먼저 제가 MATLAB과 Linux를 처음 접했다는 점을 먼저 말씀드리고 싶습니다. 아마도 제가 뭔가 분명한 것을 놓치고 있을 수도 있습니다. 만약 그렇다면 인내심을 가지시기 바랍니다.
저는 수학 부서의 모델링 프로젝트에 도움을 달라는 요청을 받았기 때문에 모든 코드를 다운로드하고 컴퓨터에 MATLAB을 설치한 다음 몇 가지 어려움을 겪은 후("glu"라는 라이브러리를 설치해야 함) 스크립트를 그 자체가 실제로 실행됩니다. 시스템이 충돌하는 플롯을 렌더링하려고 한다고 생각하는 지점에 이르고 ctrl-alt-F(아무거나)를 사용하여 다른 tty에 액세스할 수 없으며 잠시 후 오른쪽 상단에 깜박이는 커서가 나타납니다. 여전히 아무것도 할 수 없습니다. ctrl-alt-delete, 아무것도 없습니다. 그래서 전원 버튼을 누른 채 컴퓨터를 종료했습니다.
크래시 덤프를 찾았는데 그 중 상당수가 비어 있고 일부 정보가 있습니다. 여기 "matlab_crash_dump.4121-1"이 있습니다.
------------------------------------------------------------------------
Assertion detected at Sun Sep 18 17:13:44 2016
------------------------------------------------------------------------
Configuration:
Crash Decoding : Disabled
Crash Mode : continue (default)
Current Graphics Driver: Intel Open Source Technology Center Mesa DRI Intel(R) Sandybridge Mobile Version 3.0 Mesa 11.0.6
Current Visual : 0x47 (class 4, depth 24)
Default Encoding : UTF-8
GNU C Library : 2.22 stable
Host Name : q
Java Crash Report : /home/d/hs_error_pid4121.log
Java Log : /home/d/java.log.4121
MATLAB Architecture : glnxa64
MATLAB Root : /usr/local/MATLAB/R2016a
MATLAB Version : 9.0.0.341360 (R2016a)
OpenGL : hardware
Operating System : Linux 4.4.6-gentoo #6 SMP Sun Sep 18 16:32:36 MDT 2016 x86_64
Processor ID : x86 Family 6 Model 42 Stepping 7, GenuineIntel
Virtual Machine : Java 1.7.0_60-b19 with Oracle Corporation Java HotSpot(TM) 64-Bit Server VM mixed mode
Window System : The X.Org Foundation (11704000), display :0
Fault Count: 1
Assertion in void {anonymous}::mwJavaAbort() at javainit.cpp line 1389:
Fatal Java Exception. See Java Crash Report for details.
Register State (captured):
RAX = 00007f22a75e21e0 RBX = 00007f2329790878
RCX = 0000000000000000 RDX = 00007f2329770c20
RSP = 00007f22a75e2100 RBP = 00007f22a75e24c0
RSI = 00007f23295273b8 RDI = 00007f22a75e2110
R8 = 0000000000000000 R9 = 00007f230ec258e0
R10 = 0000000000000000 R11 = 000000000000000f
R12 = 00007f230ec251bb R13 = 00007f230ec258e0
R14 = 00007f23297807e8 R15 = 00007f22a75e2d30
RIP = 00007f232949459e EFL = 00007f232fa03500
CS = f0b8 FS = 2939 GS = 7f23
Stack Trace (captured):
[ 0] 0x00007f232949459e /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01082782 _ZN2fl4diag5linux6x86_6412context_base12capture_dataEv+00000030
[ 1] 0x00007f2329490541 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01066305
[ 2] 0x00007f2329491bd0 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01072080
[ 3] 0x00007f2329491c42 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01072194
[ 4] 0x00007f230ebe675a /usr/local/MATLAB/R2016a/bin/glnxa64/libmwjmi.so+01099610
[ 5] 0x00007f230d8298bb /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+08513723
[ 6] 0x00007f230d6599f2 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06613490
[ 7] 0x00007f21f308ac02 /usr/local/MATLAB/R2016a/bin/glnxa64/libnativewindow_x11.so+00011266 NativewindowCommon_FatalError+00000268
[ 8] 0x00007f21f308b95a /usr/local/MATLAB/R2016a/bin/glnxa64/libnativewindow_x11.so+00014682
[ 9] 0x00007f232275edde /usr/lib64/libX11.so.6+00282078 _XIOError+00000078
[ 10] 0x00007f232275cebb /usr/lib64/libX11.so.6+00274107 _XReply+00001019
[ 11] 0x00007f2322743cb7 /usr/lib64/libX11.so.6+00171191 _XGetWindowAttributes+00000183
[ 12] 0x00007f2322743e31 /usr/lib64/libX11.so.6+00171569 XGetWindowAttributes+00000049
[ 13] 0x00007f22e16a3c44 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/xawt/libmawt.so+00109636
[ 14] 0x00007f22e19112f6 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/libawt.so+00209654 Java_sun_java2d_loops_Blit_Blit+00000534
[ 15] 0x00007f22fd012d98 <unknown-module>+00000000
[ 16] 0x00007f22fd006058 <unknown-module>+00000000
[ 17] 0x00007f22fd006058 <unknown-module>+00000000
[ 18] 0x00007f22fd006350 <unknown-module>+00000000
[ 19] 0x00007f22fd006350 <unknown-module>+00000000
