보여드린 테이블에 대해 LaTeX 코드를 작성했지만 출력이 페이지를 넘어가고 동일해 보이지 않습니다. 셀 값이 흩어져 있다는 뜻입니다. 모든 셀 번호는 위와 아래로 배열됩니다. 내 코드에 문제가 무엇입니까? 셀 너비를 제어하는 방법은 무엇입니까?
코드를 긴 테이블 형식으로 전송할 수 있나요?
\documentclass[12pt,a4paper]{article}
\begin{document}
\begin{table}
\begin{tabular}{|l|l|l|l|l|l|l|l|l|l|l|l|lll}
~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ \\ \hline
~ & Full & 2000 & 2001 & 2002 & 2003 & 2004 & 2005 & 2006 & 2007 & 2008 & 2009 & 2010 & 2011 & 2012 \\ \hline
Low & Consumer Staples\\ 15.83\% & Utilities 14.50\% & Consumer Staples 16.70\% & Consumer Staples 21.20\% & Consumer Staples\\ 17.49\% & Consumer Staples 10.04\% & Consumer Staples 8.73\% & Consumer Staples 9.66\% & Healthcare 12.58\% & Consumer Staples 28.83\% & Healthcare 16.10\% & Healthcare 13.59\% & Consumer Staples 14.21\% & Consumer Staples 11.12\% \\ \hline
2 & Healthcare\\ 17.70\% & Consumer Staples\\ 15.92\% & Utilities 16.81\% & Utilities 22.49\% & Utilities 18.67\% & Utilities 10.70\% & Financials 10.25\% & Healthcare 11.46\% & Consumer Staples 12.77\% & Healthcare 28.84\% & Consumer Staples 16.64\% & Consumer Staples 14.53\% & Healthcare 15.89\% & Healthcare 11.28\% \\ \hline
3 & Utilities\\ 19.48\% & Materials 15.97\% & Materials 19.12\% & Materials 24.66\% & Industrials 20.74\% & Healthcare 12.64\% & Consumer Discretionary 10.51\% & Utilities 13.34\% & Utilities 13.66\% & Telecom 35.05\% & Telecom 20.70\% & Telecom 17.02\% & Telecom 19.31\% & Telecom 13.98\% \\ \hline
4 & Industrials\\ 23.36\% & Financials 17.23\% & Healthcare 20.95\% & Industrials 25.87\% & Healthcare 21.83\% & Financials 12.94\% & Industrials 10.78\% & Consumer Discretionary 13.66\% & Consumer Discretionary 17.31\% & Utilities 39.31\% & Utilities 22.22\% & Utilities 17.17\% & Utilities 23.33\% & Utilities 15.96\% \\ \hline
5 & Consumer Discretionary\\ 24.04\% & Industrials 17.69\% & Industrials 22.17\% & Healthcare 26.78\% & Materials 22.13\% & Industrials 13.39\% & Healthcare 10.79\% & Financials 14.59\% & Telecom 17.74\% & Consumer Discretionary 42.57\% & Consumer Discretionary 26.25\% & Information Technology 19.66\% & Energy 23.96\% & Energy 16.62\% \\ \hline
6 & Energy\\ 24.87\% & Healthcare 18.97\% & Energy 27.71\% & Consumer Discretionary 32.04\% & Energy\\ 22.85\% & Materials 13.44\% & Utilities 11.71\% & Telecom 15.40\% & Energy 18.37\% & Information Technology 42.94\% & Energy 27.60\% & Energy 19.78\% & Consumer Discretionary 26.55\% & Industrials 18.50\% \\ \hline
7 & Telecom\\ 25.50\% & Consumer Discretionary 23.06\% & Consumer Discretionary 28.20\% & Energy 32.63\% & Telecom 23.01\% & Consumer Discretionary 14.31\% & Telecom 11.88\% & Industrials 16.47\% & Financials 19.46\% & Industrials 43.58\% & Information Technology 29.74\% & Consumer Discretionary 21.12\% & Information Technology 26.91\% & Consumer Discretionary 18.52\% \\ \hline
8 & Materials\\ 26.92\% & Energy\\ 26.09\% & Financials 28.02\% & Financials 36.18\% & Consumer Discretionary 24.72\% & Energy 14.86\% & Materials 12.69\% & Energy 16.48\% & Industrials 19.96\% & Energy 46.89\% & Industrials 30.94\% & Industrials 21.95\% & Industrials 27.78\% & Information Technology 19.30\% \\ \hline
9 & Financials\\ 28.33\% & Telecom 42.68\% & Telecom 37.31\% & Telecom 39.65\% & Financials 26.17\% & Telecom 14.87\% & Information Technology 15.49\% & Information Technology 19.03\% & Information Technology 20.43\% & Financials 50.61\% & Materials 41.26\% & Materials 26.86\% & Materials 30.38\% & Materials 21.68\% \\ \hline
