Centos7 시스템에서 Gnome과 함께 두 개의 별도 그래픽 어댑터를 활용하려고 합니다. lspci는 이러한 두 어댑터를 다음과 같이 식별합니다.
06:00.0 VGA 호환 컨트롤러: NVIDIA Corporation GF119 [GeForce GT 610] (rev a1) 하위 시스템: eVga.com. Corp. Device 2616 사용중인 커널 드라이버 : nouveau 커널 모듈 : nouveau
07:03.0 VGA 호환 컨트롤러: Matrox Electronics Systems Ltd. MGA G200eW WPCM450(rev 0a) 하위 시스템: Dell PowerEdge R710 MGA G200eW WPCM450 사용 중인 커널 드라이버: mgag200 커널 모듈: mgag200
/usr/share/X11/xorg.conf.d/10-radeon.conf에는 다음이 포함되어 있습니다:
Section "OutputClass"
Identifier "Radeon"
MatchDriver "radeon"
Driver "radeon"
EndSection
온보드 Radeon 카드를 사용하면 올바르게 작동합니다(시스템은 Dell R710입니다). 그런 다음 /usr/share/X11/xorg.conf.d/20-nouveau.conf라는 새 파일을 생성했습니다.
Section "Device"
Identifier "Nvidia card"
Driver "nouveau"
BusID "PCI:6:0:0"
EndSection
"systemctl restart gdm"을 실행하면 이제 GT610에 로그인 화면이 표시되지만(이 비디오 어댑터에 두 개의 모니터가 연결되어 있음) Radeon이 작동을 멈춥니다. /var/log에 생성된 유일한 Xorg 로그 파일은 Xorg.0.log입니다. 살펴보면 LAYOUT 섹션과 SCREEN 섹션이 필요한 것 같습니다. 나는 몇 가지 다른 것을 시도했지만 이것이 올바르게 작동하도록 할 수 없습니다. 내 실험에서 나는 내가 무엇을 하든 라데온 카드가 "장치" 섹션에서 작동하도록 할 수 없다는 것을 발견했습니다. 이는 "OutputClass" 섹션에서만 작동합니다. 이것은 다음 문제를 배제하는 문제를 나타냅니다. 올바른 레이아웃/화면 섹션이 있나요? 또한 xrandr --listproviders는 다음을 보여줍니다.
Providers: number : 0
이것은 올바른 레이아웃/화면 구성에 집중하기 전에 수정이 필요한지 궁금합니다.
내가 여기서 무엇을 놓치고 있는지 아는 사람이 있나요? 두 어댑터를 동일한 화면에 연결할 필요는 없습니다. 사실 별도의 로그인 인스턴스로 실행하는 것을 선호합니다(하나는 컴퓨터 랙에 있고 다른 하나는 원격 화면/키보드에 있음).
가상 머신에서 사용하기 위해 스텁아웃된 또 다른 비디오 카드(GT710)가 있는데, 이것과 관련이 있을지 의심스럽습니다. 그러나 이에 대해 언급할 것이라고 생각했습니다. lshw -C 디스플레이에는 다음이 확인되어 표시됩니다.
*-display
description: VGA compatible controller
product: GK208B [GeForce GT 710]
vendor: NVIDIA Corporation
physical id: 0
bus info: pci@0000:04:00.0
version: a1
width: 64 bits
clock: 33MHz
capabilities: pm msi pciexpress vga_controller cap_list rom
configuration: driver=pci-stub latency=0
resources: irq:15 memory:db000000-dbffffff memory:b8000000-bfffffff memory:b6000000-b7ffffff ioport:ec80(size=128) memory:da000000-da07ffff
*-display
description: VGA compatible controller
product: GF119 [GeForce GT 610]
vendor: NVIDIA Corporation
physical id: 0
bus info: pci@0000:06:00.0
version: a1
width: 64 bits
clock: 33MHz
capabilities: pm msi pciexpress vga_controller bus_master cap_list rom
configuration: driver=nouveau latency=0
resources: irq:48 memory:dd000000-ddffffff memory:c8000000-cfffffff memory:c6000000-c7ffffff ioport:dc80(size=128) memory:dc000000-dc07ffff
*-display
description: VGA compatible controller
product: MGA G200eW WPCM450
vendor: Matrox Electronics Systems Ltd.
physical id: 3
bus info: pci@0000:07:03.0
version: 0a
width: 32 bits
clock: 33MHz
capabilities: pm vga_controller bus_master cap_list rom
configuration: driver=mgag200 latency=32 maxlatency=32 mingnt=16
resources: irq:19 memory:d0000000-d07fffff memory:de7fc000-de7fffff memory:de800000-deffffff memory:de000000-de00ffff
Xorg.0.log에는 다음 내용이 포함되어 있습니다(전체 로그 파일이 너무 커서 붙여넣을 수 없음).
