pfgplot 막대 차트의 변경 사항

Question

pgfplots에 대한 tex.stackexchange에서 정말 많은 유용한 것들을 찾았습니다. 감사합니다!

하지만 다음 방법을 알 수 없습니다.

• "without" 또는 "with" 뒤에 새 줄을 삽입하세요.
• 값 0 또는 전체 막대 숨기기
• 소수점 이하 거듭제곱이 없도록 x 틱을 ​​변경합니다([10^..]).
• 차트 외부의 beein 플롯 좌표 근처에 있는 노드를 방지합니다.

두 차트:

그리고 소스코드:

\documentclass[a4paper]{report}

\usepackage[english]{babel}
\usepackage[utf8]{inputenc}
\usepackage{tikz}
\usepackage{pgfplots}

\title{Tests}

\pgfplotsset{counter_barchart/.style={
  width=0.85\textwidth,
  height=5cm,
  xbar,
  xmin=0,
  xmajorgrids = true,
  tick align = outside, xtick pos = left,
  x tick label style={ /pgf/number format/1000 sep=},
  enlarge y limits=0.4,
  symbolic y coords={Ass. Optimization,with Optimization,without Optimization},
  ytick=data,
  yticklabel style={text width=0.2\textwidth},
  every node near coord/.append style={/pgf/number format/1000 sep=},
  nodes near coords,
  nodes near coords align={horizontal},
  legend style={at={(0.5,-0.35)},anchor=north,legend columns=-1},
  reverse legend
}}

\begin{document}

\begin{tikzpicture}
 \begin{axis}[counter_barchart]
  \addplot coordinates {(0,Ass. Optimization)(19243,with Optimization) (8898,without Optimization)};
  \addplot coordinates {(7854,Ass. Optimization) (6652,with Optimization) (6548,without Optimization)};
  \legend{Second,First}
 \end{axis}
\end{tikzpicture}
\\

\begin{tikzpicture}
 \begin{axis}[counter_barchart]
  \addplot coordinates {(3985,without Optimization) (5456,with Optimization)};
  \addplot coordinates {(5223,without Optimization) (11054,with Optimization)};
  \legend{Second,First}
 \end{axis}
\end{tikzpicture}

\end{document}

Answer 1

하이픈을 피하려면 다음을 수행하십시오 yticklabel.

yticklabel style={text width=0.2\textwidth,align=flush left},

좌표 근처의 노드로 값 0을 숨기려면 다음을 수행하십시오.

nodes near coords={%
  \pgfmathtruncatemacro\NNC{\pgfkeysvalueof{/data point/x}}%
  \ifnumequal{\NNC}{0}{}{\NNC}% needs package etoolbox
},

xtick 크기 조정을 방지하려면:

scaled x ticks=false,

좌표 근처의 노드가 차트 외부에 플롯되는 것을 방지하려면 다음을 수행하십시오.

enlarge x limits={0.15,upper},

암호:

\documentclass[a4paper]{report}

\usepackage{etoolbox}
\usepackage{pgfplots}

\pgfplotsset{
  counter_barchart/.style={
    width=0.85\textwidth,
    height=5cm,
    xbar,
    xmin=0,
    xmajorgrids = true,
    tick align = outside, xtick pos = left,
    x tick label style={/pgf/number format/1000 sep=},
    scaled x ticks=false,
    enlarge y limits=0.4,
    enlarge x limits={0.15,upper},
    symbolic y coords={Ass. Optimization,with Optimization,without Optimization},
    ytick=data,
    yticklabel style={text width=0.2\textwidth,align=flush left},
    nodes near coords={%
      \pgfmathtruncatemacro\NNC{\pgfkeysvalueof{/data point/x}}%
      \ifnumequal{\NNC}{0}{}{\NNC}%
    },
    nodes near coords align={horizontal},
    legend style={at={(0.5,-0.35)},anchor=north,legend columns=-1},
    reverse legend
  }
}

\begin{document}

\begin{tikzpicture}
 \begin{axis}[counter_barchart,xtick={0,4000,8000,12000,16000,20000}]
  \addplot coordinates {(0,Ass. Optimization)(19243,with Optimization) (8898,without Optimization)};
  \addplot coordinates {(7854,Ass. Optimization) (6652,with Optimization) (6548,without Optimization)};
  \legend{Second,First}
 \end{axis}
\end{tikzpicture}

\vspace{1cm}
\begin{tikzpicture}
 \begin{axis}[counter_barchart]
  \addplot coordinates {(3985,without Optimization) (5456,with Optimization)};
  \addplot coordinates {(5223,without Optimization) (11054,with Optimization)};
  \legend{Second,First}
 \end{axis}
\end{tikzpicture}

\end{document}
