하나의 그림에 여러 하위 그림이 있음

하나의 캡션과 각 하위 그림에 숫자가 표시된 81개의 하위 그림을 하나의 그림에 넣고 싶습니다. 각 하위 그림의 크기는 동일합니다(따라서 아마도 tabularx이것이 필요하지 않을 것입니다). 다음과 같이 한 행에 4개의 하위 그림을 원합니다.

SUBFIG1 & SUBFIG2 & SUBFIG3 & SUBFIG4

..

SUBFIG77 & SUBFIG78 & SUBFIG79 & SUBFIG80

SUBFIG81

캡션: XXX

각 하위 그림 아래에는 괄호 안의 숫자를 원합니다. 예를 들어 SUBFIG1 아래에는 (1) 등을 원합니다.

라텍스 내에서 이를 수행하는 가장 좋은 방법은 무엇입니까? 나는 tabular환경 을 시험해 보았다.

\documentclass{report}
\usepackage{subcaption}
\begin{figure}
\begin{tabular}{cccc}
\subfloat[(1)]{\includegraphics[width=2cm]{SUBFIG1.eps}}
    & \subfloat[(2)]{\includegraphics[width=2cm]{SUBFIG2.eps}}
    &  \subfloat[(3)]{\includegraphics[width=2cm]{SUBFIG3.eps}}
    & \subfloat[(4)]{\includegraphics[width=2cm]{SUBFIG4.eps}} \\
\subfloat[(5)]{\includegraphics[width=2cm]{SUBFIG5.eps}}
    & \subfloat[(6)]{\includegraphics[width=2cm]{SUBFIG6.eps}}
 ...
\end{tabular}
\caption{XXX}
\label{xxx}
\end{figure}

하지만 여기서는 subfloat계산 구분 기호로 az가 있고 24개의 하위 숫자에 도달하자마자 페이지에서 벗어납니다(즉, 새 페이지에서 하위 숫자 25가 시작되지 않습니다). 감사해요!

답변1

모든 이미지의 너비가 동일하므로 테이블 형식 접근 방식이 필요하지 않습니다. 지시문을 사용하여 \subfloat행당 4개씩 배치하세요.

subcaption캡션(및 패키지)을 로드하므로 각 연속 환경의 상단에서 지시문을 caption사용할 수 있습니다 .\ContinuedFloatfigure

다음 스크린샷은 figure아래 코드로 생성된 마지막 환경을 보여줍니다.

여기에 이미지 설명을 입력하세요

\documentclass{report}
\usepackage[margin=2.5cm]{geometry} % set page parameters suitably
\usepackage[demo]{graphicx} % remove 'demo' option in real document

\usepackage{subcaption}
\renewcommand\thesubfigure{\arabic{subfigure}} % arabic numerals
\captionsetup[figure]{skip=0.5\baselineskip}
\captionsetup[subfigure]{skip=0.25\baselineskip,position=below}

\begin{document}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\caption{XXX}\label{fig:xxx}

\subfloat[]{\includegraphics{SUBFIG01}}\hfill
\subfloat[]{\includegraphics{SUBFIG02}}\hfill
\subfloat[]{\includegraphics{SUBFIG03}}\hfill
\subfloat[]{\includegraphics{SUBFIG04}}

\medskip
\subfloat[]{\includegraphics{SUBFIG05}}\hfill
\subfloat[]{\includegraphics{SUBFIG06}}\hfill
\subfloat[]{\includegraphics{SUBFIG07}}\hfill
\subfloat[]{\includegraphics{SUBFIG08}}

\medskip
\subfloat[]{\includegraphics{SUBFIG09}}\hfill
\subfloat[]{\includegraphics{SUBFIG10}}\hfill
\subfloat[]{\includegraphics{SUBFIG11}}\hfill
\subfloat[]{\includegraphics{SUBFIG12}}

\medskip
\subfloat[]{\includegraphics{SUBFIG13}}\hfill
\subfloat[]{\includegraphics{SUBFIG14}}\hfill
\subfloat[]{\includegraphics{SUBFIG15}}\hfill
\subfloat[]{\includegraphics{SUBFIG16}}

\medskip
\subfloat[]{\includegraphics{SUBFIG17}}\hfill
\subfloat[]{\includegraphics{SUBFIG18}}\hfill
\subfloat[]{\includegraphics{SUBFIG19}}\hfill
\subfloat[]{\includegraphics{SUBFIG20}}

\medskip
\subfloat[]{\includegraphics{SUBFIG21}}\hfill
\subfloat[]{\includegraphics{SUBFIG22}}\hfill
\subfloat[]{\includegraphics{SUBFIG23}}\hfill
\subfloat[]{\includegraphics{SUBFIG24}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG25}}\hfill
\subfloat[]{\includegraphics{SUBFIG26}}\hfill
\subfloat[]{\includegraphics{SUBFIG27}}\hfill
\subfloat[]{\includegraphics{SUBFIG28}}