[ 28082.211]
X.Org X Server 1.20.4
X Protocol Version 11, Revision 0
[ 28082.211] Build Operating System: 3.10.0-957.1.3.el7.x86_64
[ 28082.211] Current Operating System: Linux svr 3.10.0-1062.1.1.el7.x86_64 #1 SMP Fri Sep 13 22:55:44 UTC 2019 x86_64
[ 28082.211] Kernel command line: BOOT_IMAGE=/vmlinuz-3.10.0-1062.1.1.el7.x86_64 root=UUID=df548a45-26e2-448c-8c6a-964a8bcd1b6b crashkernel=256M intel_iommu=on pci-stub.ids=10de:128b,10de:0e0f vfio_iommu_type1.allow_unsafe_interrupts=1
[ 28082.211] Build Date: 09 August 2019 03:27:09AM
[ 28082.211] Build ID: xorg-x11-server 1.20.4-7.el7
[ 28082.211] Current version of pixman: 0.34.0
[ 28082.211] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 28082.211] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 28082.211] (==) Log file: "/var/log/Xorg.0.log", Time: Sat Mar 14 10:46:18 2020
[ 28082.212] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 28082.212] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 28082.212] (==) No Layout section. Using the first Screen section.
[ 28082.212] (==) No screen section available. Using defaults.
[ 28082.212] (**) |-->Screen "Default Screen Section" (0)
[ 28082.212] (**) | |-->Monitor "<default monitor>"
[ 28082.212] (==) No device specified for screen "Default Screen Section".
Using the first device section listed.
[ 28082.212] (**) | |-->Device "Nvidia card"
[ 28082.212] (==) No monitor specified for screen "Default Screen Section".
Using a default monitor configuration.
[ 28082.213] (==) Automatically adding devices
[ 28082.213] (==) Automatically enabling devices
[ 28082.213] (==) Automatically adding GPU devices
[ 28082.213] (==) Automatically binding GPU devices
답변1
여기에 업데이트가 있습니다... 10-radeon.conf 및 20-nouveau.conf를 제거하고 여기에서 모든 비디오 구성에 대해 20-vid.conf를 만들었습니다. 내가 시도하고 있는 것을 추적하는 것이 더 쉽습니다. 현재 로그 파일에서는 라데온이 오류 없이 인식된 것처럼 보이지만 화면은 비어 있습니다. 이전에는 작동하지 않을 때 왼쪽 상단에 커서가 있었습니다. 이제 화면이 완전히 어두워졌습니다. 나는 이것이 긍정적인 진전의 표시라고 생각한다. NVIDIA 카드가 활성화되기 전에는 라데온 카드의 VGA 모니터가 어떤 방식으로도 감지되지 않았습니다. 이제 로그 파일에 모니터와 어댑터 이름이 인식된 것을 볼 수 있으며, 라데온은 OUTPUTCLASS가 아닌 DEVICE로 정의되어 있습니다.
또한 이제 xrandr --listproviders에 정보가 있습니다.
[user@svr ~]$ xrandr --listproviders
Providers: number : 1
Provider 0: id: 0x64 cap: 0x7, Source Output, Sink Output, Source Offload crtcs: 2 outputs: 3 associated providers: 0 name:nouveau
점점 가까워지고 있는 것 같은 느낌이 들지만, 여전히 뭔가가 그리워요. 그게 뭔지 아는 사람 있나요?
이제 xorg 구성은 다음과 같습니다.
Section "Module"
Load "modesetting"
EndSection
Section "Monitor"
Identifier "Monitor0"
EndSection
Section "Monitor"
Identifier "Monitor1"
EndSection
Section "Monitor"
Identifier "Monitor2"
EndSection
Section "Screen"
Identifier "Screen 0"
Device "Nvidia card"
Monitor "Monitor0"
EndSection
Section "Screen"
Identifier "Screen 1"
Device "Nvidia card"
Monitor "Monitor1"
EndSection
Section "Screen"
Identifier "Screen 2"
Device "radeon"
Monitor "Monitor2"
EndSection
Section "ServerLayout"
Identifier "Main Layout"
Screen 0 "Screen 0"
Screen 1 "Screen 1"
Screen 2 "Screen 2"
EndSection
Section "Device"
Identifier "Radeon"
#MatchDriver "radeon"
Driver "modesetting"
BusID "PCI:7:3:0"
EndSection
Section "Device"
Identifier "Nvidia card"
Driver "nouveau"
BusID "PCI:6:0:0"
EndSection
그리고 이것은 xorg.0.log 파일의 일부입니다. 이것이 새로운 게시물이므로 이번에는 더 많은 내용을 포함할 수 있습니다.
[ 34847.284] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 34847.284] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 34847.285] (==) ServerLayout "Main Layout"
[ 34847.285] (**) |-->Screen "Screen 0" (0)
[ 34847.285] (**) | |-->Monitor "Monitor0"
[ 34847.285] (**) | |-->Device "Nvidia card"
[ 34847.285] (**) |-->Screen "Screen 1" (1)
[ 34847.285] (**) | |-->Monitor "Monitor1"
[ 34847.286] (**) | |-->Device "Nvidia card"
[ 34847.286] (**) |-->Screen "Screen 2" (2)
[ 34847.286] (**) | |-->Monitor "Monitor2"
[ 34847.286] (**) | |-->Device "Radeon"
[ 34847.286] (==) Automatically adding devices
[ 34847.286] (==) Automatically enabling devices
[ 34847.286] (==) Automatically adding GPU devices
[ 34847.286] (==) Automatically binding GPU devices
[ 34847.286] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 34847.286] (==) FontPath set to:
catalogue:/etc/X11/fontpath.d,
built-ins
[ 34847.286] (==) ModulePath set to "/usr/lib64/xorg/modules"
[ 34847.286] (II) The server relies on udev to provide the list of input devices.
