선버스트 차트 안의 텍스트를 굵게 표시하고 글꼴 크기를 조금 늘리는 방법은 무엇입니까?

tag-icon • tag-icon tikz-pgf pgfplots graphics bold
선버스트 차트 안의 텍스트를 굵게 표시하고 글꼴 크기를 조금 늘리는 방법은 무엇입니까?

나는 다음의 도움을 이용했습니다.Latex에서 선버스트 차트를 만드는 방법은 무엇입니까?선버스트 차트를 만드는 데 필요한 사항에 맞게 사용자 정의했습니다. 그 안의 모든 텍스트를 굵게 표시해야 하며, 가능하다면 그 안에 있는 텍스트의 크기를 늘려야 합니다. 여기 내 MWE가 있습니다.

\documentclass[border=0.05in]{standalone}
\usepackage{amsmath}
\usepackage{xcolor}
\usepackage{xparse}
\usepackage{tikz}
\definecolor{pear}{rgb}{0.82, 0.89, 0.19}
\definecolor{lavender}{rgb}{0.71, 0.49, 0.86}
\usetikzlibrary{calc,positioning}
\usetikzlibrary{decorations, decorations.text}
\newlength{\layerwd}
\newcounter{outermost}
\NewDocumentEnvironment{onion}{sm}{%*= draw axes; #1: thickness of each annulus
    \begin{tikzpicture}
        \setlength{\layerwd}{#2}%
        \setcounter{outermost}{0}
    }{%
        \foreach \A in {0,...,\theoutermost}{\draw[thick,] (0,0) circle (\A*\layerwd+\layerwd);}
    \end{tikzpicture}
}

% *=text on a circular path; [optional fill color]; #3 layer;
% #4 start angle; #5 stop angle; #6 [optional text]
%% angles are counterclockwise in degrees
\NewDocumentCommand{\annulus}{sO{lightgray}mmmo}{%
    \filldraw[thick,fill=#2,] (#4:#3*\layerwd) %% start here
    arc [radius=#3*\layerwd, start angle=#4, delta angle=#5-#4] %% inner arc
    -- (#5:#3*\layerwd+\layerwd) %% move out
    arc [radius=#3*\layerwd+\layerwd, start angle=#5, delta angle=#4-#5,] %% outer arc
    -- cycle; %% Back to the beginnning
    \pgfmathsetmacro{\tmp}{(#5-#4)/2 +#4} %% Locate the middle of the arc
    \IfNoValueF{#6}{%
        \IfBooleanTF{#1}
        {%
            \begingroup
            %% text is always rightside-up:
            \pgfmathsetmacro{\rpTF}{ifthenelse(\tmp>180,"false","true")}
            \def\\{\space} %% A safety precaution, \\ = space on decorated text
            \path[rotate=\tmp-180,postaction={
                decorate,
                decoration={
                    text along path,
                    raise=-3pt,
                    text align={align=center},
                    reverse path=\rpTF,
                    text=#6
                }
            }] (0,0) circle (#3*\layerwd+0.5*\layerwd);
            \endgroup
        }%%
        {%
            \pgfmathsetmacro{\rpTF}{ifthenelse(\tmp>180,\tmp+90,\tmp-90)}
            \node[inner sep=0pt, %%% If there is text, print it
            text width=#3*\layerwd*3+\layerwd,
            align=center,
            rotate=\rpTF,
            font=\normalsize] at (\tmp:#3*\layerwd+0.5*\layerwd)
            {#6};
        }%
    }%
    \ifnum\theoutermost<#3\setcounter{outermost}{#3}\fi
}

