라텍스 코드를 찾았어요(페이지 나누기가 있는 파일 트리, 이 코드(페이지 나누기+파일 트리)의 소유자/작성자는 Sašo Živanović입니다.).
이 코드를 문서화에 사용하고 싶습니다. 여러 개의 다른 파일 트리를 갖고 싶지만 이 코드에서는 페이지 나누기가 있는 하나의 파일 트리만 작동합니다. 여러 다른 나무에서 어떻게 작동하는지 아는 사람이 있나요? 미리 감사드립니다.
독일 포럼:https://texwelt.de/wissen/fragen/24325/wie-kann-man-2-oder-mehrere-file-trees-mit-pagebreak-abbilden
좋은 하루 되세요.
\documentclass[11pt,a4paper,titlepage,bibliography=totoc,numbers=noenddot,abstract=on,multi,dvipsnames,svgnames,x11names]{scrreprt}%Dokumentklasse wie in unserer Vorlage
\usepackage{storebox}%Pagebrak
\usepackage[edges]{forest}%FileTree
\usepackage{adjustbox}%Pagebrak
%\usepackage{lmodern}%Schrift
%Zeilenumbruch in der tikz Umgebung!%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% addaswyd o gôd Sašo Živanović: http://tex.stackexchange.com/a/296771/
\def\hiddenparcommand{\par}
\newcommand\otherhiddenparcommand{\par\noindent}
\newcommand\hiddencommacommand{, }
\forestset{%
declare keylist register={split here ids},% the list of nodes to split the tree at
split here ids={},
declare keylist register={split here interjects},% the list of comments to put in between the tree parts
split here interjects={},
declare keylist={split here auto siblings}{},% a list to hold the siblings which need edge restoration
declare toks register=split here toks,
declare dimen register=tmpdima,
tmpdima'=0pt,
declare dimen register=tmpdimb,
tmpdimb'=0pt,
declare dimen register=tmpdimc,
tmpdimc'=0pt,
to widest/.style={
tikz+={\path (\forestregister{tempdima}, \forestoption{y}) -- (\forestregister{tempdimb}, \forestoption{y});},
},
hide commas/.style={%
split here toks+={\hiddencommacommand},
split here toks+={#1},
},
split dir tree pre/.style={%
label={[text=gray, anchor=north, font=\scriptsize]below:{[cont.]}{}},
},
split dir tree post/.style={%
label={[font=\scriptsize, anchor=south, text=gray]above:{[cont.]}{}},
},
split dir tree auto post/.style={% this gets applied to the first node after a break
split dir tree post,
tempkeylistc'={},
tmpdimb/.option=y,
for nodewalk={
while={
> ORw2+d _+d < On=! & {y}{tmpdimb}{##2-##1} {\textheight-#1} {n'}{1}%
}{
next,
tempkeylistc/.option=name
}%
}{},
% save the list
split here auto siblings/.register=tempkeylistc,
tikz+/.process={% this tries to redraw the edges to the following siblings
OOw2{edge}{id}%
{%
\path [##1] (!u.parent anchor |- .north) ++(\forestregister{folder indent},1ex) coordinate (before ##2) |- (.child anchor);
\edef\tempa{\foresteoption{split here auto siblings}}
\foreach \i in \tempa \path [##1] (before ##2) |- ({forest cs:\i.child anchor});
}%
},
},
split dir tree/.code={%
\forestset{%
draw tree stage/.style={
for root'={
tempdima/.min={%
>OOw2+d{x}{min x}{####1+####2}%
}{tree},
tempdimb/.max={%
>OOw2+d{x}{max x}{####1+####2}%
}{tree},
for tree={%
to widest,
},
},
tempcountb'=-1,
do until={%
strequal((split_here_ids),"")
}{%
tempkeylistb'={},
tempkeylista'={},
split register={split here ids}{,}{tempcounta,tempkeylistb+},
split register={split here interjects}{,}{temptoksa,tempkeylista+},
split here ids'/.register=tempkeylistb,
split here interjects'/.register=tempkeylista,
% Sašo Živanović: http://chat.stackexchange.com/transcript/message/28484520#28484520
for nodewalk={%
draw tree processing order/.style={%
filter={tree}{> ORw+n< OR> & {id}{tempcounta}{########1+1}{id}{tempcountb}}%
}%
}{},
