ifconfig -a가 eth0 대신 br-ba165999130f를 표시합니다(이더넷 작동).

tag-icon • tag-icon linux networking ubuntu ethernet ifconfig
ifconfig -a가 eth0 대신 br-ba165999130f를 표시합니다(이더넷 작동).

케이블을 사용하여 PC를 라우터에 연결하고 WIFI USB TP-LINK도 연결했습니다.

-a를 확인해보니 인터페이스 ifconfig가 없다는 것을 알았습니다 eth0. 대신 첫 번째가 호출되는데 (WIFI USB를 뽑아도) br-ba165999130f인 것 같아요 .eth0

milano@milano-desktop:~$ ifconfig -a
br-ba165999130f: flags=4099<UP,BROADCAST,MULTICAST>  mtu 1500
        inet 172.18.0.1  netmask 255.255.0.0  broadcast 172.18.255.255
        ether 02:42:4a:c5:46:fb  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

docker0: flags=4099<UP,BROADCAST,MULTICAST>  mtu 1500
        inet 172.17.0.1  netmask 255.255.0.0  broadcast 172.17.255.255
        ether 02:42:56:a3:3e:ce  txqueuelen 0  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 0  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

eno1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 192.168.100.135  netmask 255.255.255.0  broadcast 192.168.100.255
        inet6 fe80::5fac:7701:876b:133e  prefixlen 64  scopeid 0x20<link>
        ether 70:85:c2:7c:b8:ff  txqueuelen 1000  (Ethernet)
        RX packets 1575526  bytes 1425272914 (1.4 GB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 737541  bytes 87452976 (87.4 MB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0
        device interrupt 16  memory 0xa3300000-a3320000

lo: flags=73<UP,LOOPBACK,RUNNING>  mtu 65536
        inet 127.0.0.1  netmask 255.0.0.0
        inet6 ::1  prefixlen 128  scopeid 0x10<host>
        loop  txqueuelen 1000  (Local Loopback)
        RX packets 14642  bytes 2453399 (2.4 MB)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 14642  bytes 2453399 (2.4 MB)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

vmnet1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 172.16.79.1  netmask 255.255.255.0  broadcast 172.16.79.255
        inet6 fe80::250:56ff:fec0:1  prefixlen 64  scopeid 0x20<link>
        ether 00:50:56:c0:00:01  txqueuelen 1000  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1525  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

vmnet8: flags=4163<UP,BROADCAST,RUNNING,MULTICAST>  mtu 1500
        inet 192.168.70.1  netmask 255.255.255.0  broadcast 192.168.70.255
        inet6 fe80::250:56ff:fec0:8  prefixlen 64  scopeid 0x20<link>
        ether 00:50:56:c0:00:08  txqueuelen 1000  (Ethernet)
        RX packets 0  bytes 0 (0.0 B)
        RX errors 0  dropped 0  overruns 0  frame 0
        TX packets 1525  bytes 0 (0.0 B)
        TX errors 0  dropped 0 overruns 0  carrier 0  collisions 0

그 이유는 무엇입니까?

답변1

그건 정말 옳지 않아요. 인터페이스br-ba165999130f가상 브리지입니다. 당신은 찾을 수 없습니다eth0이제 더 이상 방법이 바뀌었기 때문에udevd, 이더넷 장치에 이름을 할당합니다. 이제 장치 이름은 다음에 따라 지정됩니다."예측 가능한 인터페이스 이름 체계".https://wiki.debian.org/NetworkInterfaceNames

귀하의 경우 전자eth0인터페이스입니다eno1en=이더넷. 인터페이스가 가상인지 실제 장치인지 표시하려면 ls -la /sys/class/net을 수행하면 됩니다. 모든 인터페이스가 나열되어 있습니다.

ls -la /sys/class/net
total 0
drwxr-xr-x  2 root root 0 Jul 18 16:46 .
drwxr-xr-x 87 root root 0 Jul 18 16:46 ..
lrwxrwxrwx  1 root root 0 Jul 18 14:46 br-5888a0968254 -> ../../devices/virtual/net/br-5888a0968254
lrwxrwxrwx  1 root root 0 Jul 18 14:46 br-701dd1212771 -> ../../devices/virtual/net/br-701dd1212771
lrwxrwxrwx  1 root root 0 Jul 18 14:46 br-b00d55f5f1b1 -> ../../devices/virtual/net/br-b00d55f5f1b1
lrwxrwxrwx  1 root root 0 Jul 18 14:46 br-c8cc7afb1a4e -> ../../devices/virtual/net/br-c8cc7afb1a4e
lrwxrwxrwx  1 root root 0 Jul 18 14:46 docker0 -> ../../devices/virtual/net/docker0
lrwxrwxrwx  1 root root 0 Jul 19 08:45 enx08920494661c -> ../../devices/pci0000:00/0000:00:07.1/0000:39:00.0/0000:3a:02.0/0000:3b:00.0/usb6/6-2/6-2.4/6-2.4:1.0/net/enx08920494661c
lrwxrwxrwx  1 root root 0 Jul 18 16:46 lo -> ../../devices/virtual/net/lo
lrwxrwxrwx  1 root root 0 Jul 18 14:51 veth5501186 -> ../../devices/virtual/net/veth5501186
lrwxrwxrwx  1 root root 0 Jul 18 14:46 wlp0s20f3 -> ../../devices/pci0000:00/0000:00:14.3/net/wlp0s20f3

이 인터페이스는 가상입니다.

lrwxrwxrwx  1 root root 0 Jul 18 14:46 br-5888a0968254 -> ../../devices/virtual/net/br-5888a0968254

이 인터페이스는 PCIe 네트워크 장치입니다.

lrwxrwxrwx  1 root root 0 Jul 19 08:45 enx08920494661c -> ../../devices/pci0000:00/0000:00:07.1/0000:39:00.0/0000:3a:02.0/0000:3b:00.0/usb6/6-2/6-2.4/6-2.4:1.0/net/enx08920494661c

드라이버가 올바른 드라이버가 아닐 수도 있습니다. lsusb 아래에 스틱이 나타납니까?
