¿Cómo puedo iniciar usando Ansible en un servidor Dell iDRAC9 desde una ISO ubicada en un servidor remoto?

Question

Tengo este manual de estrategias de que lo que estoy tratando de hacer es instalar CentOS usando Ansible y Redfish, no quiero usar ningún módulo, instalaré CentOS en varios servidores Dell iDRAC9 y tengo un problema:

2) Después de montar el ISO, el servidor no ha ingresado automáticamente al menú de inicio ISO, y estoy tratando de lograrlo mediante la tarea Establecer ISO como dispositivo de inicio principal.

¿Alguien puede ayudarme a corregir esto?

Aquí está el código:

- hosts: Linux_OS_machine
  connection: local
  name: ULP image install
  gather_facts: false
  vars:
    ansible_python_interpreter: /usr/bin/env python
    datatype: SetBiosAttributes
    image: "{{ iso_version }}-{{ inventory_hostname }}.iso"

  tasks:
    - name: Check system power state
      uri:
        url: https://{{ idrac }}/redfish/v1/Systems/System.Embedded.1
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        method: GET
        validate_certs: false
        force_basic_auth: yes
        return_content: yes
      register: system_status

    - name: Power on system if off
      when: system_status.json.PowerState == "Off"
      uri:
        url: https://{{ idrac }}/redfish/v1/Systems/System.Embedded.1/Actions/ComputerSystem.Reset/
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        method: POST
        body:
          ResetType: PushPowerButton  # Set ResetType to PushPowerButton for system poweron
        validate_certs: false
        force_basic_auth: yes
        status_code: 204
        body_format: json
      register: poweron_status

    - name: Check if virtual media is mounted
      uri:
        url: https://{{ idrac }}/redfish/v1/Managers/iDRAC.Embedded.1/VirtualMedia/CD
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        method: GET
        validate_certs: false
        force_basic_auth: yes
        return_content: yes
      register: vm_status

    - name: Unmount virtual media if mounted
      uri:
        url: https://{{ idrac }}/redfish/v1/Managers/iDRAC.Embedded.1/VirtualMedia/CD/Actions/VirtualMedia.EjectMedia
        method: POST
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        validate_certs: false
        force_basic_auth: yes
        status_code: 204
        body_format: json
      vars:
        image: "{{ iso_version }}-{{ inventory_hostname }}.iso"
      when:
        - vm_status.json.ConnectedVia == "VirtualMedia"
        - vm_status.json.Status != "NotConnected"
        - vm_status.json.Image != image

    - name: Mount virtual media if not already mounted
      uri:
        url: https://{{ idrac }}/redfish/v1/Managers/iDRAC.Embedded.1/VirtualMedia/CD/Actions/VirtualMedia.InsertMedia
        method: POST
        headers:
          Authorization: Basic {{ (idrac_user + ':' + idrac_pass) | b64encode }}
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        validate_certs: false
        force_basic_auth: yes
        status_code: [200, 204]
        body_format: json
        body:
          Image: ""
      vars:
        image: "{{ iso_version }}-{{ inventory_hostname }}.iso"
      register: mount_media
      when:
        - vm_status.json.ConnectedVia == "NotConnected"

    - name: Set ISO as primary boot device
      uri:
        url: https://{{ idrac }}/redfish/v1/Systems/System.Embedded.1
        method: PATCH
        headers:
          Authorization: Basic {{ (idrac_user + ':' + idrac_pass) | b64encode }}
          Content-Type: application/json
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        validate_certs: false
        force_basic_auth: yes
        status_code: [200, 204]
        body_format: json
        body:
          Boot:
            BootSourceOverrideTarget: Cd
            BootSourceOverrideEnabled: Once
            BootSourceOverrideSupported: ["None", "Cd", "Floppy", "Hdd", "Usb", "Pxe", "BiosSetup", "Utilities", "Diags", "SDCard", "UefiShell"]
            BootSourceOverrideMode: Legacy
            [email protected]: "#ComputerSystem.BootSource"


    - name: Reboot the system
      uri:
        url: https://{{ idrac }}/redfish/v1/Systems/System.Embedded.1/Actions/ComputerSystem.Reset/
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        method: POST
        body:
          ResetType: ForceRestart
        validate_certs: false
        force_basic_auth: yes
        status_code: 204
        body_format: json


    - name: Display message during ULP image installation
      debug:
        msg: "ULP image installation in progress. Please wait."



    - name: Wait for system to boot up
      wait_for:
        port: 22
        host: "{{ inventory_hostname }}"
        delay: 30
        timeout: 14400

    - name: Unmount ISO from server
      uri:
        url: https://{{ idrac }}/redfish/v1/Managers/iDRAC.Embedded.1/VirtualMedia/CD/Actions/VirtualMedia.EjectMedia
        method: POST
        user: "{{ idrac_user }}"
        password: "{{ idrac_pass }}"
        validate_certs: false
        force_basic_auth: yes
        status_code: 204
        body_format: json
      when: inventory_hostname in groups['Linux_OS_machine'] and "linux" in ansible_facts['os_family']

Answer 1

Pude realizar una implementación del sistema operativo en iDRAC9 utilizando la colección dellemc.openmanage. Agregue la colección mediante comandos de Ansible Galaxy y luego, desde un libro de jugadas, importe el rol dellemc.openmanage.idrac_os_deployment. https://github.com/dell/dellemc-openmanage-ansible-modules/blob/collections/playbooks/idrac/idrac_os_deployment.yml

Si aún no lo has descubierto, puedo trabajar para poner mi proyecto en Gitlab para darte una idea de qué hacer. Hágamelo saber
