Estoy atascado al intentar llamar de un pod a otro a través del servicio cuando están en el mismo nodo.
para explicar
- Nodo1 - servicio1a (pod1A), servicio1b (pod1B)
- Nodo2 - servicio2a (pod2A)
cuando:
- PING pod1A -> pod1B OK
- PING pod1A -> pod2A OK
- CURL pod1A -> servicio2A Aceptar
- CURL pod1A -> servicio1B TIEMPO DE ESPERA
Pase varios días cambiando alguna parte de las configuraciones y también busque el mismo problema en Internet, pero no tuvo suerte.
El mismo problema estaba aquí:https://stackoverflow.com/questions/64073696/pods-running-on-the-same-node-cant-access-to-each-other-through-service, pero se solucionó pasando de IPVS a IPTABLES. Tengo IPTables.
PODS: (se cambiaron los nombres)
NAMESPACE NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
dev pod/pod1B-5d595bf69-8fgsm 1/1 Running 0 16h 10.244.2.63 kube-node2 <none> <none>
dev pod/pod1A-database-596f76d8b5-6bdqv 1/1 Running 0 16h 10.244.2.65 kube-node2 <none> <none>
dev pod/pod2A-dbb8fd4d-xv54n 1/1 Running 1 15h 10.244.3.104 kube-node3 <none> <none>
kube-system pod/coredns-6d4b75cb6d-6b2cn 1/1 Running 4 (50d ago) 292d 10.244.0.10 kube-master <none> <none>
kube-system pod/coredns-6d4b75cb6d-6m7q2 1/1 Running 4 (50d ago) 292d 10.244.0.11 kube-master <none> <none>
kube-system pod/etcd-kube-master 1/1 Running 2 (50d ago) 50d 172.31.42.90 kube-master <none> <none>
kube-system pod/kube-apiserver-kube-master 1/1 Running 2 (50d ago) 50d 172.31.42.90 kube-master <none> <none>
kube-system pod/kube-controller-manager-kube-master 1/1 Running 1 (50d ago) 50d 172.31.42.90 kube-master <none> <none>
kube-system pod/kube-flannel-ds-bwkjg 1/1 Running 0 62s 172.31.45.210 kube-node3 <none> <none>
kube-system pod/kube-flannel-ds-g9v9m 1/1 Running 0 66s 172.31.42.90 kube-master <none> <none>
kube-system pod/kube-flannel-ds-hljj5 1/1 Running 0 30s 172.31.42.77 kube-node2 <none> <none>
kube-system pod/kube-flannel-ds-k4zfw 1/1 Running 0 65s 172.31.43.77 kube-node1 <none> <none>
kube-system pod/kube-proxy-68k5n 1/1 Running 0 35m 172.31.45.210 kube-node3 <none> <none>
kube-system pod/kube-proxy-lb6s9 1/1 Running 0 35m 172.31.42.90 kube-master <none> <none>
kube-system pod/kube-proxy-vggwk 1/1 Running 0 35m 172.31.43.77 kube-node1 <none> <none>
kube-system pod/kube-proxy-wxwd7 1/1 Running 0 34m 172.31.42.77 kube-node2 <none> <none>
kube-system pod/kube-scheduler-kube-master 1/1 Running 1 (50d ago) 50d 172.31.42.90 kube-master <none> <none>
kube-system pod/metrics-server-55d58b59c9-569p5 1/1 Running 0 15h 10.244.2.69 kube-node2 <none> <none>
kubernetes-dashboard pod/dashboard-metrics-scraper-8c47d4b5d-2vxfj 1/1 Running 0 16h 10.244.2.64 kube-node2 <none> <none>
SERVICIOS:(nombres cambiados)
NAMESPACE NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE SELECTOR
default service/kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 292d <none>
dev service/pod1B(service1b) ClusterIP 10.102.52.69 <none> 5432/TCP 42h app=database
dev service/pof2A(service2a) ClusterIP 10.105.208.135 <none> 8080/TCP 42h app=keycloak
dev service/pod1A(service1a) ClusterIP 10.111.140.245 <none> 5432/TCP 42h app=keycloak-database
kube-system service/kube-dns ClusterIP 10.96.0.10 <none> 53/UDP,53/TCP,9153/TCP 292d k8s-app=kube-dns
kube-system service/metrics-server ClusterIP 10.111.227.187 <none> 443/TCP 285d k8s-app=metrics-server
kubernetes-dashboard service/dashboard-metrics-scraper ClusterIP 10.110.143.2 <none> 8000/TCP 247d k8s-app=dashboard-metrics-scraper
use kube-proxy IPTABLES y los servicios están configurados en CLUSTER IP (uso alrededor de 2-3 NodePort pero creo que esto no es un problema).
