다음 예를 고려하십시오.
암호
\documentclass{article}
\usepackage{pstricks-add}
\begin{document}
\begin{figure}
\psset{unit=0.05}
\begin{pspicture}(120,216)
\pnodes{P}(0,0)(0,120)(186,120)(216,120)(216,0)(186,0)(186,30)(186,90)
\pspolygon(P0)(P1)(P3)(P4)
\pcline[offset=12pt]{|<->|}(P1)(P3)
\ncput*[nrot=:U]{216}
\pcline[offset=12pt]{|<->|}(P3)(P4)
\ncput*[nrot=:U]{120}
\pspolygon[linestyle=none,fillstyle=vlines](P2)(P3)(P4)(P5)
\pswedge[linestyle=none,fillstyle=solid,fillcolor=white](P6){30}{270}{90}
\pswedge[linestyle=none,fillstyle=solid,fillcolor=white](P7){30}{270}{90}
\psarc(P6){30}{270}{90}
\psarc(P7){30}{270}{90}
\psdot(P6)
\psdot(P7)
\end{pspicture}
\end{figure}
\end{document}
산출
질문
위의 코드는 그림을 생성하는 잘못된 방법인 것 같습니다. 나는 갈 길을 추측 \pscustom
하지만 그것을 사용하는 방법을 알 수 없습니다. PSTricks를 사용하여 "최상의" 방법으로 그림을 생성하려면 어떻게 해야 합니까? (저는 이것저것 사용하는 것에 대한 코멘트를 받는 것이 아니라 이것이 어떻게 수행되는지 보고 싶습니다.)
답변1
두 개의 프레임과 두 개의 호 또는 \pscustom
:
\documentclass{article}
\usepackage{pstricks-add}
\begin{document}
\psset{unit=1pt}
\begin{pspicture}(240,140)
\psframe[dimen=middle](216,120)
\psframe[fillstyle=vlines,linestyle=none](186,0)(216,120)
\psarc[fillstyle=solid,fillcolor=white](186,30){30}{-90}{90}
\psarc[fillstyle=solid,fillcolor=white](186,90){30}{-90}{90}
\psdots(186,30)(186,90)
\pcline[offset=12pt]{|<->|}(0,120)(216,120) \ncput*{216}
\pcline[offset=12pt]{|<->|}(216,120)(216,0) \ncput*[nrot=:U]{120}
\end{pspicture}
\begin{pspicture}(240,140)
\psframe[dimen=middle](216,120)
\pscustom[fillstyle=vlines,hatchcolor=red]{%
\psarc(186,30){30}{-90}{90}
\psarc(186,90){30}{-90}{90}
\psline(186,120)(216,120)(216,0)
}
\psdots(186,30)(186,90)
\pcline[offset=12pt]{|<->|}(0,120)(216,120) \ncput*{216}
\pcline[offset=12pt]{|<->|}(216,120)(216,0) \ncput*[nrot=:U]{120}
\end{pspicture}
\end{document}
닫힌 경로를 그리 므로 (적절한 클리핑에 필요) 클리핑 기능을 사용하는 경우 \psframe
마지막 구성 요소로 추가할 수도 있습니다 .\pscustom
\documentclass{article}
\usepackage{pstricks-add}% http://tug.org/PSTricks/main.cgi/
\begin{document}
\begin{figure}
\psset{unit=1pt}
\begin{pspicture}(240,140)
\psclip{\psset{linestyle=solid}
\pscustom{
\psarc(186,30){30}{-90}{90}
\psarc(186,90){30}{-90}{90}
\psframe[dimen=middle](216,120)
}
}
\psframe[fillstyle=vlines,linestyle=none](186,0)(216,120)
\endpsclip
\psdots(186,30)(186,90)
\pcline[offset=12pt]{|<->|}(0,120)(216,120) \ncput*{216}% Top dimension
\pcline[offset=12pt]{|<->|}(216,120)(216,0) \ncput*[nrot=:U]{120}% Right dimension
\end{pspicture}
\end{figure}
\end{document}
이것은 또한 구조와 방식이 \psframe
그려지기 때문에 작동합니다(왼쪽 중앙에서 시계 반대 방향으로).
답변2
기존 답변을 개선하려고 노력하고 있습니다.
- - 같은 팁을 적절하게 정렬 하려면 화살표 지정자를
|<->|
로 변경해야 합니다 .|<*->|*
|
- 기본적으로 모든 단일 명령에 로컬로 지정하는 것보다 전역적
dimen=middle
으로 전달하는 것이 더 좋습니다 .\pscustom
dimen=outer
클리퍼 경로를 스트로크한 후 클리퍼 영역을 그리므로 일반적으로 클리핑 후 다시 클리퍼 패스를 스트로크해야 합니다.
내가 의미하는 바를 이해하고 싶다면 Werner의 편집 내용에
hatchcolor=red,hatchsep=1pt
잘린 부분을 추가했습니다.\psframe
원래 Werner의 설정은hatchcolor=black
눈에 띄지 않도록 되어 있었지만, 색상 변경으로 인해 다음과 같이 "결함"이 시각적으로 명백해졌습니다.그렇기 때문에 클리핑 후에 다시 스트로크가 필요한 것입니다.
탐색 그리드가 지저분해지기 때문에 사용을
unit=1pt
피해야 합니다.
\documentclass[pstricks,border=12pt]{standalone}
\usepackage{pst-node}
\def\Path[#1]{%
\pscustom[dimen=middle,#1]{
\psarc(186,30){30}{-90}{90}
\psarc(186,90){30}{-90}{90}
\psframe(216,120)
}\ignorespaces
}
\begin{document}
\psset{unit=1pt,linewidth=3pt}
\begin{pspicture}(240,140)
\psclip{\Path[linestyle=none]}
\psframe[fillstyle=vlines,hatchcolor=red,hatchsep=1pt,linestyle=none](186,0)(216,120)
\endpsclip
\Path[]
\psdots(186,30)(186,90)
\pcline[offset=12pt]{|<*->|*}(0,120)(216,120) \ncput*{216}% Top dimension
\pcline[offset=12pt]{|<*->|*}(216,120)(216,0) \ncput*[nrot=:U]{120}% Right dimension
\end{pspicture}
\end{document}