for root'={draw tree},
TeX/.process={Rw{temptoksa}{\otherhiddenparcommand ####1\hiddenparcommand}},
tempcountb'/.register=tempcounta,
},
for nodewalk={%
draw tree processing order/.style={%
filter={tree}{>OR>{id}{tempcountb}}%
}%
}{},
for root'={draw tree},
},
}%
},
split dir here auto/.style n args=2{%
split dir tree pre,
!next node.split dir tree auto post=#2,
split here ids+/.option=id,
% !next node.split resume here ids+/.option=id,
split={#1}{,}{split here toks,hide commas},
split here interjects/.register=split here toks,
},
split dir tree auto/.style={%
split dir tree,
before drawing tree={%
tempdima/.max={y}{tree},
tempdimc/.register=tempdima,
tempdimd/.min={y}{tree},
tempdima-/.register=tempdimd,
tempdimb'=\textheight,
tmpdima'=10ex,
tmpdimc'=\pagetotal,
while={%
>RR>{tempdima}{tempdimb}%
}{%
for nodewalk={%
root',
until={%
> ROw2+d RRw2+d > {tempdimc}{y}{##1-##2} {tmpdima}{tmpdimc}{\textheight-##2-##1}%
}{next node},
previous node,
split dir here auto/.process={R_w2{tmpdima}{continued}{{##2}{##1}}},
next node,
tempdima/.option=y,
tempdimc/.register=tempdima,
tempdima-/.register=tempdimd,
tmpdima'=15ex,
tmpdimc'=0pt
}{},
},
},
},
}
\begin{document}
\begin{forest}
for tree={
folder,
draw, %zeichnet Kästchen
before computing xy={l=100pt},%definiert die länge der horizontalen Linie
grow'=0,
fit=band,
},
split dir tree auto,
[ \textcolor{green}{\textbf{LASTFall}}
[ {\fontsize{8}{9} \selectfont fdsdssdfsd},edge label={node[pos=0.75,above,font=\scriptsize]{$\textbf{(2.807E+05x) 005}$}} %Mathematik Modus plus Fett
[ \scriptsize{str Rinfi aq000 tq0 fs v002 l000 AW0 check},edge label={node[pos=0.75,above,font=\ttfamily]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ \tiny{str Rinfi aq000 tq0 fs v002 l000 AW0 check},edge label={node[pos=0.75,above,font=\scriptsize]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ \normalsize{str Rinfi aq000 tq0 fs v002 l000 AW0 check},edge label={node[pos=0.75,above,font=\scriptsize]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ \large{str Rinfi aq000 tq0 fs v002 l000 AW0 check},edge label={node[pos=0.75,above,font=\Large]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ \small{str Rinfi aq000 tq0 fs v002 l000 AW0 check},edge label={node[pos=0.75,above,font=\large]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ str Rinfi aq000 tq0 fs v002 l000 AW0 check,edge label={node[pos=0.75,above,font=\footnotesize]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus
[ str Rinfi aq000 tq0 fs v002 l000 AW0 check,edge label={node[pos=0.75,above,font=\small]{$\textbf{(2.807E+05x) 005}$}}] %Mathematik Modus plus Fett
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
]
]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}}
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
[ str Rinfi aq000 tq0 fs v002 l000 AW0 kjijlopopheck,edge label={node[pos=0.75,above,font=\scriptsize]{(2.807E+05x) 005}} ]
]
]
]
]
\end{forest}
\end{document}
업데이트: 이 버전(코드)에서는 작동하지 않습니다. 왜 그런지 아시나요?
\documentclass[11pt,a4paper,titlepage,bibliography=totoc,numbers=noenddot,abstract=on,multi,dvipsnames,svgnames,x11names]{scrreprt}%Dokumentklasse wie in unserer Vorlage
\usepackage{storebox}%Pagebrak
\usepackage[edges]{forest}%FileTree
\usepackage{adjustbox}%Pagebrak
%\usepackage{lmodern}%Schrift
%Zeilenumbruch in der tikz Umgebung!
