f(x)에서 f'(x)를 명시적으로 찾지 않고도 상수 m과 함수 f'(x) 사이의 교차점을 찾기 위해 \pstInterFF를 수정하는 방법은 무엇입니까?

tag-icon • tag-icon pstricks
f(x)에서 f'(x)를 명시적으로 찾지 않고도 상수 m과 함수 f'(x) 사이의 교차점을 찾기 위해 \pstInterFF를 수정하는 방법은 무엇입니까?

여기에 이미지 설명을 입력하세요

\documentclass[preview,border=12pt]{standalone}
\usepackage{pst-plot,pst-eucl}

\def\f(#1){((#1)*(#1-5)*(#1-6)/4+1.5*(#1)-5)}
\def\xi{1}
\def\xf{6.5}
\def\m{((\f(\xf)-\f(\xi))/(\xf-\xi))}

\def\fp(#1){}% is f'(x)

% I have to use the following because the newest pst-eucl has not been installed
\pstVerb{/I2P {exec AlgParser cvx exec} def}

\begin{document}
How to find the point $c$ such that
\[
f'(c) = \frac{f(b)-f(a)}{b-a}
\]

\small
\begin{verbatim}
\begin{center}
\begin{pspicture}[algebraic,saveNodeCoors](-1,-1)(8,8)
    \psaxes[labels=none,ticks=none]{->}(0,0)(-.5,-.5)(7.5,7.5)[$x$,0][$y$,90]
    \psplot[linecolor=blue]{.75}{6.75}{\f(x)}
    %\pstInterFF[]{{\fp(x)} I2P}{{\m} I2P}{4}{c}% has not been implemented yet.
    %\psCoordinate(c)
\end{pspicture}
\end{center}
\end{verbatim}
\end{document}

간단히 말해서, 에서 명시적으로 찾을 필요 없이 상수 함수 와 함수 \pstInterFF사이의 교차점을 찾도록 수정하는 방법은 무엇입니까 ?mf'(x)f'(x)f(x)

답변1

\documentclass[preview,border=12pt]{standalone}
\usepackage{pst-eucl,pstricks-add}

\def\f#1{((#1)*(#1-5)*(#1-6)/4+1.5*(#1)-5)}
\def\A{1}
\def\B{6.5}
\def\M{(\f{\B}-\f{\A})/(\B-\A)}
\begin{document}

\begin{pspicture}[algebraic,saveNodeCoors](-1,-1)(8,8)
   \psaxes[labels=none,ticks=none]{->}(0,0)(-.5,-.5)(7.5,7.5)[$x$,0][$y$,90]
   \psplot[linecolor=blue,plotpoints=100,linewidth=1.5pt]{.75}{6.75}{\f{x}}
   \psplot[linestyle=dashed,linecolor=blue,plotpoints=100,linewidth=1.5pt]{.75}{6.75}{Derive(1,\f{x})}
   \pnodes(*{\A} {\f{\A}}){A}(*{\B} {\f{\B}}){B}
   \psCoordinates[linestyle=dashed](A)\psCoordinates[linestyle=dashed](B)
   \pcline[nodesep=-5mm,linecolor=red](A)(B)
   \pstInterFF{\M}{Derive(1,\f{x})}{1}{C}
   \pstInterFF{\M}{Derive(1,\f{x})}{4}{D}
   \psCoordinates[linestyle=dotted](C)\psCoordinates[linestyle=dotted](D)
   \pnodes(*{N-C.x} {\f{x}}){X1}(*{N-D.x} {\f{x}}){X2}
   \psCoordinates[linestyle=dashed,linecolor=red](X1)
   \psCoordinates[linestyle=dashed,linecolor=red](X2)
   \psParallelLine[linecolor=red](A)(B)(X1){0.1}{X}
   \pcline[nodesepA=-1,linecolor=red](X1)(X)
   \psParallelLine[linecolor=red](A)(B)(X2){0.1}{X}
   \pcline[nodesepA=-1,linecolor=red](X2)(X)
\end{pspicture}

\end{document}

여기에 이미지 설명을 입력하세요

답변2

여기 순진한 방법이 있습니다.

