아래 코드에서 AVI를 만들려고 합니다.
\documentclass[hyperref={pdfpagelabels=false}]{beamer}
\usepackage{amsthm}
\usepackage{graphicx} % Required for inserting images
\usepackage{tikz}
\usetikzlibrary{overlay-beamer-styles}
\usetikzlibrary{automata, positioning, arrows.meta,calc,cd,animations,shapes}
\usetikzlibrary{patterns}
\usetikzlibrary{datavisualization}
\tikzset{
->, % makes the edges directed
>=stealth, % makes the arrow heads bold
node distance=3cm, % specifies the minimum distance between two nodes. Change if necessary.
every state/.style={thick, fill=gray!10}, % sets the properties for each ’state’ node
initial text=$ $, % sets the text that appears on the start arrow
}
%\usepackage{animate}
\beamertemplatenavigationsymbolsempty
\begin{document}
\pgfdeclarelayer{background}
\pgfsetlayers{background,main}
\begin{frame}[label=GIFshow]
\begin{figure}
\begin{tikzpicture}[node distance = 2cm, on grid,>={Stealth[inset=0pt,length=6pt,angle'=28,round]}][overlay]
\node[state, initial,alt=<2->{fill=yellow}{}] at (0,0) (q1) {$q^1$};
\node[state] at (1,-2.5) (q2) {$q^2$};
\node[state, right of=q2] (q3) {$q^3$};
\node[state, right of=q3] (q4) {$q^4$};
\node[state, right of=q4] (q5) {$q^5$};
\node[state,accepting,alt=<6->{fill=yellow}{}] at (8,0) (q6) {$q^6$};
\node[state,alt=<3->{fill=yellow}{}] at (2,0) (q7) {$q^7$};
\node[state, right of=q7,alt=<4->{fill=yellow}{}] (q8) {$q^8$};
\node[state,alt=<5->{fill=yellow}{}] at (6,0) (q9) {$q^9$};
\node[state] at (1,2.5) (q10) {$q^{10}$};
\node[state, right of=q10] (q11) {$q^{11}$};
\node[state, right of=q11] (q12) {$q^{12}$};
\node[state, right of=q12] (q13) {$q^{13}$};
\node[state,fill=red!20, densely dashed] at (2,-1.25) (q14) {$q^{14}$};
\node[state,fill=red!20, densely dashed] at (4,-1.25) (q15) {$q^{15}$};
\node[state,fill=red!20, densely dashed] at (2,1.25) (q16) {$q^{16}$};
\node[state,fill=red!20, densely dashed] at (6,1.25) (q17) {$q^{17}$};
\draw
(q1) edge[bend right] node [below left]{$e^1$} (q2)
(q2) edge node [below] {$e^2$} (q3)
(q3) edge node [below]{$e^3$} (q4)
(q1) edge node [above]{$e^6$} (q7)
(q9) edge node [above]{$e^9$} (q6)
(q1) edge[bend left] node [below left]{$e^{10}$} (q10)
(q12) edge node [above]{$e^{13}$} (q13)
(q13) edge[bend left] node [above right]{$e^{14}$} (q6)
(q2) edge[bend right, densely dashed] node [above left]{$e^{15}$} (q14)
(q14) edge[bend right, densely dashed] node [ right]{$e^{16}$} (q7)
(q4) edge[bend right, densely dashed] node [ right]{$e^{17}$} (q15)
(q15) edge[bend right, densely dashed] node [ right]{$e^{18}$} (q9)
(q12) edge[bend left=10, densely dashed] node [ above]{$e^{19}$} (q16)
(q16) edge[bend left=10, densely dashed] node [ above right]{$e^{20}$} (q9)
(q12) edge[bend left=10, densely dashed] node [ above right]{$e^{21}$} (q17)
(q17) edge[bend left, densely dashed] node [ above right]{$e^{22}$} (q9)
(q10) edge node [above]{$e^{11}$} (q11)
(q11) edge node [above]{$e^{12}$} (q12)
(q4) edge node [below]{$e^4$} (q5)
(q5) edge[bend right] node [below right] {$e^5$} (q6)
(q7) edge node [above]{$e^7$} (q8)
(q8) edge node [above]{$e^8$} (q9);
\end{tikzpicture}
\end{figure}
\end{frame}
\againframe<6>{GIFshow}
\againframe<6>{GIFshow}
\end{document}
저는 오버리프를 사용하고 있어요. 첫 번째 시도에서 나는 latexmkrc아래 내용으로 를 만들었습니다.
END{ system('convert -delay 100 -loop 0 -density 300 output.pdf output.gif')}
GIF 파일을 제공합니다. 파일 형식을 AVI로 변경하려고 했더니 AVI가 손상되어 사용할 수 없게 되었습니다. 어떤 제안이 있으십니까? 또한 latexmkrc현재 온라인에서 샘플 코드를 사용하고 있으므로 명령 에 대한 링크를 제공해주세요 . 그런데 아래는 gif 파일입니다.
