TikZ 다이어그램과 함께 테이블 형식 환경 테이블을 나란히 배치하고 있습니다. 그러나 이로 인해 이상한 레이아웃 문제가 발생하고 추가 공간이 생성됩니다. 내가 사용하는 코드는 다음과 같습니다.
\documentclass[12pt,twoside]{report}
\usepackage[utf8]{inputenc}
\usepackage[margin=0.75in]{geometry}
\usepackage{setspace}
\usepackage{chemfig}
\usepackage{adjustbox}
\usepackage[pdfversion=2.0]{hyperref}
\usepackage[numbered]{bookmark}
\usepackage[activate={true,nocompatibility},final,tracking=true,kerning=true,spacing=true,factor=1100,stretch=10,shrink=10]{microtype}
\newcommand{\titlehead}[1]{\begin{center}\pdfbookmark[chapter]{#1}{chapter#1}\section*{#1}\end{center}}
\newcommand{\sectionhead}[1]{\pdfbookmark[section]{#1}{sec#1}\section*{#1}\vspace*{-1em}}
\newcommand{\subsechead}[1]{\pdfbookmark[subsection]{#1}{sec#1}\textbf{\underline{#1}}\vspace*{-0.5em}}
\newenvironment{subcalc}[1]{\vspace{0.1cm}\\\underline{#1}\vspace{0.1cm}\\}{\vspace{0.1cm}}
\doublespacing
\begin{document}
\noindent\subsechead{Sodium Borohydride Product}
\\\begin{tabular}{p {0.5\textwidth} c }
\vspace{-1em}\hspace{-0.5em}\subcalc{\textsuperscript{1}H NMR Spectroscopy:}
\begin{tabular}{ l l l l }
1.36 ppm & multiplet & 6H & \textcolor{blue}{A} \\
2.56 ppm & doublet & 1H & \textcolor{blue}{B} \\
4.23 ppm & multiplet & 3H & \textcolor{blue}{C} \\
\end{tabular} &
\adjustbox{valign=T}{
\begin{tikzpicture}
\node[anchor=south west,inner sep=0] (image) at (0,0) {\chemfig{-[:30](-[::+60]OH)-[:-30]-[:30](=[:90]O)-[:-30]O-[:30]-[:-30]}};
\begin{scope}[x={(image.south east)},y={(image.north west)}]
\footnotesize
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.2,1.14) {D};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.3,-0.23) {B};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.8,0.5) {C};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.12,-0.08) {C};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (-0.14,0) {A};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (1.06,0.06) {A};
\end{scope}
\end{tikzpicture}}\\
\end{tabular}
\noindent Lorem ipsum dolor sit amet
\end{document}
이는 다음과 같은 결과를 낳습니다(분자 구조의 불필요한 간격과 이상한 위치에 주목):
이것이 내가 원하는 방식입니다:
이를 달성하기 위한 어떤 제안이라도 주시면 감사하겠습니다.
답변1
해당 명령을 사용하지 마십시오 \vspace. 패키지 및 tikz 옵션의 m열 지정자를 사용합니다 . 실제 사례:arraybaseline=(current bounding box.west)
\documentclass[12pt,twoside]{report}
\usepackage[margin=0.75in]{geometry}
\usepackage{setspace}
\usepackage{chemfig}
\usepackage{array}
\usepackage[numbered]{bookmark}
\usepackage[activate={true,nocompatibility},final,tracking=true,kerning=true,spacing=true,factor=1100,stretch=10,shrink=10]{microtype}
\microtypecontext{spacing=nonfrench}
\usepackage{hyperref}
\newcommand{\subsechead}[1]{\pdfbookmark[subsection]{#1}{sec#1}\textbf{\underline{#1}}}
\doublespacing
\begin{document}
\noindent\subsechead{Sodium Borohydride Product}
\noindent\begin{tabular}{@{} m{0.5\textwidth} @{} m{0.5\textwidth} @{}}
\underline{\textsuperscript{1}H NMR Spectroscopy:}
\begin{tabular}{ l l l l }
1.36 ppm & multiplet & 6H & \textcolor{blue}{A} \\
2.56 ppm & doublet & 1H & \textcolor{blue}{B} \\
4.23 ppm & multiplet & 3H & \textcolor{blue}{C} \\
\end{tabular} &
\begin{tikzpicture}[baseline=(current bounding box.west)]
\node[anchor=south west,inner sep=0] (image) at (0,0) {\chemfig{-[:30](-[::+60]OH)-[:-30]-[:30](=[:90]O)-[:-30]O-[:30]-[:-30]}};
\begin{scope}[x={(image.south east)},y={(image.north west)}]
\footnotesize
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.2,1.14) {D};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.3,-0.23) {B};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.8,0.5) {C};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (0.12,-0.08) {C};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (-0.14,0) {A};
\node[draw,circle,inner sep=0.75pt,anchor=south west,blue, text=blue] at (1.06,0.06) {A};
\end{scope}
\end{tikzpicture}\\
\end{tabular}
\noindent Lorem ipsum dolor sit amet
\end{document}
산출:
