Estoy usando el servidor Ubuntu con un servicio Docker instalado desde la configuración del servidor (snap) y Prometheus ejecutándose en un contenedor acoplable.
Servidor:
Distributor ID: Ubuntu
Description: Ubuntu 22.04.3 LTS
Release: 22.04
Codename: jammy
Estibador
sudo snap services
Service Startup Current Notes
docker.dockerd enabled active -
docker.nvidia-container-toolkit enabled inactive -
lxd.activate enabled inactive -
lxd.daemon enabled inactive socket-activated
lxd.user-daemon enabled inactive socket-activated
quebrar
snap 2.61.1
snapd 2.61.1
series 16
ubuntu 22.04
kernel 5.15.0-91-generic
Prometeo docker-compose.yml
version: '3.8'
volumes:
prometheus_data: {}
services:
prometheus:
image: prom/prometheus:latest
container_name: prometheus
restart: unless-stopped
volumes:
- /home/xxxx/data/config/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
- prometheus_data:/prometheus
command:
- '--config.file=/etc/prometheus/prometheus.yml'
extra_hosts:
- "host.docker.internal:host-gateway"
ports:
- "9090:9090/tcp"
IP de la ventana acoplable:
ip addr show docker0
8: docker0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
link/ether 02:42:18:5c:09:7f brd ff:ff:ff:ff:ff:ff
inet 172.17.0.1/16 brd 172.17.255.255 scope global docker0
valid_lft forever preferred_lft forever
inet6 fe80::42:18ff:fe5c:97f/64 scope link
valid_lft forever preferred_lft forever
Asunto
Entonces, lo que quiero hacer es obtener métricas para mi servidor Prometheus ejecutándose en un contenedor acoplable. Estoy usando esta documentación:https://docs.docker.com/config/daemon/prometheus/
Al principio dice:Agregue la siguiente configuración:
Linux: /etc/docker/daemon.json
{
"metrics-addr": "127.0.0.1:9323"
}
También probé con:
{
"metrics-addr": "172.17.0.1:9323"
}
Después de algunos problemas encontré la siguiente pregunta/respuesta en Askubuntu:https://askubuntu.com/questions/1296892/snap-edit-docker-configuration
Entonces agregué daemon.json a
/var/snap/docker/current/etc/docker
y reinicié el servicio con:
sudo snap restart docker
Después del reinicio todavía no recibo ninguna métrica del host. Pruebo esto usando:
curl http://localhost:9323/metrics
curl: (7) Failed to connect to localhost port 9323 after 0 ms: Connection refused
curl http://172.17.0.1:9323/metrics
curl: (7) Failed to connect to 172.17.0.1 port 9323 after 0 ms: Connection refused
Información del sistema Docker
Client:
Context: default
Debug Mode: false
Plugins:
buildx: Docker Buildx (Docker Inc., v0.10.4)
compose: Docker Compose (Docker Inc., v2.17.2)
Server:
Containers: 20
Running: 20
Paused: 0
Stopped: 0
Images: 20
Server Version: 20.10.24
Storage Driver: overlay2
Backing Filesystem: extfs
Supports d_type: true
Native Overlay Diff: true
userxattr: false
Logging Driver: json-file
Cgroup Driver: systemd
Cgroup Version: 2
Plugins:
Volume: local
Network: bridge host ipvlan macvlan null overlay
Log: awslogs fluentd gcplogs gelf journald json-file local logentries splunk syslog
Swarm: inactive
Runtimes: io.containerd.runc.v2 io.containerd.runtime.v1.linux runc
Default Runtime: runc
Init Binary: docker-init
containerd version: 2806fc1057397dbaeefbea0e4e17bddfbd388f38
runc version:
init version: de40ad0
Security Options:
apparmor
seccomp
Profile: default
cgroupns