\begin{document}

    \begin{onion}*{0.6in}
        \draw[fill=red!20,thick] (0,0) circle (1.53cm);
        \node[color=red,thick,font=\bfseries]  at (0,0) {My research};
        \annulus*[pear]{1}{0}{180}[Materials for composites]
        \annulus*[pear!80]{2}{0}{180}[Working through trial and errors to find parameters]
        \annulus*[pear!60]{3}{0}{180}[Conditions associated with pre and post heat treatment]
        \annulus*[pear!40]{4}{20}{70}[Mechanical]
        \annulus*[pear!40]{4}{0}{20}[Physical]
        \annulus*[pear!40]{4}{70}{100}[Tribological]
        \annulus*[pear!40]{4}{100}{150}[Microstructure(OM/SEM/TEM)]
        \annulus*[pear!40]{4}{150}{180}[XRD]
        \annulus[pear!25]{5}{150}{180}[2($\theta$) and \\Bulk texture]
        \annulus[pear!25]{5}{100}{150}[Composites{,}\\Fracture{,}\\Wear track/debris]
        \annulus*[pear!25]{5}{70}{100}[Wear rate/COF]
        \annulus[pear!25]{5}{20}{40}[Hardness (Hv)]
        \annulus[pear!25]{5}{0}{20}[Density]
        \annulus[pear!25]{5}{40}{70}[Tensile (MPa)\\Yield (MPa)\\Elongation ($\delta$)]
        \annulus*[lavender!65]{1}{180}{360}[Materials for composites]
        \annulus*[lavender!55]{2}{180}{360}[Working through trial and errors to find parameters]
        \annulus*[lavender!45]{3}{180}{360}[Conditions associated with pre and post heat treatment]
        \annulus*[lavender!35]{4}{180}{200}[Physical]
        \annulus*[lavender!35]{4}{200}{250}[Mechanical]
        \annulus*[lavender!35]{4}{250}{280}[Tribological]
        \annulus*[lavender!35]{4}{280}{330}[Microstructure(OM/SEM/TEM)]
        \annulus*[lavender!35]{4}{330}{360}[XRD]
        \annulus[lavender!25]{5}{180}{200}[Density]
        \annulus[lavender!25]{5}{200}{220}[Hardness (Hv)]
        \annulus[lavender!25]{5}{220}{250}[Tensile (MPa)\\Yield (MPa)\\Elongation ($\delta$)]
        \annulus*[lavender!25]{5}{250}{280}[Wear rate/COF]
        \annulus[lavender!25]{5}{280}{330}[Composites{,}\\Fracture{,}\\Wear track/debris]
        \annulus[lavender!25]{5}{330}{360}[2($\theta$) and \\Bulk texture]

    \end{onion}

\end{document}

다음과 같은 출력이 생성됩니다.

여기에 이미지 설명을 입력하세요

답변1

글꼴 스타일을 변경하려면텍스트내부의 재산\환정의. 구체적으로 다음을 변경해야 합니다.

decoration={
    text along path,
    raise=-3pt,
    text align={align=center},
    reverse path=\rpTF,
    text=#6 % <-------------- HERE!
}

이에:

text={|\customannfont|#6}

이:

\node[inner sep=0pt, %%% If there is text, print it
text width=#3*\layerwd*3+\layerwd,
align=center,
rotate=\rpTF,
font=\normalsize] at (\tmp:#3*\layerwd+0.5*\layerwd) % <-------------- HERE!
{#6};

이에:

font=\customannfont] at (\tmp:#3*\layerwd+0.5*\layerwd)

참고: \customannfont를 사용하는 대신 다음과 같이 글꼴 스타일을 간단히 작성할 수 있습니다.

%%% code before
text={|\bfseries\fontsize{10}{0}\selectfont|#6}
%%% other code
font=\fontsize{10}{0}\selectfont

글꼴을 10pt로 굵게 만듭니다. 하지만 스타일을 정의하기 전에 스타일을 정의하는 것이 좋습니다.\환정의이므로 다음과 같이 한 번만 수정하여 코드의 두 위치에서 모두 변경할 수 있습니다.

