나는 그림 2의 Dias & Vermunt 2007에서 설명한 대로 Markov 지도를 만들려고 합니다.http://members.home.nl/jeroenvermunt/dias2006c.pdf
그림은 다음과 같습니다.
지금까지 Ti에 그리드를 사용해 보았습니다.케이Z는 그라데이션 색상 작업을 하고 있지만 상태 이름을 추가할 수 없는 것 같습니다. 나는 또한 테이블을 가지고 시도했지만 이 결과는 보기에 좋지 않았습니다(매우 지저분하고 셀 크기가 다름).
(여기가 처음이니까 제대로 됐으면 좋겠어!)
헤더 이름을 추가하고 멋진 지도를 만드는 방법을 아는 사람이 있습니까?
정말 감사합니다!
댓글에 답변을 드릴 수가 없네요.. 그래서 이렇게 하겠습니다. Ti의 매트릭스 라이브러리케이z는 매우 잘 작동하지만(댓글에 게시된 결과를 보게 됩니다), 22*22 행렬로 확장하면 오류가 나타납니다.
Overfull \hbox - 거의 모든 단락에서...
크기, 최소 너비 및 텍스트 너비를 변경해 보았지만 도움이 되지 않았습니다. 이 조치의 의미와 해결 방법을 설명해 주시겠습니까? 다시 감사합니다!
여러 개의 Markov 지도가 나란히 필요하지만 아래쪽 2개의 지도가 서로 다른 위치에 있으므로 정렬이 제대로 이루어지지 않습니다. 누군가 이 문제를 해결하는 방법을 알고 있습니까?
\begin{figure}[tb]
\subcaptionbox{Cluster 1, $\pi_1 = 0.18$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=30mm, text width=28mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ \& AC \& CH \& DP \& HP \& IA \& LB \& LP \& NL \& SC \& show\_discount\_reminder \& show\_funnel\_campaign \& show\_recc \& show\_recp \& show\_upsell \& show\_wijnatlas \& WV \& XT \\
AC \& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 45 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 37 ]|\& |[fill=black! 0 ]|\& |[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 5 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 8 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 17 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 25 ]|\& |[fill=black! 0 ]|\& |[fill=black! 13 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 2, $\pi_2 = 0.16$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ AC \& CH \& DP \& HP \& IA \& LB \& LP \& NL \& SC \& show\_discount\_reminder \& show\_funnel\_campaign \& show\_recc \& show\_recp \& show\_upsell \& show\_wijnatlas \& WV \& XT \\
|[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 79 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 14 ]|\& |[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 49 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 33 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 3, $\pi_3 = 0.23$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=30mm, text width=28mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{AC \& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 10 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 0 ]|\& |[fill=black! 7 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 18 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 25 ]|\& |[fill=black! 1 ]|\& |[fill=black! 20 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 9 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 4, $\pi_4 = 0.13$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 71 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 21 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 16 ]|\& |[fill=black! 11 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 40 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 5, $\pi_5 = 0.17$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{AC \& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 76 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 9 ]|\& |[fill=black! 28 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 29 ]|\& |[fill=black! 0 ]|\& |[fill=black! 13 ]|\& |[fill=black! 0 ]|\& |[fill=black! 3 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 5 ]|\& |[fill=black! 8 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 6, $\pi_6 = 0.12$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 18 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 33 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 7 ]|\& |[fill=black! 1 ]|\& |[fill=black! 8 ]|\& |[fill=black! 29 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 10 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 15 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 7 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\label{TP_userS6}
\caption{Transition probabilities of user data (ADJ) using MMM}
\end{figure}
답변1
다음을 사용할 수 있습니다 matrix.
\documentclass[tikz,border=2mm]{standalone}
\usetikzlibrary{matrix}
\begin{document}
\begin{tikzpicture}[font=\sffamily\tiny]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=12mm, text width=10mm, align=left}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{
& frontpage & news & tech \\
frontpage & |[fill=red]| & |[fill=orange]| & \\
news & & |[fill=red!70!black]| & \\
tech & & |[fill=yellow]| & |[fill=red!70!black]| \\
};
\end{tikzpicture}
\end{document}
업데이트:
22x22 행렬의 문제는 크기 때문이 아니라 첫 번째 열의 노드 크기 때문입니다. 이전 예에서는 다음과 같이 정의되었습니다.
column 1/.style={nodes={draw=none, minimum width=12mm, text width=10mm, align=left}},
이 크기에서는 맞을 수 있지만 frontpage맞지는 않습니다 show\_discount\_reminer. 이러한 긴 단어를 처리할 만큼 충분히 긴 열 1 노드를 선언하면 관련 메시지가 모두 overfull horizontal box사라집니다.