Kernel Version: 5.15.0-91-generic
Operating System: Ubuntu Core 22
OSType: linux
Architecture: x86_64
CPUs: 4
Total Memory: 31.26GiB
Name: blackholeport
ID: AMKQ:XQSW:OPFY:ZLWE:VCVI:BKBB:NVO4:5WYJ:W6AZ:JB7M:7T4S:WXNC
Docker Root Dir: /var/snap/docker/common/var-lib-docker
Debug Mode: false
Username: hagbart
Registry: https://index.docker.io/v1/
Labels:
Experimental: false
Insecure Registries:
127.0.0.0/8
Live Restore Enabled: false
Docker inspecciona Prometeo
[
{
"Id": "ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684",
"Created": "2024-01-19T10:23:03.520072505Z",
"Path": "/bin/prometheus",
"Args": [
"--config.file=/etc/prometheus/prometheus.yml"
],
"State": {
"Status": "running",
"Running": true,
"Paused": false,
"Restarting": false,
"OOMKilled": false,
"Dead": false,
"Pid": 83237,
"ExitCode": 0,
"Error": "",
"StartedAt": "2024-01-19T13:00:24.320370241Z",
"FinishedAt": "2024-01-19T13:00:17.400204943Z"
},
"Image": "sha256:2a72b385beafd2b3685ad337d14d23f6851f0ff335c5cd9a04c692b3eb846196",
"ResolvConfPath": "/var/snap/docker/common/var-lib-docker/containers/ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684/resolv.conf",
"HostnamePath": "/var/snap/docker/common/var-lib-docker/containers/ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684/hostname",
"HostsPath": "/var/snap/docker/common/var-lib-docker/containers/ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684/hosts",
"LogPath": "/var/snap/docker/common/var-lib-docker/containers/ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684/ded87ebe4dafa575a06781beacf7e33541a37d23c1594ce0ac80041929ba5684-json.log",
"Name": "/prometheus",
"RestartCount": 0,
"Driver": "overlay2",
"Platform": "linux",
"MountLabel": "",
"ProcessLabel": "",
"AppArmorProfile": "docker-default",
"ExecIDs": null,
"HostConfig": {
"Binds": [
"/home/lukas/data/config/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml:rw"
],
"ContainerIDFile": "",
"LogConfig": {
"Type": "json-file",
"Config": {}
},
"NetworkMode": "prometheus_default",
"PortBindings": {
"9090/tcp": [
{
"HostIp": "",
"HostPort": "9090"
}
]
},
"RestartPolicy": {
"Name": "unless-stopped",
"MaximumRetryCount": 0
},
"AutoRemove": false,
"VolumeDriver": "",
"VolumesFrom": null,
"CapAdd": null,
"CapDrop": null,
"CgroupnsMode": "private",
"Dns": [],
"DnsOptions": [],
"DnsSearch": [],
"ExtraHosts": [
"host.docker.internal:host-gateway"
],
"GroupAdd": null,
"IpcMode": "private",
"Cgroup": "",
"Links": null,
"OomScoreAdj": 0,
"PidMode": "",
"Privileged": false,
"PublishAllPorts": false,
"ReadonlyRootfs": false,
"SecurityOpt": null,
"UTSMode": "",
"UsernsMode": "",
"ShmSize": 67108864,
"Runtime": "runc",
"ConsoleSize": [
0,
0
],
"Isolation": "",
"CpuShares": 0,
"Memory": 0,
"NanoCpus": 0,
"CgroupParent": "",
"BlkioWeight": 0,
"BlkioWeightDevice": null,
"BlkioDeviceReadBps": null,
"BlkioDeviceWriteBps": null,
"BlkioDeviceReadIOps": null,
"BlkioDeviceWriteIOps": null,
"CpuPeriod": 0,
"CpuQuota": 0,
"CpuRealtimePeriod": 0,
"CpuRealtimeRuntime": 0,
"CpusetCpus": "",
"CpusetMems": "",
"Devices": null,
"DeviceCgroupRules": null,
"DeviceRequests": null,
"KernelMemory": 0,
"KernelMemoryTCP": 0,
"MemoryReservation": 0,
"MemorySwap": 0,
"MemorySwappiness": null,
"OomKillDisable": null,
"PidsLimit": null,
"Ulimits": null,
"CpuCount": 0,
