첫 번째 테이블을 적절하게 보이도록 최적화하는 데 시간을 보낸 후 동일한 내용이 다시 필요했지만 테이블이 여러 페이지를 포함하면서 문제가 발생했습니다. 에 대해 알았지 \longtable만 제가 아는 한 다른 요구 사항과 호환되지 않기 때문에 사용할 수 없습니다. 답변을 찾을 때의 문제는 각 문제에 대한 솔루션을 얻을 수 있지만 모든 요구 사항을 충족하기 위해 솔루션을 결합할 수 없다는 것입니다.
필수의:
- LuaLaTex를 사용합니다(Times New Roman을 사용해야 합니다).
- 테이블은 여러 페이지에 걸쳐 확장될 수 있습니다.
- 표 셀 내에서 줄바꿈
- 각 셀의 텍스트를 세로로 가운데 맞춤
- 표의 다른 행은 구별 가능해야 합니다(단어가 여러 줄이 있는 셀에 있더라도 단어가 어느 표 행에 속하는지 알 수 있어야 함).
- 테이블을 참조할 수 있는 레이블
- 호환성
\begin{landscape} \end{landscape}
내가 매우 감사하고 싶지만 그렇지 않으면 가능하지 않다면 없이도 견딜 수 있는 것들:
- 자동 줄 바꿈(
\linebreak대신 수동으로 설정) - 자체 조정 열 너비
- 각 열에 대한 수평 정렬의 개별 설정(한 열은 왼쪽 정렬, 다른 열은 중앙 정렬...)
\hboxunderfull -es 에 대한 경고가 없습니다.
아래 코드 예제에서는 테이블의 발전 과정을 통해 내가 겪은 몇 가지 문제와 해결 방법을 보여줍니다. 매우 만족스러운 솔루션을 찾았지만 \longtable. 이는 셀 내의 줄 바꿈, 수직 중앙 정렬 및 일반적으로 괜찮은 테이블 생성 측면에서 제가 이룬 모든 발전을 무효화합니다.
미리 답변해 주셔서 감사합니다!
코드 예시는 다음과 같습니다.
\documentclass[a4paper,11pt]{report}
% preamble
% general: margins, font, spacing
\usepackage[twoside,margin=2.5cm,bindingoffset=1.25cm]{geometry}
\usepackage{fontspec} % for times new roman
\setmainfont{Times New Roman}
\usepackage{setspace} % for 1.5 line spacing
% references to papers, figures, tables, ...
% \usepackage[style=IEEE,backend=biber]{biblatex}
% \addbibresource{library.bib}
\usepackage{refstyle} % for figure references
\usepackage{tabulary} % for easier handling of multiline entries in tables
\usepackage{array,booktabs} % http://ctan.org/pkg/
\usepackage{longtable} % for multi-page tables
\usepackage{lscape} % for horizontal tables
\begin{document}
\begin{onehalfspace} % line spacing
The following table is pretty bad. One entry/row is hard to distinguish from the other. Also, it produces four warnings for underfull hboxes. Everything is aligned to the left, which is not good, but there might be a solution for this which I didn't bother to look up due to the other problems.
\medskip
\begin{tabular}{p{7.5cm}p{2cm}p{3cm}}
\hline
\textbf{word} & \textbf{word} & \textbf{some text} \\ \hline
some even longer text, it \linebreak starts to get uncomfortable & some \linebreak more text & word \\
some text that is so long that it will have \linebreak to cover multiple lines no matter what & some \linebreak text & word \\
%\label{table:thefirstfailedattempt}
\end{tabular}
\bigskip
\bigskip
The following example is better, at least it doesn't generate warnings, decides where to include line breaks within cells and self-adjusts the width of each column. Moreover, it is easy to define the alignment for each column separately, which is something I appreciate. But the vertical centering is missing. This is not acceptable to me.
\medskip
\begin{tabulary}{14cm}{CCC} % good except for missing vertical centering
\hline
\textbf{word} & \textbf{word} & \textbf{some text} \\ \hline
some even longer text, it starts to get uncomfortable & some more text & word \\
some text that is so long that it will have to cover multiple lines no matter what & some text & word \\
%\label{table:thesecondfailedattempt}
\end{tabulary}
\bigskip
\bigskip
With this solution (Table\,\ref{table:solutionfound}) I was very happy. Distinguishable rows, vertical alignment, table-label and a nice format as the cherry on top. This is what I was looking for.
