Dell Inspiron 17(7746, 2015년 초) CentOS 7 노트북의 Linux용 Intel 무선 WiFi 드라이버

tag-icon • tag-icon linux drivers centos dell-inspiron wifi-driver
Dell Inspiron 17(7746, 2015년 초) CentOS 7 노트북의 Linux용 Intel 무선 WiFi 드라이버

그래서 최근 직장에서 새 노트북을 받았는데 CentOS 7에서 무선 드라이버가 작동하도록 할 수 없습니다.

########## wireless info START ##########

Report from: 13 Mar 2015 13:47 EDT -0400

Booted last: 13 Mar 2015 13:43 EDT -0400

Script from: 20 Sep 2014 23:04 UTC +0000

##### release ###########################

Distributor ID: CentOS
Description:    CentOS Linux release 7.0.1406 (Core)
Release:    7.0.1406
Codename:   Core

##### kernel ############################

Linux 3.19.1-1.el7.elrepo.x86_64 #1 SMP Sat Mar 7 13:55:36 EST 2015 x86_64 x86_64 x86_64 GNU/Linux

Parameters: ro, rd.lvm.lv=centos/swap, vconsole.font=latarcyrheb-sun16, rd.lvm.lv=centos/root, crashkernel=auto, vconsole.keymap=us, rhgb, quiet, LANG=en_US.UTF-8

##### desktop ###########################

GNOME Classic

##### lspci #############################

06:00.0 Network controller [0280]: Intel Corporation Wireless 7265 [8086:095a] (rev 59)
    Subsystem: Intel Corporation Dual Band Wireless-AC 7265 [8086:5410]

07:00.0 Unassigned class [ff00]: Realtek Semiconductor Co., Ltd. Device [10ec:5287] (rev 01)

07:00.1 Ethernet controller [0200]: Realtek Semiconductor Co., Ltd. RTL8111/8168/8411 PCI Express Gigabit Ethernet Controller [10ec:8168] (rev 12)
    Subsystem: Dell Device [1028:0692]
    Kernel driver in use: r8169

##### lsmod #############################

dell_wmi               13132  0
sparse_keymap          13948  1 dell_wmi
dell_laptop            14000  0
dcdbas                 14928  1 dell_laptop
iwlwifi               116602  0
cfg80211              531303  1 iwlwifi
rfkill                 26772  5 cfg80211,bluetooth,dell_laptop
mxm_wmi                13021  1 nouveau
wmi                    19193  4 dell_led,dell_wmi,mxm_wmi,nouveau

##### NetworkManager.state ##############

[main]
NetworkingEnabled=true
WirelessEnabled=true
WWANEnabled=true
WimaxEnabled=true

##### NetworkManager.conf ###############

[main]
plugins=ifcfg-rh

##### module infos ######################

[iwlwifi]
filename:       /lib/modules/3.19.1-1.el7.elrepo.x86_64/kernel/drivers/net/wireless/iwlwifi/iwlwifi.ko
license:        GPL
author:         Copyright(c) 2003- 2014 Intel Corporation <[email protected]>
version:        in-tree:
description:    Intel(R) Wireless WiFi driver for Linux
firmware:       iwlwifi-100-5.ucode
firmware:       iwlwifi-1000-5.ucode
firmware:       iwlwifi-135-6.ucode
firmware:       iwlwifi-105-6.ucode
firmware:       iwlwifi-2030-6.ucode
firmware:       iwlwifi-2000-6.ucode
firmware:       iwlwifi-5150-2.ucode
firmware:       iwlwifi-5000-5.ucode
firmware:       iwlwifi-6000g2b-6.ucode
firmware:       iwlwifi-6000g2a-5.ucode
firmware:       iwlwifi-6050-5.ucode
firmware:       iwlwifi-6000-4.ucode
firmware:       iwlwifi-7265D-10.ucode
firmware:       iwlwifi-7265-10.ucode
firmware:       iwlwifi-3165-10.ucode
firmware:       iwlwifi-3160-10.ucode
firmware:       iwlwifi-7260-10.ucode
firmware:       iwlwifi-8000-10.ucode
srcversion:     29203CA7DDFAAD012962408
depends:        cfg80211
intree:         Y
vermagic:       3.19.1-1.el7.elrepo.x86_64 SMP mod_unload modversions
parm:           swcrypto:using crypto in software (default 0 [hardware]) (int)
parm:           11n_disable:disable 11n functionality, bitmap: 1: full, 2: disable agg TX, 4: disable agg RX, 8 enable agg TX (uint)
parm:           amsdu_size_8K:enable 8K amsdu size (default 0) (int)
parm:           fw_restart:restart firmware in case of error (default true) (bool)
parm:           antenna_coupling:specify antenna coupling in dB (default: 0 dB) (int)
parm:           wd_disable:Disable stuck queue watchdog timer 0=system default, 1=disable (default: 1) (int)
parm:           nvm_file:NVM file name (charp)
parm:           uapsd_disable:disable U-APSD functionality (default: Y) (bool)
parm:           bt_coex_active:enable wifi/bt co-exist (default: enable) (bool)
parm:           led_mode:0=system default, 1=On(RF On)/Off(RF Off), 2=blinking, 3=Off (default: 0) (int)
parm:           power_save:enable WiFi power management (default: disable) (bool)
parm:           power_level:default power save level (range from 1 - 5, default: 1) (int)
parm:           fw_monitor:firmware monitor - to debug FW (default: false - needs lots of memory) (bool)