\newcommand{\customannfont}{\fontsize{10}{0}\selectfont}

글꼴을 굵고 크게 만드는 전체 코드는 다음과 같습니다.수정된 차트

\documentclass[border=0.05in]{standalone}
\usepackage{amsmath}
\usepackage{xcolor}
\usepackage{xparse}
\usepackage{tikz}
\definecolor{pear}{rgb}{0.82, 0.89, 0.19}
\definecolor{lavender}{rgb}{0.71, 0.49, 0.86}
\usetikzlibrary{calc,positioning}
\usetikzlibrary{decorations, decorations.text}
\newlength{\layerwd}
\newcounter{outermost}
\NewDocumentEnvironment{onion}{sm}{%*= draw axes; #1: thickness of each annulus
    \begin{tikzpicture}
        \setlength{\layerwd}{#2}%
        \setcounter{outermost}{0}
    }{%
        \foreach \A in {0,...,\theoutermost}{\draw[thick,] (0,0) circle (\A*\layerwd+\layerwd);}
    \end{tikzpicture}
}

% define your custom font style
\newcommand{\customannfont}{\bfseries\fontsize{10}{0}\selectfont}
% *=text on a circular path; [optional fill color]; #3 layer;
% #4 start angle; #5 stop angle; #6 [optional text]
%% angles are counterclockwise in degrees
\NewDocumentCommand{\annulus}{sO{lightgray}mmmo}{%
    \filldraw[thick,fill=#2,] (#4:#3*\layerwd) %% start here
    arc [radius=#3*\layerwd, start angle=#4, delta angle=#5-#4] %% inner arc
    -- (#5:#3*\layerwd+\layerwd) %% move out
    arc [radius=#3*\layerwd+\layerwd, start angle=#5, delta angle=#4-#5,] %% outer arc
    -- cycle; %% Back to the beginnning
    \pgfmathsetmacro{\tmp}{(#5-#4)/2 +#4} %% Locate the middle of the arc
    \IfNoValueF{#6}{%
        \IfBooleanTF{#1}
        {%
            \begingroup
            %% text is always rightside-up:
            \pgfmathsetmacro{\rpTF}{ifthenelse(\tmp>180,"false","true")}
            \def\\{\space} %% A safety precaution, \\ = space on decorated text
            \path[rotate=\tmp-180,postaction={
                decorate,
                decoration={
                    text along path,
                    raise=-3pt,
                    text align={align=center},
                    reverse path=\rpTF,
                    text={|\customannfont|#6}
                }
            }] (0,0) circle (#3*\layerwd+0.5*\layerwd);
            \endgroup
        }%%
        {%
            \pgfmathsetmacro{\rpTF}{ifthenelse(\tmp>180,\tmp+90,\tmp-90)}
            \node[inner sep=0pt, %%% If there is text, print it
            text width=#3*\layerwd*3+\layerwd,
            align=center,
            rotate=\rpTF,
            font=\customannfont] at (\tmp:#3*\layerwd+0.5*\layerwd)
            {#6};
        }%
    }%
    \ifnum\theoutermost<#3\setcounter{outermost}{#3}\fi
}

\begin{document}

    \begin{onion}*{0.6in}
        \draw[fill=red!20,thick] (0,0) circle (1.53cm);
        \node[color=red,thick,font=\bfseries]  at (0,0) {My research};
        \annulus*[pear]{1}{0}{180}[Materials for composites]
        \annulus*[pear!80]{2}{0}{180}[Working through trial and errors to find parameters]
        \annulus*[pear!60]{3}{0}{180}[Conditions associated with pre and post heat treatment]
        \annulus*[pear!40]{4}{20}{70}[Mechanical]
        \annulus*[pear!40]{4}{0}{20}[Physical]
        \annulus*[pear!40]{4}{70}{100}[Tribological]
        \annulus*[pear!40]{4}{100}{150}[Microstructure(OM/SEM/TEM)]
        \annulus*[pear!40]{4}{150}{180}[XRD]
        \annulus[pear!25]{5}{150}{180}[2($\theta$) and \\Bulk texture]
        \annulus[pear!25]{5}{100}{150}[Composites{,}\\Fracture{,}\\Wear track/debris]
        \annulus*[pear!25]{5}{70}{100}[Wear rate/COF]
        \annulus[pear!25]{5}{20}{40}[Hardness (Hv)]
        \annulus[pear!25]{5}{0}{20}[Density]
        \annulus[pear!25]{5}{40}{70}[Tensile (MPa)\\Yield (MPa)\\Elongation ($\delta$)]
        \annulus*[lavender!65]{1}{180}{360}[Materials for composites]
        \annulus*[lavender!55]{2}{180}{360}[Working through trial and errors to find parameters]
        \annulus*[lavender!45]{3}{180}{360}[Conditions associated with pre and post heat treatment]
        \annulus*[lavender!35]{4}{180}{200}[Physical]
        \annulus*[lavender!35]{4}{200}{250}[Mechanical]
        \annulus*[lavender!35]{4}{250}{280}[Tribological]
        \annulus*[lavender!35]{4}{280}{330}[Microstructure(OM/SEM/TEM)]
        \annulus*[lavender!35]{4}{330}{360}[XRD]
        \annulus[lavender!25]{5}{180}{200}[Density]
        \annulus[lavender!25]{5}{200}{220}[Hardness (Hv)]
        \annulus[lavender!25]{5}{220}{250}[Tensile (MPa)\\Yield (MPa)\\Elongation ($\delta$)]
        \annulus*[lavender!25]{5}{250}{280}[Wear rate/COF]
        \annulus[lavender!25]{5}{280}{330}[Composites{,}\\Fracture{,}\\Wear track/debris]
        \annulus[lavender!25]{5}{330}{360}[2($\theta$) and \\Bulk texture]