High & Information Technology\\ 34.91\% & Information Technology 52.46\% & Information Technology 58.59\% & Information Technology 53.73\% & Information Technology 37.15\% & Information Technology 26.39\% & Energy 16.23\% & Materials 19.45\% & Materials 23.87\% & Materials 53.86\% & cc & Financials 43.69\% & Financials 27.01\% & Financials 33.02\% \\ \hline
\end{tabular}
\end{table}
\end{document}
편집하다:
\documentclass[12pt,a4paper]{article}
\usepackage{amsmath}\usepackage{amssymb}\usepackage{tabularx} \usepackage{comment}
\oddsidemargin-16mm
\usepackage{graphicx} \usepackage{hyperref} \usepackage[english]{babel}
\usepackage{lscape}
\usepackage{rotating}
\newcommand{\specificthanks}[1]{\@fnsymbol{#1}}% Inserts a specific \thanks symbol
\usepackage[left=1.25in, right=1.0in, top=1.25in, bottom=1.0in]{geometry}
\usepackage{booktabs} % Allows the use of \toprule, \midrule and \bottomrule in tables for horizontal lines
\newcommand{\piRsquare}{\pi r^2}
\begin{document} \baselineskip=22pt
\begin{landscape}
\maketitle
%\begin{table}
% \begin{tabular}{|l|l|l|l|l|l|l|l|l|l|l|l|lll}
\begin{tabular}{|*{15}{p{7mm}|}}
~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ \\ \hline
~ & Full & 2000 & 2001 & 2002 & 2003 & 2004 & 2005 & 2006 & 2007 & 2008 & 2009 & 2010 & 2011 & 2012 \\ \hline
Low & Consu\-mer Staples 15.83\% & Utili\-ties 14.50\% & Consu\-mer Staples 16.70\% & Consu\-mer Staples 21.20\% & Consu\-mer Staples 17.49\% & Consu\-mer Staples 10.04\% & Consu\-mer Staples 8.73\% & Consu\-mer Staples 9.66\% & Health\-care 12.58\% & Consu\-mer Staples 28.83\% & Health\-care 16.10\% & Health\-care 13.59\% & Consu\-mer Staples 14.21\% & Consu\-mer Staples 11.12\% \\ \hline
\end{tabular} % prematurely
\begin{comment}
2 & Healthcare\\ 17.70\% & Consumer Staples\\ 15.92\% & Utilities 16.81\% & Utilities 22.49\% & Utilities 18.67\% & Utilities 10.70\% & Financials 10.25\% & Healthcare 11.46\% & Consumer Staples 12.77\% & Healthcare 28.84\% & Consumer Staples 16.64\% & Consumer Staples 14.53\% & Healthcare 15.89\% & Healthcare 11.28\% \\ \hline
3 & Utilities\\ 19.48\% & Materials 15.97\% & Materials 19.12\% & Materials 24.66\% & Industrials 20.74\% & Healthcare 12.64\% & Consumer Discretionary 10.51\% & Utilities 13.34\% & Utilities 13.66\% & Telecom 35.05\% & Telecom 20.70\% & Telecom 17.02\% & Telecom 19.31\% & Telecom 13.98\% \\ \hline
4 & Industrials\\ 23.36\% & Financials 17.23\% & Healthcare 20.95\% & Industrials 25.87\% & Healthcare 21.83\% & Financials 12.94\% & Industrials 10.78\% & Consumer Discretionary 13.66\% & Consumer Discretionary 17.31\% & Utilities 39.31\% & Utilities 22.22\% & Utilities 17.17\% & Utilities 23.33\% & Utilities 15.96\% \\ \hline
5 & Consumer Discretionary\\ 24.04\% & Industrials 17.69\% & Industrials 22.17\% & Healthcare 26.78\% & Materials 22.13\% & Industrials 13.39\% & Healthcare 10.79\% & Financials 14.59\% & Telecom 17.74\% & Consumer Discretionary 42.57\% & Consumer Discretionary 26.25\% & Information Technology 19.66\% & Energy 23.96\% & Energy 16.62\% \\ \hline
6 & Energy\\ 24.87\% & Healthcare 18.97\% & Energy 27.71\% & Consumer Discretionary 32.04\% & Energy\\ 22.85\% & Materials 13.44\% & Utilities 11.71\% & Telecom 15.40\% & Energy 18.37\% & Information Technology 42.94\% & Energy 27.60\% & Energy 19.78\% & Consumer Discretionary 26.55\% & Industrials 18.50\% \\ \hline
