 seconds ago
  transfer: 533.52 MiB received, 5.18 GiB sent

Respuesta1

Si todos sus clientes tienen el mismo problema, verificaría algunas cosas en el servidor.

  1. Sospechoso habitual, actualización y actualización completa del sistema.

  2. Problemas de sincronización horaria y/o configuración de zona horaria correcta

    hora fechactl

Debe tener exactamente el mismo tiempo (min/seg) que sus clientes.

  1. Instalar herramientas de máquina virtualsudo apt install open-vm-tools

  2. ¿Ocurre el mismo problema a las 3 a. m. o a las 3 p. m.? Quizás el servidor gratuito de Oracle esté sobreaprovisionado y esté causando este problema.

  3. Ejecute htop y vea si algún servicio está consumiendo demasiados recursos en su servidor. ¿Se puede actualizar la distribución (hacer-liberar-actualizar) a Ubuntu 20.04?

¿Háganos saber si esto ayudó?
