저는 새로운 LaTeX 사용자이고 이 Stack Exchange를 처음 접하는 사람입니다. 그러니 편하게 대해주세요!
MiKTeX의 현재 2.9 버전(basic-miktex-2.9.7386-x64.exe)이 LaTeX 코드가 작성된 이전 MiKTeX 2.1보다 더 엄격한 것 같기 때문에 여러 경계 상자 문제가 있는 사용자 매뉴얼이 있습니다.
작동하도록 하는 일련의 지침을 찾았지만 여전히 작동하지 않습니다. 지침은 다음과 같습니다.
MikTex 2.1 설정을 복제하는 절차는 다음과 같습니다.
1) \[...Network_Location...]\LATEX\MiKTeX 2.1\texmf.zip에 있는 zip 파일을
로컬 PC에 복사합니다.2) 루트 수준의 부팅 드라이브(C:\texm이 아닌 C:)에 압축을 풉니다.
c:\texmf로 추출하면 추가 레벨이 생성되고 MikTex는 현재 구성된 대로 제대로 작동하지 않습니다.
3) 경로 지정을 추가합니다.
c:\texmf\miktex\bin to the Windows PATH environmental variable.CMD 창을 열고 라텍스 애플리케이션을 시작할 수 있는지 확인하십시오.
D:\PAWSUA_UG2_5>latex 이것은 TeX 버전 3.14159(MiKTeX 2.1)입니다 **
이제 컴파일하고 올바른 크기의 이미지로 PDF 파일을 생성할 수 있습니다.
위의 지침을 따랐을 때 현재 MiKTeX 2.9 설치 위에 있었습니다.
Latex가 실행되고 버전 2.1이 표시되는지 확인하는 것을 포함하여 모든 지침을 따랐습니다.
그런 다음 TeXworks를 사용하려고 시도했지만 이미지가 여전히 엉망으로 나타납니다. LaTeX 2.1 명령줄 인터페이스에서 직접 .DVI를 생성하기도 했습니다. 두 버전 사이에 약간의 상호 작용이 있는 것 같습니다!
나는 여전히 TeXworks에서 작업하고 싶지만 현재 2.9 대신 이전 버전 2.1에서 작동할 수 있는지 전혀 모르겠습니다. 가능합니까? 나는 최신 2.9 버전에 따라 수백 페이지에 달하는 설명서 전체를 다시 포맷해야 하는 것을 원하지 않습니다. 돕다!
편집: 다음은 진단과 도움을 받는 데 도움이 되는 일부 소스 코드와 로그 파일입니다.
코드의 경계 상자 문제를 보여주기 전에 생성된 PDF에서 시각적으로 경험하고 있는 내용을 보여 주어야 합니다. 다음은 MiKTeX 2.9에서 왼쪽에 잘못 나타나는 사진과 MiKTeX 2.1에서 렌더링된 오른쪽 사진(다른 사람에 의해)을 나란히 비교한 것입니다. 독점 정보가 유출되는 것을 방지하기 위해 사진이 약간 흐릿하거나(회색 직사각형으로) 가려졌습니다.
이것이 경계 상자에 문제가 있음을 분명히 하기를 바랍니다. 아마도 그들은 이전에 느슨하게 지정되었고 어느 시점에서 어떤 "경계 상자"가 허용되고 강화되고 "수정"되었을까요? 그럼에도 불구하고, 진짜 문제는 경계 상자 문제가 아닙니다. 진짜 문제는 "최신화"라는 측면에서 회사에 너무 많은 비용을 들이지 않고 이전 버전으로 성공적으로 작업하는 방법입니다.
첫 번째 경계 상자 문제는 다음과 같습니다.
\begin{figure}[!hbt]
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=1.5]{PAWS_RunScreen.jpg}
\caption{Run Screen}
\label{fig:runscreen}
\end{center}
\end{figure}
로그 메시지로:
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 481.
