LaTeX에서 이 흐름도를 생성하는 데 도움을 줄 수 있는 사람이 있습니까?

Question

지금까지 내가 한 일은 내가 원하는 것과 전혀 가깝지 않습니다.

\documentclass[12pt]{article}
\usepackage[utf8]{inputenc}
\usepackage{graphicx}
\usepackage{tikz}
\usetikzlibrary{shapes,arrows}
\usepackage{mathtools}
\usepackage{ifthen}
\usepackage{pgfplots}
\pgfplotsset{compat=1.14}



\begin{document}
%Flow diagram Node Definitions
\tikzstyle{prof} = [rectangle, rounded corners, minimum width=2cm,     minimum height=0.5cm,text centered,text width=8em, draw=black, fill=red!30]
\tikzstyle{process} = [rectangle, minimum width=3cm, minimum height=1cm, text centered, text width=15em, draw=black, fill=green!30]
\tikzstyle{arrow} = [->, >=latex', shorten >=1pt, thick]
\tikzstyle{cloud} = [draw, ellipse,fill=red!20, node distance=2cm,minimum width=2.5cm, minimum height=2em, align=center]
\tikzstyle{cfr} = [rectangle, rounded corners, minimum width=3cm, minimum height=1cm,text centered,text width=15em, draw=black, fill=blue!40]
\tikzstyle{cbr} = [rectangle, rounded corners, minimum width=3cm, minimum height=1cm,text width=15em,text centered, draw=black, fill=blue!40]
\tikzstyle{hyb} = [rectangle, rounded corners, minimum width=4cm, minimum height=1cm,text width=25em, text centered, draw=black, fill=green!30]


\begin{figure}
\begin{center}
\begin{tikzpicture}[node distance=2cm]


\node (bt) [cfr] {Phase 7};
\node (pp) [cbr, right of=bt, xshift=8.5cm] {Phase 1};
\node (newuser) [cfr, below of=bt,yshift=-2.5cm, xshift=-3cm] {Phase 2};
\node (olduser) [cbr, below of=pp,yshift=-2.5cm, xshift=2cm] {Phase 3};
\node (dm) [cbr, below of=bt, yshift=-7cm] {Phase 4};
\node (dmo) [cbr, below of=pp, yshift=-7cm] {Phase 5};
\node (ver) [cloud, below of=bt, yshift=-2.5cm, xshift=5cm] {Phase 6};

\end{tikzpicture}
\caption{Process Flow}
\label{pic:flow}
\end{center}
\end{figure}
\end{document}

Answer 1

더 이상 사용되지 않는 구문과 원하지 않는 색상으로 절대 사용하지 않는 스타일을 만드는 것은 의미가 없기 때문에 그림을 그리려고 코드를 생성했는지 의심됩니다. (그래서 코드가 실제로 승인되지 않은 소스에서 나온 것인지 궁금합니다.)

순서도에 대한 패키지가 있으므로 해당 패키지를 조사해야 합니다.

\documentclass[border=10pt]{standalone}
\usepackage[utf8]{inputenc}
\usepackage{tikz}
\usetikzlibrary{shapes.arrows,arrows.meta,positioning,shapes.geometric}

\begin{document}
\begin{tikzpicture}
  [
    node distance=2cm,
    >=Latex,
    cbr/.style={text centered, draw=black, minimum height=1cm, rounded corners, minimum width=3cm, text width=15em, },
  ]
  \begin{scope}[local bounding box=c]
    \draw (-.5,-.75) coordinate (a) [out=-30, in=120] to (.5,-.75) |- (-.5,.75) coordinate [midway] (b) -- cycle ;
    \clip  (a) |- (b) -- ++(0,1) -- ++(-2,0) |- cycle ;
    \begin{scope}[shift=(135:.25)]
      \draw (-.5,-.75) coordinate (a1) [out=-30, in=120] to (.5,-.75) |- (-.5,.75) coordinate [midway] (b1) -- cycle ;
    \end{scope}
    \clip  (a1) |- (b1) -- ++(0,1) -- ++(-2,0) |- cycle ;
    \begin{scope}[shift=(135:.5)]
      \draw (-.5,-.75) coordinate (a2) [out=-30, in=120] to (.5,-.75) |- (-.5,.75) coordinate [midway] (b2) -- cycle ;
    \end{scope}
  \end{scope}
  \foreach \i [count=\j] in {60,120,...,360}
  {
    \node (p\j) [cbr] at (\i:7) {Phase \j};
    \draw [<->] (p\j) -- (c);
  }
  \foreach \i/\j [remember=\i as \ilast (initially 6) ] in {1,...,6}
  {
    \pgfmathor{\i==1}{\i==4}\ifnum\pgfmathresult=1\draw  [<->, densely dotted] (p\ilast) |- (p\i);
    \else\pgfmathor{\i==2}{\i==5}\ifnum\pgfmathresult=1\draw  [<->, densely dotted] (p\ilast) -- (p\i);
    \else\draw [<->, densely dotted] (p\ilast) -| (p\i);
    \fi\fi
  }
  \node (w) [right=of p6, double arrow, draw, text width=20mm, text centered] {Arrow};
  \node [right=of w, draw, cylinder, shape border rotate=90,  anchor=center, minimum width=15mm, minimum height=30mm] {Drum};
\end{tikzpicture}
\end{document}