Configuración del demonio de Kube-proxy
apiVersion: v1
data:
config.conf: |-
apiVersion: kubeproxy.config.k8s.io/v1alpha1
bindAddress: 0.0.0.0
bindAddressHardFail: false
clientConnection:
acceptContentTypes: ""
burst: 0
contentType: ""
kubeconfig: /var/lib/kube-proxy/kubeconfig.conf
qps: 0
clusterCIDR: 10.244.10.0/16
configSyncPeriod: 0s
conntrack:
maxPerCore: null
min: null
tcpCloseWaitTimeout: null
tcpEstablishedTimeout: null
detectLocal:
bridgeInterface: ""
interfaceNamePrefix: ""
detectLocalMode: ""
enableProfiling: false
healthzBindAddress: ""
hostnameOverride: ""
iptables:
masqueradeAll: false
masqueradeBit: null
minSyncPeriod: 0s
syncPeriod: 0s
ipvs:
excludeCIDRs: null
minSyncPeriod: 0s
scheduler: ""
strictARP: false
syncPeriod: 0s
tcpFinTimeout: 0s
tcpTimeout: 0s
udpTimeout: 0s
kind: KubeProxyConfiguration
metricsBindAddress: 127.0.0.1:10249
mode: ""
nodePortAddresses: null
oomScoreAdj: null
portRange: ""
showHiddenMetricsForVersion: ""
udpIdleTimeout: 0s
winkernel:
enableDSR: false
forwardHealthCheckVip: false
networkName: ""
rootHnsEndpointName: ""
sourceVip: ""
kubeconfig.conf: |-
apiVersion: v1
kind: Config
clusters:
- cluster:
certificate-authority: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
server: https://172.31.42.90:6443
name: default
contexts:
- context:
cluster: default
namespace: default
user: default
name: default
current-context: default
users:
- name: default
user:
tokenFile: /var/run/secrets/kubernetes.io/serviceaccount/token
kind: ConfigMap
metadata:
annotations:
kubeadm.kubernetes.io/component-config.hash: sha256:ebcfa3923c1228031a5b824f2edca518edc4bd49fd07cedeffa371084cba342b
creationTimestamp: "2022-07-03T19:28:14Z"
labels:
app: kube-proxy
name: kube-proxy
namespace: kube-system
resourceVersion: "40174591"
uid: cfadfa22-ed43-4a3f-9897-25f605ebb8b9
ajuste de demonio de franela
apiVersion: v1
data:
cni-conf.json: |
{
"name": "cbr0",
"cniVersion": "0.3.1",
"plugins": [
{
"type": "flannel",
"delegate": {
"hairpinMode": true,
"isDefaultGateway": true
}
},
{
"type": "portmap",
"capabilities": {
"portMappings": true
}
}
]
}
net-conf.json: |
{
"Network": "10.244.0.0/16",
"Backend": {
"Type": "vxlan"
}
}
kind: ConfigMap
metadata:
annotations:
kubectl.kubernetes.io/last-applied-configuration: |
{"apiVersion":"v1","data":{"cni-conf.json":"{\n \"name\": \"cbr0\",\n \"cniVersion\": \"0.3.1\",\n \"plugins\": [\n {\n \"type\": \"flannel\",\n \"delegate\": {\n \"hairpinMode\": true,\n \"isDe$ creationTimestamp: "2022-07-03T20:34:32Z"
labels:
app: flannel
tier: node
name: kube-flannel-cfg
namespace: kube-system
resourceVersion: "40178136"
uid: ccb81719-7013-4f0b-8c20-ab9d5c3d5f8e
TABLAS IP sistema-kube
iptables -L -t nat | grep kube-system
KUBE-MARK-MASQ all -- ip-10-244-2-69.us-east-2.compute.internal anywhere /* kube-system/metrics-server:https */
DNAT tcp -- anywhere anywhere /* kube-system/metrics-server:https */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-11.us-east-2.compute.internal anywhere /* kube-system/kube-dns:dns-tcp */
