브리지에 연결된 veth가 있는 Ubuntu 22.04 netns는 게이트웨이를 ping할 수 없습니다.

안녕하세요 여러분, 이것은 아마도 제가 놓친 멍청한 것일 수도 있지만 VPN에 사용할 넷 네임스페이스를 설정하는 데 문제가 있습니다. 이상한 부분은 이 스크립트/설정이 작동 중이었는데 지난 몇 주 동안 갑자기 중단되었다는 것입니다.

모든 일반 트래픽에 사용하려는 고정 IP 세트가 있는 서버에 단일 이더넷 인터페이스가 있습니다. 그런 다음 브리지와 마스터를 사용하고 가상 이더넷을 통해 VPN을 동일한 브리지에 연결합니다. 어떤 이유로 VPN 인터페이스가 ARP 요청에 성공적으로 응답할 수 있지만 게이트웨이를 핑할 수 없는 것 같아서 인터넷에 연결할 수 없습니다. 라우팅 문제인 것 같지만 알아낼 수는 없습니다.

넷플랜

# Let NetworkManager manage all devices on this system
network:
  version: 2
  renderer: networkd
  ethernets:
    enp3s0:
      dhcp4: false
      addresses:
        - 192.168.0.54/24

  bridges:
    br0:
      interfaces:
        - enp3s0
      routes:
      - to: default
        via: 192.168.0.1
      - to: 192.168.0.0/24
      nameservers:
        addresses: [1.1.1.1, 8.8.8.8]

VPN Net 네임스페이스 설정 스크립트:

ip link add vpn0 type veth peer name vpn1

ip link set dev vpn0 master br0

ip netns add vpn

ip link set vpn1 netns vpn

ip link set dev vpn0 promisc on
ip link set vpn0 up

ip netns exec vpn ip link set lo up
ip netns exec vpn ip link set vpn1 up

ip netns exec vpn ip address add 192.168.0.53/24 dev vpn1
ip netns exec vpn ip route add default via 192.168.0.1 dev vpn1

VPN 주소/경로

root@sam-server:~# ip address
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
5: vpn1@if6: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000
    link/ether 06:9e:19:5a:a4:a5 brd ff:ff:ff:ff:ff:ff link-netnsid 0
    inet 192.168.0.53/24 scope global vpn1
       valid_lft forever preferred_lft forever
    inet6 fe80::49e:19ff:fe5a:a4a5/64 scope link
       valid_lft forever preferred_lft forever
root@sam-server:~# ip route
default via 192.168.0.1 dev vpn1
192.168.0.0/24 dev vpn1 proto kernel scope link src 192.168.0.53

일반 주소/경로

root@sam-server:~# ip address
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: enp3s0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc fq_codel master br0 state UP group default qlen 1000
    link/ether 88:d7:f6:78:91:72 brd ff:ff:ff:ff:ff:ff
    inet 192.168.0.54/24 brd 192.168.0.255 scope global enp3s0
       valid_lft forever preferred_lft forever
3: br0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000
    link/ether e6:3d:5a:ce:a9:fb brd ff:ff:ff:ff:ff:ff
    inet6 fe80::e43d:5aff:fece:a9fb/64 scope link
       valid_lft forever preferred_lft forever
4: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default
    link/ether 02:42:19:80:3c:94 brd ff:ff:ff:ff:ff:ff
    inet 172.17.0.1/16 brd 172.17.255.255 scope global docker0
       valid_lft forever preferred_lft forever
6: vpn0@if5: <BROADCAST,MULTICAST,PROMISC,UP,LOWER_UP> mtu 1500 qdisc noqueue master br0 state UP group default qlen 1000
    link/ether 66:2c:f9:35:3d:0e brd ff:ff:ff:ff:ff:ff link-netns vpn
    inet6 fe80::642c:f9ff:fe35:3d0e/64 scope link
       valid_lft forever preferred_lft forever
root@sam-server:~# ip route
default via 192.168.0.1 dev br0 proto static onlink
172.17.0.0/16 dev docker0 proto kernel scope link src 172.17.0.1 linkdown
192.168.0.0/24 dev br0 proto static scope link
192.168.0.0/24 dev enp3s0 proto kernel scope link src 192.168.0.54

VPN 네임스페에서 핑(Arp가 해결된 것 같지만 게이트웨이에 ping을 보낼 수 없습니다)

root@sam-server:~# ping 192.168.0.1
PING 192.168.0.1 (192.168.0.1) 56(84) bytes of data.
^C
--- 192.168.0.1 ping statistics ---
4 packets transmitted, 0 received, 100% packet loss, time 3066ms

root@sam-server:~# ping 192.168.0.54
PING 192.168.0.54 (192.168.0.54) 56(84) bytes of data.
64 bytes from 192.168.0.54: icmp_seq=1 ttl=64 time=0.037 ms
64 bytes from 192.168.0.54: icmp_seq=2 ttl=64 time=0.052 ms
64 bytes from 192.168.0.54: icmp_seq=3 ttl=64 time=0.052 ms
^C
--- 192.168.0.54 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2031ms
rtt min/avg/max/mdev = 0.037/0.047/0.052/0.007 ms
root@sam-server:~# arp
Address                  HWtype  HWaddress           Flags Mask            Iface
192.168.0.1              ether   b0:95:75:8c:fe:80   C                     vpn1
192.168.0.54             ether   e6:3d:5a:ce:a9:fb   C                     vpn1
root@sam-server:~#

이것이 충분한 정보였기를 바랍니다. 필요한 경우 더 게시할 수 있습니다.

답변1

여기에 제안된 대로 인터페이스의 macaddress를 추가해 보십시오.Netplan을 사용한 Ubuntu 22.04 브리징이 작동하지 않습니다.

   # Let NetworkManager manage all devices on this system
network:
  version: 2
  renderer: networkd
  ethernets:
    enp3s0:
      dhcp4: false
      addresses:
        - 192.168.0.54/24

  bridges:
    br0:
      interfaces:
        - enp3s0
      routes:
      - to: default
        via: 192.168.0.1
      - to: 192.168.0.0/24
      nameservers:
        addresses: [1.1.1.1, 8.8.8.8]
      macaddress: 88:d7:f6:78:91:72

답변2

내 문제에 대한 답을 찾았습니다. 정말 간단한 일이었습니다. 기본적으로 2주 전에 Docker. 나는 이것을 몰랐지만 Docker는 iptables.

root@sam-server:~# iptables --list
Chain INPUT (policy ACCEPT)
target     prot opt source               destination

Chain FORWARD (policy DROP) <----------- PROBLEM IS HERE
target     prot opt source               destination
DOCKER-USER  all  --  anywhere             anywhere
DOCKER-ISOLATION-STAGE-1  all  --  anywhere             anywhere
ACCEPT     all  --  anywhere             anywhere             ctstate RELATED,ESTABLISHED
DOCKER     all  --  anywhere             anywhere
ACCEPT     all  --  anywhere             anywhere
ACCEPT     all  --  anywhere             anywhere

Chain OUTPUT (policy ACCEPT)
target     prot opt source               destination

Chain DOCKER (1 references)
target     prot opt source               destination

Chain DOCKER-ISOLATION-STAGE-1 (1 references)
target     prot opt source               destination
DOCKER-ISOLATION-STAGE-2  all  --  anywhere             anywhere
RETURN     all  --  anywhere             anywhere

Chain DOCKER-ISOLATION-STAGE-2 (1 references)
target     prot opt source               destination
DROP       all  --  anywhere             anywhere
RETURN     all  --  anywhere             anywhere

Chain DOCKER-USER (1 references)
target     prot opt source               destination
RETURN     all  --  anywhere             anywhere

FORWARDDocker가 자동 으로 내 패킷을 설정했기 때문에 DROP인터페이스로 전달되지 않았습니다. ARPiptables의 영향을 받지 않기 때문에 작동하고 있다고 가정합니다 .

수정 사항은 다음을 허용하도록 정책을 재설정하는 것이었습니다.iptables --policy FORWARD ACCCEPT