    \end{onion}

\end{document}

답변2

글꼴은 \bfseries및 로 지정할 수 있습니다 \large.

코드는 다음을 사용하여 단순화할 수 있습니다.휠차트내가 쓴 패키지.

호 안의 텍스트는 키에 제공됩니다 arc data. 여기서는 \\텍스트를 여러 줄로 분할하는 데 사용할 수 있습니다. 이 텍스트의 방향은 \WCmidangle키에 사용되는 호의 중앙 각도에 따라 달라집니다 arc data dir. 이 텍스트는 가 있는 호의 중심에 있습니다 arc data pos=0.5.

여기에 이미지 설명을 입력하세요

\documentclass[border=6pt]{standalone}
\usepackage{wheelchart}
\usetikzlibrary{decorations.text}
\begin{document}
\begin{tikzpicture}[scale=1.2]
\bfseries\large
\definecolor{lavender}{rgb}{0.71, 0.49, 0.86}
\definecolor{pear}{rgb}{0.82, 0.89, 0.19}
\pgfkeys{
  /wheelchart,
  arc data=\WCvarB,
  arc data dir={\WCmidangle<180?1:-1},
  arc data expand=f,
  arc data pos=0.5,
  data=,
  slices style={fill=\WCcolor,draw=black,thick},
  total angle=180
}
\fill[red!20] (0,0) circle[radius=1.5] node[red] {My research};
\foreach\WCstartangle/\WCcolorA/\WCcolorB/\WCcolorC/\WCcolorD/\WCcolorE in {%
  180/pear/pear!80/pear!60/pear!40/pear!25,
  0/lavender!65/lavender!55/lavender!45/lavender!35/lavender!25%
}{
  \pgfkeys{
    /wheelchart,
    start angle=\WCstartangle
  }
  \edef\WCcolor{\WCcolorA}
  \wheelchart[
    radius={1.5}{3}
  ]{%
    1/Materials for composites%
  }
  \edef\WCcolor{\WCcolorB}
  \wheelchart[
    radius={3}{4.5}
  ]{%
    1/Working through trial and errors to find parameters%
  }
  \edef\WCcolor{\WCcolorC}
  \wheelchart[
    radius={4.5}{6}
  ]{%
    1/Conditions associated with pre and post heat treatment%
  }
  \edef\WCcolor{\WCcolorD}
  \wheelchart[
    radius={6}{7.5}
  ]{%
    30/XRD,
    50/{Microstructure (OM/SEM/TEM)},
    30/Tribological,
    50/Mechanical,
    20/Physical%
  }
  \edef\WCcolor{\WCcolorE}
  \wheelchart[
    radius={7.5}{9}
  ]{%
    30/$2({\theta})$ and\\Bulk texture,
    50/{Composites,\\Fracture,\\Wear track/debris},
    30/{Wear rate/COF},
    30/Tensile (MPa)\\Yield (MPa)\\Elongation (${\delta}$),
    20/Hardness (Hv),
    20/Density%
  }
}
\end{tikzpicture}
\end{document}
