테이블 번호가 제대로 증가하지 않음
\documentclass{book}

\usepackage{array}
\usepackage{mdframed}
\usepackage{multirow}
\usepackage{xcolor} % Required for specifying colors by name
\definecolor{ocre}{RGB}{243,102,25}
\usepackage{float}
\usepackage{caption}
\usepackage{booktabs}
\usepackage{longtable}

\newmdenv[%
linecolor=ocre,
backgroundcolor=ocre!10,
linewidth=1pt]
{Tablebox}


\newenvironment{mytablebox}
{
    \begin{Tablebox}

    }
    {
    \end{Tablebox}
}



\begin{document}
    The various activities which are performed in the Crane shop are given in table \ref{table:crane_shop_activities}.
    \begin{mytablebox}
        %\begin{table}[H]
        \centering
        \captionof{table}{Crane shop activities.}
            \label{table:crane_shop_activities}
        \begin{longtable}{|m{2cm}| m{4cm}| m{4cm}|}
            \hline
            \textbf{Category} & \textbf{Types} & \textbf{Activities}\\
            \hline
            \multirow{3}{*}{Tower Car} & Mark II, III, IV & \multirow{3}{4cm}{Earlier Manufacturing, currently only POH}\\
            \cline{2-2}
            & DHTC (Diesel Hydraulic Tower Car) & \\
            \cline{2-2}
            & 8 Wheeler &\\
            \hline
            \multirow{2}{*}{20T Crane} & Mechanical & \multirow{2}{4cm}{Both Manufacturing and POH}\\
            \cline{2-2}
            & Hydraulic (retrofitting of mechanical superstructure with hydraulic one) & \\
            \hline
            \multirow{2}{*}{140T Crane} & Old Design Crane & POH, MLR, SP MLR\\
            \cline{2-3}
            & New Design Crane & Manufacturing, POH, MLR, SP MLR\\
            \hline

        \end{longtable}
        %\end{table}
    \end{mytablebox}

    Activities related to 140T crane are given in detail in table \ref{table:140T_activities}.
    \begin{mytablebox}
        \begin{table}[H]
            \caption{140T Crane activities.}
            \begin{tabular}{|p{0.45\textwidth}|p{0.45\textwidth}|}
                \hline
                1$^{st}$ POH & After 8 yrs\\
                \hline
                2$^{nd}$ POH & After 16 yrs\\
                \hline
                MLR & After 22 yrs\\
                \hline
                SP MLR & After 30 yrs\\
                \hline
                SR (Special Repair) & Accidental and unpredictable\\
                \hline
            \end{tabular}
            \label{table:140T_activities}
        \end{table}
    \end{mytablebox}



\end{document}

두 번째 테이블의 테이블 번호가 잘못되었습니다.

테이블 번호 2가 세 번째 테이블로 제공됩니다. 이를 수정하는 방법은 무엇입니까?

답변1

유감스럽게도 이것을 말할 수 있는 부드러운 방법이 없습니다. 귀하는 longtable및 table환경을 오용하고 있습니다.그리고매크로 \captionof.

  • 환경 을 사용하는 경우 longtable,사용하지 마세요성명 \captionof{table}{...}. 대신 표준 \caption설명을 사용하세요.

  • 환경 내부에 표 형식의 자료를 포함시키려는 경우 mytablebox,사용하지 마세요table진술 과 함께 환경 \caption. 대신 래퍼를 제거하고 지시문 table을 적용 \centering하고 \captionof명령문을 사용하세요.