업데이트: 업데이트가 다음을 찾으려고 시도합니다.모두주어진 기울기를 가진 점.

추가 업데이트: 이것은 코드 최적화입니다. 로컬 극값을 감지하기 위해 새 버전에서는 곱셈을 피하고 부호만 조작하므로 이것이 더 효율적입니다(이것은 를 사용하는 코드의 일부입니다 \xintifboolexpr).

롤 멀티플

롤 멀티플 B

이 방법은 (기본적으로) 무차별 대입 계산을 통해 이루어집니다.100 중간점의 무차별 대입 계산을 통해 로컬 극값을 식별합니다. 계산은 다음을 통해 수행됩니다.xintexpr, 이는 (현재) 범위를 유리 함수 및 제곱근으로 제한합니다. 다른 수학 엔진을 사용하여 계산을 수행하도록 코드를 자연스럽게 수정할 수 있습니다.

\documentclass[multi=pspicture,border=12pt]{standalone}
\usepackage{pst-plot,pst-eucl}
\usepackage{xintexpr}

\def\FindRolleN {100}% number of tested points
\makeatletter
\def\FindRollePt #1#2#3{%
    % #1 = function (defined with parentheses as below, not with braces, to
    %                conform to OP's code)
    % #2 = start of interval
    % #3 = end of interval
    % the action of this  macro is to set \RolleSlope and \RolleList
    \begingroup
    \let\ROL@N \FindRolleN
    \xintDigits := 6;%
    \xintNewFloatExpr \ROL@F [1]{#1(##1)}%
    \oodef\ROL@Fa {\ROL@F{#2}}%
    \oodef\ROL@Fb {\ROL@F{#3}}%
    \oodef\ROL@Dx {\xintfloatexpr #3 - #2 \relax }%
    \oodef\ROL@Dy {\xintfloatexpr \ROL@Fb-\ROL@Fa\relax }%
    \oodef\ROL@Slope  {\xintfloatexpr \ROL@Dy/\ROL@Dx\relax }%
    \oodef\ROL@Stepx  {\xintfloatexpr \ROL@Dx/\ROL@N\relax }%
    \oodef\ROL@Stepy  {\xintfloatexpr \ROL@Dy/\ROL@N\relax }%
    %
    \oodef\ROL@X {\xintfloatexpr #2\relax }%
    \let\ROL@Y   \ROL@Fa
    %
    \oodef\ROL@@X {\xintthefloatexpr \ROL@X + \ROL@Stepx\relax }%
    \oodef\ROL@@Y {\xintthefloatexpr \ROL@F{\ROL@@X}\relax }%
    % \count0 1 (no need for a count, use \xintiloop!)
    \def\ROL@List {}% list of local extrema
    \xintiloop [2+1]
      \oodef\ROL@@@X {\xintthefloatexpr \ROL@@X + \ROL@Stepx\relax }%
      \oodef\ROL@@@Y {\xintthefloatexpr \ROL@F{\ROL@@@X}\relax }%
      % commented out, code below avoids a multiplication.
      %\xintifSgn {\xintthefloatexpr (\ROL@@Y-\ROL@Y-\ROL@Stepy)*
      %                              (\ROL@@@Y-\ROL@@Y-\ROL@Stepy)\relax}
      %           {% found a local extrema etc...
      %              code as below}
      %           {}{}%
      \xintifboolexpr
      % this is a cleverer way to detect a change of sign. "constancy" compatible, too
      {sgn(\ROL@@Y-\ROL@Y-\ROL@Stepy)+sgn(\ROL@@@Y-\ROL@@Y-\ROL@Stepy)}
                 {}% not an extrema
                 {% sum of signs=0, hence opposite signs or both zero, hence
                  % found a local extrema or a "constancy",
% Let's round the coordinates to 4 digits after decimal mark
% Mainly because I don't know how to use floating point notation in pspicture
% point coordinates but surely it can be done.
        \edef\ROL@List{\expandafter\unexpanded\expandafter{\ROL@List}%
                      {{\xintRound{4}{\ROL@@X}}{\xintRound{4}{\ROL@@Y}}}}%
                  }%
      \let\ROL@X\ROL@@X
      \let\ROL@Y\ROL@@Y
      \let\ROL@@X\ROL@@@X
      \let\ROL@@Y\ROL@@@Y
      \ifnum\xintiloopindex < \ROL@N\space
    \repeat
    \global\let\RolleListe\ROL@List
    \global\oodef\RolleSlope{\xinttheexpr round(\ROL@Slope,4)\relax}%
    \endgroup
}
\makeatother

