안녕하세요 여러분 :) 저는 Raspberry Pi를 메일 서버로 설정하기 위해 실험하고 있습니다. 저는 집에 Dual Stack Lite만 있기 때문에 dynv6.net을 IPv6 전용 동적 DNS 공급자로 사용하고 있습니다. 이메일 서버에 필요한 포트가 열려 있습니다. 그리고 내가 이메일을 보낼 수 있는 곳은[이메일 보호됨]Pi(IPv6 사용)를 통해 정상적으로 도착합니다. 하지만 외부로부터 어떤 이메일도 받을 수 없습니다. 해당 도메인에 대해 DNS MX 레코드가 설정됩니다. 지금까지 이메일 제공업체로부터 어떤 오류도 받지 못했습니다. 실수를 찾는 데 도움을 주실 수 있나요? 다음은 postfix의 main.cf입니다.
## See /usr/share/postfix/main.cf.dist for a commented, more complete version
inet_protocols = ipv6
# Debian specific: Specifying a file name will cause the first
# line of that file to be used as the name. The Debian default
# is /etc/mailname.
#myorigin = /etc/mailname
smtpd_banner = $myhostname ESMTP $mail_name (Raspbian)
biff = no
# appending .domain is the MUA's job.
append_dot_mydomain = no
# Uncomment the next line to generate "delayed mail" warnings
#delay_warning_time = 4h
readme_directory = no
# See http://www.postfix.org/COMPATIBILITY_README.html -- default to 2 on
# fresh installs.
compatibility_level = 2
# TLS parameters
smtpd_tls_cert_file=/etc/ssl/certs/emailserv.crt
smtpd_tls_key_file=/etc/ssl/private/emailserv.key
smtpd_use_tls=yes
smtpd_tls_session_cache_database = btree:${data_directory}/smtpd_scache
smtp_tls_session_cache_database = btree:${data_directory}/smtp_scache
smtpd_tls_received_header = yes
smtpd_tls_mandatory_protocols = SSLv3, TLSv1
smtpd_tls_mandatory_ciphers = medium
smtpd_tls_auth_only = yes
tls_random_source = dev:/dev/urandom
# See /usr/share/doc/postfix/TLS_README.gz in the postfix-doc package for
# information on enabling SSL in the smtp client.
smtpd_relay_restrictions = permit_mynetworks permit_sasl_authenticated defer_unauth_destination
myhostname = Kaito-RasPi
mydomain = futuregadgetlab.dynv6.net
alias_maps = hash:/etc/aliases
alias_database = hash:/etc/aliases
mydestination = $myhostname, Kaito-RasPi, localhost.localdomain, localhost, futuregadgetlab.dynv6.net
#relayhost =
mynetworks = 127.0.0.0/8 [::ffff:127.0.0.0]/104 [::1]/128
mailbox_size_limit = 0
recipient_delimiter = +
inet_interfaces = all
#inet_protocols = all
home_mailbox = Maildir/
smtpd_sasl_auth_enable = yes
smtpd_sasl_type = dovecot
smtpd_sasl_path = private/dovecot-auth
smtpd_sasl_authenticated_header = yes
smtpd_sasl_local_domain = $myhostname
broken_sasl_auth_clients = yes
smtpd_recipient_restrictions = reject_unknown_sender_domain reject_unknown_recipient_domain reject_unauth_pipelining permit_mynetworks permit_sasl_authenticated reject_unauth_destination
smtpd_sender_restrictions = reject_unknown_sender_domain permit_sasl_authenticated
mailbox_command = /usr/lib/dovecot/deliver -c /etc/dovecot/conf.d/01-mail-stack-delivery.conf -m "${EXTENSION}"
virtual_alias_maps = hash:/etc/postfix/virtual
여기 master.cf:
