안녕하세요 여러분 저는 방정식 시스템과 동일한 행 공간에 행렬 방정식을 배치하려고 합니다. align*두 개를 합치기 위해 어떻게 세 번째를 넣으려고 했는지 잘 모르겠지만 작동하지 않는 것 같습니다.
\begin{align*}
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
x_{11} \\
x_{12} \\
x_{13} \\
x_{21}\\
x_{22}\\
x_{23}\\
\end{bmatrix}
&=
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
u_{11} \\
u_{12} \\
u_{13} \\
u_{21}\\
u_{22}\\
u_{23}\\
\end{bmatrix}
\end{align*}
\begin{align*}
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
\end{align*}
답변1
어쩌면 이런 게 있지 않을까요?
\documentclass{article}
\usepackage[a4paper,margin=2.5cm]{geometry} % set page margins
\usepackage{amsmath} % for 'bmatrix' and 'aligned' environments
\begin{document}
\[
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1
\end{bmatrix}
\begin{bmatrix}
x_{11} \\
x_{12} \\
x_{13} \\
x_{21} \\
x_{22} \\
x_{23}
\end{bmatrix}
=
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1
\end{bmatrix}
\begin{bmatrix}
u_{11} \\
u_{12} \\
u_{13} \\
u_{21} \\
u_{22} \\
u_{23}
\end{bmatrix}
\qquad\qquad
\begin{aligned}
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0
\end{aligned}
\]
\end{document}
답변2
이 말인가요?
\documentclass{article}
\usepackage{mathtools}
\begin{document}
\begin{align*}
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
x_{11} \\
x_{12} \\
x_{13} \\
x_{21}\\
x_{22}\\
x_{23}\\
\end{bmatrix}
&=
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
u_{11} \\
u_{12} \\
u_{13} \\
u_{21}\\
u_{22}\\
u_{23}\\
\end{bmatrix} \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
x_{11}x_{22}-x_{12}x_{21}&=0 \\
\end{align*}
\end{document}
답변3
아니면 이러한 솔루션 중 하나일까요?
\documentclass{article}
\usepackage{mathtools, nccmath}
\usepackage[showframe]{geometry}
\begin{document}
\vspace*{1cm}
\begin{alignat*}{2}
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
x_{11} \\
x_{12} \\
x_{13} \\
x_{21}\\
x_{22}\\
x_{23}\\
\end{bmatrix}
&=
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
u_{11} \\
u_{12} \\
u_{13} \\
u_{21}\\
u_{22}\\
u_{23}\\
\end{bmatrix}%
& \hspace{ 4em}%
\begin{matrix} x_{11}x_{22}-x_{12}x_{21}=0 \\
x_{11}x_{22}-x_{12}x_{21}=0 \\
x_{11}x_{22}-x_{12}x_{21}=0 \\
\end{matrix}
\end{alignat*}
\vskip1cm
\begin{align*}
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
x_{11} \\
x_{12} \\
x_{13} \\
x_{21}\\
x_{22}\\
x_{23}\\
\end{bmatrix}
&=
\begin{bmatrix}
1 & 1 & 1 & 0 & 0 & 0\\
0 & 0 & 0 & 1 & 1 & 1\\
1 & 0 & 0 & 1 & 0 & 0\\
0 & 1 & 0 & 0 & 1 & 0\\
0 & 0 & 1 & 0 & 0 & 1\\
\end{bmatrix}
\begin{bmatrix}
u_{11} \\
u_{12} \\
u_{13} \\
u_{21}\\
u_{22}\\
u_{23}\\
\end{bmatrix}%
& \hspace{ 4em}%
\begin{cases} x_{11}x_{22}-x_{12}x_{21}=0 \\
x_{11}x_{22}-x_{12}x_{21}=0 \\
x_{11}x_{22}-x_{12}x_{21}=0 \\
\end{cases}\hspace{-1em}
\end{align*}
\end{document}