7 & Telecom\\ 25.50\% & Consumer Discretionary 23.06\% & Consumer Discretionary 28.20\% & Energy 32.63\% & Telecom 23.01\% & Consumer Discretionary 14.31\% & Telecom 11.88\% & Industrials 16.47\% & Financials 19.46\% & Industrials 43.58\% & Information Technology 29.74\% & Consumer Discretionary 21.12\% & Information Technology 26.91\% & Consumer Discretionary 18.52\% \\ \hline
8 & Materials\\ 26.92\% & Energy\\ 26.09\% & Financials 28.02\% & Financials 36.18\% & Consumer Discretionary 24.72\% & Energy 14.86\% & Materials 12.69\% & Energy 16.48\% & Industrials 19.96\% & Energy 46.89\% & Industrials 30.94\% & Industrials 21.95\% & Industrials 27.78\% & Information Technology 19.30\% \\ \hline
9 & Financials\\ 28.33\% & Telecom 42.68\% & Telecom 37.31\% & Telecom 39.65\% & Financials 26.17\% & Telecom 14.87\% & Information Technology 15.49\% & Information Technology 19.03\% & Information Technology 20.43\% & Financials 50.61\% & Materials 41.26\% & Materials 26.86\% & Materials 30.38\% & Materials 21.68\% \\ \hline
High & Information Technology\\ 34.91\% & Information Technology 52.46\% & Information Technology 58.59\% & Information Technology 53.73\% & Information Technology 37.15\% & Information Technology 26.39\% & Energy 16.23\% & Materials 19.45\% & Materials 23.87\% & Materials 53.86\% & cc & Financials 43.69\% & Financials 27.01\% & Financials 33.02\% \\ \hline
\end{tabular}
\end{table}
\end{comment}
\end{landscape}
%
\end{document}
답변1
조옮김 작업을 통해 테이블 내용을 전환하고 가로 모드로 전환하는 것은 어떻습니까? 여기서는 tabularx패키지의 X 열이 사용되며 width=1.2 옵션을 사용 \textwidth하면 필요한 경우 더 나은 가독성을 위해 테이블을 오른쪽으로 확장할 수 있습니다.
암호
\documentclass{article}
\usepackage{tabularx}
\usepackage{pdflscape}
\usepackage[margin=10pt]{geometry}
\begin{document}
\begin{landscape}
\begin{tabularx}{1.2\textwidth}{|l|*{10}{X|}}\hline
& Low & 2 & 3 & 4 & 5 & 6 & 7 & 8 & 9 & High \\ \hline
Fall & Consumer Staples 15.83\% &Healthcare 17.70\% & Utilities 19.48\% & Industrials 23.36\% & Consumer Discretionary 24.04\% & Energy 24.87\% & Telecom 25.50\% & Materials 26.92\% & Financials 28.33\% &Information Technology 34.91\% \\ \hline
2000 & Utilities 14.50\% & Consumer Staples 15.92\% & & & & & & & &\\\hline
2001 & Consumer Staples 16.70\% & Utilities 16.81\% & & & & & & & &\\\hline
2002 & Consumer Staples 21.20\% & Utilities 22.49\% & & & & & & & & \\\hline
2031 & Consumer Staples 17.49\% & Utilities 18.67\% & & & & & & & & \\\hline
2004 & Consumer Staples 10.04\% & Utilities 10.70\% & & & & & & & & \\\hline
2005 & Consumer Staples 8.73\% & Financials 10.25\% & & & & & & & & \\\hline
2006 & Consumer Staples 9.66\% & Healthcare 11.46\% & & & & & & & & \\\hline
2007 & Healthcare 12.58\% & Consumer Staples 12.77\% & & & & & & & & \\\hline
2008 & Consumer Staples 28.83\% & Healthcare 28.84\% & & & & & & & & \\\hline
2009 & Healthcare 16.10\% & Consumer Staples 16.64\% & & & & & & & &\\\hline
2010 & Healthcare 13.59\% & Consumer Staples 14.53\% & & & & & & & & \\\hline
2011 & Consumer Staples 14.21\% & Healthcare 15.89\% & & & & & & & & \\\hline
2012 & Consumer Staples 11.12\% & Healthcare 11.28\% & & & & & & & & \\\hline
\end{tabularx}
\end{landscape}
\end{document}
답변2
편집하다:이것은 부분적으로 질문의 초기 버전에 대한 답변이므로 일부 조각은 이전 버전을 수정합니다.
