내 PC 뒷면의 녹색 포트에 연결된 헤드셋이 있습니다. 마이크가 작동하지 않습니다. 내 PC에는 설정 > 사운드가 있습니다.
출력 장치: 테스트 버튼이 있는 헤드폰 내장 오디오. Line Out-Built-In Audio로 변경하는 옵션이 있습니다.
입력 장치: 전면 마이크 내장 오디오. 테스트 버튼도 없고 변경 옵션도 없습니다.
터미널에서 aplay 추천 결과는 다음과 같습니다.
$ aplay -l
**** List of PLAYBACK Hardware Devices ****
card 0: HDMI [HDA Intel HDMI], device 3: HDMI 0 [HDMI 0]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 7: HDMI 1 [HDMI 1]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 8: HDMI 2 [HDMI 2]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 9: HDMI 3 [HDMI 3]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 10: HDMI 4 [HDMI 4]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 1: PCH [HDA Intel PCH], device 0: ALC662 rev1 Analog [ALC662 rev1 Analog]
Subdevices: 0/1
Subdevice #0: subdevice #0
다음은 터미널의 믹서 결과입니다. 마이크 컨트롤은 오디오 입력이 헤드셋과 분리되어 있음을 암시하는 것 같습니다. 헤드셋 마이크를 사용할 수 있는 경우 어떤 조정을 해야 합니까?
$ amixer -c1
Simple mixer control 'Master',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 64 [100%] [0.00dB] [on]
Simple mixer control 'Headphone',0
Capabilities: pswitch
Playback channels: Front Left - Front Right
Mono:
Front Left: Playback [on]
Front Right: Playback [on]
Simple mixer control 'Headphone+LO',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 64
Mono:
Front Left: Playback 64 [100%] [0.00dB]
Front Right: Playback 64 [100%] [0.00dB]
Simple mixer control 'PCM',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 255
Mono:
Front Left: Playback 255 [100%] [0.00dB]
Front Right: Playback 255 [100%] [0.00dB]
Simple mixer control 'Front',0
Capabilities: pswitch
Playback channels: Front Left - Front Right
Mono:
Front Left: Playback [on]
Front Right: Playback [on]
Simple mixer control 'Front Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Front Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 3 [100%] [30.00dB]
Front Right: 3 [100%] [30.00dB]
Simple mixer control 'Surround',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 64
Mono:
Front Left: Playback 0 [0%] [-64.00dB] [off]
Front Right: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'Center',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'LFE',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'Line',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Capture',0
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 31 [100%] [33.00dB] [on]
Front Right: Capture 31 [100%] [33.00dB] [on]
Simple mixer control 'Capture',1
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 0 [0%] [-13.50dB] [off]
Front Right: Capture 0 [0%] [-13.50dB] [off]
Simple mixer control 'Channel Mode',0
Capabilities: enum
Items: '2ch' '4ch' '6ch'
Item0: '2ch'
Simple mixer control 'Input Source',0
Capabilities: cenum
Items: 'Front Mic' 'Rear Mic' 'Line'
Item0: 'Front Mic'
Simple mixer control 'Input Source',1
Capabilities: cenum
Items: 'Front Mic' 'Rear Mic' 'Line'
Item0: 'Front Mic'
Simple mixer control 'Loopback Mixing',0
Capabilities: enum
Items: 'Disabled' 'Enabled'
Item0: 'Disabled'
Simple mixer control 'Rear Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Rear Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 0 [0%] [0.00dB]
Front Right: 0 [0%] [0.00dB]