If no devices become available, reconfigure udev or disable AutoAddDevices.
[ 34847.286] (II) Loader magic: 0x5650e5f28020
[ 34847.286] (II) Module ABI versions:
[ 34847.286] X.Org ANSI C Emulation: 0.4
[ 34847.286] X.Org Video Driver: 24.0
[ 34847.286] X.Org XInput driver : 24.1
[ 34847.286] X.Org Server Extension : 10.0
[ 34847.287] (II) xfree86: Adding drm device (/dev/dri/card1)
[ 34847.288] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 34847.309] (--) PCI: (4@0:0:0) 10de:128b:3842:2713 rev 161, Mem @ 0xdb000000/16777216, 0xb8000000/134217728, 0xb6000000/33554432, I/O @ 0x0000ec80/128, BIOS @ 0x????????/524288
[ 34847.309] (--) PCI: (6@0:0:0) 10de:104a:3842:2616 rev 161, Mem @ 0xdd000000/16777216, 0xc8000000/134217728, 0xc6000000/33554432, I/O @ 0x0000dc80/128, BIOS @ 0x????????/524288
[ 34847.309] (--) PCI:*(7@0:3:0) 102b:0532:1028:0235 rev 10, Mem @ 0xd0000000/8388608, 0xde7fc000/16384, 0xde800000/8388608, BIOS @ 0x????????/65536
[ 34847.309] (II) "glx" will be loaded by default.
[ 34847.309] (II) LoadModule: "modesetting"
[ 34847.309] (II) Loading /usr/lib64/xorg/modules/drivers/modesetting_drv.so
[ 34847.309] (II) Module modesetting: vendor="X.Org Foundation"
[ 34847.309] compiled for 1.20.4, module version = 1.20.4
[ 34847.309] Module class: X.Org Video Driver
[ 34847.309] ABI class: X.Org Video Driver, version 24.0
[ 34847.309] (II) LoadModule: "glx"
[ 34847.310] (II) Loading /usr/lib64/xorg/modules/extensions/libglx.so
[ 34847.311] (II) Module glx: vendor="X.Org Foundation"
[ 34847.311] compiled for 1.20.4, module version = 1.0.0
[ 34847.311] ABI class: X.Org Server Extension, version 10.0
[ 34847.311] (II) LoadModule: "nouveau"
[ 34847.312] (II) Loading /usr/lib64/xorg/modules/drivers/nouveau_drv.so
[ 34847.312] (II) Module nouveau: vendor="X.Org Foundation"
[ 34847.312] compiled for 1.20.1, module version = 1.0.15
[ 34847.312] Module class: X.Org Video Driver
[ 34847.312] ABI class: X.Org Video Driver, version 24.0
[ 34847.312] (II) LoadModule: "modesetting"
[ 34847.312] (II) Loading /usr/lib64/xorg/modules/drivers/modesetting_drv.so
[ 34847.312] (II) Module modesetting: vendor="X.Org Foundation"
[ 34847.312] compiled for 1.20.4, module version = 1.20.4
[ 34847.312] Module class: X.Org Video Driver
[ 34847.312] ABI class: X.Org Video Driver, version 24.0
[ 34847.312] (II) UnloadModule: "modesetting"
[ 34847.312] (II) Unloading modesetting
[ 34847.312] (II) Failed to load module "modesetting" (already loaded, 0)
[ 34847.312] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
[ 34847.312] (II) NOUVEAU driver
[ 34847.312] (II) NOUVEAU driver for NVIDIA chipset families :
[ 34847.312] RIVA TNT (NV04)
[ 34847.312] RIVA TNT2 (NV05)
[ 34847.312] GeForce 256 (NV10)
[ 34847.312] GeForce 2 (NV11, NV15)
[ 34847.313] GeForce 4MX (NV17, NV18)
[ 34847.313] GeForce 3 (NV20)
[ 34847.313] GeForce 4Ti (NV25, NV28)
[ 34847.313] GeForce FX (NV3x)
[ 34847.313] GeForce 6 (NV4x)
[ 34847.313] GeForce 7 (G7x)
[ 34847.313] GeForce 8 (G8x)
[ 34847.313] GeForce GTX 200 (NVA0)
[ 34847.313] GeForce GTX 400 (NVC0)
[ 34847.313] (++) using VT number 1
[ 34847.348] (II) modeset(0): using drv /dev/dri/card0
[ 34847.348] (II) [drm] nouveau interface version: 1.3.1
[ 34847.348] (II) Loading sub module "dri2"
[ 34847.348] (II) LoadModule: "dri2"
[ 34847.348] (II) Module "dri2" already built-in
[ 34847.349] (--) NOUVEAU(0): Chipset: "NVIDIA NVD9"
[ 34847.349] (II) NOUVEAU(0): Creating default Display subsection in Screen section
"Screen 0" for depth/fbbpp 24/32
[ 34847.349] (==) NOUVEAU(0): Depth 24, (--) framebuffer bpp 32
[ 34847.349] (==) NOUVEAU(0): RGB weight 888
[ 34847.349] (==) NOUVEAU(0): Default visual is TrueColor
[ 34847.349] (==) NOUVEAU(0): Using HW cursor
[ 34847.349] (==) NOUVEAU(0): Allowed maximum DRI level 2.
