반복되는 텍스트로 단락을 채우는 명령(정렬/간격 문제)

tag-icon • tag-icon spacing horizontal-alignment boxes
반복되는 텍스트로 단락을 채우는 명령(정렬/간격 문제)

여러 번 반복하여 \todopar[dummy]{msg}단락을 채우고 단락 중앙에 조판하는 명령을 정의하려고 합니다 .dummymsg

최종 결과는 다음과 같아야 합니다(간격 문제 없음).

원하는

나의 첫 번째 시도는

\documentclass[draft]{article}

\usepackage{lipsum}
\usepackage{xcolor}

\colorlet{todocol}{green!30!black}

\newcommand{\repetita}[1]{\leavevmode\xleaders\hbox{#1\ }\hfill\kern0pt}
\newcommand{\todopar}[2][To Do]{%
  \par\medskip\noindent{%
  \color{todocol!50!white}
  \null\repetita{#1}\\%
  \null\repetita{#1}\\%
  \null\repetita{#1}%
  \textcolor{todocol}{#2}%
  \repetita{#1}\\%
  \null\repetita{#1}\\%
  \null\repetita{#1}\par\medskip%
}}

\begin{document}
  \lipsum*[1]
  \todopar{This is somehing we have to do soooo bad that takes even more than one line oh my gosh.}
  \lipsum*[1]
  \todopar{Lot of work}
  \lipsum*[1]
\end{document}

불행히도 \xleadersI를 사용하면 중앙 줄의 더미 텍스트가 나머지 단락의 텍스트와 정렬되지 않고 hbox리더의 내용이 공백으로 끝나므로 마지막 반복에서 줄이 공백으로 끝납니다. 또한.

이 두 가지 문제를 어떻게 해결할 수 있습니까? 이 효과를 구현하는 더 우아한 방법이 있습니까?

답변1

나는 리더 대신 단락을 사용하겠습니다.

여기에 이미지 설명을 입력하세요

\documentclass[draft]{article}

\usepackage{lipsum}
\usepackage{xcolor}

\colorlet{todocol}{green!30!black}


\newcommand{\todopar}[2][To Do]{%
% end the previous par and start a local group
  \par\medskip{%
% special para uses full length lines, no white space
% at start or end
  \parindent0pt
  \parfillskip0pt
% set colour for the filler text
  \color{todocol!50!white}%
% save filler text in box, for measuring
  \sbox0{#1 }%
%
% Set the message text in a normal paragraph with normal
% \parfillskip to allow the last line to be short as usual.
% the whole construct is inside a scratch box 2.
  \setbox2\vbox{\parfillskip\fill\strut#2\unskip\strut
% Finish the paragraph with the message text
  \par
% Probably not needed but remove any glue or penalty
% after the last line
  \unskip\unpenalty
% remove the last (or only) line of the message paragraph
  \setbox0\lastbox
%
% At this point box0 is always full width but contains the last
% line of the message followed by \rightskip and \parfillskip glue
% so \unskip twice and globally save box1 with the natural length
% of the last line of the message.
  \global\setbox1\hbox{\unhbox0\unskip\unskip}%
%
% Now remove the baselineskip glue before that last line.
  \unskip\unpenalty\unskip\unpenalty
% and finish the box
  }%
% Now box2 contains all the lines of the message except the last
% so for a short message it will be empty
%
% see how many filler text it takes for 2 lines of text
  \count0=\dimexpr2\columnwidth\relax
  \divide\count0 \wd0 %
%
% see how many filler text it takes to pad one side
% of a line that has the (last line of) the message in
% the middle
  \count2=\dimexpr(\columnwidth-\wd1-2em)/2\relax
  \divide\count2 \wd0 %
%
% save the filler text, use a macro rather than the box
% to allow any white space in the filler to stretch
  \def\tmp{\strut#1 }%
%
% make a paragraph of \count0 copies of the filler making
% a two full length  line paragraph
  \xrep{\count0}\par
%
% unbox box 2 this is the initial full length lines of the message
% in the main color. As this is unboxed it is a normal sequence of
% line boxes and glue so can break at a page.
  {\color{todocol}\unvbox2}%
%
% Now make a 1-line paragraph with count2 copies of filler
% either side of the last line of the message, with a word space
% padding either side/
  \xrep{\count2} \textcolor{todocol}{\unhbox1} \xrep{\count2}\par
%
% As before a 2 line filler paragraph
  \xrep{\count0}\par%
%
% end the local group
  }%
% A skip to match the one at the start.
 \medskip}

% A simple recursive loop macro, makes #1
% copies of \tmp
\def\xrep#1{%
\ifnum#1>0
\tmp
\xrep{\numexpr#1-1\relax}%
\fi}

% A test document....
\begin{document}
  \lipsum*[1]
  \todopar{This is somehing we have to do soooo bad that takes even more than one line oh my gosh.}
  \lipsum*[1]
  \todopar{Lot of work}
  \lipsum*[1]
\end{document}