% addaswyd o gôd Sašo Živanović: http://tex.stackexchange.com/a/296771/
\def\hiddenparcommand{\par}
\newcommand\otherhiddenparcommand{\par\noindent}
\newcommand\hiddencommacommand{, }
\forestset{%
declare keylist register={split here ids},% the list of nodes to split the tree at
split here ids={},
declare keylist register={split here interjects},% the list of comments to put in between the tree parts
split here interjects={},
%declare keylist={split here auto siblings}{},% a list to hold the siblings which need edge restoration
declare toks register=split here toks,
declare dimen register=tmpdima,
tmpdima'=0pt,
declare dimen register=tmpdimb,
tmpdimb'=0pt,
declare dimen register=tmpdimc,
tmpdimc'=0pt,
to widest/.style={
tikz+={\path (\forestregister{tempdima}, \forestoption{y}) -- (\forestregister{tempdimb}, \forestoption{y});},
},
hide commas/.style={%
split here toks+={\hiddencommacommand},
split here toks+={#1},
},
split dir tree pre/.style={%
label={[text=gray, anchor=north, font=\scriptsize]below:{[cont.]}{}},
},
split dir tree post/.style={%
label={[font=\scriptsize, anchor=south, text=gray]above:{[cont.]}{}},
},
split dir tree auto post/.style={% this gets applied to the first node after a break
split dir tree post,
tempkeylistc'={},
tmpdimb/.option=y,
for nodewalk={
while={
> ORw2+d _+d < On=! & {y}{tmpdimb}{##2-##1} {\textheight-#1} {n'}{1}%
}{
next,
tempkeylistc/.option=name
}%
}{},
% save the list
%split here auto siblings/.register=tempkeylistc,
tikz+={\path(!u.parent anchor |- .north) ++(\forestregister{folder indent},1ex) coordinate (before split) |- (.child anchor);},
split register={tempkeylistc}{,}{edge in tikz},
},
edge in tikz/.style={
tikz+/.process=OOw2{#1.edge}{#1.edge label}{%
\path [##1] (before split) |- (#1.child anchor)##2;
},
},
split dir tree/.code={%
\forestset{%
draw tree stage/.style={
for root'={
tempdima/.min={%
>OOw2+d{x}{min x}{####1+####2}%
}{tree},
tempdimb/.max={%
>OOw2+d{x}{max x}{####1+####2}%
}{tree},
for tree={%
to widest,
},
},
tempcountb'=-1,
do until={%
strequal((split_here_ids),"")
}{%
tempkeylistb'={},
tempkeylista'={},
split register={split here ids}{,}{tempcounta,tempkeylistb+},
split register={split here interjects}{,}{temptoksa,tempkeylista+},
split here ids'/.register=tempkeylistb,
split here interjects'/.register=tempkeylista,
% Sašo Živanović: http://chat.stackexchange.com/transcript/message/28484520#28484520
for nodewalk={%
draw tree processing order/.style={%
filter={tree}{> ORw+n< OR> & {id}{tempcounta}{########1+1}{id}{tempcountb}}%
}%
}{},
for root'={draw tree},
TeX/.process={Rw{temptoksa}{\otherhiddenparcommand ####1\hiddenparcommand}},
tempcountb'/.register=tempcounta,
},
for nodewalk={%
draw tree processing order/.style={%
filter={tree}{>OR>{id}{tempcountb}}%
}%
}{},
for root'={draw tree},
},
}%
},
split dir here auto/.style n args=2{%
split dir tree pre,
!next node.split dir tree auto post=#2,
split here ids+/.option=id,
% !next node.split resume here ids+/.option=id,
split={#1}{,}{split here toks,hide commas},
split here interjects/.register=split here toks,
},
split dir tree auto/.style={%
split dir tree,
before drawing tree={%
tempdima/.max={y}{tree},
tempdimc/.register=tempdima,
tempdimd/.min={y}{tree},
tempdima-/.register=tempdimd,
tempdimb'=\textheight,
tmpdima'=10ex,
tmpdimc'=\pagetotal,
while={%
>RR>{tempdima}{tempdimb}%
}{%
for nodewalk={%
root',
until={%
> ROw2+d RRw2+d > {tempdimc}{y}{##1-##2} {tmpdima}{tmpdimc}{\textheight-##2-##1}%
}{next node},
previous node,
split dir here auto/.process={R_w2{tmpdima}{continued}{{##2}{##1}}},
next node,
tempdima/.option=y,
tempdimc/.register=tempdima,
tempdima-/.register=tempdimd,
tmpdima'=15ex,
tmpdimc'=0pt
}{},
},
},
},
}
%Zeilenumbruch in der tikz Umgebung! Ende
%
\ExplSyntaxOn
\box_new:N \l_helmutW_box
\cs_new_protected:Npx \helmutW_replace_verb_newline:Nn #1 #2
{
\tl_replace_all:Nnn #1 { \char_generate:nn { 13 } { 12 } } { #2 }
}
\cs_new_protected:Npx \helmutW_replace_verb_newline_newline:Nn #1 #2
{
\tl_replace_all:Nnn #1
{ \char_generate:nn { 13 } { 12 } \char_generate:nn { 13 } { 12 } } { #2 }
}
\cs_new_protected:Npn \helmutW_process_verb_newline:nnn #1 #2 #3
{