% http://tex.stackexchange.com/questions/127050/vertically-align-text-in-table-in-latex
\medskip
\begin{table}[htbp]
\centering
%\caption{Data Units, Sources, and Dates}
\renewcommand{\arraystretch}{1.5}% Spread rows out...
\begin{tabular}{>{\centering}m{7.5cm} >{\centering}m{2cm} >{\centering\arraybackslash}m{3cm}}
\toprule
\textbf{word} & \textbf{word} & \textbf{some text} \\
\midrule
some even longer text, it starts to get uncomfortable & some more text & word \\
some text that is so long that it will have \linebreak to cover multiple lines no matter what & some text & word \\
\bottomrule
\end{tabular}
\caption[The table I was happy with]{\textbf{The table I was happy with.} Some longer text describing the table. Some longer text describing the table. Some longer text describing the table. Some longer text describing the table.
\label{table:solutionfound}}
\end{table}
\bigskip
\bigskip
But then I reached the next table (Table\,\ref{table:thetablethatistoolong}), which is quite the monster. I had to switch to landscape to fit all the columns in, but I quickly found a solution that worked. However, it is too long and stretches over multiple pages. By looking up other stackexchange answers I found out that longtable is the solution for this. But my previous solution is not compatible with longtable, which nullifies all the advances I have made in terms of linebreaks within cells, vertical centering and generally producing a respectable table.
I could split this table into three separate tables (defined by the second column), but the third table (second column is 'bar') would still be too long for one page.
\begin{landscape}
\begin{table}[htbp] % doesn't work with longtable
\centering
%\caption{Data Units, Sources, and Dates}
\renewcommand{\arraystretch}{1.5}% Spread rows out...
\begin{tabular}{>{\centering}m{2cm} >{\centering}m{2cm} >{\centering}m{2cm} >{\centering}m{5cm} >{\centering}m{3cm} >{\centering}m{2cm} >{\centering}m{2cm} >{\centering\arraybackslash}m{3cm}}
\toprule
\textbf{some ID} & \textbf{a property} & \textbf{another column} & \textbf{column containing much text} & \textbf{more text} & \textbf{further specification of foo} & \textbf{further specification of bar} & \textbf{final comment} \\
\midrule
B01 & foo & word & some middle-length text & some text & some text & & some middle-length text \\
B02 & foo & word & some even longer text, it starts to get uncomfortable & word & word & & some text \\
B04 & foo & word & some text with a bit more length & word & word & & some text \\
B05 & foo & word & some text with a bit more length & some text & word & & some text \\
B06 & foo & word & some middle-length text & some text & some text & & some text \\
B08 & foo & word & some text with a bit more length & some text & some text & & some text with a bit more length \\
B10 & foo & word & some middle-length text & some text & some text & & some text \\
B11 & foo & word & some text with a bit more length & some text & word & & word \\
B12 & foo & word & some middle-length text & some text & word & & some text \\
B13 & foo & word & some middle-length text & some text & some text & & some text \\
B15 & foo & word & some even longer text, it starts to get uncomfortable & some text & some text & & some text \\
B16 & foo & word & some text that is so long that it will have to cover multiple lines no matter what & some text & some text & & some text \\
B17 & foo & word & some even longer text, it starts to get uncomfortable & word & some text & & some text \\
B18 & foo & word & some even longer text, it starts to get uncomfortable & word & some text & & some text \\
B19 & foo & word & some text that is so long that it will have to cover multiple lines no matter what & word & word & & some text \\
B21 & foo & word & some text with a bit more length & some text & some text & & word \\
B23 & foo & word & some text with a bit more length & some text & word & & some text \\
B25 & foo & word & some middle-length text & some text & some text & & some text \\
B27 & foo & word & some middle-length text & some text & word & & some text \\
B29 & foo & word & some text with a bit more length & some text & word & & some text \\
B30 & foo & word & some even longer text, it starts to get uncomfortable & some text & word & & some text \\
B32 & foo & word & some text with a bit more length & some text & word & & some text \\
B34 & foo & word & some middle-length text & some text & word & & word \\
B35 & foo & word & some text with a bit more length & some text & some text & & word \\
B39 & foo & word & some middle-length text & some text & some text & & word \\
B41 & foo & word & some even longer text, it starts to get uncomfortable & some text & some text & & word \\
B42 & foo & word & some text with a bit more length & word & word & & word \\
B45 & foo & word & some text with a bit more length & word & some text & & word \\
B04 & foo+bar & word & some middle-length text & some text & word & some text & some text \\
B14 & foo+bar & word & some middle-length text & some text & some text & word & some text \\