\medskip
\subfloat[]{\includegraphics{SUBFIG29}}\hfill
\subfloat[]{\includegraphics{SUBFIG30}}\hfill
\subfloat[]{\includegraphics{SUBFIG31}}\hfill
\subfloat[]{\includegraphics{SUBFIG32}}

\medskip
\subfloat[]{\includegraphics{SUBFIG33}}\hfill
\subfloat[]{\includegraphics{SUBFIG34}}\hfill
\subfloat[]{\includegraphics{SUBFIG35}}\hfill
\subfloat[]{\includegraphics{SUBFIG36}}

\medskip
\subfloat[]{\includegraphics{SUBFIG37}}\hfill
\subfloat[]{\includegraphics{SUBFIG38}}\hfill
\subfloat[]{\includegraphics{SUBFIG39}}\hfill
\subfloat[]{\includegraphics{SUBFIG40}}

\medskip
\subfloat[]{\includegraphics{SUBFIG41}}\hfill
\subfloat[]{\includegraphics{SUBFIG42}}\hfill
\subfloat[]{\includegraphics{SUBFIG43}}\hfill
\subfloat[]{\includegraphics{SUBFIG44}}

\medskip
\subfloat[]{\includegraphics{SUBFIG45}}\hfill
\subfloat[]{\includegraphics{SUBFIG46}}\hfill
\subfloat[]{\includegraphics{SUBFIG47}}\hfill
\subfloat[]{\includegraphics{SUBFIG48}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG49}}\hfill
\subfloat[]{\includegraphics{SUBFIG50}}\hfill
\subfloat[]{\includegraphics{SUBFIG51}}\hfill
\subfloat[]{\includegraphics{SUBFIG52}}

\medskip
\subfloat[]{\includegraphics{SUBFIG53}}\hfill
\subfloat[]{\includegraphics{SUBFIG54}}\hfill
\subfloat[]{\includegraphics{SUBFIG55}}\hfill
\subfloat[]{\includegraphics{SUBFIG56}}

\medskip
\subfloat[]{\includegraphics{SUBFIG57}}\hfill
\subfloat[]{\includegraphics{SUBFIG58}}\hfill
\subfloat[]{\includegraphics{SUBFIG59}}\hfill
\subfloat[]{\includegraphics{SUBFIG60}}

\medskip
\subfloat[]{\includegraphics{SUBFIG61}}\hfill
\subfloat[]{\includegraphics{SUBFIG62}}\hfill
\subfloat[]{\includegraphics{SUBFIG63}}\hfill
\subfloat[]{\includegraphics{SUBFIG64}}

\medskip
\subfloat[]{\includegraphics{SUBFIG65}}\hfill
\subfloat[]{\includegraphics{SUBFIG66}}\hfill
\subfloat[]{\includegraphics{SUBFIG67}}\hfill
\subfloat[]{\includegraphics{SUBFIG68}}

\medskip
\subfloat[]{\includegraphics{SUBFIG69}}\hfill
\subfloat[]{\includegraphics{SUBFIG70}}\hfill
\subfloat[]{\includegraphics{SUBFIG71}}\hfill
\subfloat[]{\includegraphics{SUBFIG72}}

\end{figure}

\begin{figure}[ht!]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG73}}\hfill
\subfloat[]{\includegraphics{SUBFIG74}}\hfill
\subfloat[]{\includegraphics{SUBFIG75}}\hfill
\subfloat[]{\includegraphics{SUBFIG76}}

\medskip
\subfloat[]{\includegraphics{SUBFIG77}}\hfill
\subfloat[]{\includegraphics{SUBFIG78}}\hfill
\subfloat[]{\includegraphics{SUBFIG79}}\hfill
\subfloat[]{\includegraphics{SUBFIG80}}

\medskip
\subfloat[]{\includegraphics{SUBFIG81}}\hfill

\end{figure}


\end{document}

답변2

아마도 그림을 표에 넣은 다음 \ContinuedFloat. 하지만 이 접근 방식에서는 그림을 수동으로 분할해야 하지만 이는 물론 그리 우아하지는 않습니다.

\documentclass{scrreprt}
\usepackage{graphicx}
\usepackage{subcaption}

\DeclareCaptionSubType*{figure}\renewcommand\thesubfigure{\arabic{subfigure}}
\newcommand{\sub}[1]{\begin{minipage}{.2\linewidth}\includegraphics[width=\linewidth]{#1}\subcaption{}\end{minipage}}
\newcommand{\tabfig}[4]{\sub{#1} & \sub{#2} & \sub{#3} & \sub{#4}\\}

\begin{document}
\begin{figure}[ht]
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\begin{figure}[ht]\ContinuedFloat
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\end{document}