여기에 이미지 설명을 입력하세요

\documentclass{book}
\usepackage{array}
\setlength\extrarowheight{2pt} % for a more "open" look
\usepackage{mdframed}
\usepackage{multirow}
\usepackage{xcolor} % Required for specifying colors by name
\definecolor{ocre}{RGB}{243,102,25}
\usepackage{float}
\usepackage[skip=0.333\baselineskip]{caption}
\usepackage{booktabs}
\usepackage{longtable}

\newmdenv[%
    linecolor=ocre,
    backgroundcolor=ocre!10,
    linewidth=1pt]
  {Tablebox}
\newenvironment{mytablebox}
   {\begin{Tablebox}}{\end{Tablebox}}

\begin{document}
Various activities performed in the Crane shop are given in table \ref{table:crane_shop_activities}.
    \begin{mytablebox}
    \begin{longtable}{|m{2cm}| m{4cm}| m{4cm}|}
        \caption{Crane shop activities.}
        \label{table:crane_shop_activities}\\
        \hline
        \textbf{Category} & \textbf{Types} & \textbf{Activities}\\
        \hline
        \multirow{3}{*}{Tower Car} & Mark II, III, IV &
        \multirow{3}{4cm}{Earlier Manufacturing, currently only POH}\\
        \cline{2-2}
        & DHTC (Diesel Hydraulic Tower Car) & \\
        \cline{2-2}
        & 8 Wheeler &\\
        \hline
        \multirow{2}{*}{20T Crane} & Mechanical &
        \multirow{2}{4cm}{Both Manufacturing and POH}\\
        \cline{2-2}
        & Hydraulic (retrofitting of mechanical superstructure with hydraulic one) & \\
        \hline
        \multirow{2}{*}{140T Crane} & Old Design Crane & POH, MLR, SP MLR\\
        \cline{2-3}
        & New Design Crane & Manufacturing, POH, MLR, SP MLR\\
        \hline
    \end{longtable}
    \end{mytablebox}

Activities related to 140T crane are given in detail in table \ref{table:140T_activities}.
    \begin{mytablebox}
    \centering % <-- new!
    %\begin{table}[H] %% do NOT use a 'table' env.
        \captionof{table}{140T Crane activities.} %% use '\captionof', not '\caption'
        \label{table:140T_activities}
        \begin{tabular}{|p{0.45\textwidth}|p{0.45\textwidth}|}
        \hline
        1$^{st}$ POH & After 8 yrs\\
        \hline
        2$^{nd}$ POH & After 16 yrs\\
        \hline
        MLR & After 22 yrs\\
        \hline
        SP MLR & After 30 yrs\\
        \hline
        SR (Special Repair) & Accidental and unpredictable\\
        \hline
        \end{tabular}
    %\end{table}
    \end{mytablebox}

\end{document}

답변2

솔루션longtabular

안에 \captionand 를 적어야 합니다 .\labellongtabular

\documentclass{book}

\usepackage{array}
\usepackage{mdframed}
\usepackage{multirow}
\usepackage{xcolor} % Required for specifying colors by name
\definecolor{ocre}{RGB}{243,102,25}
\usepackage{float}
\usepackage{caption}
\usepackage{booktabs}
\usepackage{longtable}

\newmdenv[%
linecolor=ocre,
backgroundcolor=ocre!10,
linewidth=1pt]
{Tablebox}

\newenvironment{mytablebox}
{
    \begin{Tablebox}
}
{
    \end{Tablebox}
}

\begin{document}
    The various activities which are performed in the Crane shop are given in table \ref{table:crane_shop_activities}.
    \begin{mytablebox}
        \centering
        \begin{longtable}{|m{2cm}| m{4cm}| m{4cm}|}
            \caption{Crane shop activities.}
            \label{table:crane_shop_activities}\\
            \hline
            \textbf{Category} & \textbf{Types} & \textbf{Activities}\\
            \hline
            \multirow{3}{*}{Tower Car} & Mark II, III, IV & \multirow{3}{4cm}{Earlier Manufacturing, currently only POH}\\
            \cline{2-2}
            & DHTC (Diesel Hydraulic Tower Car) & \\
            \cline{2-2}
            & 8 Wheeler &\\
            \hline
            \multirow{2}{*}{20T Crane} & Mechanical & \multirow{2}{4cm}{Both Manufacturing and POH}\\
            \cline{2-2}
            & Hydraulic (retrofitting of mechanical superstructure with hydraulic one) & \\
            \hline
            \multirow{2}{*}{140T Crane} & Old Design Crane & POH, MLR, SP MLR\\
            \cline{2-3}
            & New Design Crane & Manufacturing, POH, MLR, SP MLR\\
            \hline
        \end{longtable}
    \end{mytablebox}