\begin{document}
% How to find the point or points $c$ such that
% \[
% f'(c) = \frac{f(b)-f(a)}{b-a}
% \]

\def\f(#1){((#1)*(#1-5)*(#1-6)/4+1.5*(#1)-5)}
\def\xi{1}
\def\xf{6.5}

% \FindRollePt {\f}{\xi}{\xf}%
% \show\RolleListe % debugging

\begin{pspicture}[algebraic,saveNodeCoors](-1,-1)(8,8)
    \psaxes[labels=none,ticks=none]{->}(0,0)(-.5,-.5)(7.5,7.5)[$x$,0][$y$,90]
    \psplot[linecolor=blue]{.75}{6.75}{\f(x)}
    \FindRollePt {\f}{\xi}{\xf}%
    \psplot[linecolor=green]{.75}{6.75}{\RolleSlope*(x-\xi)+\f(\xi)}
    \psCoordinates[linestyle=dashed](*\xi\space {\f(\xi)})
    \psCoordinates[linestyle=dashed](*\xf\space {\f(\xf)})
    \xintFor* #1 in {\RolleListe}\do {%
          \xintAssign  #1\to\RolleX\RolleY
          \psdot(\RolleX,\RolleY)
          \psplot[linecolor=red]{.75}{6.75}{\RolleSlope*(x-\RolleX)+\RolleY}
     }
\end{pspicture}

\def\f(#1){2.5*(#1-2.5)*((#1-2.5)^2-1)*((#1-2.5)^2-2)}
\def\xi{1}
\def\xf{4}
\psset{unit=2cm}

\begin{pspicture}[algebraic,saveNodeCoors](-.25,-2.5)(5,3)
    \rput(2.5,2.5){\parbox {10cm}{How to find the point or rather the points $c$
        such that \[ f'(c) = \frac{f(b)-f(a)}{b-a} \]}}
    \psaxes[labels=none,ticks=none]{->}(0,0)(-.25,-2)(5,2)[$x$,0][$y$,90]
    \psplot[linecolor=blue,plotpoints=200]{.95}{4.05}{\f(x)}
    \psCoordinates[linestyle=dashed](*\xi\space {\f(\xi)})
% NOTE: how to use * with negative coordinate? I had to shift
% everything to be positive
    \psCoordinates[linestyle=dashed](*\xf\space {\f(\xf)})
    \FindRollePt {\f}{\xi}{\xf}%
    \psplot[linecolor=green]{\xi}{\xf}{\RolleSlope*(x-\xi)+\f(\xi)}
    \xintFor* #1 in {\RolleListe}\do {%
          \xintAssign  #1\to\RolleX\RolleY
          \psdot(\RolleX,\RolleY)
          \oodef\xa {\xinttheexpr round(\RolleX-.5,4)\relax}%
          \oodef\xb {\xinttheexpr round(\RolleX+.5,4)\relax}%
          \psplot[linecolor=red]{\xa}{\xb}
                                {\RolleSlope*(x-\RolleX)+\RolleY}
     }
\end{pspicture}

\end{document}

이 답변의 첫 번째 버전:

롤

\documentclass[preview,border=12pt]{standalone}
\usepackage{pst-plot,pst-eucl}
\usepackage{xintexpr}

