Después de instalar Istio CNI para malla ambiental, me enfrenté al problema de que Istio CNI bloqueaba el tráfico en los contenedores de inicio de la aplicación. Estoy familiarizado con la solución al problema que se propone en la documentación (https://istio.io/latest/docs/setup/additional-setup/cni/#compatibility-with-application-init-containers) pero estas instrucciones no me ayudaron, el complemento las ignora.
Intenté ejecutar Redis Helm Chart con el contenedor de inicio usando dicho archivo de valores.
helm install redis bitnami/redis --version 18.2.0 --namespace test --values <(cat redis-values.yaml)
<valores.yaml>
image:
registry: quay.io
repository: opstree/redis
tag: latest
master:
livenessProbe:
enabled: true
initialDelaySeconds: 40
periodSeconds: 15
timeoutSeconds: 15
successThreshold: 1
failureThreshold: 5
podSecurityContext:
enabled: true
fsGroup: 1337
podAnnotations:
proxy.istio.io/config: |
proxyMetadata:
ISTIO_META_DNS_CAPTURE: "true"
ISTIO_META_DNS_AUTO_ALLOCATE: "true"
traffic.sidecar.istio.io/includeOutboundIPRanges: "*"
traffic.sidecar.istio.io/includeInboundPorts: "*"
traffic.sidecar.istio.io/excludeOutboundPorts: "443"
traffic.sidecar.istio.io/excludeInboundPorts: "443"
traffic.sidecar.istio.io/excludeOutboundIPRanges: "172.20.0.1/32"
initContainers:
- name: init-celery-workers-restart
image: bitnami/kubectl
command: ['sh', '-c', 'sleep 30; kubectl delete pods -n test -l app.kubernetes.io/component=celery-worker']
securityContext:
runAsUser: 1337
resources:
requests:
cpu: 80m
memory: 60Mi
limits:
cpu: 80m
memory: 60Mi
Cuando se inicia el pod, obtengo dichos registros en la salida del contenedor de inicio. Al mismo tiempo, istio cni, ztunnel e istiod tienen los siguientes registros.
"contenedor de inicio"
E0118 09:57:46.188460 8 memcache.go:265] couldn't get current server API group list: Get "https://172.20.0.1:443/api?timeout=32s": EOF
E0118 09:57:56.195553 8 memcache.go:265] couldn't get current server API group list: Get "https://172.20.0.1:443/api?timeout=32s": EOF
E0118 09:58:06.202729 8 memcache.go:265] couldn't get current server API group list: Get "https://172.20.0.1:443/api?timeout=32s": EOF
Unable to connect to the server: EOF
"istio cni"
info cni istio-cni ambient cmdAdd podName: redis-master-0 podIPs: [{IP:10.0.95.14 Mask:ffffffff}]
info cni Adding pod 'redis-master-0/test' (a9573a59-6adc-48e8-9d41-a9bd08fdc40c) to ipset
info cni Adding route for redis-master-0/test: [table 100 10.0.95.14/32 via 192.168.126.2 dev istioin src 10.0.81.204]
"túnel"
INFO xds{id=2}: ztunnel::xds::client: received response type_url="type.googleapis.com/istio.workload.Address" size=1
INFO xds{id=2}: ztunnel::xds::client: received response type_url="type.googleapis.com/istio.workload.Address" size=1
WARN outbound{id=b395fe07254d28f5ec84ffc0850994eb}: ztunnel::proxy::outbound: failed dur=96.464µs err=unknown source: 10.0.82.219
WARN outbound{id=a1c3ba7180c313fa148f1899baa136e4}: ztunnel::proxy::outbound: failed dur=87.892µs err=unknown source: 10.0.82.219
"istiodo"
info ads Push debounce stable[44] 3 for config ServiceEntry/pslabs/redis-master.pslabs.svc.cluster.local and 1 more configs: 100.244777ms since last change, 103.240829ms since last push, full=true
info ads XDS: Pushing Services:95 ConnectedEndpoints:6 Version:2024-01-18T10:05:13Z/37
info validationController Not ready to switch validation to fail-closed: dummy invalid config not rejected
info validationController validatingwebhookconfiguration istio-validator-istio-system (failurePolicy=Ignore, resourceVersion=14938048) is up-to-date. No change required.
error controllers error handling istio-validator-istio-system, retrying (retry count: 1004): webhook is not ready, retry controller=validation
También intenté usar ServiceEntry y DestinationRule para permitir el tráfico al servicio k8 sin pasar por la malla de istio.
apiVersion: networking.istio.io/v1beta1
kind: ServiceEntry
metadata:
name: k8s-api
namespace: test
spec:
hosts:
- kubernetes.default.svc.cluster.local
addresses:
- 172.20.0.1
endpoints:
- address: 172.20.0.1
exportTo:
- "*"
location: MESH_EXTERNAL
resolution: STATIC
ports:
- number: 443
name: https-k8s
protocol: HTTPS
___
apiVersion: networking.istio.io/v1alpha3
kind: DestinationRule
metadata:
name: k8s-destrule
namespace: test
spec:
host: kubernetes.default.svc.cluster.local
trafficPolicy:
tls:
mode: DISABLE