옵션 으로 셀을 제어할 수 있습니다 p{with}. 그러나 그러한 양의 데이터로 인해 많은 문제가 발생할 것으로 예상됩니다. 하나의 논리적 라인이 수정되었습니다( \\이런 맥락에서는 수정되지 않았습니다). 대부분의 코드는 무슨 일이 일어나는지 보여주기 위해 주석으로 처리됩니다.
%\documentclass[12pt,a4paper]{article}
\documentclass{article}
\usepackage{comment}
\oddsidemargin-16mm
\begin{document}
\tiny
%\begin{table}
% \begin{tabular}{|l|l|l|l|l|l|l|l|l|l|l|l|lll}
\begin{tabular}{|*{15}{p{7mm}|}}
~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ \\ \hline
~ & Full & 2000 & 2001 & 2002 & 2003 & 2004 & 2005 & 2006 & 2007 & 2008 & 2009 & 2010 & 2011 & 2012 \\ \hline
Low & Consu\-mer Staples 15.83\% & Utili\-ties 14.50\% & Consu\-mer Staples 16.70\% & Consu\-mer Staples 21.20\% & Consu\-mer Staples 17.49\% & Consu\-mer Staples 10.04\% & Consu\-mer Staples 8.73\% & Consu\-mer Staples 9.66\% & Health\-care 12.58\% & Consu\-mer Staples 28.83\% & Health\-care 16.10\% & Health\-care 13.59\% & Consu\-mer Staples 14.21\% & Consu\-mer Staples 11.12\% \\ \hline
\end{tabular} % prematurely
\begin{comment}
2 & Healthcare\\ 17.70\% & Consumer Staples\\ 15.92\% & Utilities 16.81\% & Utilities 22.49\% & Utilities 18.67\% & Utilities 10.70\% & Financials 10.25\% & Healthcare 11.46\% & Consumer Staples 12.77\% & Healthcare 28.84\% & Consumer Staples 16.64\% & Consumer Staples 14.53\% & Healthcare 15.89\% & Healthcare 11.28\% \\ \hline
3 & Utilities\\ 19.48\% & Materials 15.97\% & Materials 19.12\% & Materials 24.66\% & Industrials 20.74\% & Healthcare 12.64\% & Consumer Discretionary 10.51\% & Utilities 13.34\% & Utilities 13.66\% & Telecom 35.05\% & Telecom 20.70\% & Telecom 17.02\% & Telecom 19.31\% & Telecom 13.98\% \\ \hline
4 & Industrials\\ 23.36\% & Financials 17.23\% & Healthcare 20.95\% & Industrials 25.87\% & Healthcare 21.83\% & Financials 12.94\% & Industrials 10.78\% & Consumer Discretionary 13.66\% & Consumer Discretionary 17.31\% & Utilities 39.31\% & Utilities 22.22\% & Utilities 17.17\% & Utilities 23.33\% & Utilities 15.96\% \\ \hline
5 & Consumer Discretionary\\ 24.04\% & Industrials 17.69\% & Industrials 22.17\% & Healthcare 26.78\% & Materials 22.13\% & Industrials 13.39\% & Healthcare 10.79\% & Financials 14.59\% & Telecom 17.74\% & Consumer Discretionary 42.57\% & Consumer Discretionary 26.25\% & Information Technology 19.66\% & Energy 23.96\% & Energy 16.62\% \\ \hline
6 & Energy\\ 24.87\% & Healthcare 18.97\% & Energy 27.71\% & Consumer Discretionary 32.04\% & Energy\\ 22.85\% & Materials 13.44\% & Utilities 11.71\% & Telecom 15.40\% & Energy 18.37\% & Information Technology 42.94\% & Energy 27.60\% & Energy 19.78\% & Consumer Discretionary 26.55\% & Industrials 18.50\% \\ \hline
7 & Telecom\\ 25.50\% & Consumer Discretionary 23.06\% & Consumer Discretionary 28.20\% & Energy 32.63\% & Telecom 23.01\% & Consumer Discretionary 14.31\% & Telecom 11.88\% & Industrials 16.47\% & Financials 19.46\% & Industrials 43.58\% & Information Technology 29.74\% & Consumer Discretionary 21.12\% & Information Technology 26.91\% & Consumer Discretionary 18.52\% \\ \hline
8 & Materials\\ 26.92\% & Energy\\ 26.09\% & Financials 28.02\% & Financials 36.18\% & Consumer Discretionary 24.72\% & Energy 14.86\% & Materials 12.69\% & Energy 16.48\% & Industrials 19.96\% & Energy 46.89\% & Industrials 30.94\% & Industrials 21.95\% & Industrials 27.78\% & Information Technology 19.30\% \\ \hline
9 & Financials\\ 28.33\% & Telecom 42.68\% & Telecom 37.31\% & Telecom 39.65\% & Financials 26.17\% & Telecom 14.87\% & Information Technology 15.49\% & Information Technology 19.03\% & Information Technology 20.43\% & Financials 50.61\% & Materials 41.26\% & Materials 26.86\% & Materials 30.38\% & Materials 21.68\% \\ \hline
High & Information Technology\\ 34.91\% & Information Technology 52.46\% & Information Technology 58.59\% & Information Technology 53.73\% & Information Technology 37.15\% & Information Technology 26.39\% & Energy 16.23\% & Materials 19.45\% & Materials 23.87\% & Materials 53.86\% & cc & Financials 43.69\% & Financials 27.01\% & Financials 33.02\% \\ \hline
\end{tabular}
\end{table}
\end{comment}
\end{document}
그리고 이것은 문서 \tiny에 있습니다 10pt!
