Estoy ejecutando FreeBSD 11RC2 con la versión actual del controlador Nvidia 367.44 y usando el módulo del kernel nvidia-modeset que se carga al inicio en mi

/etc/rc.conf

archivo agregando

kld_list="nvidia-modeset"

Aquí está la información sobre mi GPU.

vgapci0@pci0:1:0:0: class=0x030000 card=0x0130106b chip=0x0fe910de rev=0xa1 hdr=0x00
    vendor     = 'NVIDIA Corporation'
    device     = 'GK107M [GeForce GT 750M Mac Edition]'
    class      = display
    subclass   = VGA
    cap 01[60] = powerspec 3  supports D0 D3  current D0
    cap 05[68] = MSI supports 1 message, 64 bit enabled with 1 message
    cap 10[78] = PCI-Express 2 endpoint max data 256(256) RO NS
                 link x8(x16) speed 8.0(8.0) ASPM L0s/L1(L0s/L1)
    cap 09[b4] = vendor (length 20)
    ecap 0002[100] = VC 1 max VC0
    ecap 0004[128] = Power Budgeting 1
    ecap 0001[420] = AER 2 0 fatal 0 non-fatal 0 corrected
    ecap 000b[600] = Vendor 1 ID 1
    ecap 0019[900] = PCIe Sec 1 lane errors 0