\def\FindRolleN {100}% number of tested points
\makeatletter
\def\FindRollePt #1#2#3{%
    % #1 = function (defined with parentheses as below, not with braces, to
    % confirm to OP)
    % #2 = start of interval
    % #3 = end of interval
    % the action of this  macro is to set \RolleX, \RolleY, \RolleSlope
    \begingroup
    \let\ROL@N \FindRolleN
% I use floating point numbers with some hesitation, it is not always faster
% than exact evaluations when the manipulated numbers don't have many digits
    \xintDigits := 6;%
% I define this for the parsing of the algebraic expression to be done once and
% for all.
% subtle detail: if \ROL@F was defined with \xintNewExpr, rather than
% \xintNewFloatExpr, its output would be in a/b[n] form, its use in the next
% expressions would have to be mandatorily within a brace pair (see manual)
% other subtle detail: \ROL@F is a macro not able to parse an argument like
% \xintexpr knows how to do. For this, explicit \xinttheexpr ..\relax, or
% \xintthefloatexpr..\relax must be used in this argument.
    \xintNewFloatExpr \ROL@F [1]{#1(##1)}%
    \oodef\ROL@Fa {\ROL@F{#2}}%
    \oodef\ROL@Fb {\ROL@F{#3}}%
    \oodef\ROL@Slope {\xintfloatexpr (\ROL@Fb-\ROL@Fa)/(#3-#2)\relax }%
    \oodef\ROL@Step  {\xintfloatexpr (#3-#2)/\ROL@N\relax }%
    \def\ROL@U {0}%
    \count0 0
    \def\ROL@J {0}%
    \xintloop
      \advance\count0 1
      \oodef\ROL@X {\xintthefloatexpr #2+\count0*\ROL@Step\relax }%
      \oodef\ROL@V {\xintthefloatexpr
  abs(\ROL@N*\ROL@F{\ROL@X}-(\ROL@N-\count0)*\ROL@Fa-\count0*\ROL@Fb)
                    \relax }%
      \xintifGt\ROL@V\ROL@U {\let\ROL@U\ROL@V\odef\ROL@J{\the\count0}}{}%
      \ifnum\count0 < \ROL@N\space
    \repeat
% Now converting to fixed point format with 4 digits after decimal mark
% Mainly because I don't know how to use floating point notation in pspicture
% but surely can be done.
    \oodef\ROL@Result       {\xinttheexpr round(#2+\ROL@J*\ROL@Step,4)\relax}%
    \global\let\RolleX\ROL@Result
    \global\oodef\RolleY    {\xinttheexpr round(\ROL@F{\RolleX},4)\relax}%
    \global\oodef\RolleSlope{\xinttheexpr round(\ROL@Slope,4)\relax}%
    \endgroup
}
\makeatother

\def\f(#1){((#1)*(#1-5)*(#1-6)/4+1.5*(#1)-5)}
\def\xi{1}
\def\xf{6.5}

\begin{document}
How to find the (rather, `a') point $c$ such that
\[
f'(c) = \frac{f(b)-f(a)}{b-a}
\]


\begin{center}
\begin{pspicture}[algebraic,saveNodeCoors](-1,-1)(8,8)
    \psaxes[labels=none,ticks=none]{->}(0,0)(-.5,-.5)(7.5,7.5)[$x$,0][$y$,90]
    \psplot[linecolor=blue]{.75}{6.75}{\f(x)}
    \FindRollePt {\f}{\xi}{\xf}%
    \psdot(\RolleX,\RolleY)
    \psplot[linecolor=red]{.75}{6.75}{\RolleSlope*(x-\RolleX)+\RolleY}
    \psplot[linecolor=green]{.75}{6.75}{\RolleSlope*(x-\xi)+\f(\xi)}
    % I don't know how to create a dot, using algebraic expressions for the
    % coordinates, I don't know anything about pstricks
    % I have tried various things, for example this:
    \psCoordinates[linestyle=dashed](*\xi\space {\f(\xi)})
    \psCoordinates[linestyle=dashed](*\xf\space {\f(\xf)})
    % user manual is big.
    % \rput(*\xf\space {\f(\xf)}){\rule{3pt}{3pt}}
    % \rput(*\xi\space {\f(\xi)}){\rule{3pt}{3pt}}
\end{pspicture}
\end{center}