DNAT tcp -- anywhere anywhere /* kube-system/kube-dns:dns-tcp */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-10.us-east-2.compute.internal anywhere /* kube-system/kube-dns:metrics */
DNAT tcp -- anywhere anywhere /* kube-system/kube-dns:metrics */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-10.us-east-2.compute.internal anywhere /* kube-system/kube-dns:dns-tcp */
DNAT tcp -- anywhere anywhere /* kube-system/kube-dns:dns-tcp */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-10.us-east-2.compute.internal anywhere /* kube-system/kube-dns:dns */
DNAT udp -- anywhere anywhere /* kube-system/kube-dns:dns */ udp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-11.us-east-2.compute.internal anywhere /* kube-system/kube-dns:dns */
DNAT udp -- anywhere anywhere /* kube-system/kube-dns:dns */ udp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-0-11.us-east-2.compute.internal anywhere /* kube-system/kube-dns:metrics */
DNAT tcp -- anywhere anywhere /* kube-system/kube-dns:metrics */ tcp DNAT [unsupported revision]
KUBE-SVC-TCOU7JCQXEZGVUNU udp -- anywhere ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:dns cluster IP */ udp dpt:domain
KUBE-SVC-JD5MR3NA4I4DYORP tcp -- anywhere ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:metrics cluster IP */ tcp dpt:9153
KUBE-SVC-Z4ANX4WAEWEBLCTM tcp -- anywhere ip-10-111-227-187.us-east-2.compute.internal /* kube-system/metrics-server:https cluster IP */ tcp dpt:https
KUBE-SVC-ERIFXISQEP7F7OF4 tcp -- anywhere ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:dns-tcp cluster IP */ tcp dpt:domain
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:dns-tcp cluster IP */ tcp dpt:domain
KUBE-SEP-OP4AXEAS4OXHBEQX all -- anywhere anywhere /* kube-system/kube-dns:dns-tcp -> 10.244.0.10:53 */ statistic mode random probability 0.50000000000
KUBE-SEP-A7YQ4MY4TZII3JTK all -- anywhere anywhere /* kube-system/kube-dns:dns-tcp -> 10.244.0.11:53 */
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:metrics cluster IP */ tcp dpt:9153
KUBE-SEP-HJ7EWOW62IX6GL6R all -- anywhere anywhere /* kube-system/kube-dns:metrics -> 10.244.0.10:9153 */ statistic mode random probability 0.50000000000
KUBE-SEP-ZJHOSXJEKQGYJUBC all -- anywhere anywhere /* kube-system/kube-dns:metrics -> 10.244.0.11:9153 */
KUBE-MARK-MASQ udp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-96-0-10.us-east-2.compute.internal /* kube-system/kube-dns:dns cluster IP */ udp dpt:domain
KUBE-SEP-R7EMXN5TTQQVP4UW all -- anywhere anywhere /* kube-system/kube-dns:dns -> 10.244.0.10:53 */ statistic mode random probability 0.50000000000
KUBE-SEP-VR6VIIG2A6524KLY all -- anywhere anywhere /* kube-system/kube-dns:dns -> 10.244.0.11:53 */
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-111-227-187.us-east-2.compute.internal /* kube-system/metrics-server:https cluster IP */ tcp dpt:https