[ 34847.349] (==) NOUVEAU(0): GLX sync to VBlank enabled.
[ 34847.349] (==) NOUVEAU(0): Page flipping enabled
[ 34847.349] (==) NOUVEAU(0): Swap limit set to 1 [Max allowed 2]
[ 34847.349] (==) NOUVEAU(0): Page flipping synced to vblank by kernel.
[ 34847.349] (II) NOUVEAU(0): Initializing outputs ...
[ 34847.393] (II) NOUVEAU(0): Output DVI-I-1 using monitor section Monitor0
[ 34847.439] (II) NOUVEAU(0): Output DVI-I-2 has no monitor section
[ 34847.440] (II) NOUVEAU(0): Output HDMI-1 has no monitor section
[ 34847.440] (II) NOUVEAU(0): 3 crtcs needed for screen.
[ 34847.441] (II) NOUVEAU(0): Allocated crtc nr. 0 to this screen.
[ 34847.441] (II) NOUVEAU(0): Allocated crtc nr. 1 to this screen.
[ 34847.486] (II) NOUVEAU(0): EDID for output DVI-I-1
[ 34847.486] (II) NOUVEAU(0): Manufacturer: DEL Model: 4079 Serial#: 1094206284
[ 34847.486] (II) NOUVEAU(0): Year: 2012 Week: 49
[ 34847.486] (II) NOUVEAU(0): EDID Version: 1.3
[ 34847.486] (II) NOUVEAU(0): Digital Display Input
[ 34847.486] (II) NOUVEAU(0): Max Image Size [cm]: horiz.: 44 vert.: 25
[ 34847.486] (II) NOUVEAU(0): Gamma: 2.20
[ 34847.486] (II) NOUVEAU(0): DPMS capabilities: StandBy Suspend Off
[ 34847.486] (II) NOUVEAU(0): Supported color encodings: RGB 4:4:4 YCrCb 4:4:4
[ 34847.486] (II) NOUVEAU(0): First detailed timing is preferred mode
[ 34847.486] (II) NOUVEAU(0): redX: 0.636 redY: 0.339 greenX: 0.319 greenY: 0.618
[ 34847.486] (II) NOUVEAU(0): blueX: 0.154 blueY: 0.049 whiteX: 0.313 whiteY: 0.329
[ 34847.486] (II) NOUVEAU(0): Supported established timings:
[ 34847.486] (II) NOUVEAU(0): 720x400@70Hz
[ 34847.486] (II) NOUVEAU(0): 640x480@60Hz
[ 34847.486] (II) NOUVEAU(0): 640x480@75Hz
[ 34847.486] (II) NOUVEAU(0): 800x600@60Hz
[ 34847.486] (II) NOUVEAU(0): 800x600@75Hz
[ 34847.486] (II) NOUVEAU(0): 1024x768@60Hz
[ 34847.486] (II) NOUVEAU(0): 1024x768@75Hz
[ 34847.486] (II) NOUVEAU(0): 1280x1024@75Hz
[ 34847.486] (II) NOUVEAU(0): Manufacturer's mask: 0
[ 34847.486] (II) NOUVEAU(0): Supported standard timings:
[ 34847.486] (II) NOUVEAU(0): #0: hsize: 1152 vsize 864 refresh: 75 vid: 20337
[ 34847.486] (II) NOUVEAU(0): #1: hsize: 1280 vsize 1024 refresh: 60 vid: 32897
[ 34847.486] (II) NOUVEAU(0): #2: hsize: 1600 vsize 900 refresh: 60 vid: 49321
[ 34847.486] (II) NOUVEAU(0): Supported detailed timing:
[ 34847.486] (II) NOUVEAU(0): clock: 97.8 MHz Image Size: 443 x 249 mm
[ 34847.486] (II) NOUVEAU(0): h_active: 1600 h_sync: 1648 h_sync_end 1680 h_blank_end 1760 h_border: 0
[ 34847.486] (II) NOUVEAU(0): v_active: 900 v_sync: 903 v_sync_end 908 v_blanking: 926 v_border: 0
[ 34847.486] (II) NOUVEAU(0): Serial No: W5HWR2C7A8CL
[ 34847.486] (II) NOUVEAU(0): Monitor name: DELL P2012H
[ 34847.486] (II) NOUVEAU(0): Ranges: V min: 56 V max: 76 Hz, H min: 30 H max: 83 kHz, PixClock max 175 MHz
[ 34847.486] (II) NOUVEAU(0): EDID (in hex):
[ 34847.486] (II) NOUVEAU(0): 00ffffffffffff0010ac79404c433841
[ 34847.486] (II) NOUVEAU(0): 31160103802c1978eafda5a256519e27
[ 34847.486] (II) NOUVEAU(0): 0c5054a54b00714f8180a9c001010101
[ 34847.486] (II) NOUVEAU(0): 0101010101012f2640a060841a303020
[ 34847.486] (II) NOUVEAU(0): 3500bbf91000001a000000ff00573548
[ 34847.486] (II) NOUVEAU(0): 57523243374138434c0a000000fc0044
[ 34847.486] (II) NOUVEAU(0): 454c4c205032303132480a20000000fd
[ 34847.486] (II) NOUVEAU(0): 00384c1e5311000a2020202020200002
[ 34847.486] (II) NOUVEAU(0): Printing probed modes for output DVI-I-1
[ 34847.486] (II) NOUVEAU(0): Modeline "1600x900"x60.0 97.75 1600 1648 1680 1760 900 903 908 926 +hsync -vsync (55.5 kHz eP)
[ 34847.486] (II) NOUVEAU(0): Modeline "1280x1024"x75.0 135.00 1280 1296 1440 1688 1024 1025 1028 1066 +hsync +vsync (80.0 kHz e)