B20 & foo+bar & word & some middle-length text & word & some text & some text & word \\
B24 & foo+bar & word & some middle-length text & word & some middle-length text & word & some text \\
B26 & foo+bar & word & some text with a bit more length & some text & some middle-length text & some text & word \\
B28 & foo+bar & word & some even longer text, it starts to get uncomfortable & word & some text & word & word \\
B31 & foo+bar & word & some even longer text, it starts to get uncomfortable & some text & word & some text & word \\
B33 & foo+bar & word & some text with a bit more length & some text & some middle-length text & word & word \\
B40 & foo+bar & word & some text with a bit more length & word & some text & some text & word \\
B44 & foo+bar & word & some text with a bit more length & word & some middle-length text & some text & word \\
B46 & foo+bar & word & some middle-length text & some text & word & word & word \\
B48 & foo+bar & word & some middle-length text & word & some middle-length text & some text & some text \\
D01 & foo+bar & word & some even longer text, it starts to get uncomfortable & word & some middle-length text & some text & word \\
D05 & foo+bar & word & some middle-length text & some text & some text with a bit more length & word & infiltrated \\
D09 & foo+bar & word & some even longer text, it starts to get uncomfortable & some text & some text with a bit more length & word & infiltrated \\
D22 & foo+bar & word & some text with a bit more length & some text & some text with a bit more length & some text & some text \\
D31 & foo+bar & word & some text with a bit more length & some text & some text with a bit more length & some text & some text \\
D02 & bar & word & some text with a bit more length & some text & & word & word \\
D03 & bar & word & some text with a bit more length & word & & some text & some text \\
D04 & bar & word & some text with a bit more length & some text & & some text & some text \\
D06 & bar & word & some even longer text, it starts to get uncomfortable & word & & some text & some text \\
D07 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & some text \\
D08 & bar & word & some even longer text, it starts to get uncomfortable & some text & & some text & some text \\
D10 & bar & word & some even longer text, it starts to get uncomfortable & some text & & some text & some text \\
D11 & bar & word & some text with a bit more length & some text & & some text & some text \\
D12 & bar & word & some even longer text, it starts to get uncomfortable & word & & word & some text \\
D13 & bar & word & some text that is so long that it will have to cover multiple lines no matter what & word & & some text & word \\
D14 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D15 & bar & word & some middle-length text & word & & some text & word \\
D16 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D17 & bar & word & some text with a bit more length & some text & & some text & some text \\
D18 & bar & word & some text with a bit more length & some text & & some text & some text \\
D19 & bar & word & some text with a bit more length & some text & & word & word \\
D20 & bar & word & some text with a bit more length & word & & word & infiltrated \\
D21 & bar & word & some text with a bit more length & some text & & some text & some text \\
D23 & bar & word & some middle-length text & word & & some text & some text \\
D24 & bar & word & some text with a bit more length & some text & & some text & word \\
D25 & bar & word & some middle-length text & some text & & some text & word \\
D26 & bar & word & some text with a bit more length & some text & & word & word \\
D27 & bar & word & some text with a bit more length & word & & some text & word \\
D28 & bar & word & some text with a bit more length & some text & & word & word \\
D29 & bar & word & some text with a bit more length & some text & & word & word \\
D32 & bar & word & some text with a bit more length & some text & & word & word \\
D33 & bar & word & some middle-length text & word & & word & word \\
D34 & bar & word & some middle-length text & word & & some text & word \\
D35 & bar & word & some middle-length text & some text & & some text & word \\
D38 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D39 & bar & word & some text with a bit more length & word & & some text & word \\
D40 & bar & word & some text with a bit more length & some text & & word & word \\
D42 & bar & word & some text with a bit more length & word & & word & word \\
D43 & bar & word & some text with a bit more length & some text & & some text & word \\
D44 & bar & word & some text with a bit more length & some text & & some text & word \\
D45 & bar & word & some text with a bit more length & some text & & some text & word \\
D46 & bar & word & some text with a bit more length & some text & & word & word \\
\bottomrule
\end{tabular}
\caption[This table is too long]{\textbf{This table is too long, you won't even see this.} Some longer text describing the table. Some longer text describing the table. Some longer text describing the table. Some longer text describing the table.