[ 20] 0x00007f22fd0069fe <unknown-module>+00000000
[ 21] 0x00007f22fd0069fe <unknown-module>+00000000
[ 22] 0x00007f22fd006350 <unknown-module>+00000000
[ 23] 0x00007f22fd006350 <unknown-module>+00000000
[ 24] 0x00007f22fd006350 <unknown-module>+00000000
[ 25] 0x00007f22fd006706 <unknown-module>+00000000
[ 26] 0x00007f22fd006058 <unknown-module>+00000000
[ 27] 0x00007f22fd006058 <unknown-module>+00000000
[ 28] 0x00007f22fd006058 <unknown-module>+00000000
[ 29] 0x00007f22fd006058 <unknown-module>+00000000
[ 30] 0x00007f22fd006058 <unknown-module>+00000000
[ 31] 0x00007f22fd006058 <unknown-module>+00000000
[ 32] 0x00007f22fd006058 <unknown-module>+00000000
[ 33] 0x00007f22fd006058 <unknown-module>+00000000
[ 34] 0x00007f22fd006058 <unknown-module>+00000000
[ 35] 0x00007f22fd006058 <unknown-module>+00000000
[ 36] 0x00007f22fd006058 <unknown-module>+00000000
[ 37] 0x00007f22fd006058 <unknown-module>+00000000
[ 38] 0x00007f22fd006058 <unknown-module>+00000000
[ 39] 0x00007f22fd006058 <unknown-module>+00000000
[ 40] 0x00007f22fd006058 <unknown-module>+00000000
[ 41] 0x00007f22fd006706 <unknown-module>+00000000
[ 42] 0x00007f22fd006058 <unknown-module>+00000000
[ 43] 0x00007f22fd006058 <unknown-module>+00000000
[ 44] 0x00007f22fd006058 <unknown-module>+00000000
[ 45] 0x00007f22fd006058 <unknown-module>+00000000
[ 46] 0x00007f22fd006058 <unknown-module>+00000000
[ 47] 0x00007f22fd006058 <unknown-module>+00000000
[ 48] 0x00007f22fd006233 <unknown-module>+00000000
[ 49] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 50] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 51] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 52] 0x00007f230d68fc74 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06835316 JVM_DoPrivileged+00000676
[ 53] 0x00007f22fd012d98 <unknown-module>+00000000
[ 54] 0x00007f22fd006233 <unknown-module>+00000000
[ 55] 0x00007f22fd006233 <unknown-module>+00000000
[ 56] 0x00007f22fd0068e1 <unknown-module>+00000000
[ 57] 0x00007f22fd006233 <unknown-module>+00000000
[ 58] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 59] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 60] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 61] 0x00007f230d68fc74 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06835316 JVM_DoPrivileged+00000676
[ 62] 0x00007f22fd012d98 <unknown-module>+00000000
[ 63] 0x00007f22fd006233 <unknown-module>+00000000
[ 64] 0x00007f22fd0068e1 <unknown-module>+00000000
[ 65] 0x00007f22fd006058 <unknown-module>+00000000
[ 66] 0x00007f22fd006058 <unknown-module>+00000000
[ 67] 0x00007f22fd006058 <unknown-module>+00000000
[ 68] 0x00007f22fd006058 <unknown-module>+00000000
[ 69] 0x00007f22fd006058 <unknown-module>+00000000
[ 70] 0x00007f22fd006058 <unknown-module>+00000000
[ 71] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 72] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 73] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 74] 0x00007f230d609627 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284839
[ 75] 0x00007f230d609747 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06285127
[ 76] 0x00007f230d6861d5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06795733
[ 77] 0x00007f230d963bdf /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+09800671
[ 78] 0x00007f230d963ce5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+09800933
[ 79] 0x00007f230d82a7f8 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+08517624
[ 80] 0x00007f232d73d494 /lib64/libpthread.so.0+00029844
[ 81] 0x00007f232d4825dd /lib64/libc.so.6+00955869 clone+00000109
[ 82] 0x0000000000000000 <unknown-module>+00000000
If this problem is reproducible, please submit a Service Request via:
http://www.mathworks.com/support/contact_us/
A technical support engineer might contact you with further information.
Thank you for your help.
여기에 해당하는 "java.log.4121"이 있습니다.