"CpuPercent": 0,
"IOMaximumIOps": 0,
"IOMaximumBandwidth": 0,
"Mounts": [
{
"Type": "volume",
"Source": "prometheus_prometheus_data",
"Target": "/prometheus",
"VolumeOptions": {}
}
],
"MaskedPaths": [
"/proc/asound",
"/proc/acpi",
"/proc/kcore",
"/proc/keys",
"/proc/latency_stats",
"/proc/timer_list",
"/proc/timer_stats",
"/proc/sched_debug",
"/proc/scsi",
"/sys/firmware"
],
"ReadonlyPaths": [
"/proc/bus",
"/proc/fs",
"/proc/irq",
"/proc/sys",
"/proc/sysrq-trigger"
]
},
"GraphDriver": {
"Data": {
"LowerDir": "/var/snap/docker/common/var-lib-docker/overlay2/5656a88cbb1d0e0fd4ed939b0cdb30de86b7d2e4af2afd06d2ea33d8dd110199-init/diff:/var/snap/docker/common/var-lib-docker/overlay2/0aa7d62082adf6dcde04943d937cac5dae5d0609b12ae7319421cbf63131fca3/diff:/var/snap/docker/common/var-lib-docker/overlay2/59878a50f72e66a191110dadd15bf94d352cb1e0a543cf6ab0e96f210d9a16e5/diff:/var/snap/docker/common/var-lib-docker/overlay2/d7dd0384e6e888b48e94d3f32bf1e504c2ed1d11526ba5caba7a6cbaa43f1304/diff:/var/snap/docker/common/var-lib-docker/overlay2/8943641d04172c565f42e75963910fdf6df436bc60d3929284c657b16d831dd1/diff:/var/snap/docker/common/var-lib-docker/overlay2/6c943a9276d504534ec9c66ade625447ad516058dce64053b899283aac500395/diff:/var/snap/docker/common/var-lib-docker/overlay2/416d42bd54e76f8a2c78da2799ad6e6c5d2c3d78b822ed8e17ada9bdc0fc17a7/diff:/var/snap/docker/common/var-lib-docker/overlay2/89ab8fa214a8141179afa2c21071e565dc841d1e0f5a69dc372d5b6514456cb0/diff:/var/snap/docker/common/var-lib-docker/overlay2/d99204b78e6ddf1279d8f1b099318f921a61e9017d457955e5a53c5c2d17be8a/diff:/var/snap/docker/common/var-lib-docker/overlay2/259c1d3c5a275a0c51fe499c1a8a2857427cf592eb094dea65447b591ec66058/diff:/var/snap/docker/common/var-lib-docker/overlay2/721958698d3add899bd2597d3dab22267c3aaa40dc556eb7f0cdb8c564b14a74/diff:/var/snap/docker/common/var-lib-docker/overlay2/c122e772ebb24d66d663577b099800060d10e1d1fda0b38e75ea73bc2fdf6273/diff:/var/snap/docker/common/var-lib-docker/overlay2/b1a9df93abc1fbba6b8f3644eaf5ec9a76b8b2193ad1d934241242fb54b74cd0/diff",
"MergedDir": "/var/snap/docker/common/var-lib-docker/overlay2/5656a88cbb1d0e0fd4ed939b0cdb30de86b7d2e4af2afd06d2ea33d8dd110199/merged",
"UpperDir": "/var/snap/docker/common/var-lib-docker/overlay2/5656a88cbb1d0e0fd4ed939b0cdb30de86b7d2e4af2afd06d2ea33d8dd110199/diff",
"WorkDir": "/var/snap/docker/common/var-lib-docker/overlay2/5656a88cbb1d0e0fd4ed939b0cdb30de86b7d2e4af2afd06d2ea33d8dd110199/work"
},
"Name": "overlay2"
},
"Mounts": [
{
"Type": "bind",
"Source": "/home/lukas/data/config/prometheus/prometheus.yml",
"Destination": "/etc/prometheus/prometheus.yml",
"Mode": "rw",
"RW": true,
"Propagation": "rprivate"
},
{
"Type": "volume",
"Name": "prometheus_prometheus_data",
"Source": "/var/snap/docker/common/var-lib-docker/volumes/prometheus_prometheus_data/_data",
"Destination": "/prometheus",
"Driver": "local",
"Mode": "z",
"RW": true,
"Propagation": ""
}
],
"Config": {
"Hostname": "ded87ebe4daf",
"Domainname": "",
"User": "nobody",
"AttachStdin": false,
"AttachStdout": true,
"AttachStderr": true,
"ExposedPorts": {
"9090/tcp": {}
},
"Tty": false,
"OpenStdin": false,
"StdinOnce": false,
"Env": [
"PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
],
"Cmd": [
"--config.file=/etc/prometheus/prometheus.yml"