Aquí está la información acpi para esta máquina:http://paste2.org/LUcIwtzn

device  acpi
debug.acpi.resume_beep: 0
debug.acpi.batt.batt_sleep_ms: 0
debug.acpi.ec.timeout: 750
debug.acpi.ec.polled: 0
debug.acpi.ec.burst: 0
debug.acpi.cpu_unordered: 0
debug.acpi.suspend_bounce: 0
debug.acpi.reset_clock: 1
debug.acpi.default_register_width: 1
debug.acpi.interpreter_slack: 1
debug.acpi.enable_debug_objects: 0
debug.acpi.acpi_ca_version: 20160527
debug.acpi.max_threads: 3
debug.acpi.tasks_hiwater: 40
debug.acpi.max_tasks: 1024
hw.acpi.acline: 1
hw.acpi.battery.info_expire: 5
hw.acpi.battery.units: 1
hw.acpi.battery.state: 0
hw.acpi.battery.time: -1
hw.acpi.battery.life: 97
hw.acpi.cpu.cx_lowest: C2
hw.acpi.reset_video: 0
hw.acpi.handle_reboot: 1
hw.acpi.disable_on_reboot: 0
hw.acpi.verbose: 0
hw.acpi.s4bios: 0
hw.acpi.sleep_delay: 1
hw.acpi.suspend_state: S3
hw.acpi.standby_state: NONE
hw.acpi.lid_switch_state: NONE
hw.acpi.sleep_button_state: S3
hw.acpi.power_button_state: S5
hw.acpi.supported_sleep_state: S3 S4 S5
machdep.idle: acpi
machdep.idle_available: spin, mwait, hlt, acpi
machdep.acpi_root: 2061033492
machdep.acpi_timer_freq: 3579545
dev.acpi_perf.7.%parent: cpu7
dev.acpi_perf.7.%pnpinfo:
dev.acpi_perf.7.%location:
dev.acpi_perf.7.%driver: acpi_perf
dev.acpi_perf.7.%desc:
dev.acpi_perf.6.%parent: cpu6
dev.acpi_perf.6.%pnpinfo:
dev.acpi_perf.6.%location:
dev.acpi_perf.6.%driver: acpi_perf
dev.acpi_perf.6.%desc:
dev.acpi_perf.5.%parent: cpu5
dev.acpi_perf.5.%pnpinfo:
dev.acpi_perf.5.%location:
dev.acpi_perf.5.%driver: acpi_perf
dev.acpi_perf.5.%desc:
dev.acpi_perf.4.%parent: cpu4
dev.acpi_perf.4.%pnpinfo:
dev.acpi_perf.4.%location:
dev.acpi_perf.4.%driver: acpi_perf
dev.acpi_perf.4.%desc:
dev.acpi_perf.3.%parent: cpu3
dev.acpi_perf.3.%pnpinfo:
dev.acpi_perf.3.%location:
dev.acpi_perf.3.%driver: acpi_perf
dev.acpi_perf.3.%desc:
dev.acpi_perf.2.%parent: cpu2
dev.acpi_perf.2.%pnpinfo:
dev.acpi_perf.2.%location:
dev.acpi_perf.2.%driver: acpi_perf
dev.acpi_perf.2.%desc:
dev.acpi_perf.1.%parent: cpu1
dev.acpi_perf.1.%pnpinfo:
dev.acpi_perf.1.%location:
dev.acpi_perf.1.%driver: acpi_perf
dev.acpi_perf.1.%desc:
dev.acpi_perf.0.%parent: cpu0
dev.acpi_perf.0.%pnpinfo:
dev.acpi_perf.0.%location:
dev.acpi_perf.0.%driver: acpi_perf
dev.acpi_perf.0.%desc:
dev.acpi_perf.%parent:
dev.fpupnp.0.%parent: acpi0
dev.atdma.0.%parent: acpi0
dev.acpi_button.1.%parent: acpi0
dev.acpi_button.1.%pnpinfo: _HID=PNP0C0E _UID=0
dev.acpi_button.1.%location: handle=\_SB_.SLPB
dev.acpi_button.1.%driver: acpi_button
dev.acpi_button.1.%desc: Sleep Button
dev.acpi_button.0.%parent: acpi0
dev.acpi_button.0.%pnpinfo: _HID=PNP0C0C _UID=0
dev.acpi_button.0.%location: handle=\_SB_.PWRB
dev.acpi_button.0.%driver: acpi_button
dev.acpi_button.0.%desc: Power Button
dev.acpi_button.%parent:
dev.acpi_lid.0.wake: 1
dev.acpi_lid.0.%parent: acpi0
dev.acpi_lid.0.%pnpinfo: _HID=PNP0C0D _UID=0
dev.acpi_lid.0.%location: handle=\_SB_.LID0
dev.acpi_lid.0.%driver: acpi_lid
dev.acpi_lid.0.%desc: Control Method Lid Switch
dev.acpi_lid.%parent:
dev.acpi_acad.0.wake: 0
dev.acpi_acad.0.%parent: acpi0
dev.acpi_acad.0.%pnpinfo: _HID=ACPI0003 _UID=0
dev.acpi_acad.0.%location: handle=\_SB_.ADP1
dev.acpi_acad.0.%driver: acpi_acad
dev.acpi_acad.0.%desc: AC Adapter
dev.acpi_acad.%parent:
dev.battery.0.%parent: acpi0
dev.pcib.0.%parent: acpi0
dev.pci_link.7.%parent: acpi0
dev.pci_link.6.%parent: acpi0
dev.pci_link.5.%parent: acpi0
dev.pci_link.4.%parent: acpi0
dev.pci_link.3.%parent: acpi0
dev.pci_link.2.%parent: acpi0
dev.pci_link.1.%parent: acpi0
dev.pci_link.0.%parent: acpi0
dev.acpi_timer.0.%parent: acpi0
dev.acpi_timer.0.%pnpinfo: unknown
dev.acpi_timer.0.%location: unknown
dev.acpi_timer.0.%driver: acpi_timer
dev.acpi_timer.0.%desc: 24-bit timer at 3.579545MHz
dev.acpi_timer.%parent:
dev.attimer.0.%parent: acpi0
dev.atrtc.0.%parent: acpi0
dev.cpu.7.%parent: acpi0
dev.cpu.6.%parent: acpi0
dev.cpu.5.%parent: acpi0
dev.cpu.4.%parent: acpi0
dev.cpu.3.%parent: acpi0
dev.cpu.2.%parent: acpi0
dev.cpu.1.%parent: acpi0
dev.cpu.0.%parent: acpi0
dev.acpi_sysresource.2.%parent: acpi0
dev.acpi_sysresource.2.%pnpinfo: _HID=PNP0C01 _UID=2
dev.acpi_sysresource.2.%location: handle=\_SB_.MEM2
dev.acpi_sysresource.2.%driver: acpi_sysresource
dev.acpi_sysresource.2.%desc: System Resource
dev.acpi_sysresource.1.%parent: acpi0
dev.acpi_sysresource.1.%pnpinfo: _HID=PNP0C02 _UID=1
dev.acpi_sysresource.1.%location: handle=\_SB_.PCI0.PDRC
dev.acpi_sysresource.1.%driver: acpi_sysresource
dev.acpi_sysresource.1.%desc: System Resource
dev.acpi_sysresource.0.%parent: acpi0
dev.acpi_sysresource.0.%pnpinfo: _HID=PNP0C02 _UID=2
dev.acpi_sysresource.0.%location: handle=\_SB_.PCI0.LPCB.LDRC
dev.acpi_sysresource.0.%driver: acpi_sysresource
dev.acpi_sysresource.0.%desc: System Resource
dev.acpi_sysresource.%parent:
dev.hpet.0.%parent: acpi0
dev.acpi_ec.0.wake: 0
dev.acpi_ec.0.%parent: acpi0
dev.acpi_ec.0.%pnpinfo: _HID=PNP0C09 _UID=0
dev.acpi_ec.0.%location: handle=\_SB_.PCI0.LPCB.EC__
dev.acpi_ec.0.%driver: acpi_ec
dev.acpi_ec.0.%desc: Embedded Controller: GPE 0x17, ECDT
dev.acpi_ec.%parent:
dev.acpi.0.%parent: nexus0
dev.acpi.0.%pnpinfo:
dev.acpi.0.%location:
dev.acpi.0.%driver: acpi
dev.acpi.0.%desc: APPLE Apple00
dev.acpi.%parent:

