Nunca antes había instalado Rancher, pero estoy intentando configurar un entorno Rancher en un clúster HA RKE2 local. Tengo un F5 como equilibrador de carga y está configurado para manejar los puertos 80, 443, 6443 y 9345. Un registro DNS llamado rancher-demo.localdomain.local apunta a la dirección IP del equilibrador de carga. Quiero proporcionar mis propios archivos de certificado y he creado dicho certificado a través de nuestra CA interna.
El grupo en sí se puso en funcionamiento y funciona. Cuando ejecuté la instalación en nodos distintos al primero, usaron el nombre DNS que apunta a la IP del LB, así que sé que parte del LB funciona.
kubectl get nodes
NAME STATUS ROLES AGE VERSION
rancher0001.localdomain.local Ready control-plane,etcd,master 25h v1.26.12+rke2r1
rancher0002.localdomain.local Ready control-plane,etcd,master 25h v1.26.12+rke2r1
rancher0003.localdomain.local Ready control-plane,etcd,master 25h v1.26.12+rke2r1
Antes de instalar Rancher, ejecuté los siguientes comandos:
kubectl create namespace cattle-system
kubectl -n cattle-system create secret tls tls-rancher-ingress --cert=~/tls.crt --key=~/tls.key
kubectl -n cattle-system create secret generic tls-ca --from-file=cacerts.pem=~/cacerts.pem
Finalmente, instalé Rancher:
helm install rancher rancher-stable/rancher --namespace cattle-system --set hostname=rancher-demo.localdomain.local --set bootstrapPassword=passwordgoeshere --set ingress.tls.source=secret --set privateCA=true
No recuerdo el error, pero vi un error de tiempo de espera poco después de ejecutar la instalación. Definitivamente hizo *parte* de la instalación:
kubectl -n cattle-system rollout status deploy/rancher
deployment "rancher" successfully rolled out
kubectl get ns
NAME STATUS AGE
cattle-fleet-clusters-system Active 5h18m
cattle-fleet-system Active 5h24m
cattle-global-data Active 5h25m
cattle-global-nt Active 5h25m
cattle-impersonation-system Active 5h24m
cattle-provisioning-capi-system Active 5h6m
cattle-system Active 5h29m
cluster-fleet-local-local-1a3d67d0a899 Active 5h18m
default Active 25h
fleet-default Active 5h25m
fleet-local Active 5h26m
kube-node-lease Active 25h
kube-public Active 25h
kube-system Active 25h
local Active 5h25m
p-c94zp Active 5h24m
p-m64sb Active 5h24m
kubectl get pods --all-namespaces
NAMESPACE NAME READY STATUS RESTARTS AGE
cattle-fleet-system fleet-controller-56968b86b6-6xdng 1/1 Running 0 5h19m
cattle-fleet-system gitjob-7d68454468-tvcrt 1/1 Running 0 5h19m
cattle-system rancher-64bdc898c7-56fpm 1/1 Running 0 5h27m
cattle-system rancher-64bdc898c7-dl4cz 1/1 Running 0 5h27m
cattle-system rancher-64bdc898c7-z55lh 1/1 Running 1 (5h25m ago) 5h27m
cattle-system rancher-webhook-58d68fb97d-zpg2p 1/1 Running 0 5h17m
kube-system cloud-controller-manager-rancher0001.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system cloud-controller-manager-rancher0002.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system cloud-controller-manager-rancher0003.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system etcd-rancher0001.localdomain.local 1/1 Running 0 25h
kube-system etcd-rancher0002.localdomain.local 1/1 Running 3 (22h ago) 25h
kube-system etcd-rancher0003.localdomain.local 1/1 Running 3 (22h ago) 25h
kube-system kube-apiserver-rancher0001.localdomain.local 1/1 Running 0 25h
kube-system kube-apiserver-rancher0002.localdomain.local 1/1 Running 0 25h
kube-system kube-apiserver-rancher0003.localdomain.local 1/1 Running 0 25h
kube-system kube-controller-manager-rancher0001.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system kube-controller-manager-rancher0002.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system kube-controller-manager-rancher0003.localdomain.local 1/1 Running 0 25h
kube-system kube-proxy-rancher0001.localdomain.local 1/1 Running 0 25h
kube-system kube-proxy-rancher0002.localdomain.local 1/1 Running 0 25h
kube-system kube-proxy-rancher0003.localdomain.local 1/1 Running 0 25h
kube-system kube-scheduler-rancher0001.localdomain.local 1/1 Running 1 (22h ago) 25h
kube-system kube-scheduler-rancher0002.localdomain.local 1/1 Running 0 25h
kube-system kube-scheduler-rancher0003.localdomain.local 1/1 Running 0 25h
kube-system rke2-canal-2jngw 2/2 Running 0 25h
kube-system rke2-canal-6qrc4 2/2 Running 0 25h
kube-system rke2-canal-bk2f8 2/2 Running 0 25h
kube-system rke2-coredns-rke2-coredns-565dfc7d75-87pjr 1/1 Running 0 25h
kube-system rke2-coredns-rke2-coredns-565dfc7d75-wh64f 1/1 Running 0 25h
kube-system rke2-coredns-rke2-coredns-autoscaler-6c48c95bf9-mlcln 1/1 Running 0 25h
kube-system rke2-ingress-nginx-controller-6p8ll 1/1 Running 0 22h
kube-system rke2-ingress-nginx-controller-7pm5c 1/1 Running 0 5h22m
kube-system rke2-ingress-nginx-controller-brfwh 1/1 Running 0 22h
kube-system rke2-metrics-server-c9c78bd66-f5vrb 1/1 Running 0 25h
kube-system rke2-snapshot-controller-6f7bbb497d-vqg9s 1/1 Running 0 22h
kube-system rke2-snapshot-validation-webhook-65b5675d5c-dt22h 1/1 Running 0 22h
Sin embargo, obviamente (dada la página 404 No encontrado cuando voy ahttps://rancher-demo.localdomain.local) las cosas no funcionan bien.
