내 pgfgantt다이어그램에서 작업 6과 작업 7은 다른 작업에 비해 겹쳐서 굵게 표시됩니다.
\documentclass[xcolor=table]{beamer}
\usepackage{pgfgantt}
\usetheme{Madrid}
\begin{document}
\begin{frame}{Work plan}{Tasks}
\frametitle{Gantt charts}
\begin{ganttchart}[
today=18,
today rule/.style= {blue, thick},
x unit=0.25cm,
y unit title=0.5cm,
y unit chart=0.35cm,
title label font=\tiny,
bar label font=\tiny,
group label font=\tiny\bfseries,
milestone label font=\tiny\itshape,
vgrid, hgrid]{1}{36}
\gantttitle{2017}{12}
\gantttitle{2018}{24} \\
\gantttitle{October}{4}
\gantttitle{November}{4}
\gantttitle{December}{4}
\gantttitle{January}{4}
\gantttitle{February}{4}
\gantttitle{March}{4}
\gantttitle{April}{4}
\gantttitle{May}{4}
\gantttitle{June}{4} \\
\ganttbar[bar/.append style={fill=blue!40}]{Task 1}{1}{36} \\
\ganttbar[bar/.append style={fill=blue!10}]{Task 2}{5}{6} \\
\ganttbar[bar/.append style={fill=blue!10}]{Task 3}{8}{10} \\
\ganttbar[bar/.append style={fill=blue!10}]{Task 4}{11}{13} \\
\ganttbar[bar/.append style={fill=blue!10}]{Task 5}{12}{18} \\
\ganttmilestone{Task 5.1}{18}\\
\ganttbar[bar/.append style={fill=blue!40}]{Task 6}{13}{24}
\ganttbar[bar/.append style={fill=blue!40}]{Task 6}{29}{29}
\ganttbar[bar/.append style={fill=blue!40}]{Task 6}{31}{32}\\
\ganttbar[bar/.append style={fill=blue!40}]{Task 7}{25}{28}
\ganttbar[bar/.append style={fill=blue!40}]{Task 7}{33}{36} \\
\ganttbar[bar/.append style={fill=blue!40}]{Task 8}{30}{30} \\
\ganttbar[bar/.append style={fill=blue!40}]{Task 9}{17}{32} \\
\ganttmilestone{Task 9.1}{32}\\
\ganttbar[bar/.append style={fill=blue!40}]{Task 10}{30}{35} \\
\ganttmilestone{Task 11}{35}
\ganttlink{elem1}{elem2}
\ganttlink{elem2}{elem3}
\ganttlink{elem4}{elem5}
\ganttlink{elem6}{elem9}
\ganttlink{elem9}{elem7}
\ganttlink{elem7}{elem11}
\ganttlink{elem11}{elem8}
\ganttlink{elem8}{elem10}
\ganttlink{elem12}{elem13}
\ganttlink{elem14}{elem15}
\end{ganttchart}
\end{frame}
\end{document}
나에게 해결책을 주실 수 있나요? 감사해요.
답변1
Task 6같은 곳에 세 번 인쇄되어 있어서 굵게 보입니다 . 하지만 제 생각에 한 번만 인쇄하면 되므로 해당 작업의 마지막 두 부분에 대해서는 라벨을 비워 두세요. 예를 \ganttbar[bar/.append style={fill=blue!40}]{}{29}{29}들어 \ganttbar[bar/.append style={fill=blue!40}]{Task 6}{29}{29}.
\ganttset그런데 다이어그램 내부를 사용하면 코드를 약간 단순화할 수 있습니다 .
\documentclass[xcolor=table]{beamer}
\usepackage{pgfgantt}
\usetheme{Madrid}
\begin{document}
\begin{frame}{Work plan}{Tasks}
\frametitle{Gantt charts}
\begin{ganttchart}[
today=18,
today rule/.style= {blue, thick},
x unit=0.25cm,
y unit title=0.5cm,
y unit chart=0.35cm,
title label font=\tiny,
bar label font=\tiny,
group label font=\tiny\bfseries,
milestone label font=\tiny\itshape,
bar/.append style={fill=blue!40},
vgrid, hgrid]{1}{36}
\gantttitle{2017}{12}
\gantttitle{2018}{24} \\
\gantttitle{October}{4}
\gantttitle{November}{4}
\gantttitle{December}{4}
\gantttitle{January}{4}
\gantttitle{February}{4}
\gantttitle{March}{4}
\gantttitle{April}{4}
\gantttitle{May}{4}
\gantttitle{June}{4} \\
\ganttbar{Task 1}{1}{36} \\
\ganttset{bar/.append style={fill=blue!10}}
\ganttbar{Task 2}{5}{6} \\
\ganttbar{Task 3}{8}{10} \\
\ganttbar{Task 4}{11}{13} \\
\ganttbar{Task 5}{12}{18} \\
\ganttmilestone{Task 5.1}{18}\\
\ganttset{bar/.append style={fill=blue!40}}
\ganttbar{Task 6}{13}{24}
\ganttbar{}{29}{29} % <-- empty label
\ganttbar{}{31}{32}\\ % <-- empty label
\ganttbar{Task 7}{25}{28}
\ganttbar{}{33}{36} \\ % <-- empty label
\ganttbar{Task 8}{30}{30} \\
\ganttbar{Task 9}{17}{32} \\
\ganttmilestone{Task 9.1}{32}\\
\ganttbar{Task 10}{30}{35} \\
\ganttmilestone{Task 11}{35}
\ganttlink{elem1}{elem2}
\ganttlink{elem2}{elem3}
\ganttlink{elem4}{elem5}
\ganttlink{elem6}{elem9}
\ganttlink{elem9}{elem7}
\ganttlink{elem7}{elem11}
\ganttlink{elem11}{elem8}
\ganttlink{elem8}{elem10}
\ganttlink{elem12}{elem13}
\ganttlink{elem14}{elem15}
\end{ganttchart}
\end{frame}
\end{document}
