각 행의 왼쪽에 추가 캡션을 추가하는 방법은 무엇입니까?

Question

첫 번째 행 상단과 각 행 왼쪽에 추가 캡션을 추가하려고 하는데 각 행 왼쪽에 캡션을 추가하는 방법을 모르겠습니다. 이것은 내가 시도한 코드입니다.

\documentclass{article}
\usepackage{graphicx}
\usepackage{subcaption}

\begin{document}

\begin{figure}
    \begin{subfigure}{0.18\linewidth}
        \centering
        \caption*{Caption for Figure 1}
        \label{fig:sub1}
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \caption*{Caption for Figure 2}
        \label{fig:sub2}
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \caption*{Caption for Figure 3}
        \label{fig:sub3}
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \caption*{Caption for Figure 4}
        \label{fig:sub4}
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \caption*{Caption for Figure 5}
        \label{fig:sub5}
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}

    \vspace{10pt} % Add vertical space between the rows

    \begin{subfigure}{0.18\linewidth}
        \centering
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}%
    \hspace{5pt}%
    \begin{subfigure}{0.18\linewidth}
        \centering
        \includegraphics[width=\linewidth]{example-image}
    \end{subfigure}

    \caption{Caption}
    \label{fig:main}
\end{figure}

\end{document}

다음은 코드의 출력입니다.

이것이 내가 원하는거야:

Answer 1

또한 일부 서식을 무료로 변경했습니다. 에서는 작동 \label하지 않습니다 \caption*.

\documentclass{article}
\usepackage{subcaption}
\usepackage[export]{adjustbox}% for valign
\usepackage{graphicx}
\usepackage{showframe}% alignment tool

\begin{document}

\begin{figure}
    \centering
    \captionsetup[subfigure]{justification=raggedright}
    \begin{subfigure}{0.15\linewidth}
      \caption*{Caption 1}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \caption*{Caption for Figure 1}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \caption*{Caption for Figure 2}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \caption*{Caption for Figure 3}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \caption*{Caption for Figure 4}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \caption*{Caption for Figure 5}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}

    \vspace{\floatsep} % Add vertical space between the rows

    \begin{subfigure}{0.15\linewidth}
      \caption*{Caption 2}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}\hfil
    \begin{subfigure}{0.15\linewidth}
        \includegraphics[width=\linewidth, valign=c]{example-image}
    \end{subfigure}

    \caption{Caption}
    \label{fig:main}
\end{figure}

\end{document}

---

이 솔루션은 표 형식을 사용합니다. 이를 위해서는 컴퓨팅이 필요하지만 \tabcolsep결과는 표 형식* 버전보다 간단합니다.

\documentclass{article}
\usepackage{array}
\usepackage{graphicx}
\usepackage{showframe}% alignment tool

\begin{document}

\begin{figure}
    \centering
    \setlength{\tabcolsep}{\dimexpr 0.1\textwidth/12}% 6*0.15=0.9
    \begin{tabular}{*6{m{0.15\textwidth}}}
      & {\raggedright Caption for Figure 1}
      & {\raggedright Caption for Figure 2}
      & {\raggedright Caption for Figure 3}
      & {\raggedright Caption for Figure 4}
      & {\raggedright Caption for Figure 5}
    \\[\abovecaptionskip]
      {\hfil Caption 1}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
    \\[\floatsep]
      {\hfil Caption 2}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
      & \includegraphics[width=\linewidth]{example-image}
    \end{tabular}
    \caption{Caption}
    \label{fig:main}
\end{figure}

\end{document}