],
"Image": "prom/prometheus:latest",
"Volumes": {
"/prometheus": {}
},
"WorkingDir": "/prometheus",
"Entrypoint": [
"/bin/prometheus"
],
"OnBuild": null,
"Labels": {
"com.docker.compose.config-hash": "f387601dc597da679d6a2290f4192863d07c16791b9d33e29a4e84eb43b2e5df",
"com.docker.compose.container-number": "1",
"com.docker.compose.depends_on": "",
"com.docker.compose.image": "sha256:2a72b385beafd2b3685ad337d14d23f6851f0ff335c5cd9a04c692b3eb846196",
"com.docker.compose.oneoff": "False",
"com.docker.compose.project": "prometheus",
"com.docker.compose.project.config_files": "/home/lukas/BlackholePort/docker/prometheus/docker-compose.yml",
"com.docker.compose.project.working_dir": "/home/lukas/BlackholePort/docker/prometheus",
"com.docker.compose.service": "prometheus",
"com.docker.compose.version": "2.17.2",
"maintainer": "The Prometheus Authors <[email protected]>"
}
},
"NetworkSettings": {
"Bridge": "",
"SandboxID": "b882dba1196b5ba11a81cedda028552f453ed82e42cec9fc8fc767d4192571f2",
"HairpinMode": false,
"LinkLocalIPv6Address": "",
"LinkLocalIPv6PrefixLen": 0,
"Ports": {
"9090/tcp": [
{
"HostIp": "0.0.0.0",
"HostPort": "9090"
},
{
"HostIp": "::",
"HostPort": "9090"
}
]
},
"SandboxKey": "/run/snap.docker/netns/b882dba1196b",
"SecondaryIPAddresses": null,
"SecondaryIPv6Addresses": null,
"EndpointID": "",
"Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"IPAddress": "",
"IPPrefixLen": 0,
"IPv6Gateway": "",
"MacAddress": "",
"Networks": {
"prometheus_default": {
"IPAMConfig": null,
"Links": null,
"Aliases": [
"prometheus",
"prometheus",
"ded87ebe4daf"
],
"NetworkID": "971e8873d46285b63d70fb6feeada747176a5427aa7a19127cb7e8dc8a7d8a37",
"EndpointID": "b67826c8e2736e5ac55ab67a8f9d67a6822dd3260a214622f65de968b0fa972e",
"Gateway": "192.168.32.1",
"IPAddress": "192.168.32.2",
"IPPrefixLen": 20,
"IPv6Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"MacAddress": "02:42:c0:a8:20:02",
"DriverOpts": null
}
}
}
}
]
red acoplable ls
docker network ls
NETWORK ID NAME DRIVER SCOPE
f124d5db3e0b bridge bridge local
862535ef9371 deluge_default bridge local
86bf6736570f foundryvtt_default bridge local
909b8162cdbe grafana_default bridge local
299ce7db89b5 heimdall_default bridge local
92a81645a176 host host local
a5e580aa1810 microbin_default bridge local
da8d9cb1d3e7 nginx-pm_default bridge local
055308848eba none null local
93afb48bbba2 o-portainer bridge local
460a87dcb670 o-security bridge local
ea16af5d1414 pihole_default bridge local
250440a093d7 portainer_default bridge local
971e8873d462 prometheus_default bridge local
dcbfb120b9b2 prometheus_monitoring bridge local
a482e951879d prowlarr_default bridge local
9ab6f6734815 radarr_default bridge local
f6abd6de38d3 sonarr_default bridge local
0e062c280f80 spigotmc_default bridge local
640505be1145 teamspeak_default bridge local
después de agregar portainer a la red hostmismo problema
docker-compose.yml
version: '3.8'
volumes:
prometheus_data: {}
services:
prometheus:
image: prom/prometheus:latest
container_name: prometheus
restart: unless-stopped
volumes:
- /home/lukas/data/config/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
- prometheus_data:/prometheus
command:
- '--config.file=/etc/prometheus/prometheus.yml'
extra_hosts:
- "host.docker.internal:host-gateway"