#
# Postfix master process configuration file. For details on the format
# of the file, see the master(5) manual page (command: "man 5 master" or
# on-line: http://www.postfix.org/master.5.html).
#
# Do not forget to execute "postfix reload" after editing this file.
#
# ==========================================================================
# service type private unpriv chroot wakeup maxproc command + args
# (yes) (yes) (no) (never) (100)
# ==========================================================================
smtp inet n - y - - smtpd
smtps inet n - y - - smtpd
#smtp inet n - y - 1 postscreen
#smtpd pass - - y - - smtpd
#dnsblog unix - - y - 0 dnsblog
#tlsproxy unix - - y - 0 tlsproxy
submission inet n - y - - smtpd
# -o syslog_name=postfix/submission
# -o smtpd_tls_security_level=encrypt
# -o smtpd_sasl_auth_enable=yes
# -o smtpd_reject_unlisted_recipient=no
# -o smtpd_client_restrictions=permit_sasl_authenticated,reject
# -o smtpd_helo_restrictions=$mua_helo_restrictions
# -o smtpd_sender_restrictions=$mua_sender_restrictions
# -o smtpd_recipient_restrictions=
# -o smtpd_relay_restrictions=permit_sasl_authenticated,reject
# -o milter_macro_daemon_name=ORIGINATING
#smtps inet n - y - - smtpd
# -o syslog_name=postfix/smtps
# -o smtpd_tls_wrappermode=yes
# -o smtpd_sasl_auth_enable=yes
# -o smtpd_reject_unlisted_recipient=no
# -o smtpd_client_restrictions=$mua_client_restrictions
# -o smtpd_helo_restrictions=$mua_helo_restrictions
# -o smtpd_sender_restrictions=$mua_sender_restrictions
# -o smtpd_recipient_restrictions=
# -o smtpd_relay_restrictions=permit_sasl_authenticated,reject
# -o milter_macro_daemon_name=ORIGINATING
#628 inet n - y - - qmqpd
pickup unix n - y 60 1 pickup
cleanup unix n - y - 0 cleanup
qmgr unix n - n 300 1 qmgr
#qmgr unix n - n 300 1 oqmgr
tlsmgr unix - - y 1000? 1 tlsmgr
rewrite unix - - y - - trivial-rewrite
bounce unix - - y - 0 bounce
defer unix - - y - 0 bounce
trace unix - - y - 0 bounce
verify unix - - y - 1 verify
flush unix n - y 1000? 0 flush
proxymap unix - - n - - proxymap
proxywrite unix - - n - 1 proxymap
smtp unix - - y - - smtp
relay unix - - y - - smtp
# -o smtp_helo_timeout=5 -o smtp_connect_timeout=5
showq unix n - y - - showq
error unix - - y - - error
retry unix - - y - - error
discard unix - - y - - discard
local unix - n n - - local
virtual unix - n n - - virtual
lmtp unix - - y - - lmtp
anvil unix - - y - 1 anvil
scache unix - - y - 1 scache
#
# ====================================================================
# Interfaces to non-Postfix software. Be sure to examine the manual
# pages of the non-Postfix software to find out what options it wants.
#
# Many of the following services use the Postfix pipe(8) delivery
# agent. See the pipe(8) man page for information about ${recipient}
# and other message envelope options.
# ====================================================================
#
# maildrop. See the Postfix MAILDROP_README file for details.
# Also specify in main.cf: maildrop_destination_recipient_limit=1
#
maildrop unix - n n - - pipe
flags=DRhu user=vmail argv=/usr/bin/maildrop -d ${recipient}