\documentclass{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{lmodern}
\usepackage{tikz}
\usetikzlibrary{matrix}
\usepackage{lipsum}
\begin{document}
\lipsum[1]
\begin{figure}[tb]
\begin{tikzpicture}[font=\itshape]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=left}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{
& AC & ACRC & CH & DP & HP & IA & infl\_discount\_reminder & infl\_funnel\_campaign & infl\_upsell & infl\_wijnatlas & LB & LP & NL & SC & show\_discount\_reminder & show\_funnel\_campaign & show\_recc & show\_recp & show\_upsell & show\_wijnatlas & WV & XT \\
AC & |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 39 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 43 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
ACRC & |[fill=black! 40 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 20 ]|& |[fill=black! 20 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 20 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
CH & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 30 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 22 ]|\\
DP & |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 17 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 52 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
HP & |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 49 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 18 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 13 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 3 ]|\\
IA & |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 14 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 1 ]|& |[fill=black! 25 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|\\
infl\_discount\_reminder & |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 2 ]|& |[fill=black! 2 ]|& |[fill=black! 30 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 33 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
infl\_funnel\_campaign & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 27 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 48 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|\\
infl\_upsell & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 64 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 36 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
infl\_wijnatlas & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 64 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 27 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
LB & |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 13 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 32 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
LP & |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 36 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
NL & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 5 ]|& |[fill=black! 81 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
SC & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 2 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 47 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 23 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
show\_discount\_reminder & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 82 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|\\
show\_funnel\_campaign & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 81 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
show\_recc & |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 11 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 13 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 34 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|\\
show\_recp & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 50 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 50 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
show\_upsell & |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 45 ]|& |[fill=black! 1 ]|& |[fill=black! 3 ]|& |[fill=black! 32 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
show\_wijnatlas & |[fill=black! 10 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 12 ]|& |[fill=black! 3 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 43 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 21 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
WV & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 33 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 24 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 10 ]|& |[fill=black! 3 ]|\\
XT & |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 25 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
\caption{Markov map aggregated data (S=1).}
\end{figure}
\end{document}
답변2
귀하의 질문에서 제안한 것과 유사한 접근 방식은 다음과 같습니다. 두 개의 루프를 사용하여 열과 행에 레이블을 지정한 다음 \fill선택한 셀에 레이블을 지정하고 마지막으로 그리드에 레이블을 지정합니다. 그리드는 마지막 단계로 그려지므로 그리드의 선이 채워진 셀의 가장자리를 덮습니다.
\documentclass [border=2mm]{standalone}
\usepackage{graphicx}
\usepackage{tikz}
\begin{document}
\begin{tikzpicture}[scale=0.4]
% Put column headers
\foreach \header [count=\c] in {Lorem, ipsum, dolor, sit, amet, consectetur, adipiscing, elit, Proin, vulputate, dignissim, odio, eu, euismod, sapien, sodales, eu, Curabitur, ipsum, nibh, dictum, eu} {
\node[above] at (\c-0.5,22) {\rotatebox{90}{\small\sffamily\header}};
}
% Put row headers
\foreach \header [count=\c] in {Lorem, ipsum, dolor, sit, amet, consectetur, adipiscing, elit, Proin, vulputate, dignissim, odio, eu, euismod, sapien, sodales, eu, Curabitur, ipsum, nibh, dictum, eu} {
\node[left] at (0,22-\c+0.5) {\small\sffamily\header};
}
% Fill some squares
\fill[black!10] (0,21) rectangle +(1,1); % Use relative coordinates for the rectangle size
\fill[black!30] (1,20) rectangle +(1,1); % Use relative coordinates for the rectangle size
% Finally, the grid
\draw[black, very thin] (0,0) grid (22,22);
\end{tikzpicture}
\end{document}
결과:
