화면 해상도를 변경하기 위해 Powershell(또는 기타) 스크립트를 수행하는 방법은 무엇입니까?

tag-icon • tag-icon resolution powershell
화면 해상도를 변경하기 위해 Powershell(또는 기타) 스크립트를 수행하는 방법은 무엇입니까?

화면 해상도 변경(예: 1024*768)을 어떻게 스크립팅할 수 있습니까?

답변1

해상도를 설정하는 기본 Powershell 방법은 없습니다. 이를 수행하려면 Powershell 스크립트에 인라인 C# 코드를 작성할 수 있습니다. 그렇지 않으면 이를 수행하는 타사 명령줄 응용 프로그램을 찾아서 스크립트에서 호출해야 합니다.

답변2

Andy Schneider는 다음을 통해 화면 해상도를 변경할 수 있는 스크립트를 작성했습니다.핀보케그리고디스플레이 설정 변경Win32API. 에서 받으실 수 있어요TechNet 갤러리. 도 있습니다Timothy Mui 버전으로 수정됨다중 모니터를 지원하는 이 스크립트의

다음은 경우에 따라 수정된 스크립트 자체입니다.

# ------------------------------------------------------------------------
# NAME: Set-ScreenResolutionEx.ps1
# AUTHOR: Timothy Mui (https://github.com/timmui)
# DATE: Jan. 7, 2015
#
# DESCRIPTION: Sets the Screen Resolution of the specified monitor.
#              Uses Pinvoke and ChangeDisplaySettingsEx Win32API to
#              make the changes. Written in C# and executed in PowerShell.
#
# KEYWORDS: PInvoke, height, width, pixels, Resolution, Win32 API,
#           Mulitple Monitor, display
#
# ARGUMENTS: -Width : Desired Width in pixels
#            -Height : Desired Height in pixels
#            -DeviceID : DeviceID of the monitor to be changed. DeviceID
#                        starts with 0 representing your first monitor.
#                        For Laptops, the built-in display is usually 0.
#
# EXAMPLE: Set-ScreenResolution -Width 1920 -Height 1080 -DeviceID 0
#
# ACKNOWLEDGEMENTS: Many thanks to Andy Schneider for providing the original
#                   code for a single monitor resolution changer.
#                   TechNet (https://gallery.technet.microsoft.com/ScriptCenter/2a631d72-206d-4036-a3f2-2e150f297515/)
#
# ------------------------------------------------------------------------
Function Set-ScreenResolutionEx {
param (
[Parameter(Mandatory=$true,
           Position = 0)]
[int]
$Width,

[Parameter(Mandatory=$true,
           Position = 1)]
[int]
$Height,

[Parameter(Mandatory=$true,
           Position = 2)]
[int]
$DeviceID
)
$Code = @"
using System;
using System.Runtime.InteropServices;

namespace Resolution
{
    [Flags()]
    public enum DisplayDeviceStateFlags : int
    {
        /// <summary>The device is part of the desktop.</summary>
        AttachedToDesktop = 0x1,
        MultiDriver = 0x2,
        /// <summary>The device is part of the desktop.</summary>
        PrimaryDevice = 0x4,
        /// <summary>Represents a pseudo device used to mirror application drawing for remoting or other purposes.</summary>
        MirroringDriver = 0x8,
        /// <summary>The device is VGA compatible.</summary>
        VGACompatible = 0x10,
        /// <summary>The device is removable; it cannot be the primary display.</summary>
        Removable = 0x20,
        /// <summary>The device has more display modes than its output devices support.</summary>
        ModesPruned = 0x8000000,
        Remote = 0x4000000,
        Disconnect = 0x2000000
    }

    [StructLayout(LayoutKind.Sequential, CharSet=CharSet.Ansi)]
    public struct DISPLAY_DEVICE
    {
        [MarshalAs(UnmanagedType.U4)]
        public int cb;
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst=32)]
        public string DeviceName;
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst=128)]
        public string DeviceString;
        [MarshalAs(UnmanagedType.U4)]
        public DisplayDeviceStateFlags StateFlags;
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst=128)]
        public string DeviceID;
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst=128)]
        public string DeviceKey;
    }

    [Flags()]
    public enum ChangeDisplaySettingsFlags : uint
    {
        CDS_NONE = 0,
        CDS_UPDATEREGISTRY = 0x00000001,
        CDS_TEST = 0x00000002,
        CDS_FULLSCREEN = 0x00000004,
        CDS_GLOBAL = 0x00000008,
        CDS_SET_PRIMARY = 0x00000010,
        CDS_VIDEOPARAMETERS = 0x00000020,
        CDS_ENABLE_UNSAFE_MODES = 0x00000100,
        CDS_DISABLE_UNSAFE_MODES = 0x00000200,
        CDS_RESET = 0x40000000,
        CDS_RESET_EX = 0x20000000,
        CDS_NORESET = 0x10000000
    }

    [StructLayout(LayoutKind.Sequential)]
    public struct DEVMODE
    {
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 32)]
        public string dmDeviceName;
        public short dmSpecVersion;
        public short dmDriverVersion;
        public short dmSize;
        public short dmDriverExtra;
        public int dmFields;

        public short dmOrientation;
        public short dmPaperSize;
        public short dmPaperLength;
        public short dmPaperWidth;

        public short dmScale;
        public short dmCopies;
        public short dmDefaultSource;
        public short dmPrintQuality;
        public short dmColor;
        public short dmDuplex;
        public short dmYResolution;
        public short dmTTOption;
        public short dmCollate;
        [MarshalAs(UnmanagedType.ByValTStr, SizeConst = 32)]
        public string dmFormName;
        public short dmLogPixels;
        public short dmBitsPerPel;
        public int dmPelsWidth;
        public int dmPelsHeight;
        public int dmPosition;

        public int dmDisplayFlags;
        public int dmDisplayFrequency;

        public int dmICMMethod;
        public int dmICMIntent;
        public int dmMediaType;
        public int dmDitherType;
        public int dmReserved1;
        public int dmReserved2;

        public int dmPanningWidth;
        public int dmPanningHeight;
    };