<PAWS_RunScreen.jpg, id=62, 832.61063pt x 565.36218pt>
File: PAWS_RunScreen.jpg Graphic file (type jpg)
<use PAWS_RunScreen.jpg>
Package pdftex.def Info: PAWS_RunScreen.jpg used on input line 481.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[10 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_RunScreen.jpg>]
두 번째 경계 상자 오류:
\vspace{0.70in}
\begin{figure}[!hbt]
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=2.3]{PAWS_RunSetupScreen.jpg}
\vspace{-1.2in}
\caption{Run Setup Screen}
\label{runsetup}
\end{center}
\end{figure}
로그 메시지로:
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 515.
<PAWS_RunSetupScreen.jpg, id=68, 578.16pt x 462.22687pt>
File: PAWS_RunSetupScreen.jpg Graphic file (type jpg)
<use PAWS_RunSetupScreen.jpg>
Package pdftex.def Info: PAWS_RunSetupScreen.jpg used on input line 515.
(pdftex.def) Requested size: 1329.7665pt x 532.13614pt.
세 번째 경계 상자 오류:
\vspace{0.05in}
\begin{figure}
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=1.5]{PAWS_MethodScreen.jpg}
\caption{Method Editor Screen}
\label{fig:me}
\end{center}
\end{figure}
\vspace{-0.3in}
관련 로그 메시지와 함께:
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 581.
<PAWS_MethodScreen.jpg, id=78, 832.61063pt x 565.36218pt>
File: PAWS_MethodScreen.jpg Graphic file (type jpg)
<use PAWS_MethodScreen.jpg>
Package pdftex.def Info: PAWS_MethodScreen.jpg used on input line 581.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
로그 파일에는 다음과 같은 패턴이 많이 포함되어 있는데, 이를 적합하게 만들기 위해 제거해야 했습니다.
Overfull \hbox (4.27394pt too wide) in paragraph at lines 561--562
[][]
[]
다음은 TeXworks에서 PDF를 생성하여 생성된 대부분의 완전한 로그 파일이며 이에 맞게 수정되었습니다.
This is pdfTeX, Version 3.1415926-2.4-1.40.13 (MiKTeX 2.9)
(preloaded format=pdflatex 2019.6.4) 27 APR 2020 13:48
entering extended mode
**C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/pawsua_ug2_5.tex
(C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/pawsua_ug2_5.tex
LaTeX2e <2011/06/27>
Babel <v3.8m> and hyphenation patterns for english, ..., welsh, loaded.
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\specification.cls
Document Class: specification 2001/12/20 v1.4 Custom LaTeX document class
\@sbcurrent=\count79
(C:\MikTeX\tex\latex\base\size11.clo
File: size11.clo 2007/10/19 v1.4h Standard LaTeX file (size option)
)
\tempa=\dimen102
\c@part=\count80
\c@Section=\count81
\c@section=\count82
\c@sectionpage=\count83
\c@subsection=\count84
\c@subsubsection=\count85
\c@paragraph=\count86
\c@subparagraph=\count87
\c@table=\count88
\c@figure=\count89
\headrulewidth=\dimen103
\footrulewidth=\dimen104
\headwidth=\dimen105
\EpsFig=\box26
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\testplan.sty)
(C:\MikTeX\tex\latex\graphics\graphicx.sty
Package: graphicx 1999/02/16 v1.0f Enhanced LaTeX Graphics (DPC,SPQR)
(C:\MikTeX\tex\latex\graphics\keyval.sty
Package: keyval 1999/03/16 v1.13 key=value parser (DPC)
\KV@toks@=\toks14
)
(C:\MikTeX\tex\latex\graphics\graphics.sty
Package: graphics 2009/02/05 v1.0o Standard LaTeX Graphics (DPC,SPQR)
(C:\MikTeX\tex\latex\graphics\trig.sty
Package: trig 1999/03/16 v1.09 sin cos tan (DPC)
)
(C:\MikTeX\tex\latex\00miktex\graphics.cfg
File: graphics.cfg 2007/01/18 v1.5 graphics configuration of teTeX/TeXLive
)
Package graphics Info: Driver file: pdftex.def on input line 91.