Nunca he configurado esto antes, así que no estoy seguro de cómo solucionarlo. Pasé horas revisando varias publicaciones, pero nada de lo que encontré parece coincidir con este problema en particular.
Algunas cosas que he encontrado:
kubectl -n cattle-system logs -f rancher-64bdc898c7-56fpm
2024/01/17 21:13:23 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:13:38 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:13:53 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
(repeats every 15 seconds)
kubectl get ingress --all-namespaces
No resources found
(I *know* there was an ingress at some point, I believe in cattle-system; now it's gone. I didn't remove it.)
kubectl -n cattle-system describe service rancher
Name: rancher
Namespace: cattle-system
Labels: app=rancher
app.kubernetes.io/managed-by=Helm
chart=rancher-2.7.9
heritage=Helm
release=rancher
Annotations: meta.helm.sh/release-name: rancher
meta.helm.sh/release-namespace: cattle-system
Selector: app=rancher
Type: ClusterIP
IP Family Policy: SingleStack
IP Families: IPv4
IP: 10.43.199.3
IPs: 10.43.199.3
Port: http 80/TCP
TargetPort: 80/TCP
Endpoints: 10.42.0.26:80,10.42.1.22:80,10.42.1.23:80
Port: https-internal 443/TCP
TargetPort: 444/TCP
Endpoints: 10.42.0.26:444,10.42.1.22:444,10.42.1.23:444
Session Affinity: None
Events: <none>
kubectl -n cattle-system logs -l app=rancher
2024/01/17 21:17:38 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:17:53 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:18:08 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:18:23 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:18:38 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:18:53 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:19:08 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:19:23 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:19:38 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:19:53 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.23]: dial tcp 10.42.0.26:443: i/o timeout
2024/01/17 21:19:40 [ERROR] Failed to connect to peer wss://10.42.1.22/v3/connect [local ID=10.42.0.26]: dial tcp 10.42.1.22:443: i/o timeout
E0117 21:19:45.551484 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
E0117 21:19:45.646038 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
2024/01/17 21:19:45 [ERROR] Failed to read API for groups map[metrics.k8s.io/v1beta1:the server is currently unable to handle the request]
2024/01/17 21:19:49 [ERROR] [updateClusterHealth] Failed to update cluster [local]: Internal error occurred: failed calling webhook "rancher.cattle.io.clusters.management.cattle.io": failed to call webhook: Post "https://rancher-webhook.cattle-system.svc:443/v1/webhook/mutation/clusters.management.cattle.io?timeout=10s": context deadline exceeded
E0117 21:19:52.882877 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
E0117 21:19:53.061671 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
2024/01/17 21:19:53 [ERROR] Failed to read API for groups map[metrics.k8s.io/v1beta1:the server is currently unable to handle the request]
2024/01/17 21:19:55 [ERROR] Failed to connect to peer wss://10.42.1.23/v3/connect [local ID=10.42.0.26]: dial tcp 10.42.1.23:443: i/o timeout
2024/01/17 21:19:55 [ERROR] Failed to connect to peer wss://10.42.1.22/v3/connect [local ID=10.42.0.26]: dial tcp 10.42.1.22:443: i/o timeout
E0117 21:19:37.826713 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
E0117 21:19:37.918579 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
2024/01/17 21:19:37 [ERROR] Failed to read API for groups map[metrics.k8s.io/v1beta1:the server is currently unable to handle the request]
E0117 21:19:45.604537 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
E0117 21:19:45.713901 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
2024/01/17 21:19:45 [ERROR] Failed to read API for groups map[metrics.k8s.io/v1beta1:the server is currently unable to handle the request]
2024/01/17 21:19:49 [ERROR] Failed to connect to peer wss://10.42.0.26/v3/connect [local ID=10.42.1.22]: dial tcp 10.42.0.26:443: i/o timeout
E0117 21:19:52.899035 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
E0117 21:19:52.968048 34 gvks.go:69] failed to sync schemas: unable to retrieve the complete list of server APIs: metrics.k8s.io/v1beta1: the server is currently unable to handle the request
2024/01/17 21:19:52 [ERROR] Failed to read API for groups map[metrics.k8s.io/v1beta1:the server is currently unable to handle the request]
Estoy seguro de que hice algo mal, pero no sé qué ni cómo solucionarlo.