Operating System: Linux 4.4.6-gentoo #6 SMP Sun Sep 18 16:32:36 MDT 2016 x86_64
Processor ID: x86 Family 6 Model 42 Stepping 7, GenuineIntel
Host Name: q
FATAL ERROR in native method: Nativewindow X11 IOError: Display 0x7f230b054450 (:0): Resource temporarily unavailable
at sun.java2d.loops.Blit.Blit(Native Method)
at sun.java2d.pipe.DrawImage.blitSurfaceData(Unknown Source)
at sun.java2d.pipe.DrawImage.renderImageCopy(Unknown Source)
at sun.java2d.pipe.DrawImage.copyImage(Unknown Source)
at sun.java2d.pipe.DrawImage.copyImage(Unknown Source)
at sun.java2d.pipe.ValidatePipe.copyImage(Unknown Source)
at sun.java2d.SunGraphics2D.copyImage(Unknown Source)
at sun.java2d.SunGraphics2D.drawImage(Unknown Source)
at sun.java2d.SunGraphics2D.drawImage(Unknown Source)
at com.jogamp.opengl.awt.GLJPanel$OffscreenBackend.doPaintComponent(GLJPanel.java:2101)
at com.jogamp.opengl.awt.GLJPanel.paintComponent(GLJPanel.java:568)
at com.mathworks.hg.peer.JavaSceneServerGLJPanel.paintComponent(JavaSceneServerGLJPanel.java:147)
at javax.swing.JComponent.paint(Unknown Source)
at javax.swing.JComponent.paintChildren(Unknown Source)
- locked <0x00000000e81d1210> (a java.awt.Component$AWTTreeLock)
at javax.swing.JComponent.paint(Unknown Source)
at javax.swing.JComponent.paintChildren(Unknown Source)
- locked <0x00000000e81d1210> (a java.awt.Component$AWTTreeLock)
at javax.swing.JComponent.paint(Unknown Source)
at java.awt.GraphicsCallback$PaintCallback.run(Unknown Source)
at sun.awt.SunGraphicsCallback.runOneComponent(Unknown Source)
at sun.awt.SunGraphicsCallback.runComponents(Unknown Source)
at java.awt.Container.paint(Unknown Source)
at java.awt.Window.paint(Unknown Source)
at sun.awt.RepaintArea.paintComponent(Unknown Source)
at sun.awt.X11.XRepaintArea.paintComponent(Unknown Source)
at sun.awt.RepaintArea.paint(Unknown Source)
at sun.awt.X11.XComponentPeer.handleEvent(Unknown Source)
at java.awt.Component.dispatchEventImpl(Unknown Source)
at java.awt.Container.dispatchEventImpl(Unknown Source)
at java.awt.Window.dispatchEventImpl(Unknown Source)
at java.awt.Component.dispatchEvent(Unknown Source)
at java.awt.EventQueue.dispatchEventImpl(Unknown Source)
at java.awt.EventQueue.access$200(Unknown Source)
at java.awt.EventQueue$3.run(Unknown Source)
at java.awt.EventQueue$3.run(Unknown Source)
at java.security.AccessController.doPrivileged(Native Method)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.awt.EventQueue$4.run(Unknown Source)
at java.awt.EventQueue$4.run(Unknown Source)
at java.security.AccessController.doPrivileged(Native Method)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.awt.EventQueue.dispatchEvent(Unknown Source)
at java.awt.EventDispatchThread.pumpOneEventForFilters(Unknown Source)
at java.awt.EventDispatchThread.pumpEventsForFilter(Unknown Source)
at java.awt.EventDispatchThread.pumpEventsForHierarchy(Unknown Source)
at java.awt.EventDispatchThread.pumpEvents(Unknown Source)
at java.awt.EventDispatchThread.pumpEvents(Unknown Source)
at java.awt.EventDispatchThread.run(Unknown Source)
이 시점에서 저는 그것이 그래픽 문제라고 확신합니다. OpenGL 소프트웨어 렌더링도 시도해 보았습니다. 프로젝트 책임자는 커널이 전체 시스템을 제거하므로 커널에 문제가 있을 수 있다고 제안했습니다. 이 시점에서 그는 계속 진행할 수 있도록 다른 환경으로 전환하기를 원하지만 여전히 알고 싶습니다. 젠투에 무슨 일이 일어나고 있는 걸까요?
제가 생각했던 것 중 하나는 DE가 없고 타일링 WM(굉장한 3.5)만 있다는 것이었습니다. 이것이 문제를 일으킬지는 모르겠습니다. 그냥 생각만 하면 됩니다.
제가 작업하는 내용은 다음과 같습니다.
Matlab2016a
최고 3.5
젠투-4.4.6
인텔 2760M
Quadro 2000M (이건 안쓰는거 같네요)
20GB RAM
이러한 부품에 대한 표준 드라이버가 무엇이든 함께
그 밖에 필요한 것이 있으면 알려주시기 바랍니다.