(C:\MikTeX\tex\latex\pdftex-def\pdftex.def
File: pdftex.def 2011/05/27 v0.06d Graphics/color for pdfTeX
(C:\MikTeX\tex\generic\oberdiek\infwarerr.sty
Package: infwarerr 2010/04/08 v1.3 Providing info/warning/error messages (HO)
)
(C:\MikTeX\tex\generic\oberdiek\ltxcmds.sty
Package: ltxcmds 2011/11/09 v1.22 LaTeX kernel commands for general use (HO)
)
\Gread@gobject=\count90
))
\Gin@req@height=\dimen106
\Gin@req@width=\dimen107
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\rotating.sty
Package: rotating 1997/09/26, v2.13 Rotation package
(C:\MikTeX\tex\latex\base\ifthen.sty
Package: ifthen 2001/05/26 v1.1c Standard LaTeX ifthen package (DPC)
)
\c@r@tfl@t=\count91
\rot@float@box=\box27
)
(C:\MikTeX\tex\latex\multirow\multirow.sty
\bigstrutjot=\dimen108
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\comment.sty
\CommentStream=\write3
Excluding comment 'comment') (C:\MikTeX\tex\latex\tools\tabularx.sty
Package: tabularx 1999/01/07 v2.07 `tabularx' package (DPC)
(C:\MikTeX\tex\latex\tools\array.sty
Package: array 2008/09/09 v2.4c Tabular extension package (FMi)
\col@sep=\dimen109
\extrarowheight=\dimen110
\NC@list=\toks15
\extratabsurround=\skip41
\backup@length=\skip42
)
\TX@col@width=\dimen111
\TX@old@table=\dimen112
\TX@old@col=\dimen113
\TX@target=\dimen114
\TX@delta=\dimen115
\TX@cols=\count92
\TX@ftn=\toks16
) (C:\MikTeX\tex\latex\graphics\lscape.sty
Package: lscape 2000/10/22 v3.01 Landscape Pages (DPC)
) (C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.aux)
LaTeX Font Info: Checking defaults for OML/cmm/m/it on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for T1/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OT1/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OMS/cmsy/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OMX/cmex/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for U/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <12> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <8> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <6> on input line 72.
LaTeX Font Info: Try loading font information for OMS+cmr on input line 72.
(C:\MikTeX\tex\latex\base\omscmr.fd
File: omscmr.fd 1999/05/25 v2.5h Standard LaTeX font definitions
)
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <9> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <9> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <5> on input line 72.
[1
{C:/Users/dev/AppData/Local/MiKTeX/2.9/pdftex/config/pdftex.map}]
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <10> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 74.
[2
]
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.toc
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <10.95> on input line 2.
[1
] [2])
\tf@toc=\write4
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.lot)
\tf@lot=\write5
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.lof [3])
\tf@lof=\write6
[4]
[1
]
2: Station Overview
[4]
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <10.95> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 270.
[5] [6]
[9]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 481.
<PAWS_RunScreen.jpg, id=62, 832.61063pt x 565.36218pt>
File: PAWS_RunScreen.jpg Graphic file (type jpg)
<use PAWS_RunScreen.jpg>
Package pdftex.def Info: PAWS_RunScreen.jpg used on input line 481.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[10 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_RunScreen.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 515.
<PAWS_RunSetupScreen.jpg, id=68, 578.16pt x 462.22687pt>
File: PAWS_RunSetupScreen.jpg Graphic file (type jpg)
<use PAWS_RunSetupScreen.jpg>
Package pdftex.def Info: PAWS_RunSetupScreen.jpg used on input line 515.
(pdftex.def) Requested size: 1329.7665pt x 532.13614pt.
[12]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 581.
<PAWS_MethodScreen.jpg, id=78, 832.61063pt x 565.36218pt>
File: PAWS_MethodScreen.jpg Graphic file (type jpg)
<use PAWS_MethodScreen.jpg>
Package pdftex.def Info: PAWS_MethodScreen.jpg used on input line 581.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[13
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_MethodScreen.jpg>]
[14] [15]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 697.
<PAWS_ProductScreen_VelocityLength.jpg, id=91, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_VelocityLength.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_VelocityLength.jpg>
Package pdftex.def Info: PAWS_ProductScreen_VelocityLength.jpg used on input li
ne 697.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[16
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_VelocityLength.jpg
>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 836.
