tcolorbox의 왼쪽 오른쪽 및 아래쪽 여백에 음영 서라운드 상자를 설정하는 방법, 경계선, 왼쪽 규칙 등을 사용하여 tcolorbox에서 많은 옵션을 시도했지만 작동하지 않았습니다. 첨부된 이미지에 따라 설정하는 방법을 알려주세요.(무시 첨부된 이미지 하단에 검정색으로 강조 표시되어 있습니다.)
죄송합니다. 코드는 다음과 같습니다.
\documentclass{book}
\RequirePackage{amsmath,amssymb,lipsum,textcase,multicol}
\RequirePackage[breakable,hooks]{tcolorbox}
\tcbuselibrary{breakable,skins}
\makeatletter
\def\boxthreelabelfont{\noindent\fontsize{17bp}{14bp}\selectfont\bfseries\color{white}}
\def\boxthreetitlefont{\noindent\fontsize{11bp}{14bp}\selectfont\color{white}}
\def\boxthreetextfont{\noindent\fontsize{8.5bp}{11bp}\selectfont\parindent0pt\parskip9pt}
\newenvironment{Boxthree}[2][]{\begingroup\begin{tcolorbox}
[enhanced,breakable,%
arc=0pt,outer arc=0pt,boxrule=1pt,boxsep=0pt,top=22.7pt,left=14.5pt,right=15pt,bottom=5.5pt,middle=0pt,
bottomsep at break=0pt,topsep at break=2pt,
titlerule=0pt,titlerule style={gray,line width=0pt,},toptitle=9.9pt,bottomtitle=9.0pt,lefttitle=22pt,
righttitle=22pt,
title={{\boxthreelabelfont\MakeTextUppercase{#1}}\par\vskip4.5pt{\boxthreetitlefont\MakeTextUppercase{#2}}},
colbacktitle=black,colframe=gray,colback=white,rounded corners=southeast,
fontupper={\boxthreetextfont},
before skip=15pt,after skip=15pt,
toggle enlargement,
grow to left by=15pt,grow to right by=46pt, bottomrule at break=-8pt, toprule at break=-20pt,
arc=15pt,%leftrule=60pt,rightrule=60pt,
overlay={\draw[gray,line width=63pt]
(frame.south west) -- (frame.north west);}
%borderline={60pt}{20pt}{15black},
%leftrule=60pt
%overlay first={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
%overlay last={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
]\null\ignorespaces\removelastskip\vspace{-16.8\p@}\begin{multicols}{2}}{\end{multicols}\end{tcolorbox}\endgroup}
\def\boxtwobreak{\end{multicols}\pagebreak\begin{multicols}{2}}
\begin{document}
\begin{Boxthree}{Example 1.4}
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\boxtwobreak
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\end{Boxthree}
\end{document}
답변1
확실하지는 않지만 당신이 원하는 것일 수도 있습니다drop midday shadow(v4.20의 185페이지)
\documentclass{book}
\RequirePackage{amsmath,amssymb,lipsum,textcase,multicol}
\RequirePackage[breakable,hooks]{tcolorbox}
\tcbuselibrary{breakable,skins}
\makeatletter
\def\boxthreelabelfont{\noindent\fontsize{17bp}{14bp}\selectfont\bfseries\color{white}}
\def\boxthreetitlefont{\noindent\fontsize{11bp}{14bp}\selectfont\color{white}}
\def\boxthreetextfont{\noindent\fontsize{8.5bp}{11bp}\selectfont\parindent0pt\parskip9pt}
\newenvironment{Boxthree}[2][]{%
\begingroup\begin{tcolorbox}[%
enhanced,breakable,%
%arc=0pt, outer arc=0pt,
boxrule=1pt, boxsep=0pt, top=22.7pt, left=14.5pt, right=15pt, bottom=5.5pt, middle=0pt, bottomsep at break=0pt, topsep at break=2pt, titlerule=0pt,
titlerule style={gray, line width=0pt,},
toptitle=9.9pt, bottomtitle=9.0pt, lefttitle=22pt, righttitle=22pt,title={{\boxthreelabelfont\MakeTextUppercase{#1}}%
\par\vskip4.5pt{\boxthreetitlefont\MakeTextUppercase{#2}}},
colbacktitle=black,
colframe=gray,
colback=white, rounded corners=southeast,
fontupper={\boxthreetextfont}, before skip=15pt, after skip=15pt,
toggle enlargement, grow to left by=15pt, grow to right by=46pt, bottomrule at break=-8pt, toprule at break=-20pt,
arc=15pt,
drop midday shadow,
%
%
%leftrule=60pt,rightrule=60pt,
%overlay={\draw[gray,line width=63pt]
% (frame.south west) -- (frame.north west);}
%borderline={60pt}{20pt}{15black},
%leftrule=60pt
%overlay first={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
%overlay last={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
]\null\ignorespaces\removelastskip\vspace{-16.8\p@}\begin{multicols}{2}}{\end{multicols}\end{tcolorbox}\endgroup}
\makeatother
\def\boxtwobreak{\end{multicols}\pagebreak\begin{multicols}{2}}
\begin{document}
\begin{Boxthree}{Example 1.4}
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\boxtwobreak
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\end{Boxthree}
\end{document}