[ 34847.486] (II) NOUVEAU(0): Modeline "1280x1024"x60.0 108.00 1280 1328 1440 1688 1024 1025 1028 1066 +hsync +vsync (64.0 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "1152x864"x75.0 108.00 1152 1216 1344 1600 864 865 868 900 +hsync +vsync (67.5 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "1024x768"x75.0 78.75 1024 1040 1136 1312 768 769 772 800 +hsync +vsync (60.0 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "1024x768"x60.0 65.00 1024 1048 1184 1344 768 771 777 806 -hsync -vsync (48.4 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "800x600"x75.0 49.50 800 816 896 1056 600 601 604 625 +hsync +vsync (46.9 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "800x600"x60.3 40.00 800 840 968 1056 600 601 605 628 +hsync +vsync (37.9 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "640x480"x75.0 31.50 640 656 720 840 480 481 484 500 -hsync -vsync (37.5 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "640x480"x59.9 25.18 640 656 752 800 480 490 492 525 -hsync -vsync (31.5 kHz e)
[ 34847.487] (II) NOUVEAU(0): Modeline "720x400"x70.1 28.32 720 738 846 900 400 412 414 449 -hsync +vsync (31.5 kHz e)
[ 34847.532] (II) NOUVEAU(0): EDID for output DVI-I-2
[ 34847.532] (II) NOUVEAU(0): Manufacturer: DEL Model: 4079 Serial#: 892678722
[ 34847.532] (II) NOUVEAU(0): Year: 2012 Week: 30
[ 34847.532] (II) NOUVEAU(0): EDID Version: 1.3
[ 34847.532] (II) NOUVEAU(0): Digital Display Input
[ 34847.532] (II) NOUVEAU(0): Max Image Size [cm]: horiz.: 44 vert.: 25
[ 34847.532] (II) NOUVEAU(0): Gamma: 2.20
[ 34847.532] (II) NOUVEAU(0): DPMS capabilities: StandBy Suspend Off
[ 34847.532] (II) NOUVEAU(0): Supported color encodings: RGB 4:4:4 YCrCb 4:4:4
[ 34847.532] (II) NOUVEAU(0): First detailed timing is preferred mode
[ 34847.532] (II) NOUVEAU(0): redX: 0.636 redY: 0.339 greenX: 0.319 greenY: 0.618
[ 34847.532] (II) NOUVEAU(0): blueX: 0.154 blueY: 0.049 whiteX: 0.313 whiteY: 0.329
[ 34847.532] (II) NOUVEAU(0): Supported established timings:
[ 34847.532] (II) NOUVEAU(0): 720x400@70Hz
[ 34847.532] (II) NOUVEAU(0): 640x480@60Hz
[ 34847.532] (II) NOUVEAU(0): 640x480@75Hz
[ 34847.532] (II) NOUVEAU(0): 800x600@60Hz
[ 34847.532] (II) NOUVEAU(0): 800x600@75Hz
[ 34847.532] (II) NOUVEAU(0): 1024x768@60Hz
[ 34847.532] (II) NOUVEAU(0): 1024x768@75Hz
[ 34847.532] (II) NOUVEAU(0): 1280x1024@75Hz
[ 34847.532] (II) NOUVEAU(0): Manufacturer's mask: 0
[ 34847.532] (II) NOUVEAU(0): Supported standard timings:
[ 34847.532] (II) NOUVEAU(0): #0: hsize: 1152 vsize 864 refresh: 75 vid: 20337
[ 34847.532] (II) NOUVEAU(0): #1: hsize: 1280 vsize 1024 refresh: 60 vid: 32897
[ 34847.532] (II) NOUVEAU(0): #2: hsize: 1600 vsize 900 refresh: 60 vid: 49321
[ 34847.532] (II) NOUVEAU(0): Supported detailed timing:
[ 34847.532] (II) NOUVEAU(0): clock: 97.8 MHz Image Size: 443 x 249 mm
[ 34847.532] (II) NOUVEAU(0): h_active: 1600 h_sync: 1648 h_sync_end 1680 h_blank_end 1760 h_border: 0
[ 34847.532] (II) NOUVEAU(0): v_active: 900 v_sync: 903 v_sync_end 908 v_blanking: 926 v_border: 0
[ 34847.532] (II) NOUVEAU(0): Serial No: 8VVND27Q552B
[ 34847.532] (II) NOUVEAU(0): Monitor name: DELL P2012H
[ 34847.532] (II) NOUVEAU(0): Ranges: V min: 56 V max: 76 Hz, H min: 30 H max: 83 kHz, PixClock max 175 MHz
[ 34847.532] (II) NOUVEAU(0): EDID (in hex):
[ 34847.532] (II) NOUVEAU(0): 00ffffffffffff0010ac794042323535
[ 34847.532] (II) NOUVEAU(0): 1e160103802c1978eafda5a256519e27
[ 34847.532] (II) NOUVEAU(0): 0c5054a54b00714f8180a9c001010101
[ 34847.532] (II) NOUVEAU(0): 0101010101012f2640a060841a303020
[ 34847.532] (II) NOUVEAU(0): 3500bbf91000001a000000ff00385656
[ 34847.532] (II) NOUVEAU(0): 4e44323751353532420a000000fc0044
[ 34847.533] (II) NOUVEAU(0): 454c4c205032303132480a20000000fd
[ 34847.533] (II) NOUVEAU(0): 00384c1e5311000a2020202020200062
[ 34847.533] (II) NOUVEAU(0): Printing probed modes for output DVI-I-2
[ 34847.533] (II) NOUVEAU(0): Modeline "1600x900"x60.0 97.75 1600 1648 1680 1760 900 903 908 926 +hsync -vsync (55.5 kHz eP)