가로 모드로 변경하는 방법은 다음과 같습니다.특정 페이지를 가로/세로 모드로 변경하는 방법.
그러나 코드를 약간 수정할 수 있는 경우 다음 솔루션은 표 형식을 두 부분으로 분할합니다(초기 3줄만 분할). & -> &!의 사용법에서 8번째 열 끝의 변형을 관찰하십시오 \2.
\def\1 #1& #2 & #3 & #4 & #5 & #6 & #7 & #8 & #9 \\ \hline{ #1& #2 & #3 & #4 & #5 & #6 & #7 & #8 \\ \hline}
% \begin{tabular}{|*{15}{p{7mm}|}}
\begin{tabular}{|*{8}{p{7mm}|}}
\1 ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ \\ \hline
\1 ~ & Full & 2000 & 2001 & 2002 & 2003 & 2004 & 2005 & 2006 & 2007 & 2008 & 2009 & 2010 & 2011 & 2012 \\ \hline
\1 Low & Consu\-mer Staples 15.83\% & Utili\-ties 14.50\% & Consu\-mer Staples 16.70\% & Consu\-mer Staples 21.20\% & Consu\-mer Staples 17.49\% & Consu\-mer Staples 10.04\% & Consu\-mer Staples 8.73\% & Consu\-mer Staples 9.66\% & Health\-care 12.58\% & Consu\-mer Staples 28.83\% & Health\-care 16.10\% & Health\-care 13.59\% & Consu\-mer Staples 14.21\% & Consu\-mer Staples 11.12\% \\ \hline
\end{tabular}
\bigskip
\def\2 #1&! #2 & #3 & #4 & #5 & #6 & #7 & #8 \\ \hline{ #2 & #3 & #4 & #5 & #6 & #7 & #8 \\ \hline}
% \begin{tabular}{|*{15}{p{7mm}|}}
\begin{tabular}{|*{8}{p{7mm}|}}
\2 ~ & ~ & ~ & ~ & ~ & ~ & ~ & ~ &! ~ & ~ & ~ & ~ & ~ & ~ & ~ \\ \hline
\2 ~ & Full & 2000 & 2001 & 2002 & 2003 & 2004 & 2005 & !2006 & 2007 & 2008 & 2009 & 2010 & 2011 & 2012 \\ \hline
\2 Low & Consu\-mer Staples 15.83\% & Utili\-ties 14.50\% & Consu\-mer Staples 16.70\% & Consu\-mer Staples 21.20\% & Consu\-mer Staples 17.49\% & Consu\-mer Staples 10.04\% & Consu\-mer Staples 8.73\% &! Consu\-mer Staples 9.66\% & Health\-care 12.58\% & Consu\-mer Staples 28.83\% & Health\-care 16.10\% & Health\-care 13.59\% & Consu\-mer Staples 14.21\% & Consu\-mer Staples 11.12\% \\ \hline
\end{tabular}
표 형식의 코드를 반복하는 것을 두려워하지 않는다면 이러한 복잡한 정의를 형식 매개변수가 2개만 있는 형식으로 변환할 수 있습니다. 그러나 예를 들어 3개 부분으로 분할된 표가 필요한 경우를 대비해 아이디어가 표시되었습니다.