\end{document}

답변3

계산기(및 xpicture)를 사용하여 가능한 솔루션입니다.평균값 예

\documentclass[preview,border=12pt]{standalone}
\usepackage{xpicture}
\usepackage{amsmath,ifthen}

\begin{document}
How to find the point $c$ such that
\[
   f'(c) = \frac{f(b)-f(a)}{b-a}
\]

\newcpoly{\fI}{0}{30}{-11}{1}                      % fI(x)=30x-11x^2+x^3
\newlpoly{\fII}{-5}{1.5}                           % fII(x)=-5+1.5x
\LINEARCOMBINATIONfunction{0.25}{\fI}{1}{\fII}{\F} % F(x)=(1/4)fI(x)+fII(x) (this is our function)

Our function is
\[
    F(x)=\frac{x(x-5)(x-6)}{4}+1.5x-5
\]

\F{0}{\solZero}{\DsolZero}
\F{7}{\solSeven}{\DsolSeven}
Values of $F$ and $F'$ at $0$ and $7$ are
\[
   \begin{gathered}
      f(0)=\solZero\qquad f'(0)=\DsolZero  \\
      f(7)=\solSeven\qquad f'(7)=\DsolSeven
   \end{gathered}
\]
\SUBTRACT{\solSeven}{\solZero}{\meanvalue}
\DIVIDE{\meanvalue}{7}{\meanvalue}
And the mean value is
\[
  \frac{f(7)-f(0)}{7-0}=\meanvalue
\]
So, we search $c\in[0,7]$ such that $f'(c)=\meanvalue$.
We apply the bisection strategy
(in fact, this strategy is not secure, because the sign of the derivative
changes sign several times).

\COPY{0}{\XZERO}
\COPY{7}{\XONE}
\COPY{3.5}{\currentamplitude}
\COPY{0.0001}{\tolerance}

\whiledo{\lengthtest{\currentamplitude pt>\tolerance pt}}{%
  \ADD{\XZERO}{\currentamplitude}{\XMED}
  \F{\XZERO}{\solzero}{\Dsolzero}
  \F{\XMED}{\solmed}{\Dsolmed}
  \F{\XONE}{\solone}{\Dsolone}
  \SUBTRACT{\Dsolzero}{\meanvalue}{\derzero}
  \SUBTRACT{\Dsolmed}{\meanvalue}{\dermean}
  \MULTIPLY{\derzero}{\dermean}{\derproduct}
  \ifthenelse{\lengthtest{\derproduct pt<0 pt}}{\COPY{\XMED}{\XONE}}{\COPY{\XMED}{\XZERO}}
  \DIVIDE{\currentamplitude}{2}{\currentamplitude}
}
\medskip

Having applied this method we have obtained that
the derivative equals mean value of function $F$ at $c=\XMED$.


\setlength{\unitlength}{1cm}
\begin{Picture}(-1,-6)(8,11)
   \cartesiangrid(0,-5)(7,10)
   \pictcolor{red}
   \PlotFunction[10]{\F}{0}{7}
   \pictcolor{blue}
   \xLINE(0,\solZero)(7,\solSeven)
   \Put(\XMED,\solmed){\xLINE(-1,-\Dsolmed)(1,\Dsolmed)}
   \Polyline(\XMED,0)(\XMED,\solmed)(0,\solmed)
   \Put[S](\XMED,0){$c$}
   \Put[W](0,\solmed){$f(c)$}
   \Put[E](\XMED,\solmed){\scriptsize$f'(c)=\frac{f(b)-f(a)}{b-a}$}
\end{Picture}

\end{document}

관련 정보
