좀 더 내보내기 쉬운 방식으로 어떻게 작성할 수 있나요?

좀 더 내보내기 쉬운 방식으로 어떻게 작성할 수 있나요?

제가 Circuitikz로 그린 이 그림은 첫 번째 돌 이후로 제가 다뤘던 최초의 "복잡한" 그림입니다. 그러나 향후 프로젝트를 위해 이를 더 "수출 가능"하게 만드는 것이 가능한지, 즉 변경이 가능한지 알고 싶습니다. FlipFlops 간의 분리로 인해 지금과 달리 위치가 바뀌는 것은 많지 않습니다.

이것이 내가 쓴 것입니다:

\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage[siunitx, RPvoltages]{circuitikzgit}

\tikzset{flipflop JK/.style={flipflop,
flipflop def={t1=Q, t3={\ctikztextnot{Q}}, t6=J, t4=K,c5=1, td=PRST,
tu=CLR},
}}

\begin{document}
    \begin{center}
      \begin{circuitikz}[scale=0.8, transform shape]
        \node[vsourcesquareshape, rotate=90](clk){};
         \draw (-3,0) node[flipflop JK,external pins width=0](FF0){};
         \draw (-6,0) node[flipflop JK,external pins width=0](FF1){};
         \draw (-9,0) node[flipflop JK,external pins width=0](FF2){};
         \draw (-12,0) node[flipflop JK,external pins width=0](FF3){};
         \draw (-15,0) node[flipflop JK,external pins width=0](FF4){};

         \draw (clk.north) -- (FF0.east)node[inputarrow,rotate=180]{};
         \draw (FF0.pin 1) -| (-4.5,0);
         \draw (-4.5,0) -- (FF1.pin 5)node[inputarrow,rotate=180]{};

         \draw (FF1.pin 1) -| (-7.5,0);
         \draw (-7.5,0) -- (FF2.pin 5)node[inputarrow,rotate=180]{};

         \draw (FF2.pin 1) -| (-10.5,0);
         \draw (-10.5,0) -- (FF3.pin 5)node[inputarrow,rotate=180]{};

         \draw (FF3.pin 1) -| (-13.5,0);
         \draw (-13.5,0) -- (FF4.pin 5)node[inputarrow,rotate=180]{};

         \draw (FF0.pin 1) -| (-4.5,2)node[inputarrow,rotate=90]
          {\rotatebox{-90}{$Q_0$}};
         \draw (FF1.pin 1) -| (-7.5,2)node[inputarrow,rotate=90]
          {\rotatebox{-90}{$Q_1$}};
         \draw (FF2.pin 1) -| (-10.5,2)node[inputarrow,rotate=90]
          {\rotatebox{-90}{$Q_2$}};
           \draw (FF3.pin 1) -| (-13.5,2)node[inputarrow,rotate=90]
           {\rotatebox{-90}{$Q_3$}};
           \draw (FF4.pin 1) -| (-16.5,2)node[inputarrow,rotate=90]
           {\rotatebox{-90}{$Q_4$}};

     \end{circuitikz}
   \end{center}
\end{document}

답변1

나는 이 질문을 회로의 일부 기능을 전 세계적으로 더 쉽게 변경하려는 의도로 해석합니다. 이는 Rmano가 지적한 대로 calc를 chains사용 하여 수행할 수 있습니다 . \foreach플립플롭을 체인에 걸고 나머지는 루프로 만들 수 있습니다. 그러면 이러한 매개변수는 한 번만 나타나며 전역적으로 변경될 수 있습니다. 예를 들어, 플립플롭 사이의 거리는 다음과 같이 주어진다 node distance.

\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage[siunitx, RPvoltages]{circuitikz}
\usetikzlibrary{calc,chains}
\tikzset{flipflop JK/.style={flipflop,
flipflop def={t1=Q, t3={\ctikztextnot{Q}}, t6=J, t4=K,c5=1, td=PRST,
tu=CLR},
}}

\begin{document}
    \begin{center}
      \begin{circuitikz}[scale=0.8, transform shape]
         \node[vsourcesquareshape, rotate=90](clk){};
         % do the flip flops
         \begin{scope}[start chain=going left,node distance=1.5cm,
            nodes={on chain,flipflop JK,external pins width=0}]
            \path foreach \X in {0,...,4}
            {node(FF\X){}};
         \end{scope}
         % determine the midpoints between the flip flops and name them
         \path foreach \X in {1,...,4}
          {(FF\the\numexpr\X-1|-0,0) -- coordinate (c\X) (FF\X|-0,0)};
         % add one more of the points to the left
         \path let \p1=($(FF0.center)-(c1)$) in (FF4.center|-0,0)
          ++ (-\x1,0) coordinate (c5);
         % from original code
         \draw (clk.north) -- (FF0.east)node[inputarrow,rotate=180]{};
         % draw the stuff between those nodes
         \foreach \X in {1,...,4}
         {\draw (FF\the\numexpr\X-1\relax.pin 1) -| (c\X);
          \draw (c\X) -- (FF\X.pin 5)node[inputarrow,rotate=180]{};
          \draw (FF\the\numexpr\X-1\relax.pin 1) -| (c\X|-0,2)node[inputarrow,rotate=90]
          {\rotatebox{-90}{$Q_{\the\numexpr\X-1\relax}$}};}
         % use c5
         \draw (FF4.pin 1) -| (c5|-0,2) node[inputarrow,rotate=90]
            {\rotatebox{-90}{$Q_4$}};
     \end{circuitikz}
   \end{center}
\end{document}

여기에 이미지 설명을 입력하세요

코드를 실행하는 방법을 알려준 Rmano에게 큰 감사를 드립니다. circuitikzCTAN 의 최신 버전을 사용하고 있습니다 . 그리고 죄송합니다. 저는 이 내용을 뒷면에 어떻게 넣는지 말씀드릴 수 없으며, 뒷면에 있는 문제를 해결하는 방법에 대해서도 아는 바가 없습니다.