Vengo de ejecutar Linux y normalmente hay un video o algunas configuraciones de ACPI que controlarán el brillo de la pantalla, pero en FreeBSD no parece haber nada como esto, por lo que mi monitor está constantemente al 100% de brillo. ¿No debería haber alguna forma de atenuar el brillo a través de la interfaz acpi?

¿Puedo obtener ayuda para poder atenuar el brillo de la pantalla?

[editar] Aquí está el resultado de mi xorg.conf

# nvidia-xconfig: X configuration file generated by nvidia-xconfig
# nvidia-xconfig:  version 367.35  Wed Sep  7 17:03:49 CST 2016

Section "ServerLayout"
    Identifier     "Layout0"
    Screen      0  "Screen0"
    InputDevice    "Keyboard0" "CoreKeyboard"
    InputDevice    "Mouse0" "CorePointer"
EndSection

Section "Files"
EndSection

Section "InputDevice"
    # generated from default
    Identifier     "Mouse0"
    Driver         "mouse"
    Option         "Protocol" "auto"
    Option         "Device" "/dev/sysmouse"
    Option         "Emulate3Buttons" "no"
    Option         "ZAxisMapping" "4 5"
EndSection

Section "InputDevice"
    # generated from default
    Identifier     "Keyboard0"
    Driver         "keyboard"
EndSection

Section "Monitor"
    Identifier     "Monitor0"
    VendorName     "Unknown"
    ModelName      "Unknown"
    HorizSync       28.0 - 33.0
    VertRefresh     43.0 - 72.0
    Option         "DPMS"
EndSection

Section "Device"
    Identifier     "Device0"
    Driver         "nvidia"
    VendorName     "NVIDIA Corporation"
EndSection

Section "Screen"
    Identifier     "Screen0"
    Device         "Device0"
    Monitor        "Monitor0"
    DefaultDepth    24
    SubSection     "Display"
        Depth       24
    EndSubSection
EndSection

Respuesta1

Tuve problemas con el brillo en Dell L702X con Nvidia GT550M. Puedes ver lo que he encontrado eneste hilo (enlace). Quizás algunas de esas cosas funcionen para ti.

No pude usar xbacklight(1)(o activar las teclas de control de brillo) pero encontré un par de otras formas de cambiar el brillo:

  • xrandr(1)

Gracias aesta publicación (enlace)Pude cambiar el brillo del monitor externo usando xrandr. El comando se ve así:

    xrandr --output HDMI-0 --brightness 0.9

El valor predeterminado parece ser 1.

  • redshift(1)

    Redshift es un software que le permite cambiar la temperatura de su pantalla. Tiene -bopciones -ty -gopciones que pueden resultar útiles (consulte man redshiftpara obtener más detalles).