\tl_set:Nn \ProcessedArgument { #3 }
\helmutW_replace_verb_newline_newline:Nn \ProcessedArgument { #2 }
\helmutW_replace_verb_newline:Nn \ProcessedArgument { #1 }
}
\NewDocumentCommand \AutoSplittedTree
{
s
O{ for~tree = { folder, grow'=0, fit=band,draw } }
>{ \helmutW_process_verb_newline:nnn { ~ } { ~ \par } } +v
}
{
\par
\IfBooleanTF { #1 }
{ \iftrue }
{
\vbox_set:Nn \l_helmutW_box { \helmutW_tree:n { #2, #3 } }
\dim_compare:nNnTF { \box_ht:N \l_helmutW_box } >
{ \dim_min:nn { \pagegoal-\pagetotal } { \textheight } }
{
\iftrue
}
{
\box_use:N \l_helmutW_box
\iffalse
}
}
\helmutW_tree:n { #2, split~dir~tree~auto, #3 }
\fi
}
\cs_new_protected:Npn \helmutW_tree:n #1
{
\scantokens
{
\begin{forest}
#1
\end{forest}%
}
}
\ExplSyntaxOff
\begin{document}
\AutoSplittedTree
{
[ XYZ
[ XYZ
[ \textcolor{green}{\textbf{gfgfg}},edge label={node[pos=0.75,above,font=\scriptsize]{A}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ XYZ,edge label={node[pos=0.75,above,font=\scriptsize]{AAA}}]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head1}} ]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},rounded corners,edge label={node[pos=0.75,above,font=\scriptsize]{ist das}}
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{lang}}
[ XYZ,before computing xy={l=50pt},edge label={node[pos=0.75,above,font=\scriptsize]{wow}}
[ XYZ,before computing xy={l=100pt},fill=yellow,edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}
]
]
]
]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]\\
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]\\
[ \textcolor{red}{LASTFall},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head11}} ]
[ gfgh,before computing xy={l=50pt}, edge label={node[midway,left,font=\scriptsize]{head1111111111}},minimum size=6cm ]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head1111111111}},minimum size=3cm ]
[ gfgh,edge label={node[fill=red!20,midway,left,font=\scriptsize]{head1111111111}},minimum size=1cm ]
[ 7,before computing xy={l=50pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
]
]
]
}
\mbox{}
\AutoSplittedTree
{
[ XYZ
[ XYZ
[ \textcolor{green}{\textbf{gfgfg}},edge label={node[pos=0.75,above,font=\scriptsize]{A}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ XYZ,edge label={node[pos=0.75,above,font=\scriptsize]{AAA}}]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head1}} ]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},rounded corners,edge label={node[pos=0.75,above,font=\scriptsize]{ist das}}
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{lang}}
[ XYZ,before computing xy={l=50pt},edge label={node[pos=0.75,above,font=\scriptsize]{wow}}
[ XYZ,before computing xy={l=100pt},fill=yellow,edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}
]
]
]
]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ XYZ,before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]\\
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]\\
[ \textcolor{red}{LASTFall},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ \textcolor{red}{LASTFall},before computing xy={l=100pt},edge label={node[pos=0.75,above,font=\scriptsize]{\textcolor{green}{\textbf{gfgfg}}}}]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head11}} ]
[ gfgh,before computing xy={l=50pt}, edge label={node[midway,left,font=\scriptsize]{head1111111111}},minimum size=6cm ]
[ gfgh,edge label={node[midway,left,font=\scriptsize]{head1111111111}},minimum size=3cm ]
[ gfgh,edge label={node[fill=red!20,midway,left,font=\scriptsize]{head1111111111}},minimum size=1cm ]
[ 7,before computing xy={l=50pt},edge label={node[pos=0.75,above,font=\scriptsize]{Too longggggggg}}]
]
]
]
}
\end{document}
답변1
자동 분할 트리(의 첫 번째 부분) 앞에 페이지에 세로 공간이 너무 적게 남아 있기 때문에 오류가 발생합니다. 분할 알고리즘은 루트 노드에서 트리를 분할하려고 시도하지만 이를 알아차리는 대신 이전 노드로 이동하려고 시도합니다(포맷을 지정하기 위해, 즉continued 오류가 발생한 이전 노드로 이동하려고 시도합니다(형식을 지정하기 위해, 즉 레이블을 추가하기 위해).
적절한 해결책은 트리 분할 코드의 문제를 해결하는 것이지만 다음 임시 솔루션으로도 충분할 수 있다고 생각합니다.needspace 트리를 시작하기 전에 페이지에 충분한 수직 공간이 남아 있는지 확인하십시오.
OP의 예에서 추가\Needspace{2\baselineskip} 두 번째 트리 앞에 추가하면 효과가 있지만 일반적으로 필요한 공간의 양은 다를 수 있습니다.
실제로 \Needspace{2\baselineskip}정의의 시작 부분에 추가하는 것이 좋습니다.\AutoSplittedTree 추가하는 것이 좋습니다 .