KUBE-SEP-6BOUBB2FEQTN2GDB all -- anywhere anywhere /* kube-system/metrics-server:https -> 10.244.2.69:4443 */
iptables -L -t nat | grep dev
KUBE-MARK-MASQ all -- ip-10-244-3-104.us-east-2.compute.internal anywhere /* dev/pod2A:pod2A */
DNAT tcp -- anywhere anywhere /* dev/pod2A:pod2A */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-2-63.us-east-2.compute.internal anywhere /* dev/pod1B:pod1B */
DNAT tcp -- anywhere anywhere /* dev/pod1B:pod1B */ tcp DNAT [unsupported revision]
KUBE-MARK-MASQ all -- ip-10-244-2-65.us-east-2.compute.internal anywhere /* dev/pod1A:pod1A */
DNAT tcp -- anywhere anywhere /* dev/pod1A:pod1A */ tcp DNAT [unsupported revision]
KUBE-SVC-MI7BJVF4L3EWWCLA tcp -- anywhere ip-10-105-208-135.us-east-2.compute.internal /* dev/pod2A:pod2A cluster IP */ tcp dpt:http-alt
KUBE-SVC-S2FASJERAWCYNV26 tcp -- anywhere ip-10-111-140-245.us-east-2.compute.internal /* dev/pod1A:pod1A cluster IP */ tcp dpt:postgresql
KUBE-SVC-5JHIIG3NJGZTIC4I tcp -- anywhere ip-10-102-52-69.us-east-2.compute.internal /* dev/pod1B:pod1B cluster IP */ tcp dpt:postgresql
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-102-52-69.us-east-2.compute.internal /* dev/pod1B:pod1B cluster IP */ tcp dpt:postgresql
KUBE-SEP-FOQDGOYPAUSJGXYE all -- anywhere anywhere /* dev/pod1B:pod1B -> 10.244.2.63:5432 */
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-105-208-135.us-east-2.compute.internal /* dev/pod2A:pod2A cluster IP */ tcp dpt:http-alt
KUBE-SEP-AWG5CHYLOHV7OCEH all -- anywhere anywhere /* dev/pod2A:pod2A -> 10.244.3.104:8080 */
KUBE-MARK-MASQ tcp -- !ip-10-244-0-0.us-east-2.compute.internal/16 ip-10-111-140-245.us-east-2.compute.internal /* dev/pod1A:pod1A cluster IP */ tcp dpt:postgresql
KUBE-SEP-YDMKERDDJRZDWWVM all -- anywhere anywhere /* dev/pod1A:pod1A -> 10.244.2.65:5432 */
¿Alguien puede ayudarme a descubrir por qué no puedo conectarme desde el pod al servicio en el mismo nodo?
Respuesta1
Resuelto, pero quizás alguien más pueda encontrar aquí una solución. La cuestión eran más problemas a la vez.
- Teníamos diferentes versiones de Server, Client y Kubelets en los trabajadores (1.24.3, 1.24.5, .... evento 1.26.x).
- La configuración en kube-proxy/masqueradeAll no era correcta para las versiones 1.26
Después de actualizar todos los planos y nodos a la misma versión, en nuestro caso usando kubeadm desde 1.24.x->1.25.9->1.26.4 + actualizar ubuntu OSapt upgrade
El clúster comienza a ser estable nuevamente y todos los nodos se conectaron correctamentekubectl get nodes
El cambio final se debió a la actualización 1.25 -> 1.26 y la discusión en GitHub.respuesta mweissdigchg...experimentó los mismos problemas después de actualizar de v1.25 a v1.26.
... resultó que la configuración de kube-proxy iptables masqueradeAll: true hacía que nuestros servicios fueran inaccesibles desde pods en otros nodos. Parece que la configuración predeterminada cambió de masqueradeAll: false a masqueradeAll: true....