<PAWS_ProductScreen_VelocityMotion.jpg, id=103, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_VelocityMotion.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_VelocityMotion.jpg>
Package pdftex.def Info: PAWS_ProductScreen_VelocityMotion.jpg used on input li
ne 836.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 881.
<PAWS_ProductScreen_Force.jpg, id=105, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_Force.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_Force.jpg>
Package pdftex.def Info: PAWS_ProductScreen_Force.jpg used on input line 881.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[19] [20 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_VelocityM
otion.jpg>] [21 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_For
ce.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 907.
<PAWS_DataScreen.jpg, id=119, 832.61063pt x 565.36218pt>
File: PAWS_DataScreen.jpg Graphic file (type jpg)
<use PAWS_DataScreen.jpg>
Package pdftex.def Info: PAWS_DataScreen.jpg used on input line 907.
(pdftex.def) Requested size: -1174.89139pt x -1442.13919pt.
[22
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_DataScreen.jpg>]
[25]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1040.
<PAWS_CalibrationScreen.jpg, id=135, 832.61063pt x 565.36218pt>
File: PAWS_CalibrationScreen.jpg Graphic file (type jpg)
<use PAWS_CalibrationScreen.jpg>
Package pdftex.def Info: PAWS_CalibrationScreen.jpg used on input line 1040.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[26
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_CalibrationScreen.jpg>]
[27]
Missing character: There is no ’ in font cmti10!
[28]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1149.
<PAWS_UtilitiesScreen.jpg, id=148, 832.61063pt x 565.36218pt>
File: PAWS_UtilitiesScreen.jpg Graphic file (type jpg)
<use PAWS_UtilitiesScreen.jpg>
Package pdftex.def Info: PAWS_UtilitiesScreen.jpg used on input line 1149.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[29
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_UtilitiesScreen.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1167.
<PAWS_DiagnosticsScreen.jpg, id=154, 578.16pt x 462.22687pt>
File: PAWS_DiagnosticsScreen.jpg Graphic file (type jpg)
<use PAWS_DiagnosticsScreen.jpg>
Package pdftex.def Info: PAWS_DiagnosticsScreen.jpg used on input line 1167.
(pdftex.def) Requested size: 867.23787pt x 347.04485pt.
[30
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_DiagnosticsScreen.jpg>]
[31
]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1229.
<MT_SAG285_BalanceScreen.jpg, id=164, 786.94pt x 468.75125pt>
File: MT_SAG285_BalanceScreen.jpg Graphic file (type jpg)
<use MT_SAG285_BalanceScreen.jpg>
Package pdftex.def Info: MT_SAG285_BalanceScreen.jpg used on line 1229.
(pdftex.def) Requested size: 1180.40712pt x 356.83138pt.
[32 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/MT_SAG285_BalanceScreen.jpg>]
[33
]
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <7> on input line 1253.
LaTeX Warning: Float too large for page by 37.16692pt on line 1296.
[34]
Missing character: There is no – in font cmr10!
[35
]
Overfull \hbox (8.62225pt too wide) in parag @ lines 1366--1373
\OT1/cmr/m/n/10.95 Run re-ports can be re-viewed/approved by
se-lect-ing the \O T1/cmr/bx/n/10.95 Mark as Re-viewed/Approved
[]
[36
] [37]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1411.
<PAWS_reviewscreen.jpg, id=186, 452.4403pt x 328.22626pt>
File: PAWS_reviewscreen.jpg Graphic file (type jpg)
<use PAWS_reviewscreen.jpg>
Package pdftex.def Info: PAWS_reviewscreen.jpg used on input line 1411.
(pdftex.def) Requested size: 678.65881pt x 146.04442pt.
[38 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_reviewscreen.jpg>]
[39] [40
] [41] [42] [43]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1583.
<PAWS_methodrpt2.jpg, id=208, 1946.02031pt x 1219.55624pt>
File: PAWS_methodrpt2.jpg Graphic file (type jpg)
<use PAWS_methodrpt2.jpg>
Package pdftex.def Info: PAWS_methodrpt2.jpg used on input line 1583.
(pdftex.def) Requested size: 486.50389pt x 247.17268pt.
[44 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_methodrpt2.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1602.
<PAWS_productrpt.jpg, id=214, 434.37282pt x 556.32843pt>
File: PAWS_productrpt.jpg Graphic file (type jpg)
<use PAWS_productrpt.jpg>
Package pdftex.def Info: PAWS_productrpt.jpg used on input line 1602.
(pdftex.def) Requested size: 651.55762pt x 488.19685pt.
[45]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1622.
<PAWS_calhistoryrpt.jpg, id=219, 437.38406pt x 336.50719pt>
File: PAWS_calhistoryrpt.jpg Graphic file (type jpg)
<use PAWS_calhistoryrpt.jpg>
Package pdftex.def Info: PAWS_calhistoryrpt.jpg used on line 1622.
(pdftex.def) Requested size: 656.07446pt x 158.46579pt.
[46 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_productrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1638.
<PAWS_curcalrpt.jpg, id=225, 435.12563pt x 519.44063pt>
File: PAWS_curcalrpt.jpg Graphic file (type jpg)
<use PAWS_curcalrpt.jpg>
Package pdftex.def Info: PAWS_curcalrpt.jpg used on input line 1638.
(pdftex.def) Requested size: 652.68683pt x 432.86528pt.
[47 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_calhistoryrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1657.
<PAWS_runrptp1.jpg, id=231, 438.13687pt x 551.81157pt>
File: PAWS_runrptp1.jpg Graphic file (type jpg)
<use PAWS_runrptp1.jpg>
Package pdftex.def Info: PAWS_runrptp1.jpg used on input line 1657.
(pdftex.def) Requested size: 657.20367pt x 481.42159pt.
[48 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_curcalrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1671.
<PAWS_runrptp2.jpg, id=237, 391.4625pt x 552.56438pt>
File: PAWS_runrptp2.jpg Graphic file (type jpg)
<use PAWS_runrptp2.jpg>
Package pdftex.def Info: PAWS_runrptp2.jpg used on input line 1671.
(pdftex.def) Requested size: 587.19229pt x 482.55077pt.
[49 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp1.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1684.
<PAWS_runrptp3.jpg, id=244, 403.5075pt x 551.05875pt>
File: PAWS_runrptp3.jpg Graphic file (type jpg)
<use PAWS_runrptp3.jpg>
Package pdftex.def Info: PAWS_runrptp3.jpg used on input line 1684.
(pdftex.def) Requested size: 605.25977pt x 480.29234pt.
[50 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp2.jpg>] [51 <C:/VIDEOS
_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp3.jpg>]
F: Service
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
[52
] [53] (C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.aux) )
Here is how much of TeX's memory you used:
1399 strings out of 493921
18919 string characters out of 3154507
80525 words of memory out of 3000000
4673 multiletter control sequences out of 15000+200000
11650 words of font info for 40 fonts, out of 3000000 for 9000
841 hyphenation exceptions out of 8191
29i,15n,29p,442b,310s stack positions out of 5000i,500n,10000p,200000b,50000s
<C:/MikTeX/f
onts/type1/public/amsfonts/cm/cmbx10.pfb><C:/MikTeX/fonts/type1/public/amsfonts
/cm/cmbx12.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmcsc10.pfb><C:/MikTeX
/fonts/type1/public/amsfonts/cm/cmmi10.pfb><C:/MikTeX/fonts/type1/public/amsfon
ts/cm/cmmi6.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmmi9.pfb><C:/MikTeX/
fonts/type1/public/amsfonts/cm/cmr10.pfb><C:/MikTeX/fonts/type1/public/amsfonts
/cm/cmr12.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmr17.pfb><C:/MikTeX/fo
nts/type1/public/amsfonts/cm/cmr6.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm
/cmr9.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmsl12.pfb><C:/MikTeX/fonts
/type1/public/amsfonts/cm/cmsy10.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/
cmsy9.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmti10.pfb>
Output written on pawsua_ug2_5.pdf (59 pages, 2500488 bytes).
PDF statistics:
309 PDF objects out of 1000 (max. 8388607)
0 named destinations out of 1000 (max. 500000)
210 words of extra memory for PDF output out of 10000 (max. 10000000)
