Question 1

이를 수행하는 한 가지 방법은 다음과 같습니다.

p{<width>}일반 의 모든 열에 사용합니다 tabular.
이렇게 하려면 새 길이를 생성 \tabularlength하고 이를 테이블 형식의 전체 너비로 설정합니다. 저는 .975\linewidth여기를 이용했어요.
\tabularlength그런 다음 각 열을 예 를 들어 정의합니다 p{.1\tabularlength}.
첫 번째 열이 작동하도록 하려면 multicolumn선이 깨질 수 있도록 생략하세요.
이는 하이픈을 원하므로 load 를 의미합니다 babel.
열의 첫 번째 단어에 하이픈 넣기를 허용하지 않기 때문에 이것만으로는 충분하지 않습니다. 따라서 를 사용하여 이러한 단어를 직접 하이픈으로 연결하세요 \-.
geometry페이지 레이아웃을 올바르게 만드는 데 사용합니다 .
>{\bfseries}모든 줄에 굵게 지정하지 않으려면 첫 번째 열에 사용하세요 .
\multicolumn허위 수직 규칙을 얻지 않도록 첫 번째 줄에는 여전히 하나가 필요합니다 .
\centering환경보다는 환경을 사용하십시오 center. 왜냐하면 후자는 여기서 원하지 않는 추가 간격을 추가하기 때문입니다.

이것은 실제로 (약간의) 여유 공간에 맞습니다. 테이블이 더 큰 경우 환경 \small내에서 table글꼴 크기를 조금 더 작게 설정하는 것을 고려할 수 있습니다. 또는 를 사용하여 여백 등을 조정할 수 있습니다 geometry. 전체 문서에 대해 이 작업을 수행할 수 있으며, 필요한 경우 단일 페이지에 대해 수행할 수 있습니다.

코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{tabularx}

\begin{document}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
  \cline{2-4}
  \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{document}

출력

페이지에 맞는 테이블 형식

대체 레이아웃

사람들이 더 쉽게 소화할 수 있도록 가로 방향으로 표 형식을 포함시키는 것도 고려할 수 있습니다. 예를 들어:

가로 방향의 표 형식

이 경우에는 첫 번째 열인 에 대해 추가 형식 지시문을 사용하여 \raggedright합리적으로 보이도록 했습니다.

가로 표 형식의 코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}

\begin{document}

\begin{landscape}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\raggedright}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
    \cline{2-4}
    \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
    Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
    Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
    Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

중앙 열 및 세로 규칙

주석에서 Flame_Phoenix가 언급한 대로 m{<width>}세로 중앙에 지정된 너비의 열을 제공합니다. 이 지정자에는 array패키지가 필요합니다.

\multicolumn'Hibernate OGM' 앞에 수직 규칙을 추가하는 것은 단지 표의 첫 번째 항목을 조정하는 문제일 뿐입니다 . >{\centering}표 형식 구성을 추가하면 모든 셀을 가로 및 세로로 중앙에 배치할 수 있습니다 . 그러나 이는 약간 지루해지고 지속적으로 조정하기가 더 어렵습니다. 더 나은 솔루션은 array새로운 열 유형을 정의하는 기능을 사용합니다 .

\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

내 예제는 세로 및 가로 모두에 대한 레이아웃을 보여주기 때문에 이미 정의된 길이를 정의하려고 하지 않도록 환경 \tabularlength에서 추가 항목도 가져와야 합니다 .tabular

\newlength{\tabularlength}

열 m유형은 \\행의 끝이 아닌 열 내의 새 줄로 처리됩니다. 그러므로 \\\hline로 교체해야 합니다 \tabularnewline\hline.

마지막으로 깔끔함을 위해 맨 오른쪽에 수직선을 추가했습니다.

코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}
\newlength{\tabularlength}
\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

\begin{document}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\centering\bfseries}m{.1\tabularlength}|*{3}{M}|}
  \cline{2-4}
  \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\begin{landscape}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\centering}m{.1\tabularlength}|*{3}{M}|}
    \cline{2-4}
    \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
    Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
    Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
    Document\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

출력

모두 중심 테이블 형식

Answer

이를 수행하는 한 가지 방법은 다음과 같습니다.

p{<width>}일반 의 모든 열에 사용합니다 tabular.
이렇게 하려면 새 길이를 생성 \tabularlength하고 이를 테이블 형식의 전체 너비로 설정합니다. 저는 .975\linewidth여기를 이용했어요.
\tabularlength그런 다음 각 열을 예 를 들어 정의합니다 p{.1\tabularlength}.
첫 번째 열이 작동하도록 하려면 multicolumn선이 깨질 수 있도록 생략하세요.
이는 하이픈을 원하므로 load 를 의미합니다 babel.
열의 첫 번째 단어에 하이픈 넣기를 허용하지 않기 때문에 이것만으로는 충분하지 않습니다. 따라서 를 사용하여 이러한 단어를 직접 하이픈으로 연결하세요 \-.
geometry페이지 레이아웃을 올바르게 만드는 데 사용합니다 .
>{\bfseries}모든 줄에 굵게 지정하지 않으려면 첫 번째 열에 사용하세요 .
\multicolumn허위 수직 규칙을 얻지 않도록 첫 번째 줄에는 여전히 하나가 필요합니다 .
\centering환경보다는 환경을 사용하십시오 center. 왜냐하면 후자는 여기서 원하지 않는 추가 간격을 추가하기 때문입니다.

