의 박스형 제목을 전경으로 이동하는 방법 tcolorbox
(상자 앞으로 이동)? 스크린샷(빨간색 직사각형, 강조 표시)에서 볼 수 있듯이 그리드가 제목과 겹치므로 이 동작은 원치 않습니다.
\documentclass[]{article}
\usepackage[most]{tcolorbox}
\NewTColorBox{solution}{+O{}}{%
breakable,
enhanced,
sharpish corners,
colframe=blue!50,
colback=white,
coltitle=blue!50,
parbox = false,
fonttitle=\bfseries,
title={Solution},
attach boxed title to top center ={yshift=-\tcboxedtitleheight/2,yshifttext=-\tcboxedtitleheight/2},
halign title=flush center,
boxed title style={%
colback=white,
},
boxrule=0.5mm,top=0mm,bottom=0mm,
underlay={%
\draw[help lines,step=5mm,blue!20!white,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
},
lowerbox=ignored,
#1
}
\begin{document}
\begin{solution}
Some text
\end{solution}
\end{document}
답변1
underlay boxed title
상자형 제목이 추가되기 전에 격자선 이 그려 지면 underlay
상자형 제목이 전경에 나타납니다(설명서의 200페이지도 참조 tcolorbox
).
\documentclass[]{article}
\usepackage[most]{tcolorbox}
\NewTColorBox{solution}{+O{}}{%
breakable,
enhanced,
sharpish corners,
colframe=blue!50,
colback=white,
coltitle=blue!50,
parbox = false,
fonttitle=\bfseries,
title={Solution},
attach boxed title to top center ={yshift=-\tcboxedtitleheight/2,yshifttext=-\tcboxedtitleheight/2},
halign title=flush center,
boxed title style={%
colback=white,
},
boxrule=0.5mm,top=0mm,bottom=0mm,
underlay boxed title={%
\draw[help lines,step=5mm,blue!20!white,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
},
lowerbox=ignored,
#1
}
\begin{document}
\begin{solution}
Some text
\end{solution}
\end{document}