network_mode: "host"
ports:
- "9090:9090/tcp
Docker inspecciona Prometheus (parte de la red)
"NetworkSettings": {
"Bridge": "",
"SandboxID": "f114aceaadadca19fe9da85b04dbce4fc9aedae6d7f91a2bed8b3290d3186e82",
"HairpinMode": false,
"LinkLocalIPv6Address": "",
"LinkLocalIPv6PrefixLen": 0,
"Ports": {},
"SandboxKey": "/run/snap.docker/netns/default",
"SecondaryIPAddresses": null,
"SecondaryIPv6Addresses": null,
"EndpointID": "",
"Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"IPAddress": "",
"IPPrefixLen": 0,
"IPv6Gateway": "",
"MacAddress": "",
"Networks": {
"host": {
"IPAMConfig": null,
"Links": null,
"Aliases": null,
"NetworkID": "92a81645a17671cf440926ed83cdb6063790dcf2e18813722d96ccc90614ffb3",
"EndpointID": "4a4f2cef2556314c2feb526928b24784005a4617583e10813bae06f56d5db8e2",
"Gateway": "",
"IPAddress": "",
"IPPrefixLen": 0,
"IPv6Gateway": "",
"GlobalIPv6Address": "",
"GlobalIPv6PrefixLen": 0,
"MacAddress": "",
"DriverOpts": null
}
}
}
Respuesta1
Docker Compose está creando una red llamada "prometheus_default" y está adjuntando el contenedor Prometheus a esa red. Tiene el demonio Docker configurado para anunciar métricas en la docker0interfaz que generalmente se encuentra en la bridgered predeterminada que crea Docker.
En el host donde se ejecuta Docker, puede verificar que el demonio Docker (-p, para mostrar procesos) esté escuchando (-l) en el número de puerto de métricas tcp (-t) 9323 (-n) mediante ssonetstat
$ ss -tlpn | grep :9323
LISTEN 0 4096 127.0.0.1:9323 0.0.0.0:* users:(("dockerd",pid=199176,fd=17))
Opción 1
Intente agregar esta configuración a docker-compose.yaml para agregar Prometheus a la red puente
version: '3.8'
volumes:
prometheus_data: {}
services:
prometheus:
image: prom/prometheus:latest
container_name: prometheus
restart: unless-stopped
volumes:
- /home/lukas/data/config/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
- prometheus_data:/prometheus
command:
- '--config.file=/etc/prometheus/prometheus.yml'
extra_hosts:
- "host.docker.internal:host-gateway"
network_mode: bridge
ports:
- "9090:9090/tcp
mientras se asegura de que Docker esté configurado para anunciar métricas en el puente predeterminado
{
"metrics-addr": "172.17.0.1:9323"
}
opcion 2
Cambie el demonio Docker para escuchar en prometheus_defaultla red
docker network inspect prometheus_default
[
{
"Name": "prometheus_default",
"Id": "55a40edb42b2f3c1144236a765339e9b1c8dd0542df929430dc07829c5e156d5",
"Created": "2023-03-31T16:51:48.212544059-04:00",
"Scope": "local",
"Driver": "bridge",
"EnableIPv6": false,
"IPAM": {
"Driver": "default",
"Options": null,
"Config": [
{
"Subnet": "172.19.0.0/16",
"Gateway": "172.19.0.1"
}
]
},
"Internal": false,
"Attachable": true,
"Ingress": false,
"ConfigFrom": {
"Network": ""
},
"ConfigOnly": false,
"Containers": {},
"Options": {},
"Labels": {
"com.docker.compose.network": "default",
"com.docker.compose.project": "prometheus",
"com.docker.compose.version": "1.29.2"
}
}
]
Ubicado en daemon.json
{
"metrics-addr": "172.19.0.1:9323"
}
Opción 3
Permitir que cualquier red acceda a las métricas de Docker (tenga en cuenta que muchos más servicios tendrán acceso a la interfaz de métricas del demonio de Docker, lo que puede ser deseable o no)
{
"metrics-addr": "0.0.0.0:9323"
}