이것은 실제로 (약간의) 여유 공간에 맞습니다. 테이블이 더 큰 경우 환경 \small내에서 table글꼴 크기를 조금 더 작게 설정하는 것을 고려할 수 있습니다. 또는 를 사용하여 여백 등을 조정할 수 있습니다 geometry. 전체 문서에 대해 이 작업을 수행할 수 있으며, 필요한 경우 단일 페이지에 대해 수행할 수 있습니다.

코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{tabularx}

\begin{document}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
  \cline{2-4}
  \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{document}

출력

페이지에 맞는 테이블 형식

대체 레이아웃

사람들이 더 쉽게 소화할 수 있도록 가로 방향으로 표 형식을 포함시키는 것도 고려할 수 있습니다. 예를 들어:

가로 방향의 표 형식

이 경우에는 첫 번째 열인 에 대해 추가 형식 지시문을 사용하여 \raggedright합리적으로 보이도록 했습니다.

가로 표 형식의 코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}

\begin{document}

\begin{landscape}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\raggedright}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
    \cline{2-4}
    \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
    Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
    Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
    Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

중앙 열 및 세로 규칙

주석에서 Flame_Phoenix가 언급한 대로 m{<width>}세로 중앙에 지정된 너비의 열을 제공합니다. 이 지정자에는 array패키지가 필요합니다.

\multicolumn'Hibernate OGM' 앞에 수직 규칙을 추가하는 것은 단지 표의 첫 번째 항목을 조정하는 문제일 뿐입니다 . >{\centering}표 형식 구성을 추가하면 모든 셀을 가로 및 세로로 중앙에 배치할 수 있습니다 . 그러나 이는 약간 지루해지고 지속적으로 조정하기가 더 어렵습니다. 더 나은 솔루션은 array새로운 열 유형을 정의하는 기능을 사용합니다 .

\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

내 예제는 세로 및 가로 모두에 대한 레이아웃을 보여주기 때문에 이미 정의된 길이를 정의하려고 하지 않도록 환경 \tabularlength에서 추가 항목도 가져와야 합니다 .tabular

\newlength{\tabularlength}

열 m유형은 \\행의 끝이 아닌 열 내의 새 줄로 처리됩니다. 그러므로 \\\hline로 교체해야 합니다 \tabularnewline\hline.

마지막으로 깔끔함을 위해 맨 오른쪽에 수직선을 추가했습니다.

코드

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}
\newlength{\tabularlength}
\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

\begin{document}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\centering\bfseries}m{.1\tabularlength}|*{3}{M}|}
  \cline{2-4}
  \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\begin{landscape}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\centering}m{.1\tabularlength}|*{3}{M}|}
    \cline{2-4}
    \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
    Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
    Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
    Document\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

출력

모두 중심 테이블 형식

Question 2

여기에 이미지 설명을 입력하세요

주요 오류는 지정된 너비 열을 자연 너비 열로 바꾸는 다중 열이었습니다 l.

\documentclass[a4paper,10pt]{article}
\usepackage[utf8]{inputenc}
\usepackage{array}

\begin{document}
\begin{table}
\centering\small
\newcommand{\mc}[3]{\multicolumn{#1}{#2}{#3}}
\setlength{\dimen0}{\dimexpr\textwidth-6\tabcolsep\relax}
\begin{tabular}{@{}>{\hspace*{0pt}\bfseries}p{.1\dimen0}*3{p{.3\dimen0}}}
 & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
Documentation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
\end{tabular}

\end{table}


\end{document}

Answer

여기에 이미지 설명을 입력하세요

주요 오류는 지정된 너비 열을 자연 너비 열로 바꾸는 다중 열이었습니다 l.

\documentclass[a4paper,10pt]{article}
\usepackage[utf8]{inputenc}
\usepackage{array}

\begin{document}
\begin{table}
\centering\small
\newcommand{\mc}[3]{\multicolumn{#1}{#2}{#3}}
\setlength{\dimen0}{\dimexpr\textwidth-6\tabcolsep\relax}
\begin{tabular}{@{}>{\hspace*{0pt}\bfseries}p{.1\dimen0}*3{p{.3\dimen0}}}
 & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
Documentation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
\end{tabular}

\end{table}


\end{document}

코드

답변1

코드

출력

대체 레이아웃

가로 표 형식의 코드

중앙 열 및 세로 규칙

코드

출력

답변2

관련 정보