    [Flags()]
    public enum DISP_CHANGE : int
    {
        SUCCESSFUL = 0,
        RESTART = 1,
        FAILED = -1,
        BADMODE = -2,
        NOTUPDATED = -3,
        BADFLAGS = -4,
        BADPARAM = -5,
        BADDUALVIEW = -6
    }

    public class User_32
    {
        [DllImport("user32.dll")]
        public static extern bool EnumDisplayDevices(string lpDevice, uint iDevNum, ref DISPLAY_DEVICE lpDisplayDevice, uint dwFlags);
        [DllImport("user32.dll")]
        public static extern int EnumDisplaySettingsEx(string lpszDeviceName, int iModeNum, ref DEVMODE lpDevMode, uint dwFlags);
        [DllImport("user32.dll")]
        public static extern int ChangeDisplaySettingsEx(string lpszDeviceName, ref DEVMODE lpDevMode, IntPtr hwnd, ChangeDisplaySettingsFlags dwflags, IntPtr lParam);

        public const int ENUM_CURRENT_SETTINGS = -1;
    }



    public class ScreenResolution
    {
        // Arguments
        // int width : Desired Width in pixels
        // int height : Desired Height in pixels
        // int deviceIDIn : DeviceID of the monitor to be changed. DeviceID starts with 0 representing your first
        //                  monitor. For Laptops, the built-in display is usually 0.

        static public string ChangeResolution(int width, int height, int deviceIDIn)
        {
            //Basic Error Check
            uint deviceID = 0;
            if (deviceIDIn < 0){
                deviceID = 0;
            }
            else
            {
                deviceID = (uint) deviceIDIn;
            }

            DISPLAY_DEVICE d = new DISPLAY_DEVICE();
            d.cb = Marshal.SizeOf(d);

            DEVMODE dm = GetDevMode();

            User_32.EnumDisplayDevices(null, deviceID, ref d, 1); //Get Device Information

            // Print Device Information
            Console.WriteLine("DeviceName: {0} \nDeviceString: {1}\nDeviceID: {2}\nDeviceKey {3}\nStateFlags {4}\n", d.DeviceName, d.DeviceString, d.DeviceID, d.DeviceKey, d.StateFlags);

            //Attempt to change settings
            if (0 != User_32.EnumDisplaySettingsEx ( d.DeviceName, User_32.ENUM_CURRENT_SETTINGS, ref dm, 0))
            {

                dm.dmPelsWidth = width;
                dm.dmPelsHeight = height;

                int iRet = User_32.ChangeDisplaySettingsEx( d.DeviceName, ref dm, IntPtr.Zero, ChangeDisplaySettingsFlags.CDS_TEST, IntPtr.Zero);

                if (iRet == (int) DISP_CHANGE.FAILED)
                {
                    return "Unable To Process Your Request. Sorry For This Inconvenience.";
                }
                else
                {
                    iRet = User_32.ChangeDisplaySettingsEx(d.DeviceName, ref dm, IntPtr.Zero, ChangeDisplaySettingsFlags.CDS_UPDATEREGISTRY, IntPtr.Zero);

                    switch (iRet)
                    {
                        case (int) DISP_CHANGE.SUCCESSFUL:
                            {
                                return "Success";
                            }
                        case (int) DISP_CHANGE.RESTART:
                            {
                                return "You Need To Reboot For The Change To Happen.\n If You Feel Any Problem After Rebooting Your Machine\nThen Try To Change Resolution In Safe Mode.";
                            }
                        default:
                            {
                                return "Failed To Change The Resolution.";
                            }
                    }

                }

            }
            else
            {
                return "Failed To Change The Resolution.";
            }
        }

        private static DEVMODE GetDevMode()
        {
            DEVMODE dm = new DEVMODE();
            dm.dmDeviceName = new String(new char[32]);
            dm.dmFormName = new String(new char[32]);
            dm.dmSize = (short)Marshal.SizeOf(dm);
            return dm;
        }
    }
}
"@
Add-Type $Code
[Resolution.ScreenResolution]::ChangeResolution($width,$height,$DeviceID)
}

답변3

EBGreen이 말했듯이 Powershell은 바닐라 상태에서는 이를 수행할 수 없습니다. 그러나 .NET 기반 셸이므로 Powershell 스크립트 내에서 .NET을 사용하거나 기존 CLI 애플리케이션을 사용하거나 Cmdlet을 작성하여 이를 수행할 수 있습니다.

해당 경로를 더 자세히 탐색하기로 결정한 경우 다음 링크가 도움이 될 수 있습니다.

답변4

기본 Windows 명령을 사용하여 이 작업을 수행할 수는 없지만 다음과 같이 명령줄에서 호출되는 응용 프로그램을 사용할 수 있습니다.http://www.pcdownloadworld.com/prgdb/reschange.htm.

나는 전에 그것을 사용해 본 적이 있습니다. 조금 번거롭지만 주석에 적힌 대로 작동합니다.