[ 34847.533] (II) NOUVEAU(0): Modeline "1280x1024"x75.0 135.00 1280 1296 1440 1688 1024 1025 1028 1066 +hsync +vsync (80.0 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "1280x1024"x60.0 108.00 1280 1328 1440 1688 1024 1025 1028 1066 +hsync +vsync (64.0 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "1152x864"x75.0 108.00 1152 1216 1344 1600 864 865 868 900 +hsync +vsync (67.5 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "1024x768"x75.0 78.75 1024 1040 1136 1312 768 769 772 800 +hsync +vsync (60.0 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "1024x768"x60.0 65.00 1024 1048 1184 1344 768 771 777 806 -hsync -vsync (48.4 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "800x600"x75.0 49.50 800 816 896 1056 600 601 604 625 +hsync +vsync (46.9 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "800x600"x60.3 40.00 800 840 968 1056 600 601 605 628 +hsync +vsync (37.9 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "640x480"x75.0 31.50 640 656 720 840 480 481 484 500 -hsync -vsync (37.5 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "640x480"x59.9 25.18 640 656 752 800 480 490 492 525 -hsync -vsync (31.5 kHz e)
[ 34847.533] (II) NOUVEAU(0): Modeline "720x400"x70.1 28.32 720 738 846 900 400 412 414 449 -hsync +vsync (31.5 kHz e)
[ 34847.534] (II) NOUVEAU(0): EDID for output HDMI-1
[ 34847.534] (II) NOUVEAU(0): Output DVI-I-1 connected
[ 34847.534] (II) NOUVEAU(0): Output DVI-I-2 connected
[ 34847.534] (II) NOUVEAU(0): Output HDMI-1 disconnected
[ 34847.534] (II) NOUVEAU(0): Using spanning desktop for initial modes
[ 34847.534] (II) NOUVEAU(0): Output DVI-I-1 using initial mode 1600x900 +0+0
[ 34847.534] (II) NOUVEAU(0): Output DVI-I-2 using initial mode 1600x900 +1600+0
[ 34847.534] (==) NOUVEAU(0): Using gamma correction (1.0, 1.0, 1.0)
[ 34847.534] (II) NOUVEAU(0): Virtual size is 3200x900 (pitch 0)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1600x900": 97.8 MHz (scaled from 0.0 MHz), 55.5 kHz, 60.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1600x900"x60.0 97.75 1600 1648 1680 1760 900 903 908 926 +hsync -vsync (55.5 kHz eP)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1280x1024": 135.0 MHz (scaled from 0.0 MHz), 80.0 kHz, 75.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1280x1024"x75.0 135.00 1280 1296 1440 1688 1024 1025 1028 1066 +hsync +vsync (80.0 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1280x1024": 108.0 MHz (scaled from 0.0 MHz), 64.0 kHz, 60.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1280x1024"x60.0 108.00 1280 1328 1440 1688 1024 1025 1028 1066 +hsync +vsync (64.0 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1152x864": 108.0 MHz (scaled from 0.0 MHz), 67.5 kHz, 75.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1152x864"x75.0 108.00 1152 1216 1344 1600 864 865 868 900 +hsync +vsync (67.5 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1024x768": 78.8 MHz (scaled from 0.0 MHz), 60.0 kHz, 75.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1024x768"x75.0 78.75 1024 1040 1136 1312 768 769 772 800 +hsync +vsync (60.0 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "1024x768": 65.0 MHz (scaled from 0.0 MHz), 48.4 kHz, 60.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "1024x768"x60.0 65.00 1024 1048 1184 1344 768 771 777 806 -hsync -vsync (48.4 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "800x600": 49.5 MHz (scaled from 0.0 MHz), 46.9 kHz, 75.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "800x600"x75.0 49.50 800 816 896 1056 600 601 604 625 +hsync +vsync (46.9 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "800x600": 40.0 MHz (scaled from 0.0 MHz), 37.9 kHz, 60.3 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "800x600"x60.3 40.00 800 840 968 1056 600 601 605 628 +hsync +vsync (37.9 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "640x480": 31.5 MHz (scaled from 0.0 MHz), 37.5 kHz, 75.0 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "640x480"x75.0 31.50 640 656 720 840 480 481 484 500 -hsync -vsync (37.5 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "640x480": 25.2 MHz (scaled from 0.0 MHz), 31.5 kHz, 59.9 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "640x480"x59.9 25.18 640 656 752 800 480 490 492 525 -hsync -vsync (31.5 kHz e)