[cfg80211]
filename:       /lib/modules/3.19.1-1.el7.elrepo.x86_64/kernel/net/wireless/cfg80211.ko
description:    wireless configuration support
license:        GPL
author:         Johannes Berg
srcversion:     6AAC635BDE451B0558DF56A
depends:        rfkill
intree:         Y
vermagic:       3.19.1-1.el7.elrepo.x86_64 SMP mod_unload modversions
parm:           ieee80211_regdom:IEEE 802.11 regulatory domain code (charp)
parm:           cfg80211_disable_40mhz_24ghz:Disable 40MHz support in the 2.4GHz band (bool)

##### module parameters #################

[iwlwifi]
11n_disable: 0
amsdu_size_8K: 0
antenna_coupling: 0
bt_coex_active: Y
fw_monitor: N
fw_restart: Y
led_mode: 0
nvm_file: (null)
power_level: 0
power_save: N
swcrypto: 0
uapsd_disable: Y
wd_disable: 1

[cfg80211]
cfg80211_disable_40mhz_24ghz: N
ieee80211_regdom: 00

##### dmesg #############################

[    2.823095] iwlwifi 0000:06:00.0: enabling device (0000 -> 0002)
[    2.823961] iwlwifi 0000:06:00.0: Unsupported splx structure
[    2.830609] iwlwifi 0000:06:00.0: Direct firmware load for iwlwifi-7265D-12.ucode failed with error -2
[    2.830628] iwlwifi 0000:06:00.0: Direct firmware load for iwlwifi-7265D-11.ucode failed with error -2
[    2.830641] iwlwifi 0000:06:00.0: Direct firmware load for iwlwifi-7265D-10.ucode failed with error -2
[    2.830644] iwlwifi 0000:06:00.0: request for firmware file 'iwlwifi-7265D-10.ucode' failed.
[    2.830702] iwlwifi 0000:06:00.0: Direct firmware load for iwlwifi-7265D-9.ucode failed with error -2
[    2.830704] iwlwifi 0000:06:00.0: request for firmware file 'iwlwifi-7265D-9.ucode' failed.
[    2.830748] iwlwifi 0000:06:00.0: no suitable firmware found!
[    2.851026] bluetooth hci0: Direct firmware load for intel/ibt-hw-37.8.10-fw-1.10.3.11.e.bseq failed with error -2
[    2.851032] Bluetooth: hci0 failed to open Intel firmware file: intel/ibt-hw-37.8.10-fw-1.10.3.11.e.bseq(-2)
[    2.851333] Bluetooth: hci0: Intel Bluetooth firmware file: intel/ibt-hw-37.8.bseq
[    2.855263] Bluetooth: hci0: Intel Bluetooth firmware patch completed

########## wireless info END ############

답변1

편집: CentOS 7을 kernel-ml로 업데이트하는 것은 권장하지 않습니다. 그 이유는 안정성 문제가 많이 발생할 수 있기 때문입니다(특히 가상화가 제대로 작동하지 않음). 더 나은 해결책으로 제가 찾은 것은 Linux 커널용 "백포트"를 조사하는 것이었습니다.

방문하다:https://backports.wiki.kernel.org/index.php/Main_Page 임시 다운로드 페이지가 있으므로 결국 사라질 것이라고 생각하므로 이 질문에 해당 페이지로 직접 링크하고 싶지 않습니다. 해당 릴리스를 다운로드하십시오.

tar xf backports-3.19-rc1-1.tar.xz
cd backports-3.19-rc1-1
make defconfig-iwlwifi
sudo make install

재부팅했는데 모든 것이 작동하는 것 같습니다. kernel-ml로 업데이트할 필요가 없습니다.

이전 답변은 다음과 같습니다(이 방법도 작동하지만 더 이상 CentOS 메인라인에 있지 않습니다).

그래서 커널을 ELREPO의 ML 릴리스로 업데이트하고 linux-firmware 패키지를 사용하여 추가 펌웨어를 설치하는 등 "공식적인" 상태를 유지하기 위해 몇 가지 작업을 시도했습니다.

결국 내가 해야 할 일은 다음을 방문하는 것이었습니다. https://wireless.wiki.kernel.org/en/users/drivers/iwlwifi#firmware 최신 펌웨어 업데이트를 게시했습니다.

해당 펌웨어 헤더는 실제로 최신 kernel-ml 헤더에 있으며 내 /lib/firmware 폴더에는 존재하지 않는 것으로 나타났습니다.

그래서 저는 Intel® Wireless 7265 tarball을 다음 사이트에서 다운로드했습니다.https://wireless.wiki.kernel.org/_media/en/users/drivers/iwlwifi-7265-ucode-23.15.10.0.tgz(이 페이지에는 다른 최신 드라이버도 포함된 표가 있습니다) 단계에 따라 해당 드라이버를 /lib/firmware에 복사했습니다.

# cp iwlwifi-*.ucode /lib/firmware

노트북을 재부팅했더니 모든 것이 작동했습니다!