    Activities related to 140T crane are given in detail in table \ref{table:140T_activities}.
    \begin{mytablebox}
        \begin{table}[H]
            \caption{140T Crane activities.}
            \begin{tabular}{|p{0.45\textwidth}|p{0.45\textwidth}|}
                \hline
                1$^{st}$ POH & After 8 yrs\\
                \hline
                2$^{nd}$ POH & After 16 yrs\\
                \hline
                MLR & After 22 yrs\\
                \hline
                SP MLR & After 30 yrs\\
                \hline
                SR (Special Repair) & Accidental and unpredictable\\
                \hline
            \end{tabular}
            \label{table:140T_activities}
        \end{table}
    \end{mytablebox}
\end{document}

여기에 이미지 설명을 입력하세요

없는 솔루션longtabular

tabular대신 사용하면 longtable작동합니다. 다른 간격을 피하려면 \captionof두 번째 테이블에도 사용해야 합니다.

\documentclass{book}

\usepackage{array}
\usepackage{mdframed}
\usepackage{multirow}
\usepackage{xcolor} % Required for specifying colors by name
\definecolor{ocre}{RGB}{243,102,25}
\usepackage{float}
\usepackage{caption}
\usepackage{booktabs}
\usepackage{longtable}

\newmdenv[%
linecolor=ocre,
backgroundcolor=ocre!10,
linewidth=1pt]
{Tablebox}

\newenvironment{mytablebox}
{
    \begin{Tablebox}
}
{
    \end{Tablebox}
}

\begin{document}
    The various activities which are performed in the Crane shop are given in table \ref{table:crane_shop_activities}.
    \begin{mytablebox}
        \centering
        \captionof{table}{Crane shop activities.}
        \label{table:crane_shop_activities}
        \begin{tabular}{|m{2cm}| m{4cm}| m{4cm}|}
            \hline
            \textbf{Category} & \textbf{Types} & \textbf{Activities}\\
            \hline
            \multirow{3}{*}{Tower Car} & Mark II, III, IV & \multirow{3}{4cm}{Earlier Manufacturing, currently only POH}\\
            \cline{2-2}
            & DHTC (Diesel Hydraulic Tower Car) & \\
            \cline{2-2}
            & 8 Wheeler &\\
            \hline
            \multirow{2}{*}{20T Crane} & Mechanical & \multirow{2}{4cm}{Both Manufacturing and POH}\\
            \cline{2-2}
            & Hydraulic (retrofitting of mechanical superstructure with hydraulic one) & \\
            \hline
            \multirow{2}{*}{140T Crane} & Old Design Crane & POH, MLR, SP MLR\\
            \cline{2-3}
            & New Design Crane & Manufacturing, POH, MLR, SP MLR\\
            \hline
        \end{tabular}
    \end{mytablebox}

    Activities related to 140T crane are given in detail in table \ref{table:140T_activities}.
    \begin{mytablebox}
        \captionof{table}{140T Crane activities.}
        \label{table:140T_activities}
        \begin{tabular}{|p{0.45\textwidth}|p{0.45\textwidth}|}
            \hline
            1$^{st}$ POH & After 8 yrs\\
            \hline
            2$^{nd}$ POH & After 16 yrs\\
            \hline
            MLR & After 22 yrs\\
            \hline
            SP MLR & After 30 yrs\\
            \hline
            SR (Special Repair) & Accidental and unpredictable\\
            \hline
        \end{tabular}
    \end{mytablebox}
\end{document}

여기에 이미지 설명을 입력하세요