\label{table:thetablethatistoolong}}
\end{table}
\end{landscape}
\end{onehalfspace} % line spacing
\end{document}
답변1
당신은 무엇을 했는지 말하지 않았지만 longtable아마도 당신이 뭔가 잘못한 것 같습니다. 내가 전환하면 longtable제대로 작동하는 것 같습니다.
\documentclass[a4paper,11pt]{report}
% preamble
% general: margins, font, spacing
\usepackage[twoside,margin=2.5cm,bindingoffset=1.25cm]{geometry}
\usepackage{fontspec} % for times new roman
\setmainfont{Times New Roman}
\usepackage{setspace} % for 1.5 line spacing
% references to papers, figures, tables, ...
% \usepackage[style=IEEE,backend=biber]{biblatex}
% \addbibresource{library.bib}
\usepackage{refstyle} % for figure references
\usepackage{tabulary} % for easier handling of multiline entries in tables
\usepackage{array,booktabs} % http://ctan.org/pkg/
\usepackage{longtable} % for multi-page tables
\usepackage{lscape} % for horizontal tables
\begin{document}
\begin{onehalfspace} % line spacing
The following table is pretty bad. One entry/row is hard to distinguish from the other. Also, it produces four warnings for underfull hboxes. Everything is aligned to the left, which is not good, but there might be a solution for this which I didn't bother to look up due to the other problems.
\medskip
\begin{tabular}{p{7.5cm}p{2cm}p{3cm}}
\hline
\textbf{word} & \textbf{word} & \textbf{some text} \\ \hline
some even longer text, it \linebreak starts to get uncomfortable & some \linebreak more text & word \\
some text that is so long that it will have \linebreak to cover multiple lines no matter what & some \linebreak text & word \\
%\label{table:thefirstfailedattempt}
\end{tabular}
\bigskip
\bigskip
The following example is better, at least it doesn't generate warnings, decides where to include line breaks within cells and self-adjusts the width of each column. Moreover, it is easy to define the alignment for each column separately, which is something I appreciate. But the vertical centering is missing. This is not acceptable to me.
\medskip
\begin{tabulary}{14cm}{CCC} % good except for missing vertical centering
\hline
\textbf{word} & \textbf{word} & \textbf{some text} \\ \hline
some even longer text, it starts to get uncomfortable & some more text & word \\
some text that is so long that it will have to cover multiple lines no matter what & some text & word \\
%\label{table:thesecondfailedattempt}
\end{tabulary}
\bigskip
\bigskip
With this solution (Table\,\ref{table:solutionfound}) I was very happy. Distinguishable rows, vertical alignment, table-label and a nice format as the cherry on top. This is what I was looking for.
% http://tex.stackexchange.com/questions/127050/vertically-align-text-in-table-in-latex
\medskip
\begin{table}[htbp]
\centering
%\caption{Data Units, Sources, and Dates}
\renewcommand{\arraystretch}{1.5}% Spread rows out...
\begin{tabular}{>{\centering}m{7.5cm} >{\centering}m{2cm} >{\centering\arraybackslash}m{3cm}}
\toprule
\textbf{word} & \textbf{word} & \textbf{some text} \\
\midrule
some even longer text, it starts to get uncomfortable & some more text & word \\
some text that is so long that it will have \linebreak to cover multiple lines no matter what & some text & word \\
\bottomrule
\end{tabular}
\caption[The table I was happy with]{\textbf{The table I was happy with.} Some longer text describing the table. Some longer text describing the table. Some longer text describing the table. Some longer text describing the table.
\label{table:solutionfound}}
\end{table}
\bigskip
\bigskip
But then I reached the next table (Table\,\ref{table:thetablethatistoolong}), which is quite the monster. I had to switch to landscape to fit all the columns in, but I quickly found a solution that worked. However, it is too long and stretches over multiple pages. By looking up other stackexchange answers I found out that longtable is the solution for this. But my previous solution is not compatible with longtable, which nullifies all the advances I have made in terms of linebreaks within cells, vertical centering and generally producing a respectable table.
I could split this table into three separate tables (defined by the second column), but the third table (second column is 'bar') would still be too long for one page.
\begin{landscape}
\renewcommand{\arraystretch}{1.5}% Spread rows out...
\begin{longtable}
{>{\centering}m{2cm} >{\centering}m{2cm} >{\centering}m{2cm} >{\centering}m{5cm} >{\centering}m{3cm} >{\centering}m{2cm} >{\centering}m{2cm} >{\centering\arraybackslash}m{3cm}}
\toprule
\textbf{some ID} & \textbf{a property} & \textbf{another column} & \textbf{column containing much text} & \textbf{more text} & \textbf{further specification of foo} & \textbf{further specification of bar} & \textbf{final comment} \\
\midrule
B01 & foo & word & some middle-length text & some text & some text & & some middle-length text \\
B02 & foo & word & some even longer text, it starts to get uncomfortable & word & word & & some text \\
B04 & foo & word & some text with a bit more length & word & word & & some text \\
B05 & foo & word & some text with a bit more length & some text & word & & some text \\
B06 & foo & word & some middle-length text & some text & some text & & some text \\
B08 & foo & word & some text with a bit more length & some text & some text & & some text with a bit more length \\
B10 & foo & word & some middle-length text & some text & some text & & some text \\
B11 & foo & word & some text with a bit more length & some text & word & & word \\
B12 & foo & word & some middle-length text & some text & word & & some text \\
B13 & foo & word & some middle-length text & some text & some text & & some text \\
B15 & foo & word & some even longer text, it starts to get uncomfortable & some text & some text & & some text \\
B16 & foo & word & some text that is so long that it will have to cover multiple lines no matter what & some text & some text & & some text \\
B17 & foo & word & some even longer text, it starts to get uncomfortable & word & some text & & some text \\
B18 & foo & word & some even longer text, it starts to get uncomfortable & word & some text & & some text \\
B19 & foo & word & some text that is so long that it will have to cover multiple lines no matter what & word & word & & some text \\
B21 & foo & word & some text with a bit more length & some text & some text & & word \\
B23 & foo & word & some text with a bit more length & some text & word & & some text \\
B25 & foo & word & some middle-length text & some text & some text & & some text \\
B27 & foo & word & some middle-length text & some text & word & & some text \\
B29 & foo & word & some text with a bit more length & some text & word & & some text \\
B30 & foo & word & some even longer text, it starts to get uncomfortable & some text & word & & some text \\
B32 & foo & word & some text with a bit more length & some text & word & & some text \\
B34 & foo & word & some middle-length text & some text & word & & word \\
B35 & foo & word & some text with a bit more length & some text & some text & & word \\
B39 & foo & word & some middle-length text & some text & some text & & word \\
B41 & foo & word & some even longer text, it starts to get uncomfortable & some text & some text & & word \\
B42 & foo & word & some text with a bit more length & word & word & & word \\
B45 & foo & word & some text with a bit more length & word & some text & & word \\
B04 & foo+bar & word & some middle-length text & some text & word & some text & some text \\
B14 & foo+bar & word & some middle-length text & some text & some text & word & some text \\
B20 & foo+bar & word & some middle-length text & word & some text & some text & word \\
B24 & foo+bar & word & some middle-length text & word & some middle-length text & word & some text \\
B26 & foo+bar & word & some text with a bit more length & some text & some middle-length text & some text & word \\
B28 & foo+bar & word & some even longer text, it starts to get uncomfortable & word & some text & word & word \\
B31 & foo+bar & word & some even longer text, it starts to get uncomfortable & some text & word & some text & word \\
B33 & foo+bar & word & some text with a bit more length & some text & some middle-length text & word & word \\
B40 & foo+bar & word & some text with a bit more length & word & some text & some text & word \\
B44 & foo+bar & word & some text with a bit more length & word & some middle-length text & some text & word \\
B46 & foo+bar & word & some middle-length text & some text & word & word & word \\
B48 & foo+bar & word & some middle-length text & word & some middle-length text & some text & some text \\
D01 & foo+bar & word & some even longer text, it starts to get uncomfortable & word & some middle-length text & some text & word \\
D05 & foo+bar & word & some middle-length text & some text & some text with a bit more length & word & infiltrated \\
D09 & foo+bar & word & some even longer text, it starts to get uncomfortable & some text & some text with a bit more length & word & infiltrated \\
D22 & foo+bar & word & some text with a bit more length & some text & some text with a bit more length & some text & some text \\
D31 & foo+bar & word & some text with a bit more length & some text & some text with a bit more length & some text & some text \\
D02 & bar & word & some text with a bit more length & some text & & word & word \\
D03 & bar & word & some text with a bit more length & word & & some text & some text \\
D04 & bar & word & some text with a bit more length & some text & & some text & some text \\
D06 & bar & word & some even longer text, it starts to get uncomfortable & word & & some text & some text \\
D07 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & some text \\
D08 & bar & word & some even longer text, it starts to get uncomfortable & some text & & some text & some text \\
D10 & bar & word & some even longer text, it starts to get uncomfortable & some text & & some text & some text \\
D11 & bar & word & some text with a bit more length & some text & & some text & some text \\
D12 & bar & word & some even longer text, it starts to get uncomfortable & word & & word & some text \\
D13 & bar & word & some text that is so long that it will have to cover multiple lines no matter what & word & & some text & word \\
D14 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D15 & bar & word & some middle-length text & word & & some text & word \\
D16 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D17 & bar & word & some text with a bit more length & some text & & some text & some text \\
D18 & bar & word & some text with a bit more length & some text & & some text & some text \\
D19 & bar & word & some text with a bit more length & some text & & word & word \\
D20 & bar & word & some text with a bit more length & word & & word & infiltrated \\
D21 & bar & word & some text with a bit more length & some text & & some text & some text \\
D23 & bar & word & some middle-length text & word & & some text & some text \\
D24 & bar & word & some text with a bit more length & some text & & some text & word \\
D25 & bar & word & some middle-length text & some text & & some text & word \\
D26 & bar & word & some text with a bit more length & some text & & word & word \\
D27 & bar & word & some text with a bit more length & word & & some text & word \\
D28 & bar & word & some text with a bit more length & some text & & word & word \\
D29 & bar & word & some text with a bit more length & some text & & word & word \\
D32 & bar & word & some text with a bit more length & some text & & word & word \\
D33 & bar & word & some middle-length text & word & & word & word \\
D34 & bar & word & some middle-length text & word & & some text & word \\
D35 & bar & word & some middle-length text & some text & & some text & word \\
D38 & bar & word & some even longer text, it starts to get uncomfortable & some text & & word & word \\
D39 & bar & word & some text with a bit more length & word & & some text & word \\
D40 & bar & word & some text with a bit more length & some text & & word & word \\
D42 & bar & word & some text with a bit more length & word & & word & word \\
D43 & bar & word & some text with a bit more length & some text & & some text & word \\
D44 & bar & word & some text with a bit more length & some text & & some text & word \\
D45 & bar & word & some text with a bit more length & some text & & some text & word \\
D46 & bar & word & some text with a bit more length & some text & & word & word \\
\bottomrule
\caption[This table is too long]{\textbf{This table is too long, you won't even see this.} Some longer text describing the table. Some longer text describing the table. Some longer text describing the table. Some longer text describing the table.
\label{table:thetablethatistoolong}}
\end{longtable}
\end{landscape}
\end{onehalfspace} % line spacing
\end{document}