[ 34847.535] (**) NOUVEAU(0): Driver mode "720x400": 28.3 MHz (scaled from 0.0 MHz), 31.5 kHz, 70.1 Hz
[ 34847.535] (II) NOUVEAU(0): Modeline "720x400"x70.1 28.32 720 738 846 900 400 412 414 449 -hsync +vsync (31.5 kHz e)
[ 34847.535] (==) NOUVEAU(0): DPI set to (96, 96)
[ 34847.535] (II) Loading sub module "fb"
[ 34847.535] (II) LoadModule: "fb"
[ 34847.535] (II) Loading /usr/lib64/xorg/modules/libfb.so
[ 34847.535] (II) Module fb: vendor="X.Org Foundation"
[ 34847.535] compiled for 1.20.4, module version = 1.0.0
[ 34847.535] ABI class: X.Org ANSI C Emulation, version 0.4
[ 34847.535] (II) Loading sub module "shadowfb"
[ 34847.536] (II) LoadModule: "shadowfb"
[ 34847.536] (II) Loading /usr/lib64/xorg/modules/libshadowfb.so
[ 34847.536] (II) Module shadowfb: vendor="X.Org Foundation"
[ 34847.536] compiled for 1.20.4, module version = 1.0.0
[ 34847.536] ABI class: X.Org ANSI C Emulation, version 0.4
[ 34847.536] (II) modeset(1): Creating default Display subsection in Screen section
"Screen 2" for depth/fbbpp 24/32
[ 34847.536] (==) modeset(1): Depth 24, (==) framebuffer bpp 32
[ 34847.536] (==) modeset(1): RGB weight 888
[ 34847.536] (==) modeset(1): Default visual is TrueColor
[ 34847.536] (II) Loading sub module "glamoregl"
[ 34847.536] (II) LoadModule: "glamoregl"
[ 34847.536] (II) Loading /usr/lib64/xorg/modules/libglamoregl.so
[ 34847.543] (II) Module glamoregl: vendor="X.Org Foundation"
[ 34847.543] compiled for 1.20.4, module version = 1.0.1
[ 34847.543] ABI class: X.Org ANSI C Emulation, version 0.4
[ 34847.619] (II) modeset(1): Refusing to try glamor on llvmpipe
[ 34847.619] (EE) modeset(1): glamor initialization failed
[ 34847.619] (II) modeset(1): ShadowFB: preferred YES, enabled YES
[ 34847.619] (II) modeset(1): Double-buffered shadow updates: on
[ 34847.652] (II) modeset(1): Output VGA-1 using monitor section Monitor2
[ 34847.685] (II) modeset(1): EDID for output VGA-1
[ 34847.685] (II) modeset(1): Manufacturer: ADE Model: 836 Serial#: 0
[ 34847.685] (II) modeset(1): Year: 2000 Week: 2
[ 34847.685] (II) modeset(1): EDID Version: 1.1
[ 34847.685] (II) modeset(1): Analog Display Input, Input Voltage Level: 0.700/0.700 V
[ 34847.685] (II) modeset(1): Sync: Separate
[ 34847.685] (II) modeset(1): Max Image Size [cm]: horiz.: 30 vert.: 23
[ 34847.685] (II) modeset(1): Gamma: 2.20
[ 34847.685] (II) modeset(1): DPMS capabilities: StandBy Suspend Off; RGB/Color Display
[ 34847.685] (II) modeset(1): redX: 0.595 redY: 0.350 greenX: 0.315 greenY: 0.575
[ 34847.685] (II) modeset(1): blueX: 0.150 blueY: 0.125 whiteX: 0.300 whiteY: 0.320
[ 34847.685] (II) modeset(1): Supported established timings:
[ 34847.685] (II) modeset(1): 720x400@70Hz
[ 34847.686] (II) modeset(1): 640x480@60Hz
[ 34847.686] (II) modeset(1): 800x600@56Hz
[ 34847.686] (II) modeset(1): 800x600@60Hz
[ 34847.686] (II) modeset(1): 1024x768@60Hz
[ 34847.686] (II) modeset(1): Manufacturer's mask: 0
[ 34847.686] (II) modeset(1): Supported standard timings:
[ 34847.686] (II) modeset(1): #0: hsize: 1280 vsize 1024 refresh: 60 vid: 32897
[ 34847.686] (II) modeset(1): Supported detailed timing:
[ 34847.686] (II) modeset(1): clock: 65.0 MHz Image Size: 304 x 228 mm
[ 34847.686] (II) modeset(1): h_active: 1024 h_sync: 1048 h_sync_end 1184 h_blank_end 1344 h_border: 0
[ 34847.686] (II) modeset(1): v_active: 768 v_sync: 771 v_sync_end 777 v_blanking: 806 v_border: 0
[ 34847.686] (II) modeset(1): Ranges: V min: 60 V max: 65 Hz, H min: 31 H max: 69 kHz,
[ 34847.686] (II) modeset(1): Serial No: ADE2100V2-0AF