#
# ====================================================================
#
# Recent Cyrus versions can use the existing "lmtp" master.cf entry.
#
# Specify in cyrus.conf:
# lmtp cmd="lmtpd -a" listen="localhost:lmtp" proto=tcp4
#
# Specify in main.cf one or more of the following:
# mailbox_transport = lmtp:inet:localhost
# virtual_transport = lmtp:inet:localhost
#
# ====================================================================
#
# Cyrus 2.1.5 (Amos Gouaux)
# Also specify in main.cf: cyrus_destination_recipient_limit=1
#
#cyrus unix - n n - - pipe
# user=cyrus argv=/cyrus/bin/deliver -e -r ${sender} -m ${extension} ${user}
#
# ====================================================================
# Old example of delivery via Cyrus.
#
#old-cyrus unix - n n - - pipe
# flags=R user=cyrus argv=/cyrus/bin/deliver -e -m ${extension} ${user}
#
# ====================================================================
#
# See the Postfix UUCP_README file for configuration details.
#
uucp unix - n n - - pipe
flags=Fqhu user=uucp argv=uux -r -n -z -a$sender - $nexthop!rmail ($recipient)
#
# Other external delivery methods.
#
ifmail unix - n n - - pipe
flags=F user=ftn argv=/usr/lib/ifmail/ifmail -r $nexthop ($recipient)
bsmtp unix - n n - - pipe
flags=Fq. user=bsmtp argv=/usr/lib/bsmtp/bsmtp -t$nexthop -f$sender $recipient
scalemail-backend unix - n n - 2 pipe
flags=R user=scalemail argv=/usr/lib/scalemail/bin/scalemail-store ${nexthop} ${user} ${extension}
mailman unix - n n - - pipe
flags=FR user=list argv=/usr/lib/mailman/bin/postfix-to-mailman.py
${nexthop} ${user}
답변1
dynv6.net문제는 권한 있는 DNS 서버가 손상된 DNS 응답을 보내는 것 같습니다 . MX 레코드를 처음 해결하려고 시도했을 때 본 내용은 다음과 같습니다.
$ dig mx futuregadgetlab.dynv6.net
; <<>> DiG 9.10.3-P4-Ubuntu <<>> mx futuregadgetlab.dynv6.net
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: SERVFAIL, id: 7934
;; flags: qr rd ra; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 1
;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;futuregadgetlab.dynv6.net. IN MX
;; Query time: 219 msec
;; SERVER: 127.0.1.1#53(127.0.1.1)
;; WHEN: Mon Oct 09 08:19:58 BST 2017
;; MSG SIZE rcvd: 54
나는 모두 나에게 동일한 SERVFAIL응답을 제공하는 몇 가지 다른 반복자를 테스트했습니다. 도메인으로 메일을 보내려는 시스템은 문제가 해결될 때까지 메일을 대기열에 보관합니다. 문제가 며칠 동안 지속되면 메일이 반송됩니다.
응답을 받은 이유를 알아보기 위해 SERVFAIL루트부터 시작하여 아래로 수동으로 조회를 수행했습니다. 도착했을 때 ns1.dynv6.net손상된 DNS 응답 패킷에 대한 경고를 받았습니다.
$ dig +norecurse mx futuregadgetlab.dynv6.net @ns1.dynv6.net
;; Warning: Message parser reports malformed message packet.
; <<>> DiG 9.10.3-P4-Ubuntu <<>> +norecurse mx futuregadgetlab.dynv6.net @ns1.dynv6.net
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 25407
;; flags: qr aa; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 0
;; WARNING: Message has 2 extra bytes at end
;; QUESTION SECTION:
;futuregadgetlab.dynv6.net. IN MX
;; Query time: 19 msec
;; SERVER: 2a03:4000:10:1db::#53(2a03:4000:10:1db::)
;; WHEN: Mon Oct 09 08:23:22 BST 2017
;; MSG SIZE rcvd: 82
DNS 서버가 dynv6.net수정될 때까지 합법적인 이메일이 통과할 것이라고 기대해서는 안 됩니다. 문제는 MX조회에만 영향을 미치는 것 같습니다. 적어도 조회 A는 AAAA잘 작동합니다. 그리고 조회에서 주소의 포트 25에 연결하는 것도 AAAA작동합니다.
