pgfgantt: 막대 끝에 날짜를 추가하는 방법은 무엇입니까?

Question

문제

pgffgantt 패키지를 사용하여 Gantt 차트를 만들고 있습니다. 작업 날짜를 막대 위에 표시하고 싶습니다(아래 이미지에서 주황색).

다양한 질문을 바탕으로 성공하지 못한 채 일을 시도했지만(1,2),날짜가 올바른 위치에 있지 않습니다. 두 개의 막대가 같은 줄에 있으면 겹칠 것입니다...

누구든지 이 작업을 수행하는 방법을 알고 있습니까? 아니면 올바른 방향을 알려줄 수 있습니까?

최소 작업 예

\documentclass[a4paper, 12pt]{article}
\usepackage[babel=true, kerning=true]{microtype} % Required by the package pgfgantt
\usepackage{pgfgantt}

\begin{document}
    \begin{ganttchart}[
            expand chart=\linewidth,
            time slot format=little-endian,  % Format of the date dd-mm-yyyy
            inline,
            vgrid={*6{draw=none}, *1{dotted}},  % Draw a line 1 out of 7 times, which is the same as framing the weeks
        ]{14-02-2022}{12-08-2022}
        \ganttset{calendar week text=\currentweek} % Overload the week text, display the week number (1, 2,, ...) instead of "Week <number>"
        \gantttitlecalendar{month=name, week}\\

        % Group 1
        \ganttset{
            bar/.append style={fill=lightblue},
            group/.append style={fill=darkblue},
        }
        \ganttgroup{Group 1}{14-02-2022}{25-06-2022}\\
        \ganttbar{Task 1}{14-04-2022}{28-05-2022}\\
        \ganttbar{Task 2}{18-02-2022}{18-04-2022} \ganttbar{Task 2 bis}{18-05-2022}{18-06-2022} \\
        % \ganttbar{Task 3}{14-02-2022}{28-03-2022}\\

    \end{ganttchart}
\end{document}

Answer 1

다음 코드는 두 개의 명령을 생성 \myganttgroup하고 \myganttbar두 개의 원래 막대 또는 그룹에 레이블을 추가합니다.

\PassOptionsToPackage{svgnames}{xcolor}
\documentclass[a4paper, 12pt]{article}
\usepackage[babel=true, kerning=true]{microtype} % Required by the package pgfgantt
\usepackage{pgfgantt}

\tikzset{
    date/.style={text=yellow!80!black, font=\small, anchor=south}
}

\newcommand{\myganttgroup}[4][]{%
\ganttgroup[#1, name=#2]{#2}{#3}{#4}
\node[date] at (#2.north west) {#3};
\node[date] at (#2.north east) {#4};
}

\newcommand{\myganttbar}[4][]{%
\ganttbar[#1, name=#2]{#2}{#3}{#4}
\node[date] at (#2.north west) {#3};
\node[date] at (#2.north east) {#4};
}


\begin{document}
    \begin{ganttchart}[
            expand chart=\linewidth,
            time slot format=little-endian,  % Format of the date dd-mm-yyyy
            inline,
            vgrid={*6{draw=none}, *1{dotted}},  % Draw a line 1 out of 7 times, which is the same as framing the weeks
        ]{14-02-2022}{12-08-2022}
        \ganttset{calendar week text=\currentweek} % Overload the week text, display the week number (1, 2,, ...) instead of "Week <number>"
        \gantttitlecalendar{month=name, week}\\

        % Group 1
        \ganttset{
            bar/.append style={fill=LightBlue},
            group/.append style={fill=DarkBlue},
        }
%        \ganttgroup{Group 1}{14-02-2022}{25-06-2022}\\
        \myganttgroup{Group 1}{14-02-2022}{25-06-2022}\\
        \myganttbar{Task 1}{14-04-2022}{28-05-2022}\\
        \myganttbar{Task 2}{18-02-2022}{18-04-2022} \myganttbar{Task 2 bis}{18-05-2022}{18-06-2022} \\
        % \ganttbar{Task 3}{14-02-2022}{28-03-2022}\\
%        \node[left] at (task1.north west) {A};
%        \node[right] at (task1.north east) {B};

    \end{ganttchart}
\end{document}