[ 34847.686] (II) modeset(1): Monitor name: ADE2100V2 FLK
[ 34847.686] (II) modeset(1): EDID (in hex):
[ 34847.686] (II) modeset(1): 00ffffffffffff000485360800000000
[ 34847.686] (II) modeset(1): 020a0101681e1778e86d8c9859509326
[ 34847.686] (II) modeset(1): 204c52a3080081800100010001800100
[ 34847.686] (II) modeset(1): 01000100010064190040410026301888
[ 34847.686] (II) modeset(1): 360030e410000018000000fd003c411f
[ 34847.686] (II) modeset(1): 45ff000a202020202020000000ff0041
[ 34847.686] (II) modeset(1): 44453231303056322d304146000000fc
[ 34847.686] (II) modeset(1): 0041444532313030563220464c4b003d
[ 34847.686] (II) modeset(1): Printing probed modes for output VGA-1
[ 34847.686] (II) modeset(1): Modeline "1280x1024"x60.0 108.00 1280 1328 1440 1688 1024 1025 1028 1066 +hsync +vsync (64.0 kHz e)
[ 34847.686] (II) modeset(1): Modeline "1024x768"x60.0 65.00 1024 1048 1184 1344 768 771 777 806 -hsync -vsync (48.4 kHz e)
[ 34847.686] (II) modeset(1): Modeline "800x600"x60.3 40.00 800 840 968 1056 600 601 605 628 +hsync +vsync (37.9 kHz e)
[ 34847.686] (II) modeset(1): Modeline "800x600"x56.2 36.00 800 824 896 1024 600 601 603 625 +hsync +vsync (35.2 kHz e)
[ 34847.686] (II) modeset(1): Modeline "640x480"x59.9 25.18 640 656 752 800 480 490 492 525 -hsync -vsync (31.5 kHz e)
[ 34847.686] (II) modeset(1): Output VGA-1 connected
[ 34847.686] (II) modeset(1): Using exact sizes for initial modes
[ 34847.686] (II) modeset(1): Output VGA-1 using initial mode 1024x768 +0+0
[ 34847.686] (==) modeset(1): Using gamma correction (1.0, 1.0, 1.0)
[ 34847.686] (==) modeset(1): DPI set to (96, 96)
[ 34847.686] (II) Loading sub module "fb"
[ 34847.686] (II) LoadModule: "fb"
[ 34847.687] (II) Loading /usr/lib64/xorg/modules/libfb.so
[ 34847.687] (II) Module fb: vendor="X.Org Foundation"
[ 34847.687] compiled for 1.20.4, module version = 1.0.0
[ 34847.687] ABI class: X.Org ANSI C Emulation, version 0.4
[ 34847.687] (II) Loading sub module "shadow"
[ 34847.687] (II) LoadModule: "shadow"
[ 34847.687] (II) Loading /usr/lib64/xorg/modules/libshadow.so
[ 34847.687] (II) Module shadow: vendor="X.Org Foundation"
[ 34847.687] compiled for 1.20.4, module version = 1.1.0
[ 34847.687] ABI class: X.Org ANSI C Emulation, version 0.4
[ 34847.689] (II) NOUVEAU(0): Channel setup complete.
[ 34847.689] (II) NOUVEAU(0): [COPY] async initialised.
[ 34847.690] (II) NOUVEAU(0): Hardware support for Present enabled
[ 34847.690] (II) NOUVEAU(0): [DRI2] Setup complete
[ 34847.690] (II) NOUVEAU(0): [DRI2] DRI driver: nouveau
[ 34847.690] (II) NOUVEAU(0): [DRI2] VDPAU driver: nouveau
[ 34847.690] (II) Loading sub module "exa"
[ 34847.690] (II) LoadModule: "exa"
[ 34847.690] (II) Loading /usr/lib64/xorg/modules/libexa.so
[ 34847.690] (II) Module exa: vendor="X.Org Foundation"
[ 34847.690] compiled for 1.20.4, module version = 2.6.0
[ 34847.690] ABI class: X.Org Video Driver, version 24.0
[ 34847.690] (II) EXA(0): Driver allocated offscreen pixmaps
[ 34847.690] (II) EXA(0): Driver registered support for the following operations:
[ 34847.690] (II) Solid
[ 34847.690] (II) Copy
[ 34847.690] (II) Composite (RENDER acceleration)
[ 34847.690] (II) UploadToScreen
[ 34847.690] (II) DownloadFromScreen
[ 34847.690] (==) NOUVEAU(0): Backing store enabled
[ 34847.690] (==) NOUVEAU(0): Silken mouse enabled
[ 34847.690] (II) NOUVEAU(0): [XvMC] Associated with Nouveau GeForce 8/9 Textured Video.
[ 34847.690] (II) NOUVEAU(0): [XvMC] Extension initialized.
[ 34847.690] (==) NOUVEAU(0): DPMS enabled
[ 34847.691] (==) modeset(1): Backing store enabled
[ 34847.691] (==) modeset(1): Silken mouse enabled
[ 34847.691] (II) modeset(1): Initializing kms color map for depth 24, 8 bpc.
[ 34847.691] (==) modeset(1): DPMS enabled
[ 34847.691] (II) Found 2 VGA devices: arbiter wrapping enabled
[ 34847.691] (II) Initializing extension Generic Event Extension
